kincrome K12105 User manual

ENGINE LEVELLER
K12105
Distributed by Kincrome Group www.kincrome.com.au

Owner’s Assembly and Operating Manual
SPECIFICATIONS..................................................................................................................2
IMPORTANT SAFETY INFORMATION ..................................................................................3
UNPACKING AND ASSEMBLING SUPPORT BAR................................................................3
Unpacking Carton ...............................................................................................................3
OPERATING SUPPORT BAR ................................................................................................4
Preparing WorkArea...........................................................................................................4
Using the Leveler................................................................................................................4
Working on Engine..............................................................................................................5
MAINTENANCE AND STORAGE...........................................................................................5
Lubricating...........................................................................................................................5
Cleaning..............................................................................................................................5
SPECIFICATIONS
Working Load Limit 680 KG
Adjustable Length 0-300 mm
Part Number K12105

IMPORTANT SAFETY INFORMATION
The use of an engine Leveler has inherent dangers to avoid risk of personal injury or property damage make
sure you are fully aware of the operating instructions for this product and any recommendations in the vehicle
owners manual prior to using this tool. Do not exceed maximum lifting capacity of this engine leveler.This
engine Leveler is intended for automotive use only. Be aware that large or heavy engines may exceed the
stated capacity check vehicle owners manual or contact the engine manufacturer. Do not use for any other
purpose except the supporting of an engine on a suitable lifting device.
Warning dynamic (load which swings, slips from center or moves quickly) loads can exert a force much
greater than their physical mass (weight) resulting in failure of the Leveler and/or loss of the load leading to
property damage, personnel injury, even death.
UNPACKING AND ASSEMBLING SUPPORT BAR
Unpacking Carton
Place carton in a clear, open area such as garage floor. Remove components and lay them out neatly on
selected work surface. Make sure all nuts, bolts, washers, and pins, are properly assembled, Keep hooks
and L brackets safely until needed.
Supporting an engine using an engine Leveler can be dangerous. This engine Leveler is designed and
intended for use by properly trained and experienced personnel only. If you are not familiar with the
proper and safe operation of an engine support bar, do not use until proper training and knowledge have
been obtained.
The Handle (21) needs to
be positioned on the Load
Leveler before use. To do
this:
a. Remove the
Bolt(19),Nut(20) and
Handle from the Crank(9).
b. Place the handle outside
of the Crank and replace
the Bolt and Nut.

OPERATING SUPPORT BAR
Preparing Work Area
Before using the Engine Leveler, it is important to prepare work area properly. Follow this procedure each
time the Leveler is used to help prevent property damage and or serious injury.
1.) Thoroughly inspect Leveler for damage or wear before each use. Briefly test operation of unloaded
Leveler before using to support any load. If Leveler is damaged or is malfunctioning DO NOT SUPPORT
ANY LOAD until the problem is corrected.
2.) Consult vehicle owner’s manual for safety precautions, engine weight, and location of support areas on
engine. The working load limit of this engine Leveler is between 680 kg. NEVER EXCEED WORKING
LOAD LIMIT OF support bar.
3.) Loads which are allowed to swing or move of center can exert a force greater then the weight of the
object lifted.Make sure load is secured and not able to move from the vertical lifting line.
4.) Clear children and others from work area before commencing work. Another adult should be nearby for
extra safety and assistance but must be clear of vehicle as it is worked on.
5.) Clear obstructions from work area. Working in tight or cluttered work areas is dangerous.
6.) Be sure vehicle is on solid, level ground such as paved or concrete driveway or garage floor. Uneven or
sloped surfaces create hazardous working conditions and dangerously impeded the function of the
support bar.
7.) With vehicle in proper position, set vehicle’s parking brake or emergency brake and put gearshift in park
(manual transmissions should be placed in lowest gear). TURN VEHICLE IGNITION OFF AND TO THE
“LOCK” POSITION making sure steering wheel locks.
8.) Chock all wheels of vehicle to prevent vehicle rolling. Using wedge-shaped blocks that tyre cannot roll
over, position one chock tight against the tyre in both forward and reverse rolling paths.
Using the Leveler
Follow all instructions and precautions below and those of the lifting device.
1.) With Leveler properly assembled, place the Leveler onto the lifting device making instruction from both
devices are adhered too.
2.) Attach Chains to the Engine, making sure the device is securely attached to the engine and is suitably
rated to hold the weight.
3.) Slowly lift load via lifting device until it just about to bear load, check the leveler is securely connect to the
engine and the leveler appears level.
4.) Inspect engine securing device making sure it is properly attached to the engine.
5.) Remove connections on engine. Slight adjust of the leveler may be required by cranking the handle to
maintain engine position after other fasteners are loosened or removed.
6.) Never leave an engine suspended by an engine Leveler and other lifting device – the product is intended
for short term use during repair. As soon as is practicable engine should repaired and engine Leveler
removed.

7.) NEVER work under an engine supported by a lifting device. Never place and part of you body under an
engine supported by am engine leveler.
Working on Engine
Any engine being supported by an engine Leveler creates a potentially hazardous working environment.
Never place any part of your body beneath an engine supported by an engine support bar. Work should only
be attempted on the removed engine once it is no longer supported by the lifting device, either securely
attached to an engine stand or other suitable supporting device.
MAINTENANCE AND STORAGE
Lubricating
Moving parts on engine Leveler should be lubricated occasionally with a light machine oil to maintain
efficient operation.
Cleaning
Engine Leveler should be wiped clean with soft cloth only. Do not use gasoline, kerosene, or other such
solvents or any abrasive cleanser.
