kincrome KP15201 User manual

INDUSTRIAL
GRINDER/
LINISHER
KP15210
DEC 18
ED1
900W
MOTOR
INDUCTION
GRIND
AND
SAND
PERSPEX
EYE
SHIELD
100MM
900W
MOTOR
INDUCTION
GRIND
AND
SAND
PERSPEX
EYE
SHIELD
100MM
LINISHING
BELT
200MM
GRINDING
WHEEL

1
INDUSTRIAL GRINDER/LINISHER
Table of Contents
Know Your Product...................................................................................................1
Instruction Images ...................................................................................................2
Grinder/LinsherSafety Instructions.......................................................................3-5
Grinder/LinsherAssembly ......................................................................................5-6
Grinder/LinsherOperation ......................................................................................6-7
Maintenance..............................................................................................................8
Trouble Shooting.......................................................................................................9
Warranty....................................................................................................................10
Know your product
1. Linishing/Sanding Belt
2. Linishing/Sanding Tool Rest
3. Linisher Side Guard
4. Linisher Safety Guard
5. Mounting Holes
6. ON/OFF Switch
7. Grinding Tool Rest Knob
8. Grinding Wheel Tool Rest
9. Grinding Wheel
10. Grinding Wheel Cover
11. Safety Eye Shield
12. Safety Eye Shield Bracket
13. Safety Eye Shield Knob
14. Linishing Arm Angle
Adjustment Hex Bolt
15. Linisher Tool Rest Lever
16. Linisher Belt Tensioner Lever
17. Linisher Belt Tracking Knob
18. Debris Output Port
Model No:...................................................................................................KP15201
Power: .......................................................................................................900W (S2:30min)
Motor Type:................................................................................................Induction
Rated Speed: .............................................................................................2950RPM
Grinding Wheel:.........................................................................................200mm x 32mm x 32mm 36# Vo:30m/s
Grinding Wheel Bushes: ...........................................................................20, 25.4, 32mm
Linishing Belt: ...........................................................................................914mm x 100mm 80# Vo:18 m/s
Output Shaft: .............................................................................................16mm (Accepts M16 Tapered Spindles)
Net Weight: ...............................................................................................29.2kg
3
4
5
6
7
8
9
10
11
13
14
15
17
16
12
1
2
18

2
INDUSTRIAL GRINDER/LINISHER
FIG 1. FIG 2. FIG 3. FIG 4.
FIG 5. FIG 6. FIG 7. FIG 8.
FIG 9. FIG 10. FIG 11. FIG 12.
FIG 13. FIG 14. FIG 15. FIG 16.
FIG17. FIG 18. FIG 19. FIG 20.
FIG21. FIG 22. FIG 23. FIG 24.
Instruction Manual Images

3
INDUSTRIAL GRINDER/LINISHER
General Power Tools Safety Warnings
Save all warnings and instructions for future reference.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future
reference. The term ‘power tool’ in the warnings refers to your mains-operated (corded) power tool
1. Work Area Safety
a. Keep work area clean and well lit. Cluttered ordark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c. Keepchildren and bystanders away while operatingapower tool. Distractions can cause you to lose control.
2. Electrical Safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is earthed orgrounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool willincrease the riskof
electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or entangled cords increasethe risk of electric shock.
e. Whenoperating a power tool outdoors, use an extension cord suitable for outdoor use.Use of a cord suitable for outdoor
use reduces therisk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an
RCD reduces the riskof electric shock.
3. Personal safety
a. Stay alert, watch what you are doingand use common sense when operating apower tool. Do notuse a power tool while
you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury.
b. Use personal protective equipment. Always wear eyeprotection. Protective equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is inthe off-position before connecting to power source and/orbattery
pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the
switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times.This enables better control ofthe power tool in unexpected
situations.
f. Dress properly. Do not wear loose clothing or jewellery.Keep your hair and clothing f rom moving parts. Looseclothes,
jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related hazards.
4. Powertool use and care
a. Do not force the power tool. Use the correct power tool for your application.The correct power tool will do the job better and
safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn iton and off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
c. Disconnect the plug from the power source before making any adjustments, changing accessories, or storing power tools.
Suchpreventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reachof children and do not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are dangerous inthe hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and anyother condition that
may affect the power tool’soperation. If damaged,have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.

4
INDUSTRIAL GRINDER/LINISHER
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working
conditions and the work to be performed. Use of the power tool for operationsdifferent from those intended could result in a
hazardous situation.
5. Service
a. Have your power tool serviced by a qualified repairperson using only identical replacement parts. This will ensure that the
safety of the power toolis maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
Additional Safety Warnings
WARNING! To avoid mistakes that could cause serious permanent injury, do not plug the Grinder/Linisherin until the following
steps are completed:
1.Young children and the infirm. This appliance is not intended for use by young children or infirm persons
without supervision.
2.This product is not intended for use by persons (including children) suffering from diminished physical, sensory or mental
abilities; lack of experience, knowledge or skills unless they are supervised by a person responsible for their safety.
3. Children should never be left alone with this product.
4. Never stand on the tool. Serious injury could occur if the tool tips.
5. Make sure all clamps and locks are tight and no parts have excessive play.
6. Never use the bench Grinder/Linishernear flammable liquids, vapours or gases.
7. Make sure there are no nails or foreign objects in the part of the workpiece to be sanded.
8. Whensanding irregularly shaped workpieces, plan your workpiece support so it will not slipand be pulled from your hands.
9. Use extra caution with large, very small or awkward workpieces.
10. Never use this tool to finish pieces too small to hold by hand.
11. Sandonly one workpiece at a time.
12. Clear everything except the workpiece and related support devices off the table before turning the Grinder/Linisher ON.
13. Always remove the plug from the mains socket before making any adjustments or maintenance, including changing the
Grinding Wheel (9)or Linishing/Sanding Belt (1).
14. Always turn the Grinder/LinisherOFF when it is not in useand never leave it unattended without first switching OFF and
removingthe power plug.Never leave the Grinder/Linisher until the Grinding Wheel (9) and Linishing/Sanding Belt (1) have
come to a complete stop.
15. Use only a Grinding Wheelwhich is marked with details of the manufacturer, or have thesame dimensions and the permissible
rated RPM.
16. Do not usethe Grinder/Linisherunless all the guards are properly fitted and secure.
17. Grinding Wheel (9)must be stored in a dry place, ideally at a constant temperature.
18. Use only the clamping flanges supplied with the equipment to mount theGrinding Wheel (9).
19. Adjust the Grinding Wheel Tool Rest (8) periodically in order to compensate the wear of the wheel. Please note that the distance
between the Grinding Wheel Tool Rest (8) and the Grinding Wheel (9)is to be kept as small as possible and should in no case
exceed 2mm.
20. The Grinding Wheel (9) must be replaced at the latestest when the GrindingWheel ToolRest (8)can no longer be set a
maximum distance of 2mm.
21. The machine may exceed 85 db (A) at the workplace. The operator will require noise protection measures and ear muffs (not
supplied) if this is the case. Even if you use this electric power tool inaccordance with instructions, certain residual risks cannot
be ruled out.
The following hazards may arisein connection with the equipment’s construction and layout.

5
INDUSTRIAL GRINDER/LINISHER
Read Instruction Manual Wear Hearing Protection Wear Safety Shoels
EMC Compiance Wear Eye Protection
WARNING Wear Dusk Mask
4) Risk of Electric Shock
1. Never touch the mains plug and the socket with wet hands.
2. Do not pull the plug from the socket by pulling on the power cable.
3. Check the power cord and mains plug for damage before every use.
4. To avoid accidents due to electrical faults we recommend the use of sockets witha line-side current-limiting circuit breaker
(max. 30 mA nominaltripping current).
5. Check the appliance and the power cord regularly for any possible damage. Don’t use damaged appliances.
5) Labels on Tool
The followingsymbols are shown on the tool:
ASSEMBLY
Unpacking the Grinder/Linisher Machine and its Parts.
1. Carefully lift the Grinder/Linisher out of its package.
2. Take out all accessories and assembly hardware.
3. Disposeofall discarded packaging, as per local council regulations.
Mounting the Grinder/Linisher to a Bench Grinder Stand or Workbench (Fig.1 - Fig.3)
TheGrinder/Linisher must be mounted onto a bench grinder stand or workbench (fasteners not included).
1. If mounting onto a workbench, mark the position of the four Mounting Holes (5) provided in the base of the
Grinder/Linisher onto the workbench or bench grinder stand if needed.
2. Drill an Ø 8-12mm hole at each of the marked positions (Hole size to suit your fasteners) (Fig.1).
3. Place the Grinder/Linisheron the workbench and insert an M8-M12 bolt witha washer through the Mounting Holes (5)
in the base into each of the holes drilled inthe workbench. Make sure the protruding length is at least 15 mm for each of the
bolts used(Fig2.).
4. Place a washer, nyloc nut on each of the bolts and securely tighten the nuts approx.torque: 8Nm (Fig.3).
Fitting the Safety Eye Shield Bracket (12) (Fig. 4 - Fig 6)
1. Position the Safety Eye Shield Bracket (12) in front of the Grinding Wheel Guard Mount aligning the slots on the Safety
Eye Shield Bracket (12) with the holes of the Grinding Wheel Guard Mount.
2. Attach the Safety Eye Shield Bracket (12)to the Grinding Wheel Guard Mountby screwing the Safety Eye Shield (11)adjusting
screws withthe spring washers and the washers, to the nuts (Fig.4).
3. Position the Safety Eye Shield Bracket (12)so that the distance between the Grinding Wheel (9) and the Safety Eye Shield
Bracket (12) is as smallas possible and does not exceed 2mm (Fig.5).
4. Holdthe nuts at the rear of the Safety Eye Shield Bracket (12)in place with an 8mm spanner (not supplied), while tightening
the front adjusting screw witha Phillips screwdriver (not supplied) (Fig. 6).
Note: Adjust the Safety Eye Shield Bracket (12)periodically to compensate for wear on the Grinding Wheel (9).

6
INDUSTRIAL GRINDER/LINISHER
Fitting the Safety Eye Shield (11) (Fig. 7 - Fig 9)
1. Position the Safety Eye Shield (11)between the vertical braces at the top of the Safety Eye Shield Bracket (12) (Fig.7).
2. Insert the long bolt through the Safety Eye Shield (11), allthe way through the Safety Eye Shield Bracket (11)until thesquare
shank of the bolt rests against the Safety Eye Shield (11). Add a flat washer, spring washer & Safety Eye Shield Knob (13)(Fig. 8).
3. Fasten the Safety Eye Shield (11) assembly in place with the Safety Shield Knob (13) (Fig.9).
WARNING! All covers and safety devices have to beproperly fitted before the Grinder/Linisher is switched ON.
Note: The Grinder/Linisher comes with two Tool Rests (2&8) that aid the user in holding items steady as they are being applied to the
GrindingWheel (9) or Linishing/Sanding Belt (1).
Fitting the Linishing/Sanding Belt Tool Rest (2) (Fig. 10 - Fig 13)
1. Insert the Linisher tool rest lever (15) threaded bolt and flat washer through the hole in the Linishing/Sanding Tool Rest
(2) (Fig.10).
2. Place the Linishing/Sanding Tool Rest (2) and Linisher Tool Rest Lever (15) threaded bolt into the inner Linisher Side Cover (3)
threaded fastener (Fig.11).
3. Secure the Linishing/Sanding Tool Rest (2) in place using the Linisher Tool Rest Lever (15). Do not fully tighten untilthe final
adjustments have been made (Fig.12).
4. Adjust the Linishing/Sanding Tool Rest (2) so that the distance betweenthe Linisher/Sanding Belt (1)andthe Linishing/Sanding
Tool Rest (2)is as small as possible and does not exceed 2mm. Tighten the Linisher ToolRest Lever (15) (Fig. 13).
Fitting the Grinding Wheel Tool Rest (8) (Fig. 14-Fig 17)
1. Allign the Grinding Wheel Tool Rest (8), with the adjustment knob hole and insert the Grinding Tool Rest Knob (7)
(Fig.14&15).
2. Secure the Grinding Wheel Tool Rest (8) to the Inner Wheel Guard Cover using the Grinding Tool Rest Knob (7).
Do not fully tighten untilthe final adjustments have been made (Fig.16).
3. Adjust the Grinding Wheel Tool Rest (8)so that the distance between the Grinding Wheel (9) and the Grinding Wheel Tool Rest
(8) is as small as possible and does not exceed 2mm (Fig.17).
4. Tighten the Grinding Tool Rest Knob (7).
Note: Adjust the Grinding Wheel ToolRest (8) periodically to compensate for wear on the Grinding Wheel (9).
OPERATION
WARNING!Always observe the safety instructions and applicable regulations.
WARNING! To reduce the risk of serious personal injury, turn toolOFF wait untilit comes to a complete stop and
disconnect tool from power source before making any adjustments or removing/installing attachments or accessories. Be
sure the ON/OFF switch is in the OFF position. An accidental start-up can cause injury.
ON/OFF Switch (6)
To reduce the risk of electrical shock, the use of a residual current device (R.C.D) (rated 30mA or less) is recommended (Not Included).
1. To switch ON the Grinder/Linisher press the GREEN “I” ON button of the ON/OFF Switch (6).
2. After switching ON, wait for the Grinder/Linisherto reach its maximum speed of rotation. Only then should you begin
Grinding/Linishing.
3. Press the RED “O” OFF button of the ON/OFF Switch (6) to switch OFF the Grinder/Linisher.

7
INDUSTRIAL GRINDER/LINISHER
Grinding
1. Place the workpiece onto the Grinding Wheel Tool Rest (8).
2. Slowly guide the workpiece towards the Grinding Wheel (9), ensuring that the workpiece is at the desired angle when it makes
contact contact with the Grinding Wheel (9).
Note: Exert only moderate pressure on the workpiece so that it can be machined at the Grinder/Linishers constant speed.
Allow the Grinding Wheel (9)to do the work, excessive force will cause the Grinding Wheel (9) to slow down and even stop/
overload the motor.
3. Move the workpiece from side to side to produce an optimal grinding result. This will also ensure that the Grinding Wheel (9)
willbe evenly worn across the width of the GrindingWheel (9) surface.
Note: Always allow the workpiece to cool down between extended grinding periods.
Linishing Belt Tracking (Fig. 18- Fig 21)
Caution: Before use, it may be necessary to usethe Linisher Belt Tracking Knob (17) to ensure the Linishing/Sanding Belt (1) tracks
in the centre of the Linishing Belt Side Cover (3).
WARNING: Failure to check the belt tracking could result in damage to the Linishing/Sanding Belt (1). Damage to the
Linishing/Sanding Belt (1),due to false tracking of the Linishing/Sanding Belt (1) , is not covered by warranty.
1. Adjust the tracking of the Linishing /Sanding Belt (1) to ensure it is running central to Linishing Belt Side Cover (3).
To adjust the belt tracking, rotate the Linisher Belt Tracking Knob (17) clockwise or anti-clockwise to track the
Linishing/Sanding Belt (1), making sure the belt is running central to the Linishing Belt Side Cover (3) (Fig.18&19).
2. If theLinishing/Sanding Belt (1)wanders to the left or right onto the Linishing Belt Side Cover (3), rotate the Linisher Belt
Tracking Knob (17) clockwise or anti-clockwise to track the Linishing/Sanding Belt (1),until the belt is running central to the
Linishing Belt Side Cover (3) (Fig. 20&21).
Linishing Arm Angle Adjustment (Fig. 22 - Fig 24)
The angle of the Linishing Armcan be adjusted to suit your linishing/sanding requirements. The degree of angle can
be adjusted as follows:
1. Using a 6mm hex key, loosen the Linishing Arm Angle Adjustment Hex Bolt (14) on the grinder body side of the linisher
attachment, anti-clockwise until the linishing arm can be rotated up/down (Fig.22).
2. Rotate theLinishing Arm up or down, untilis is positioned at your desired angle (Fig.23&24).
3. Tighten the 6 mm hex bolt clockwise until tight, to lock the linishing arminto yourdesired position (Fig.22).
Belt Linishing
1. Always hold the workpiece firmly while using the Linishing/Sanding Belt (1). Do not exert excessive pressure.
2. The workpiece should be moved from side to side on the Linishing/Sanding Belt (1) as you sand it, to prevent the paper wearing
on one side.
Note: Exert only moderate pressure on the workpiece so that it can be sanded at the Grinder/Linishers constant speed, instead of
applying excessive pressure of your material to the Linishing/Sanding Belt (1). High pressure will cause the drive unit to slow
down and even stop/overloadthe motor.
Caution: Ifthe Grinding Wheel (9)or Linishing/Sanding Belt (1) becomes jammed duringoperation, removethe workpiece and wait
until the Grinder/Linisher reaches its constant speed.
Caution: Always ensure that you have a good secure grip of the material being sanded or linished.

8
INDUSTRIAL GRINDER/LINISHER
MAINTENANCE
Changing the Grinding Wheel (9)
1. Remove the three and Phillips head bolts and nuts securing the Grinder Wheel Cover (10) using an 8mm spanner and
Phillips head screwdriver (not supplied).
2. Remove the Grinder Wheel Cover (10).
3. Remove the Flange Nut from the Spindle by rotating clockwise a 24mm spanner (not supplied).
4. Remove the Outer Flange, the Packing Piece/Blotter Label Card and the Grinding Wheel (9)from the Spindle.
5. Place the new Grinding Wheel (9) onto the spindle, ensuring that the Grinding Wheel (9)bore is the correct diameter.
Caution: Some replacement Grinding wheels may require bushing.
6. Replace the Packing Piece/Blotter Label Card, the Outer Flange and the Flange Nut on the Spindle.
7. Securely tighten the Flange Nutby rotating anti-clockwise, using a 24mm spanner (not supplied) (approx. torque: 6Nm).
8. Replace the Grinder Wheel Cover (10).
9. Replace the three Phillips head bolts and nuts securing the Grinder Wheel Cover (10) and securely tighten them.
WARNING! STAND WELL CLEAR OF THE GRINDER/LINISHER when switching ON.
DO NOT use adamaged Grinding Wheel (9).
10. Switch ON the Grinder/Linisher and let the Grinder Wheel (9) run with no load for one minute to check for
wheel damage or cracks.
Changing the Linishing/SandingBelt (1)
WARNING!Ensure the tool is disconnected from the power supply before cleaning or
maintaining the appliance.
1. Remove the three screws securing the Linishing Belt Side Cover (3) using Phillips Head Screwdriver (not supplied).
Note: One of thescrews has a plastic securing knob, located on the inner Linishing Belt Side Cover (3).
2. Remove the Linishing Belt Side Cover (3).
3. Move the Linishing Belt Tension Lever (16) downwards towards the motor, to release tension of the
Linishing/Sanding Belt (1).
4. Remove the Linishing/Sanding Belt (1).
5. Place a new Linishing/Sanding Belt (1) over the upper and lower rollers, making sure that the arrow on the insideof the
Linishing/Sanding Belt (1) points in the same direction as thearrow on the Linishing Belt Side Cover (3).
6. Raise theLinishing Belt Tension Lever (16) to apply tension to the installed Linishing/Sanding Belt (1).
7. Adjust the tracking ofthe Linishing/Sanding Belt (1), to ensure it is running central to the Linishing Belt Side Cover (3).
8. To adjust the belt tracking, slowly rotate the Linisher Belt Tracking Knob (17) clockwise or anti-clockwise, then slowly rotate
the Linishing/Sanding Belt (1) by hand to trackthe Linishing/Sanding Belt (1), making sure the belt is running central to the
Linishing Belt Side Cover (3) (Fig.18).
9. If the belt wanders to the leftor right of the Linishing Belt Side Cover (3), continue to rotate the Linisher Belt Tracking
Knob (17) clockwise or anti-clockwise to correctly rack the Linishing/Sanding Belt (1), untilthe belt is running central to the
Linishing Belt Side Cover (3) (Fig.19, 20 & 21).
10. Replace the Linishing Belt Side Cover (3) screws & tighten the three screws & plastic securing knob.
Lubrication
Your Grinder/Linisher requires no additional lubrication.
Cleaning
WARNING: Blow debris and dust out of the main housing with dry air as often as debris is seen collecting in and around the air vents,
safety guards.
Wear approved eye protection andapproved dust mask when performing this procedure.
WARNING: Never use solvents or other harsh chemicals for cleaning the non-metallic parts of the tool. These chemicals may weaken
the materials usedin these parts. Use a cloth dampened only with water and mild soap.
Never let any liquidget inside the tool; never immerse any part of the tool into aliquid. Keep the ventilation slots clear and regularly
clean the housing with a soft cloth.

9
INDUSTRIAL GRINDER/LINISHER
IMPORTANT!
If the Grinder/Linisher still fails to operate correctly after you have carried out theabove operations, or in the eventof anomalies
other thanthose described above, contact Kincrome Customer Service on 1300 657 528 for assistance.
Spare Parts
For a full list of available spare parts for this item visit the Kincrome website www.kincrome.com.au or alternatively contact Kincrome
Customer Service on 1300 657 528 for assistance.
TROUBLE SHOOTING
PROBLEM CAUSES SOLUTIONS
Excessive Vibration
1. Grinding Wheel (9) Damage
2. Grinder spindle damaged
3. Grinding Wheel (9) loose flanges
ehtotdenetsaftonrehsiniL/rednirG.4
bench grinder stand or work bench
5. Grinding Wheel (9) has the
incorrect size bore
1. Check for damage of the
Grinding Wheel (9)
2. Ensure the Grinder shaft is
not damaged
3. Check the tightening of the
Grinding Wheel (9) flanges
4. Fasten the Grinder/Linisher to a
workbench or bench grinder stand
5. Ensure the correct bushes are
used in the Grinding Wheel (9) bore
Linishing/Sanding Belt (1)
Not Tracking Straight
1. Belt Tracking not aligned correctly
2. Damage to the upper and/or
lower roller
1. Re-adjust Linishing/Sanding Belt
(1) tracking, as instructed page 6
2. Contact Kincome Customer Service
Uneven Grinding Wheel (9) Surface. 1. Grinding Wheel (9) worn out
of square
1. Dress the Grinding Wheel (9) with a
wheel dresser (not supplied)
2. Replace Grinding Wheel (9)
Linishing/Sanding Belt (1) Slipping
1. Linisher Belt Tensioner Lever (16)
not fully engaged
2. Lower Linishing Sanding Belt
roller worn
3. Incorrect Linishing/Sanding
Belt (1)
1. Ensure that Linisher Belt Tensioner
Lever (16) is fully extended
2. Replace the Lower Linishing
Belt Roller
3. Replace the Linishing/Sanding Belt (1)
4. Ensure the correct size
Linishing/Sanding Belt (1) is used

10
INDUSTRIAL GRINDER/LINISHER
CONTACT INFORMATION
Australian Office Contact Details
Phone: [phone]
Fax:[phone]
Email: [e-mail]
Website: www.kincrome.com.au
Warranty given by KincromeAustralia Pty Ltd of3 Lakeview Drive, Caribbean Park, Scoresby, Victoria
(Tel [phone]). The applicable warranty period (12 months) commences on the date that the product is
purchased. If this product has materials or workmanship defects (other than defects caused by abnormal or
non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome
service agent or one of Kincromes addresses for repair or replacement. Your rights under this warranty are in
addition to any other rights you have under the Australian Consumer Law or other applicable laws. Ourgoods
come with guarantees that cannot be excluded under the Australian ConsumerLaw. You are entitled to a replacement or refund for a
major failure and compensation for any other reasonably foreseeable loss ordamage. You are also entitled to have the goods repaired
or replaced if thegoods fail to be ofacceptable quality and the failure does not amount to a major failure. For further details please
visit www.kincrome.com.au or call us. Due to minor changes in design or manufacture, the product you purchase may sometimes
differ from the oneshown onthe packaging.

www.kincrome.com.au
