Kinetik Wellbeing TMB-2088 User manual

Guangdong Transtek Medical Electronics Co., Ltd.
Zone A, No.105, Dongli Road, Torch Development
District, 528437 Zhongshan, Guangdong, China
EC REP Medical Device Safety Service GmbH
Schiffgraben 41, 30175 Hannover, Germany Kinetik TMB-2088 UK IB 20210914
User Manual
Smart Blood Pressure Monitor
Thank you very much for selecting the Kinetik Wellbeing Smart Blood
Pressure Monitor.
Please read the user manual carefully and thoroughly so as to ensure
the safe usage of this product, keep the manual safe for future reference
in case you have problems.
TMB-2088

INTRODUCTION....................................................................................................................3
SUPPORT..............................................................................................................................2
General Description
Indications for Use
Contraindications
Measurement Principle
Safety Information
Display and Symbols
Name of Each Part
Contents/Product Includes
BEFORE YOU START..........................................................................................................10
The Choice of Power Supply
Installing and Replacing the Batteries
Setting the Date and Time
Setting a user ID
Pair a smart device with the monitor
MEASUREMENT..................................................................................................................18
Applying the cuff
Start a Measurement
DATA MANAGEMENT..........................................................................................................22
Recall the Records
Delete the Records
INFORMATION FOR USER.................................................................................................26
Tips for measurement
Maintenance
ABOUT BLOOD PRESSURE...............................................................................................28
What are systolic pressure and diastolic pressure?
What is the standard blood pressure classification?
Irregular heartbeat detector
Why does my blood pressure fluctuate throughout the day?
Why do I get a different blood pressure at home compared to the hospital?
Is the result the same if measuring on the right arm?
TROUBLESHOOTING.........................................................................................................31
SPECIFICATIONS................................................................................................................32
AUTHORISED COMPONENT .............................................................................................33
CONTACT INFORMATION...................................................................................................33
EMC GUIDANCE.................................................................................................................34
TABLE OF CONTENTS
1
EU Declaration of Conformity (DoC).....................................................................................33

Our manual should provide you with all the information you need
to set up and use this product.
If you have a question, have a look at our Troubleshooting page!
For further assistance, why not contact our Customer Care team
directly? We’re here to help!
Our Customer Care team are available from 9am-5pm, Monday to
Friday (excluding bank holidays).
We promise to respond to all queries and will ensure to resolve any
issue you may be having.
You can reach us by…
Phone:
[phone]
Live Chat:
Simply visit www.kinetikwellbeing.com and send us a message.
Email:
[email protected]
Post:
Kinetik Medical Devices Limited
Unit 3, Perrywood Business Park, Honeycrock Lane,
Salfords, Redhill. RH1 5DZ
Support
SUPPORT
2
General Description
Indications for Use
Measurement Principle
The Kinetik Wellbeing Smart Blood Pressure Monitor is a digital monitor
intended for use in measuring the blood pressure and pulse rate of those
with an arm circumference ranging from 22 cm to 42 cm.
It is intended for indoor, adult use only.
1.The device is not suitable for use on women who are or may be pregnant.
2.The device is not suitable for use on patients with implanted, electrical
devices, such as cardiac pacemakers or defibrillators.
Contraindications
This product uses the Oscillometric Measuring method to detect blood
pressure. Before every measurement, the unit establishes a “zero
pressure” equivalent to the atmospheric pressure. Then it starts inflating
the arm cuff, meanwhile, the unit detects pressure oscillations generated
by beat-to-beat pulsatile, which is used to determine the systolic and
diastolic pressure, and also pulse rate.
3
INTRODUCTION
Thank you for selecting Kinetik Wellbeing Smart Blood Pressure Monitor
(TMB-2088). The monitor features blood pressure measurement, pulse
rate measurement and the result storage.
The design provides you with two years of reliable service.
FEATURES:
• 124 mm × 76 mm Digital LCD display
• Systolic, Diastolic Blood Pressure & Pulse Display
• Date / Time Indication
• Irregular Heartbeat detection
• 2 × 250 memory storage, Guest mode available
• Up-to-date measuring-during-inflation technology

Safety Information
The symbols below might be in the user manual, labeling or other
component. They are the requirement of standard and using.
Symbol for “The operation guide must be read”
Symbol for “Class II Equipment”
Symbol for “Manufacturer”
Symbol for “Serial Number”
Symbol for “Type BF applied parts”
Symbol for “Direct Current”
Symbol for “ENVIRONMENT PROTECTION - Electrical waste
products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your local
authority or retailer for recycling advice”
For indoor use only
Symbol for “Manufacture date”
SN
Symbol for “Recycle”
Indicates the need for the user to consult the instructions for
use for important cautionary information such as warnings
and precautions that cannot, for a variety of reasons, be
presented on the medical device itself.
Symbol for “Complies with MDD 93/42/EEC requirements”
Symbol for “European Authorised Representative (EC Rep)”
EC REP
INTRODUCTION
4
CAUTION
* This device is intended for indoor, home use.
* This device is not intended for public use.
* This device is portable, but it is not intended for use during patient transport.
* This device is not suitable for continuous monitoring during medical emergencies or operations.
* This device is intended for no-invasive measuring and monitoring of arterial blood pressure. It is
not intended for use on extremities other than the arm, or for any purpose other than obtaining a
blood pressure measurement.
* This device is for adults. Do not use this device on neonates or infants. Do not use it on children
unless otherwise instructed by a medical professional.
* Do not use on women who may be or are pregnant, including pre-eclamptic patients
* The device is not suitable for use on patients with implanted, electrical devices, such as cardiac
pacemakers or defibrillators.
* The effectiveness of this device has not been established for use:
-on users with common arrhythmias such as atrial or ventricular premature beats or atrial
fibrillation,
-on users with peripheral arterial disease,
-on users undergoing intravascular therapy, or with arteriovenous (AV) shunt.
Consult a medical professional before use.
* Do not use this device for diagnosis or treatment of any health problem or disease. Contact your
physician if you have or suspect any medical problem. Do not change your medications without
the advice of your physician or health care professional.
* If you are taking medication, consult your physician to determine the proper time to measure
your blood pressure.
* This device may be used only for the intended use described in this manual, the manufacturer
shall have no liability for any incidental, consequential, or special damages caused by misuse or
abuse.
* Report any unexpected operation or events to the manufacturer.
* Do not apply the cuff on an arm that has an intravenous drip or a blood transfusion attached.
* Warning: Do not kink, fold, stretch, compress, or otherwise deform the tube during measuring,
as the cuff pressure might continuously increase, which could prevent blood flow and result in
injury
* Warning: Taking blood pressure measurements too frequently could disrupt blood circulation and
cause injuries.
*Warning: Do not apply cuff to areas on patient where skin is delicate or damaged. Check cuff site
frequently for irritation.
* Warning: Do not place the cuff on the arm of a person whose arteries or veins are undergoing
medical treatment, i.e. intra-vascular access or intra-vascular therapy or an arteriovenous (A-V)
shunt, which could disrupt blood circulation and cause injuries.
* Do not place the cuff on the arm on the same side of a mastectomy (especially when lymph
nodes have been removed). It is recommended to take measurements on the unaffected side.
* Do not wrap the cuff on the same arm to which another monitoring device is applied. One or both
devices could temporarily stop functioning if you try to use them at the same time.
* Please check that the operation of the device does not result in prolonged impairment of patient
blood circulation.
* Warning: On the rare occasion of a fault causing the cuff to remain fully inflated during
measurement, loosen and remove the cuff immediately. Prolonged high pressure applied to the
arm (cuff pressure >300 mmHg or constant pressure >15 mmHg for more than 3 minutes) might
lead to bruising and discolored skin.
* Warning: Do not use this device with high-frequency (HF) surgical equipment at the same time.
5
INTRODUCTION

4
3
2
115141312
11
10
9
8
7 6 16 5
Systolic blood pressure reading
Blood pressure level
See the blood pressure classifcation on page 28-29
Diastolic blood pressure reading
Pulse display
Pulse rate appears after the measurement.
Heartbeat symbol
Flashes when decteted during a measurement.
Irregular heartbeat symbol
Appears when decteted during a measurement.
Refer to page 29 for more information.
Average value symbol
Appears when viewing the average value of the latest 7 days under
the memory mode.
1
2
3
4
5
6
SYMBOL EXPLANATION
CAUTION
* Warning: This device is not AP/APG equipment. Do not use the device where flammable
anesthetic are present, or in environments mixture with air of with oxygen or nitrous oxide.
* The device contains sensitive electronic components.To avoid measurement errors, avoid taking
blood pressure measurements near a strong electromagnetic field radiated interference signal
or electrical fast transient/burst signal.
* Wireless communication equipment, such as wireless home network devices, mobile phones,
cordless telephones and their base stations, walkie-talkies may cause interference that may
affect the accuracy of measurements. A minimum distance of 1 foot (30 cm) should be kept from
such devices during a measurement.
* You can use this device to take your own measurement, no third-party operator is required.
* Please use the device under the environment which is provided in the user manual. Otherwise,
the performance and lifetime of the device will be impacted and reduced.
* The device may require up to 30 minutes to warm up / cool down from the minimum / maximum
storage temperature before it is ready for use.
* Warning: Excessive cuff tube lengths could cause strangulation if you don't manage them
properly.
* Warning: Do not touch output of the batteries/adapter and the user simultaneously.
* Adapter is specified as a part of ME EQUIPMENT.
* Warning: The power cord is considered the disconnect device for isolating this equipment from
supply mains. Do not position the equipment so that it is difficult to reach or disconnect.
* The blood pressure monitor, its adapter, and the cuff are suitable for use within the patient
environment.
* Warning: Do not use this device if you are allergic to polyester, nylon, or plastic.
* Warning: Only use accessories approved by manufacturer. Using unapproved accessories
might cause damage to the unit and injure users.
* Warning: If you experience discomfort during a measurement, such as pain in the arm or other
complaints, press the Power button immediately to release the air from the cuff.
* No calibration is required within two years of reliable service.
* Do not attempt to repair the unit yourself if it malfunctions. Only have repairs carried out by
authorised service centers.
* At the request of authorised service personnel, circuit diagrams, component part lists,
descriptions, and calibration procedures will be made available by the manufacturer or
distributor.
* It is recommended that the performance should be checked after repair, maintenance, and
every two years of use, by retesting the requirements in limits of the error of the cuff pressure
indication and air leakage (testing at least at 50 mmHg and 200 mmHg).
* Warning: Do not use the device while under maintenance, or being serviced.
* Store your device, cuff and adapter in a clean and dry place, protect it against extreme moisture,
heat, lint, dust and direct sunlight. Never place any heavy objects on it.
* Make sure the rubber tube of the cuff is not squeezed, stretched, or kinked during storage.
* Warning: Keep the device, cuff, and batteries away from children as they may pose a risk of
choking or strangulation if used improperly.
* Clean both device and cuff with a soft, dry cloth. If necessary use a dampened cloth and natural
detergent. Do not use alcohol, benzene, or other harsh chemicals.
* Do not wash the cuff in a washing machine or dishwasher!
* The service life of the cuff may vary by the frequency of washing, skin condition, and storage
state. The typical service life is 10000 times.
* Dispose of accessories, detachable parts, and the device according to the local guidelines.
INTRODUCTION
6
Display and Symbols
7
INTRODUCTION

Date / Time display
8
9
10
12
13
14
15
16
11
7
Data pending to transmit symbol
Displays when the data transmission failed. The measurements are
saved on the device and will be sent when a successful connection
is achieved.
Excessive body motion detector symbol
Appears when talking, moving, or shaking of the arm with the cuff on
is detected during a measurement.
NOTE: The measured blood pressure reading may not be accurate
when this symbol is displayed with the reading.
Bluetooth symbol
Flashes when the Bluetooth is working.
Cuff wearing OK symbol
Appears when the cuff is wrapped well.
User ID symbol
The user ID number appears when the monitor is operated by the
selected user.
Memory symbol
Indicate it is in the memory mode and which the group of memory it is.
Blood Pressure Trends
Appears when viewing the blood pressure trends of
the specified period of the past 7 days under the
memory mode.
The X-axis of the histogram represent the time,
while the Y-axis represents the average value of
systolic and diastolic pressure.
Refer to page 22 for more information.
SYMBOL EXPLANATION
Battery power mode / High power
Appears when the power is only supplied by batteries.
Or appears along with the error symbol "BAt H" to indicate the DC
power is too high.
Adapter power mode / Adapter error symbol
Appears when the power is supplied by AC adapter.
Or appears along with the error symbol "Err USb" to indicate the
adapter error.
Low Battery symbol
Indicate the battery is low when appears with the error symbol "BAt Lo".
INTRODUCTION
8 9
INTRODUCTION
Contents/Product Includes
• Blood Pressure Monitor (TMB-2088)
• Cuff (Type BF applied part)
Upper arm circumference: 22-42 cm
• User manual
• 4x AA batteries
• Type-C cable (not included)
• AC Adapter (not included)
Reference model: BLJ06L050100U-V (with European plug)
Reference model: BLJ06L050100U-S (with Australian plug)
Reference model: BLJ06L050100U-B (with UK plug)
Name of Each Part
CUFF
AIR HOSE
AIR CONNECTOR
PLUG
LCD DISPLAY
Type-C port
[User/Forward]
button
[Memory/Pairing/Backward]
button
[Start/Stop/Set]
button
BATTERY COMPARTMENT

11
BEFORE YOU START
AC adapter
(Not included)
BEFORE YOU START
10
In order to get the best effect and protect your monitor, please use
the right batteries and approved power adapter which complies with
local safety standard.
Installing and Replacing the Batteries
CAUTION
CAUTION
The Choice of Power Supply
1. Battery powered mode:
6V DC 4× AA batteries
2. AC adapter powered mode: 5V 1A
(Please only use the AC adapter
authorised by the manufacturer -
AC adapter is not included).
Do not use new and used batteries together.
Do not use different types of batteries together.
Do not dispose the batteries in fire. Batteries may explode or leak.
Remove batteries if the device is not likely to be used for some time.
Worn batteries are harmful to the environment. Do not dispose with daily garbage.
Remove the old batteries from the device following your local recycling guidelines.
Note: Please unplug the adapter to
depart from the using utility power,
when you finish the measurement.
•Slide off the battery cover.
•Install or replace 4x AA size batteries
according to the polarity indications
inside the battery compartment.
•Place the battery cover back on.
Any time the battery is low, it will display
the icon & ”bAt Lo” and then power
off automatically after about 5 seconds.
Replace the batteries:
• When the low battery symbol appears.
(see the LCD display on the right picture)
• When any button is pressed and
nothing is displayed on the screen.
Type-C cable
(Not included)
1.
2.
Setting the Date and Time
It is important to set the date and time before using your blood pressure
monitor for the first time, so that a correct time stamp can be assigned to
each record that is stored in the memory.
(The setting range of the year: 2021—2050, Time format: 24H/12H)
Press and hold the button to quickly advance the years.
Press and hold the button to quickly go backwards through the years.
When the monitor is off, press and hold the button to display the
date format. Press the or button to switch the date format
between [month/day/year] and [day/month/year].
Press the button to confirm the date format, then the year will flash.
Press the or button to change the year.
[month/day/year] format
[day/month/year] format

13
BEFORE YOU START
12
BEFORE YOU START
Year
Month
Day
Time format
Hour
Minute
BP trends start time setting
3. Press the button to confirm the year, then the month will flash.
Repeat the same steps to change the month, day, time format, hour,
and minute.
4. Press the button to store the setting, then it will enter BP trends
time setting mode. Repeat the steps 2 and 3 to set the start time and
then the end time.
By default,
BP trends start time: 06:00 (a.m.).
BP trends end time: 10:00 (a.m.) .
BP trends end time setting
5. After confirming the BP trends end time, the LCD will display “do nE”
and the monitor will shut off after several seconds.
Note.
The date and time will automatically be set when the monitor is paired with
“MedM health” app. Refer to the section ”Pair a smart device with the
monitor”.
If you need to reset the date and time, replace batteries or press and hold
the button, then set the date and time as shown in above steps.

15
BEFORE YOU START BEFORE YOU START
14
Setting a user ID
There are 3 user ID’s available. The user and , each with 250
memory spaces, are designed for 2 different people to save the measured
values separately. The user , has no memory space, is reserved for a guest.
2. Press the button to confirm the selected user ID, the monitor will
display “do nE” and shut off after several seconds.
Note
Only user and can be selected in this setting mode.
1. When the monitor is off, press the button to display the current
user ID. Press the button to switch the user ID between the user
and .
3.
4.
5.
Pair a smart device with the monitor
You are the intended operator of this blood pressure monitor. You can
measure your blood pressure and then save and send measurement data
to a smart device (such as smartphone or tablet) with Bluetooth wireless
connectivity and MedM Health application.
When the monitor is off, press and hold the button to start pair-up,
the bluetooth symbol will flash.
Enable Bluetooth and the MedM Health app on your smart device.
Make sure both Bluetooth and app are ON when pair-up is proceeding.
In the app, select the menu in the top left corner of screen. Then select
'My Devices'.
If successful, the bluetooth symbol will not flash any more and the
monitor will display ”do nE”.
Press the button to turn off the deivce, or the monitor will automatically
shut off after about 1 minute.
Note
The date and time on your monitor
will automatically be set after
paired with your smart device
successfully.
1. Download the Blood Pressure Diary by MedM app or the MedM
Health app from the App store or Google Play.
2. Install the app, and register an account.

1716
If unsuccessful within 60 seconds, it is judged timeout and the monitor
will shut off.
1.
2.
Interference may occur in the vicinity of equipment marked with the following
symbol . And TMB-2088 may interfer the vicinity electrical equipment.
Sensitive people, including pregnant women, including pre-eclamptic, patients
and those patients with implanted, electrical devices should avoid using this
product whenever possible.
Keep the monitor at least 20 centimeters away from the human body
(especially the head) when the data transmission is proceeding after the
measurement.
To enable the data transmission function, this product should be paired to
Bluetooth end at 2.4 GHz.
How to mitigate possible interference?
The range between the device and BT end should be reasonably close, from
1 meter to 10 meters. Please ensure there are no obstacles between the
device and BT end so as to obtain quality connection and to lower the RF
output range.
To avoid interference, other electronic devices (particularly those with
wireless transmission / Transmitter) should be kept at least 1 meter away from
the monitor. And BT end so as to obtain quality connection and to lower the RF
output range.
CAUTION
Bluetooth Module information：
Bluetooth Module No.: B2088-T
RF Frequency Range: 2402 MHz to 2480 MHz
Output Power Range: 0 dBm
Supply Voltage: 1.8-3.6 V
Transmitting Distance: 10 meters
List of compatible devices:
For iOS devices:
The operating system must be iOS 13.0 or more.
For Android devices:
The operating system must be Android 5.0 or more.
BEFORE YOU START
BEFORE YOU START
6. At the bottom of the screen select Add New. This will automatically
start scanning for a new device.
When detected, select the TMB-2088.
7. Once selected you will be asked if you would like to transmit and
receive blood pressure measurement data automatically. To store
automatically you will need to select Yes on this screen. If you
select No you will need to manually input results.

1918
MEASUREMENTMEASUREMENT
Applying the cuff
2~3cm
1.
Hold your arm with your palm facing
up and tie the cuff on your upper arm,
align the Artery indicator with the
main Artery (on the inside of your arm).
Note: Locate the main Artery by pressing with
2 fingers approximately 2 cm above the bend
of your elbow on the inside of your left arm.
Identify where the pulse can be felt the
strongest, that is your main Artery！
4. Make sure the bottom edge of the
arm cuff is 2 to 3 cm above the inside
elbow. Then wrap the cuff securely.
Note: The cuff should be snug but not too tight.
You should be able to insert one finger between
the cuff and your arm.
Remove all jewelery, such as watches
and bracelets from your left arm.
Note: If your doctor has diagnosed you with poor
circulation in your left arm, use your right arm.
Roll or push up your sleeve to expose
the skin. Make sure your sleeve is not
too tight.
2.
3.
5.
6.
Sit upright in a comfortable chair with
your back against the backrest of the
chair. Keep your feet flat and your legs
uncrossed.
Place your arm resting comfortably on
a flat table. The cuff worn on your arm
should be placed at the same level as
your right atrium of the heart.
Take 5-6 deep breaths and let's start measur-
ing!
Take the measurement in a silent room.
Wait at least 3 minutes before another measurement. This allows your blood circulation to recover.
Be relax and do not move and talk during the measurement procedure.
For a meaningful comparison, try to measure under similar conditions. For example, take daily
measurements at approximately the same time, on the same arm, or as directed by a physician.
Rest for 5 minutes before a measurement.
Helpful tips:
Cuff wrap detection
Select user ID
Start a measurement
2.
3.
You can use your monitor without pairing to a smart device. To pair your
monitor with a smart device refer to the page 15-16.
Press the button to switch the user or or . press the
button to confirm the selected user ID.
1. When the monitor is off, press the button, the current user ID
will flash.
Remain still and do not talk until the full measurement is complete.
(Example shown below for User 1)
Note
When the selected user has history memory record, the monitor will display
its last measurement record first before starting “cuff wrap detection”.
Any time, to stop the measurement, press the button.
Inflating and measuring
(a heartbeat is detected)
Display and save
the measurement result

20 21
MEASUREMENT MEASUREMENT
4. Press the button to turn off the monitor, or it will shut off after
about 1 minute.
If unsuccessful within 60 seconds, it is judged timeout and the monitor will
shut off. In the case of a data transmission failure, up to 250 measurements
are saved on the device and will be sent when a successful connection is
achieved.
If successful, both symbols will disappear and the monitor will
display ”do nE”.
Press the button to turn off the deivce, or the monitor will automatically
shut off after about 1 minute.
5. If your monitor is already paired with your smart device and both
Bluetooth and app are ON, when the measurement completed, the
measurement result will start transmitting. (only user 1 and 2 available)
Note
Both user and can store maximum 250 groups of record. When you
pass that limit, every time you take the measurement, the monitor will
prompt “FULL” first and the oldest record will drop from the list after the
measurement.
6. About the irregular heartbeat and excessive body motion during the
measurement.
During a measurement, If an irregular heartbeat is detected, the symbol
will display in the measurement result. See page 29 for more information.
During a measurement, if there is excessive body motion, especially of the
arm the cuff is worn is detected, the symbol will flash for roughly 5
seconds and detect again. If it is no longer detected, the symbol will
disappear; If still detected, the symbol will final display in the
measurement result.
Note
The measured blood pressure reading may not be accurate if this symbol

22 23
The Time and Date will
display alternately.
The current record
is the group 8.
The corresponding
time is A.M. 10:00.
The corresponding
date is June 1 .
st
4. Press the or button to display the next record.
When the maximum average systolic pressure is higher than or equal to
130 mmHg, a top horizontal line will display. When the minimum average
diastolic pressure value pressure is lower than 85 mmHg, a lower horizontal
line will display.
If there is no lower horizontal line displayed or if the histogram is higher than
this top horizontal line, that means these days your blood pressure is
beyond the optimal blood pressure, it is suggest you should pay more
attention to rest. If the problem persists, contact your physician. Please note
that only a physician can tell whether your blood pressure value has
reached a dangerous point.
(according to WHO blood pressure classification, the optimal blood pressure
is systolic <130 mmHg, while diastolic <85 mmHg. see page 28 for more
information)
Note
when your monitor is paired with your smart device and both Bluetooth and
app are ON, the records will start transmitting with the symbol blinking.
Once successful, the symbol will disappear.
The most recent record (1) is shown first. Each new measurement is
assigned to the first (1) record. All other records are pushed back one
digit (e.g., 2 becomes 3, and so on), and the last record (250) is dropped
from the list.
DATA MANAGEMENTDATA MANAGEMENT
Recall the Records
2.
3.
Press the button to switch the user ID between user and .
press the button to confirm the selected user ID.
1. When the monitor is off, press the button, the LCD will display the
total groups of the memory records, with the user ID blinking.
top horizontal line
Then the LCD will display the average value of all the records of last 7
days and BP Trends chart of a specified period of last 7 days, with the
histogram of the latest day blinking. (Example shown below for User
1)
Note
BP trends is a histogram, designed to display the average blood pressure
value of a specified period of last 7 days, to help the user to visually know
their blood pressure changes.
To set the specified period of the BP trends, please refer to the section
”Setting the Date and Time”.
If there is no measurements for that period of time on a given day, the
histogram for that day will be blank.
For the BP trends chart, the X-axis of the histogram represent the time
(from left to right, from Sunday, Monday, Tuesday, Wednesday, Thursday,
Friday to Saturday), while the Y-axis of the histogram represents the
average value of systolic (high) pressure and diastolic (low) pressure of
the specified period each day.
The data displayed on the top left is the maximum average systolic
pressure value in the past 7 days, while the bottom left is the minimum
diastolic pressure value in the past 7 days.

24 25
DATA MANAGEMENT
Delete the Records
2. Press and hlod the button about 3 seconds, the LCD will display
“dELE yES” with “yES” blinking.
1. Enter the memory recall mode as described in the previous section
"Recall the records", find out the record you want to delete.
Delete the records by following the steps below.
3. Press the button to confirm the deletion, the LCD will display
“yES donE” and then the previous record will be displayed.
Note
Before you confirm the deletion,
you could press the or
button to switch the LCD display
from “dELE yES” to “dELE no”.
Then press the button, you
could stop clearing the memory.
A: Delete one record (Example shown below for User 1)
2. Press and hlod the and button at the same time for about 5
seconds, the LCD will display “dELE ALL” with “ALL” blinking.
1. Enter the memory recall mode as described in the previous section
"Recall the records".
3. Press the button to confirm the deletion, the LCD will display
“ALL donE” and then “- -” will be displayed.
Note
Before you confirm the deletion,
you could press the or
button to switch the LCD display
from “dELE ALL” to “dELE no”.
Then press the button, you
could stop clearing the memory.
B: Delete all records (Example shown below for User 1)
DATA MANAGEMENT

26 27
Tips for Measurement
Within 1 hour
after dinner or drinking
Within 20 minutes after taking a bath
In a very cold environment
Immediate measurement
after tea, coffee, smoking
When talking or moving your fingers
When you need to use the toilet
Measurements may be inaccurate if taken in the following
circumstances.
INFORMATION FOR USERINFORMATION FOR USER
Maintenance
In order to get the best performance, please follow the instructions
below.
Put in a dry place
and avoid the sunshine
Avoid intense shaking
and collisions
Using wet cloths to
remove dirt
Avoid touching water,
clean it with a dry cloth in case.
Avoid dusty and unstable
temperature environment
Do not attempt to clean the reusable
cuff with water and never immerse
the cuff in water.

28 29
What are systolic pressure and diastolic pressure?
What is the standard blood pressure classification?
When ventricles contract and pump blood out of the heart, the blood
pressure reaches its maximum value in the cycle, which is called systolic
pressure. When the ventricles relax, the blood pressure reaches its
minimum value in the cycle, which is called diastolic pressure.
press
artery vein
blood discharging
Systolic
relax
blood entering
Diastolic
The blood pressure classification published by World Health Organization
(WHO) and International Society of Hypertension (ISH) in 1999 is as
follows:
ABOUT BLOOD PRESSUREABOUT BLOOD PRESSURE
CAUTION
SYS
DIA
<120
<80
120-129
80-84
130-139
85-89
140-159
90-99
160-179
100-109
≥180
≥110
Level
Blood
Pressure
(mmHg)
Optimal Normal High-normal Mild Moderate Severe
Only a physician can tell your normal BP range. Please contact a physician if your
measuring result falls out of the range. Please note that only a physician can tell
whether your blood pressure value has reached a dangerous point.
Irregular Heartbeat Detector
CAUTION
An irregular heartbeat is detected when a heartbeat rhythm varies while the
unit is measuring the systolic and diastolic blood pressure. During each
measurement, the monitor records all the pulse intervals and calculate the
average; if there are two or more pulse intervals, the difference between
each interval and the average is more than the average value of ±25%, or
there are four or more pulse intervals, the difference between each interval
and the average is more than the average value of ±15%, the irregular
heartbeat symbol appears on the display when the measurement results
are appeared.
The appearance of the IHB icon indicates that a pulse irregularity consistent
with an irregular heart-beat was detected during measurement. Usually this is NOT
a cause for concern. However, if the symbol appears often, we recommend you seek
medical advice. Please note that the device does not replace a cardiac examination,
but serves to detect pulse irregularities at an early stage.

3130
ABOUT BLOOD PRESSURE
If any abnormality arises during use, please check the following points:
NOTE: If the product still does not work, contact Customer Service. Under no
circumstance should you disassemble or attempt to repair the unit by yourself.
PROBLEM SYMPTOM CHECK THIS REMEDY
No power
High Battery
Low Battery
Error
message
Display can
not light up.
Batteries are depleted. Replace with new batteries.
Insert the batteries
correctly.
Replace with new batteries.
Batteries are inserted
incorrectly.
bAt Lo &
shows
The battery is too low.
E 1 shows
E 3 shows
E 4 shows The measurement
failed.
Adapter is inserted
incorrectly.
Insert the AC adapter
correctly.
The cuff is not wrapped
or wrapped incorrectly,
or the cuff air plug is
loose.
Refasten the cuff and insert
air tube plug correctly then
measure again.
Relax for 5 minutes,and
then keep still, measure
again.
Relax for 5 minutes and
measure again.
Pulse is not detected
during measuring.
Loosen the clothing on the
arm and measure again.
Warning
message
Relax for a moment and
then measure again. If the
problem persists, contact
your physician.
out shows Out of measurement
range
EEx shows Hardware error
(X can be some digital
symbol, such as 1, 2, 3,
etc.)
Turn off monitor and
measure again. If EEx still
appears on the display,
please contact the retailer
or our customer service.
Err & Usb
shows
Adapter error
bAt H shows The battery is too high. Replace with new batteries.
Replace with the authorised
adapter.
Excessive body motion
(such as shaking of the
arm with the cuff on)
or weak Pulse is
detected.
E 2 or
shows
TROUBLESHOOTING
Why does my blood pressure
fluctuate throughout the day?
Is the result the same
if measuring on the
right arm?
Why do I get a different
blood pressure at home
compared to the hospital?
1. Individual blood pressure varies multiple
times everyday. It is also affected by the
way you tie your cuff and your measurement
position, so please take the measurement
under the same conditions.
2.If the person takes medicine, the pressure
will vary more.
3.Wait at least 3 minutes for another
measurement.
The blood pressure is different even
throughout the day due to weather,
emotion, exercise etc. Also, there is
the “white coat” effect, which means
blood pressure usually increases in
clinical settings.
It is ok for both arms, but there will
be some different results for
different people. We suggest you
measure the same arm every time.
What you need to pay attention to
when you measure your blood
pressure at home:
If the cuff is tied properly.
If the cuff is too tight or too loose.
If the cuff is tied on the upper arm.
If you feel anxious.
Taking 2-3 deep breaths before
beginning will be better for
measuring.
Advice: Relax for 4-5 minutes
until you calm down.

33
32
AUTHORISED COMPONENT
Authorised Component
please use the authorised adapter (Not included).
Input: 100-240V, 50-60Hz, 0.2A max
5V 1000 mA
Adapter
Type: BLJ06L050100U-B
Output:
AC adaptor
For more information about our products, please visit
www.kinetikwellbeing.com
Contact Information
EU Declaration of Conformity (DoC)
Hereby, Transtek, declares that this blood pressure monitor is in
compliance with the essential requirements and other relevant
provisions of Radio Equipment Directive 2014/53/EU.
The declaration of conformity may be consulted at
https://usimg.bjyyb.net/sites/54000/54167/20210720090946176.jpg
SPECIFICATIONS
Approx.329 g (Excluding the batteries and cuff)
Digital LCD V.A.124 mm × 76 mm
Approx.174 mm × 100 mm × 41 mm
Type BF applied part
WARNING: No modification of this equipment is allowed.
Display mode
Measurement mode Oscillographic testing mode
Measurement range
Measurement perimeter
of the upper arm
Weight
External dimensions
Mode of operation Continuous operation
Degree of protection
Protection against
ingress of water
Accuracy
Normal working
condition
Storage & transportation
condition
Pressure:
5°C-40°C within ±3 mmHg
Pulse value: ±5%
Rated cuff pressure: 0 mmHg~299 mmHg
Measurement pressure:
SYS: 60 mmHg ~ 230 mmHg
DIA: 40 mmHg ~ 130 mmHg
Pulse value: (40-199) beat/minute
IP20 It means the device could protected against
solid foreign objects of 12.5mm and greater, and
there is no special protection for water or moisture.
Device Classification
Battery Powered Mode:
Internally Powered ME Equipment
AC Adaptor Powered Mode: Class II ME Equipment
A temperature range of: +5°C to +40°C
A relative humidity range of 15% to 90%,
non-condensing, but not requiring a water vapour
partial pressure greater than 50 hPa
An atmospheric pressure range of :
700 hPa to 1060 hPa
Temperature: -20°C to +60°C
A relative humidity range of ≤ 93%, non-condensing,
at a water vapour pressure up to 50 hPa
About 22-42 cm

3534
EMC Guidance
The ME EQUIPMENT or ME SYSTEM is suitable for home healthcare environments.
Warning: Don’t be near the active HF surgical equipment and the RF shielded room of an
ME system for magnetic resonance imaging, where the intensity of EM disturbances is high.
Warning: Use of this equipment adjacent to or stacked with other equipment should be
avoided because it could result in improper operation. If such use is necessary, this
equipment and the other equipment should be observed toverify that they are operating
normally.
Warning: Use of accessories, transducers and cables other than those specified or provided
by the manufacturer of this equipment could result in increased electromagnetic emissions
or decreased electromagnetic immunity of this equipment and result in improper operation.
Warning: Portable RF communications equipment (including peripherals such as antenna
cables and external antennas) should be used no closer than 30 cm (12 inches) to any part
of the equipment TMB-2088 including cables specified by the manufacturer. Otherwise,
degradation of the performance of this equipment could result.
Technical description：
1. All necessary instructions for maintaining BASICSAFETY and ESSENTIALPERFOR-
MANCE with regard to electromagnetic disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration-electromagnetic emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration - electromagnetic emissions
RF emissions
CISPR 11
RF emissions
CISPR 11
Group 1
Class [ B ]
Class A
Comply
Compliance
Harmonic emissions
IEC 61000-3-2
Voltage fluctuations /
flicker emissions
IEC 61000-3-3
Emissions test
EMC GUIDANCE
Table 2
Guidance and manufacturer’s declaration – electromagnetic Immunity
Immunity Test
±8 kV contact
±2 kV, ±4 kV, ±8kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV, ±8kV, ±15 kV air
±2 kV for power supply lines
±1 kV signal input/output
100 kHz repetition frequency
±2 kV for power supply lines
Not applicable
100 kHz repetition frequency
±0.5 kV, ±1kV differential mode
±0.5 kV, ±1kV, ±2kV common mode
30 A/m
50 Hz / 60 Hz
30 A/m
50 Hz / 60 Hz
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
Compliance level
Electrostatic
discharge (ESD)
IEC 61000-4-2
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
Electrical fast
transient/burst
IEC 61000-4-4
Surge
IEC61000-4-5
IEC 60601-1-2
Test level
0% U
T ; 0,5 cycle. At 0°, 45°, 90°, 135°,
180°, 225°, 270° and 315°.
0% U
T ; 1cycle and 70% U T ;
25/30 cycles; Single phase: at 0°.
0% U
T ; 250 / 300 cycle
0% U
T ; 0,5 cycle. At 0°, 45°, 90°, 135°,
180°, 225°, 270° and 315°.
0% U
T ; 1cycle and 70% U T ;
25/30 cycles; Single phase: at 0°.
0% U
T ; 250 / 300 cycle
Conduced RF
IEC61000-4-6
3 V
0,15 MHz – 80 MHz
6V in ISM and amateur radio bands
between 0,15 MHz and 80 MHz
80% AM at 1 kHz
3 V
0,15 MHz – 80 MHz
6V in ISM and amateur radio bands
between 0,15 MHz and 80 MHz
80% AM at 1 kHz
10 V/m
80 MHz – 2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz – 2,7 GHz
80% AM at 1kHz
Radiated RF
IEC61000-4-3
±0.5 kV, ±1kV differential mode
Not applicable
EMC GUIDANCE

36
EMC GUIDANCE
Guidance and manufacturer’s declaration - electromagnetic Immunity
Test
Frequency
(MHz)
3850.3 27
Radiated RF
IEC61000-4-3
(Test
specifications
for
ENCLOSURE
PORT
IMMUNITY to
RF wireless
communica-
tions
equipment)
Band
(MHz)
Service Modulation Maximum
Power
(W)
Distance
(m)
380-390TETRA
400
Pulse
modulation
18Hz
1.8
450430-470
GMRS
460，FRS
460
FM ± 5kHz
deviation
1kHz sine
2 0.3 28
710704-787
745
780
LTE Band
13,17
Pulse
modulation
217Hz
0.2 0.3 9
810
870
930
800-960GSM
800/900,
TETRA 800,
iDEN 820,
CDMA 850,
LTE Band 5
Pulse
modulation
18Hz20.3 28
Compliance
level
(V/m)
27
28
9
28
1720
1845
1970
1700-
1990
GSM 1800;
CDMA 1900;
GSM 1900;
DECT;
LTE Band 1,
3,
4,25; UMTS
Pulse
modulation
217Hz20.3 28 28
20.3 28
24502400-
2570
Bluetooth,
WLAN,
802.11
b/g/n, RFID
2450, LTE
Band 7
Pulse
modulation
217 Hz 28
5240
5500
5785
5100-
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz 0.2 0.3 9 9
Table 3
IEC
60601-1-2
Test Level
(V/m)
