kincrome K13230 User manual

INDUSTRIAL AIR DIE GRINDER STRAIGHT
INDUSTRIAL AIR
DIE GRINDER
STRAIGHT
K13230
ED1 December 15
UNIQUE
TWIN BEARING
SYSTEM
ADJUSTABLE
AIR
SPEED
REGULATOR
LOW
CONSUMPTION
MAX
1492NM
TORQUE
2
YEAR
WARRANTY
1
INDUSTRIAL AIR DIE GRINDER STRAIGHT
Table of Contents
Know Your Product ...................................................................................................1
General Safety Instructions .....................................................................................2
Additional Safety Instructions..................................................................................3-4
Operation...................................................................................................................4-5
Maintenance & Warranty .........................................................................................5
Parts Breakdown......................................................................................................6
Know your product
1. Air Inlet
2. Exhaust
3. Trigger
4. Trigger Lock-Off
5. ¼” Collet size
6. Speed Selector
7. Spindle Wrench
8. Collet Wrench
9. Nitto Style Fitting
Model No:................................................................................................................... K13230
Description: .............................................................................................................. Industrial Air Die Grinder Straight
Free Speed:................................................................................................................ 22,000RPM
Collet Size: ............................................................................................................. ¼”
Air Inlet: ..................................................................................................................... ¼”
Avg Air Consumption: .......................................................................................... 99 LPM (3.5CFM)
Air Pressure Maximum:........................................................................................... 90PSI
Max Hose Length: ..................................................................................................... 10 Meters
Min. Hose Inner Diameter: ...................................................................................... 3/8” (10mm)
Overall Length .......................................................................................................... 180mm
Weight ....................................................................................................................... 0.57kg
3
5
1
2
4
789
6
2
INDUSTRIAL AIR DIE GRINDER STRAIGHT
General Safety Warnings
Save all warnings and instructions for future reference.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
1) Work Area
a. Keep the work area clean and well lit. Cluttered benches and dark areas increase the risks of electric shock, fire, and
injury to persons.
b. Do not operate the tool in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. The tool is
able to create sparks resulting in the ignition of the dust or fumes.
c. Keep bystanders, children, and visitors away while operating the tool. Distractions can result in the loss of control of the
tool.
2) Personal Safety
a. Stay alert. Watch what you are doing and use common sense when operating the tool. Do not use the tool while tired or
under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool increases the risk of
injury to persons.
b. Dress properly. Do not wear loose clothing or jewellery. Contain long hair. Keep hair, clothing, and gloves away from
moving parts. Loose clothes, jewellery, or long hair increases the risk of injury to persons as a result of being caught in
moving parts.
c. Avoid unintentional starting. Be sure the switch is off before connecting to the air supply. Do not carry the tool with your
finger on the switch or connect the tool to the air supply with the switch on.
d. Remove adjusting keys and wrenches before turning the tool on. A wrench or a key that is left attached to a rotating part of
the tool increases the risk of personal injury.
e. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of the
tool in unexpected situations.
f. Use safety equipment. A dust mask, non-skid safety shoes and a hard hat must be used for the applicable conditions. Wear
heavy-duty work gloves during use.
g. Always wear eye protection. Wear approved safety eye protection.
h. Always wear hearing protection when using the tool. Prolonged exposure to high intensity noise can lead to hearing loss.
3) Tool Use and Care
a. Use clamps or other practical ways to secure and support the workpiece to a stable platform. Holding the work by hand or
against the body is unstable and can lead to loss of control.
b. Do not force the tool. Use the correct tool for the application. The correct tool will do the job better and safer at the rate for
which the tool is designed.
c. Do not use the tool if the switch does not turn the tool on or off. Any tool that cannot be controlled with the switch is
dangerous and must be repaired, by an authorised repair agent.
d. Disconnect the tool from the air source before making any adjustments, changing accessories, or storing the tool. Such
preventive safety measures reduce the risk of starting the tool unintentionally. Turn off and detach the air supply, safely
discharge any residual air pressure, and release the throttle and/or turn the switch to its off position before leaving the
work area.
e. Store the tool when it is idle out of reach of children and other untrained persons. A tool is dangerous in the hands of
untrained users.
f. Maintain the tool with care. A properly maintained tool is easier to control.
g. Check for misalignment or binding of moving parts, breakage of parts, and any other condition that affects the tool’s
operation. If damaged, have the tool serviced before using. Many accidents are caused by poorly maintained tools.
h. Use only accessories that are identified by the manufacturer for the specific tool model. Use of an accessory not intended
for use with the specific tool model, increases the risk of injury to persons.
3
INDUSTRIAL AIR DIE GRINDER STRAIGHT
4) Service
a. Tool service must be performed only by qualified repair personnel.
b. When servicing a tool, use only identical replacement parts. Use only authorized parts.
c. Use only the lubricants specified by the manufacturer.
5) Additional Safety Warnings
a. The warnings and precautions discussed in this manual cannot cover all possible conditions and situations that may
occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this
product, but must be supplied by the operator.
b. Only use with accessories rated to handle the speeds exerted by this tool during operation. Other accessories not
designed for the speeds generated may break and forcefully launch pieces.
c. Attach all accessories properly to the tool before connecting the air supply. A loose accessory may detach or break during
operation.
d. Thoroughly read and understand the manual for the air compressor used to power this tool. Install an in-line shutoff
valve to allow immediate control over the air supply in an emergency, even if a hose is ruptured.
e. Use this tool with both hands only. Using tools with only one hand can result in loss of control.
f. Do not lay the tool down until it has come to a complete stop. Moving parts can grab the surface and pull the tool out of
your control.
g. Do not force the tool. Use a larger one if needed.
h. Use a clamp or vice to secure the workpiece in place. It is safer than using your hand and keeps both hands free to operate
the airtool
i. Do not hold Collet, accessories or adapters during use.
j. Anyone using vibrating tools regularly or for an extended period should first be examined by a doctor and then have
regular medical check-ups to ensure medical problems are not being caused or worsened from use. Pregnant women
or people who have impaired blood circulation to the hand, past hand injuries, nervous system disorders, diabetes, or
Raynaud’s Disease should not use this tool. If you feel any symptoms related to vibration (such as tingling, numbness, and
white or blue fingers),stop using immediately and seek medical advice as soon as possible.
k. Do not smoke during use. Nicotine reduces the blood supply to the hands and fingers, increasing the risk of vibration-
related injury.
l. Wear suitable gloves to reduce the vibration effects on the user.
6) Description of Symbols
The following symbols could be shown on the tool:
Read the instruction manual before use. Risk of Explosion
Wear Ear Protection Wear Eye Protection
no No-load speed, Free Speed CFM Cubic Feet per Minute flow
.../min, RPM Revolutions or reciprocation per minute SCFM Cubic Feet per Minute flow at
standard conditions
PSI Pounds per square inch of pressure NPT National pipe thread, tapered
ft-lb Foot-pounds of torque BPM Beats/ Blows per minute
Nm Newton meters of force BSP British standard pipe
4
INDUSTRIAL AIR DIE GRINDER STRAIGHT
7) Additional Safety Instructions For Die Grinders
a. Use only burr or stone types that are recommended for your air tool.
b. Make sure the burr or stone is not contacting the work piece before the tool is turned on. Having the burr/stone resting on
the work piece before starting the tool could result in the tool kicking as it grips the work piece, this could cause potential
personal harm and/or material damage.
c. Check the burr/stone carefully for cracks or damage before operation. Replace cracked or damaged burr/stones
immediately.
d. Before operation of the tool an actual work piece, let it run for a few moments. Watch for vibration or wobbling that could
indicate poor installation of the burr/stone or a poorly balanced burr/stone.
e. Watch out for flying sparks.
f. Use only burrs/stones having a maximum operating speed at least as high as the “No load speed” marked on the rating
label of this tool. Using a burr/stone with a lower maximum speed rating than the tool is dangerous and could result in
the burr/stone breaking during use, causing potential personal harm and/or material damage.
g. It should never be necessary to force the tool. If rotational speed drops abnormally, the pressure should be released
immediately. Little more than the weight of the tool should be applied. Applying (forcing) excessive pressure can cause
dangerous burr/stone breakage or burn out of the tools motor.
Die-Grinder User Instructions
8) Before Starting
TO PREVENT SERIOUS INJURY FROM EXPLOSION:
Verify compressor is off before setup. Use only clean, dry, regulated,
compressed air to power this tool. Do not use oxygen, carbon dioxide,
combustible gases, or any other bottled gas as a power source for this
tool.
1. It is recommended a filter, regulator with pressure gauge, oiler,
in-line shut-off valve, and quick coupler be fitted for optimal
operation, as shown on Figure A.
2. An in-line shut-off ball valve is an important safety device,
it will shut-off the air supply even if the air hose is ruptured.
The shut-off valve should be a ball valve because it can be
closed quickly.
Note: If an automatic oiler system is not used, add 4 to 5 drops of Kincrome Air Tool Oil to the air inlet (1) before operation. Add 1-2
drops every hour after continuous use.
3. Attach an air hose to the compressor’s air outlet. Connect the air hose to the air inlet (1) of the tool. Other components, such as
a quick connect fitting and quick connect coupler, will make operation more efficient, but are not required.
WARNING! Do not install a quick coupler directly on the tool. Couplers contains an air valve that will allow the air tool to
retain pressure and inadvertently operate after the air supply is disconnected.
4. The air hose must be long enough to reach the work area and allow free movement while working.
5. Turn on the air compressor according to the manufacturer’s directions and allow the tank to build up pressure until it cuts-off.
6. Adjust the air compressor’s regulator so that the air output is at the tools recommended working pressure, the output must not
exceed the tool’s maximum air pressure at any time. Adjust the pressure gradually, while checking the air output gauge to set
the optimal pressure range.
7. Inspect all air connections for leaks. Repair any leaks.
8. If the tool is not being used, turn off and detach the air supply, safely discharge any residual air pressure, and release the trigger
(3) and/or turn the tools switch to its off position to prevent inadvertent operation.
Figure A
5
INDUSTRIAL AIR DIE GRINDER STRAIGHT
9) Operation
1. Screw in Nitto Style Fitting (9) to the air inlet (1). Thread (teflon) tape may be required to ensure a leak free seal.
2. Adjust thje ultimate speed of the Die grinder by turning the speed selector (6) left or right, using a flat blade screw driver
(screw driver not included).
3. Using the spindle wrench (7) and the collet wrench (8) loosen the Collet nut.
4. Insert a 1/4” diameter shank die-grinder accessory (not included) fully into the Collet. Firmly tighten the Collet nut to lock both
the Collet and the die-grinder accessory in place, using the spindle wrench (7) and collet wrench (8).
5. Connect the air hose to the air inlet (1) of the tool.
6. Lightly push the trigger lock-off (4) forward and gently apply pressure to the trigger (3) until the desired speed is achieved.
7. With a firm grip on the tool, lightly apply the die-grinder accessory to the workpiece, slowly and steadily moving the tool until
you have acheived the desired finish on the workpeice.
8. If tool requires more power to accomplish task, ensure that the tool is receiving sufficient, un-obstructed airflow (CFM),
increase/decrease the pressure (PSI) output of regulator ensuring you do not exceed the rated maximum inlet air pressure of
the tool.
Caution: Do not exceed tool’s maximum inlet air pressure rating (90 PSI). If tool still does not have sufficient force at maximum
pressure and sufficient airflow, then a larger tool may be required.
10) Cleaning, Maintenance, and Lubrication
Note: These procedures are in addition to the regular checks and maintenance explained as part of the regular operation of the
air-operated tool.
The air motor and bearing uses compressed air to power the tool. Moisture in compressed air will rust the motor components, you
must lubricate the motor daily, with Kincrome air tool oil.
WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect from air supply before making any
adjustments, removing/installing attachments or accessories.
Lubrication
1. Disconnect the tool from the air supply holding it so the air inlet (1) faces up.
2. Hold the trigger (3) down and put 4 to 5 drops of Kincrome air tool oil in the air inlet. Holding the trigger down helps circulate oil
in the motor.
3. Connect the tool to air supply, cover the exhaust (2) with a towel and run for a few seconds.
WARNING! Any excess oil in the motor is immediately expelled from the exhaust (2) .Always direct exhaust (2) away from
people or objects.
Storage
1. Avoid storing the tool in a location subject to high humidity. If the tool is left as it is used, the residual moisture inside the tool
can cause rust. Before storing and after operation, oil the tool and run it for a short time.
2. Regular inspection should be carried out of spindles, threads, and clamping devices in-respect of wear and for location of
abrasive products.
11) Warranty
Warranty given by Kincrome Australia Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria (Tel 1300 657 528).
The applicable warranty period (24 months) commences on the date that the product is purchased. If this product has materials or
workmanship defects (other than defects caused by abnormal or non warranted use) you can, at your cost, send the product to place
of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement. Your rights under this
warranty are in addition to any other rights you have under the Australian Consumer Law or other applicable laws. Our goods come
with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major
failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. For further details please visit
www.kincrome.com.au or call us. Due to minor changes in design or manufacture, the product you purchase may sometimes differ
from the one shown on the packaging..
IMPORTANT! If the tool fails to operate correctly, call customer service on 1800 657 528 for advice on the best resolution for your
situation. If a resolution cannot be achieved over the phone please take the tool and all related accessories to an authorised service
centre or place of purchase showing proof of purchase for assistance.
6
INDUSTRIAL AIR DIE GRINDER STRAIGHT
12) Parts Breakdown
PARTS NO DESCRIPTION Q'TY PARTS NO DESCRIPTION Q'TY
K13230-1 SCREW 1 K13230-17 REAR PLATE 1
K13230-2 O-RING(P12) 1 K13230-18 PIN 2
K13230-3 O-RING(P8) 2 * K13230-19 ROTOR BLADE 4
K13230-4 AIR REGULATOR 1 K13230-20 ROTOR 1
K13230-5 SPRING 1 K13230-21 CYLINDER 1
K13230-6 VALVE STEM BUSHING 1 K13230-22 CONE MUFFLER 1
K13230-7 VALVE STEM 1 K13230-23 BEARING SPACER 1
K13230-8 O-RING(3.5*1.4) 1 K13230-24 FRONT PLATE 1
K13230-9 AIR INLET 1 K13230-25 BEARING(608ZZ) 2
K13230-10 EXHAUST SLEEVE 1 K13230-26 WASHER 1
K13230-11 O-RING(26.7*1.78) 1 K13230-27 CLAMP NUT 1
* K13230-12 SPRING PIN 1 K13230-28 SPINDLE 1
* K13230-13 LEVER 1 * K13230-29 COLLET 1
K13230-14 PROTECTING RUBBER 1 * K13230-30 COLLET NUT 1
K13230-15 HOUSING 1 * K13230-31 DRIVER WRENCH (14MM) 1
K13230-16 BEARING(696ZZ) 1 * K13230-32 COLLET WRENCH (19MM) 1
WE RESERVE THE RIGHT FOR ANY DESIGNING CHANGES TO THE PARTS AND WITHOUT ANY NOTICEMENT
IN ADVANCE.
AIR DIE GRINDER
* Indicated stocked spare parts. We reserve the right to change spare parts at any time without notice.
www.kincrome.com.au

Other kincrome Grinder manuals

kincrome K13231 User manual

kincrome

kincrome K13231 User manual

kincrome KP15201 User manual

kincrome

kincrome KP15201 User manual

kincrome K13235 User manual

kincrome

kincrome K13235 User manual

Popular Grinder manuals by other brands

Hilti NURON AG 4S-22-125 manual

Hilti

Hilti NURON AG 4S-22-125 manual

Hander HAG-2000N-S user manual

Hander

Hander HAG-2000N-S user manual

Worcraft EMG01-42 instruction manual

Worcraft

Worcraft EMG01-42 instruction manual

Festool RG 150 E Original operating manual

Festool

Festool RG 150 E Original operating manual

VERTO 51G014 instruction manual

VERTO

VERTO 51G014 instruction manual

Hitachi G 14DMR Handling instructions

Hitachi

Hitachi G 14DMR Handling instructions

Scheppach SM200AL Translation of original instruction manual

Scheppach

Scheppach SM200AL Translation of original instruction manual

Florida Pneumatic UT8749ADG-1 manual

Florida Pneumatic

Florida Pneumatic UT8749ADG-1 manual

Wen 4276 instruction manual

Wen

Wen 4276 instruction manual

EINHELL NTS 2000 Directions for use

EINHELL

EINHELL NTS 2000 Directions for use

Craftsman 397.19580 Operating instructions & parts list

Craftsman

Craftsman 397.19580 Operating instructions & parts list

BURR KING 960-250 instruction manual

BURR KING

BURR KING 960-250 instruction manual

Bosch GWS 20-230 Professional Original instructions

Bosch

Bosch GWS 20-230 Professional Original instructions

Graphite 59G220 manual

Graphite

Graphite 59G220 manual

SUHNER ABRASIVE LWC 16-TOP Technical document

SUHNER ABRASIVE

SUHNER ABRASIVE LWC 16-TOP Technical document

Ferm AGM1066S Original instructions

Ferm

Ferm AGM1066S Original instructions

Worcraft CEMG-S20Li instruction manual

Worcraft

Worcraft CEMG-S20Li instruction manual

GENERATION GSA675 manual

GENERATION

GENERATION GSA675 manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
