INSTRUCTION ANUAL
COPYRIGHT © 2019 ALL RIGHTS RESERVED BY KI G CA ADA TOOLS I C.
ODEL: 8530LPN
8 GALLON WET•DRY VACUU
06/2019

WARRANTY INFOR ATION
2-YEAR
LIMITED WARRA TY
FOR THIS WET/DRY VACUUM
KING CANADA TOOLS
OFFERS A 2-YEAR LIMITED WARRA TY
FOR O -COMMERCIAL USE.
PROOF OF PURCHASE
Please keep your dated proof of purchase for warranty and servicing purposes.
REPLACE ENT PARTS
Replacement parts for this product are available at our authorized King Canada service centers across Canada. Please use the 10 digit part
numbers listed in this manual for all part orders where applicable.
LI ITED TOOL WARRANTY
King Canada makes every effort to ensure that this product meets high quality and durability standards. King Canada warrants to the original
retail consumer a 2-year limited warranty as of the date the product was purchased at retail and that each product is free from defects in materials.
Warranty does not apply to defects due directly or indirectly to misuse, abuse, normal wear and tear, negligence or accidents, repairs done by
an unauthorized service center, alterations and lack of maintenance. King Canada shall in no event be liable for death, injuries to persons or
property or for incidental, special or consequential damages arising from the use of our products.
To take advantage of this limited warranty, return the product at your expense together with your dated proof of purchase to an authorized King
Canada service center. Contact your retailer or visit our web site at www.kingcanada.com for an updated listing of our authorized service centers.
In cooperation with our authorized service center, King Canada will either repair or replace the product if any part or parts covered under this
warranty which examination proves to be defective in workmanship or material during the warranty period.
NOTE TO USER
This instruction manual is meant to serve as a guide only. Specifications and references are subject to change without prior notice.
ITE S NOT COVERED UNDER WARRANTY
Accessories supplied with this vacuum such as the hose, 10” floor sweep, crevice tool, 30L dust bag, cartridge filter, foam filter and re-usable
filter are not covered under warranty and are available as optional accessories at your nearest King Canada distributor.

I PORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE
USING THIS VACUU . Read and understand this operator’s manual
and all labels on the Wet/Dry Vacuum cleaner before operating. Safety
is a combination of common sense, staying alert and knowing how
your vacuum works. Use this Wet/Dry Vacuum only as described in
this manual. To reduce the risk of personal injury or damage to your
Wet/Dry Vacuum, use only manufacturer recommended accessories.
For Household Use Only.
SAVE THIS ANUAL
WARNING: FOR FUTURE REFERE CE. When using a vacuum,
basic precautions should always be followed including the following:
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR I JURY:
• Do not run vacuum unattended.
• Do not use to pick up flammable or combustible liquids, such as
gasoline, or use in areas where they may be present.
• Do not vacuum, or use this Wet/Dry vacuum near flammable liquids,
gases, or explosive vapors like gasoline or other fuels, lighter fluids,
cleaners, oil-based paints, natural gas, hydrogen, or explosive dusts
like coal dust, magnesium dust, grain dust, or gun powder. Sparks
inside the motor can ignite flammable vapors or dust.
• To reduce the risk of health hazards from vapors or dusts, do not
vacuum toxic materials.
• Do not use or store near hazardous materials.
• Do not pick up anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
• Do not expose to rain. Store indoors.
• If vacuum is not working as it should, has been dropped, damaged,
left outdoors, or dropped into water, return it to a service center.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not use with damaged cord or plug.
• Do not pull or carry by cord, use cord as a handle, close a door on
cord, or pull cord around sharp edges or corners.
• Keep cord away from heated surfaces.
• Do not run the vacuum over cord.
• Do not handle plug or vacuum with wet hands.
• Do not use without dust bag and/or filters in place.
• Do not allow to be used as a toy. Close attention is necessary when
used by or near children.
• To reduce the risk of injury from accidental starting, unplug power
cord before changing or cleaning filter.
• Do not leave vacuum when plugged in. Unplug from outlet when not
in use and before servicing.
• Turn off all controls before unplugging.
• Unplug before connecting or disconnecting hose, or any other
accessories.
• Do not put any object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair, and anything that may reduce air
flow.
• Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.
• Use extra care when cleaning on stairs.
• Use only as described in this manual. Use only manufacturer’s
recommended attachments.
• This vacuum is provided with double insulation. Use only identical
replacement parts. See DOUBLE I SULATIO I STRUCTIO S.
CAUTION: To reduce the risk of injury from moving parts - Unplug
before servicing.
WARNING: To reduce the risk of electric shock - Unplug before cleaning
or servicing.
DOUBLE INSULATION INSTRUCTIONS
This Wet/Dry Vacuum is double insulated, eliminating the need for a
separate grounding system. Use only identical replacement parts.
Read the instructions for Servicing Double Insulated Wet/Dry Vacuum
before servicing. Use this Wet/Dry Vacuum as described in this
manual. Observe the following warnings that appear on the motor
housing of your Wet/Dry Vac.
DOUBLE I SULATED - GROU DI G OT REQUIRED - WHE
SERVICI G USE O LY IDE TICAL REPLACEME T PARTS.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK-DO OT
EXPOSE TO RAI . STORE I DOORS.
WARNING: FOR YOUR OW SAFETY, READ A D U DERSTA D
OPERATOR’S MA UAL. DO OT RU U ATTE DED. DO OT
PICK UP HOT ASHES, COALS, TOXIC, FLAMMABLE OR OTHER
HAZARDOUS MATERIALS. DO OT USE AROU D EXPLOSIVE
LIQUIDS OR VAPORS.
CAUTION: DO OT VACUUM DRYWALL DUST OR FIREPLACE
SOOT OR ASH WITH STA DARD WET/DRY FILTER. THIS TYPE OF
DUST IS VERY FI E WHICH MAY OT BE CAPTURED BY THE
FILTER A D CAUSE DAMAGE TO MOTOR. WHE VACUUMI G
FI E DUST USE A FI E DUST FILTER.
WARNING: SERVICI G OF DOUBLE I SULATED WET/DRY VACUUM
WITH A DOUBLE I SULATED WET/DRY VACUUM, TWO SYSTEMS
OF I SULATIO ARE PROVIDED I STEAD OF GROU DI G. O
GROU DI G MEA S IS PROVIDED O A DOUBLE I SULATED
APPLIA CE, OR SHOULD A MEA S FOR GROU DI G BE
ADDED. SERVICI G A DOUBLE I SULATED WET/DRY VACUUM
REQUIRES EXTREME CARE A D K OWLEDGE OF THE SYSTEM,
A D SHOULD BE DO E O LY BY QUALIFIED SERVICE PERSO -
EL. REPLACEME T PARTS FOR A DOUBLE I SULATED
WET/DRY VACUUM MUST BE IDE TICAL TO THE PARTS THEY
REPLACE. YOUR DOUBLE I SULATED WET/DRY VAC IS MARKED
WITH THE WORDS ‘DOUBLE I SULATED’ A D THE SYMBOL
MAY ALSO BE MARKED O THE APPLIA CE.

GETTING TO KNOW YOUR VACUU ,
ELECTRICAL INFO & SPECIFICATIONS
SPECIFICATIONS
odel ..........................................................................8530LP
Voltage ..............................................................................120V
Horsepower ............................................................4 HP (peak)
Amperage ..............................................................................9A
Phase ........................................................................................1
Hertz ..................................................................................60Hz
Tank size ................................................8 Gallon (US)/30 liters
Air flow ........................................................................135 CFM
Vacuum pressure (inches of water) ................................62.2”
POWER SUPPLY- WARNING: YOUR VACUUM MUST BE
CO ECTED TO A 120V, MI IMUM 15-AMP. BRA CH CIRCUIT.
FAILURE TO CO ECT I THIS WAY CA RESULT I I JURY
FROM SHOCK OR FIRE.
DOUBLE INSULATION
Double insulated tools are equipped with a polarized two-prong plug
(one blade is wider than the other). This plug will fit in a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install a
polarized outlet. Do not alter or change the plug in any way. Double
insulation eliminates the need for three wire grounded power supply
and grounded power cords.
120V OPERATION- As received from the factory, your vacuum is ready
to run for 120V operation. This vacuum is intended for use on a circuit
that has an outlet and a plug which looks like the one illustrated in Fig.1.
EXTENSION CORDS
Improper use of extension cords may cause inefficient operation of your
tool which can result in overheating. Be sure your extension cord is
rated to allow sufficient current flow to the motor. If you are using the
tool outdoors, use an extension cord rated for outdoor use (signified by
“SJW or SJTW” on the jacket).
The extension cord must have a minimum wire size depending on the
amperage of the tool and the length of the extension cord. This size is
determined by its AWG (American Wire Gauge) rating. The smaller the
gauge, the greater the cable’s capacity. The amount of cords used does
not matter: Total length determines the minimum AWG rating. Every
cord must meet the AWG rating. Use the chart in Fig.2 to determine
what AWG rating is required for your situation.
FIGURE 1
POLARIZEDOUTLET
POLARIZED PLUG
1) Cover/motor assembly
2) Cover latch (2)
3) Switch
4) Top carry handle
5) On-board accessory storage
6) Inlet
7) Tank
8) Tank drain cap
9)Foam filter
10) Re-usable filter
11) Cartridge filter
12) 30L Dust bag
13) 2pc. Extension wands
14) Hose
15) 10” floor sweep
16) Crevice tool
ELECTRICAL INFO &
SPECIFICATIONS
GETTING TO KNOW YOUR VACUU
Tool’s
Amperage
Rating
3-6
6-8
8-10
10-12
12-16
Cord Size in A.W.G.
Cord Length in Feet
25 50 100 150
18 16 16 14
18 16 14 12
18 16 14 12
18 16 14 12
14 12 - -
FIGURE 2

UNPACKING & ASSE BLING
YOUR VACUU
ATTENTION! The vacuum accessories are packed inside the vacuum tank.
UNPACKING YOUR VACUU
Remove the entire contents of the carton, please note that most of the accessories are
packed inside the vacuum tank. To access these accessories, undo the 2 latches (A) Fig.3,
remove the tank cover/motor assembly and then remove the accessories inside the tank.
WARNING! DO OT CO ECT THE POWER CORD TO THE POWER SOURCE U TIL THE
FOLLOWI G ASSEMBLY A D SET-UP I STRUCTIO S HAVE BEE DO E.
CASTER WHEEL ASSE BLY
Four caster wheels are included and should be assembled to the bottom of the tank.
1) With the tank cover/motor assembly removed, turn the tank upside down. Insert the caster
wheels (A) Fig.4 into the bottom of the tank as shown.
2) Make sure each caster wheel is pushed down all the way, then secure each caster wheel in
place using the supplied screws and a screwdriver.
TOP HANDLE ASSE BLY
A top carry handle is included and should be assembled to the top of the cover/motor assembly.
1) Place the top handle into position on the cover, please note this handle only fits in one
direction into the handle slots.
2) Make sure the handle (A) Fig.5 is pushed in all the way and secure it into place using the
supplied screws and a screwdriver.
INSTALLING THE CORRECT FILTER AND/OR DUST BAG FOR THE APPLICATION
Before reinstalling the cover/motor assembly on, it is important to determine the desired
cleaning application, wet or dry vacuuming. Each cleaning application requires different filters
and/or dust bag.
When vacuuming dry materials, to ensure proper filtration, the foam filter should be used
when vacuuming coarse materials with low dust for maximum air flow. The re-usable filter can
and should be used together with the foam filter or only install the cartridge filter instead of both
other filters when vacuuming coarse and dusty materials. Place the cover/motor assembly
upside down, slide the foam filter (A) Fig.6 or the cartridge filter over the cage (B). If you
installed the foam filter, then slide the re-usable filter over the foam filter. ow the dust bag (C)
must be installed to the inner portion of the inlet. Fit the dust bag flange over the inner inlet,
taking care not to damage the dust bag.
When vacuuming wet materials, to ensure proper filtration, the foam filter must be installed.
Place the cover/motor assembly upside down, slide the foam filter (A) Fig.6 over the cage (B).
Reposition and secure the cover/motor assembly to the tank with both cover latches.
HOSE, WANDS AND ACCESSORY ASSE BLY
1) Attach the end of the hose (A) Fig.7 to the vacuum inlet (front of the vacuum) and secure the
hose by turning clockwise.
2) Assemble the 2 extension wands together and then attach one end of the extension wand
assembly to the hose.
3) Attach either the floor sweep (B) Fig.7 or the crevice tool to the other end of the extension
wand assembly (C).
FIGURE 3
FIGURE 4
FIGURE 5
FIGURE 6
FIGURE 7

OPERATION
DRY VACUU ING OPERATIONAL STEPS
Before vacuuming dry materials, it is important that you have read and understood the
safety rules in this manual.
1) Unplug the power cord from the power source.
2) Remove the cover/motor assembly and install a clean and dry foam filter. If the vacuuming
operation is extremely dusty, install the re-usable filter over the foam filter or only install the
cartridge filter (A) Fig.9 instead of both other filters. Secure cartridge filter with lock plate (B).
If it is necessary to vacuum dry materials and you have just finished vacuuming wet
materials, the foam or cartridge filter must be completely dried or else they will clog up quickly
and will be difficult to clean. The foam or cartridge filter can be dried quickly by running the
vacuum for 5-10 minutes without the hose installed.
3) Install the disposable dust bag on the inside of the tank to the inner portion of the inlet. Fit the
dust bag flange over the inner inlet, taking care not to damage the dust bag.
4) Reposition and secure the cover/motor assembly to the tank using the 2 side mounted cover
latches.
5) Attach the hose to the inlet on the front of the vacuum.
6) Assemble the 2 extension wands together and then attach one end of the extension wand
assembly to the hose.
7) Attach either the floor sweep or the crevice tool to the other end of the extension wand.
8) Plug the power cord to a power source.
9) Start the vacuum by pushing the On/Off switch to the On position as shown in Fig.10. The On
position is indicated by the international symbol “I” on the switch.
10) Once the vacuuming operation is finished, push the switch to the Off position indicated by
the international symbol “O” on the switch and unplug the power cord from the power source.
11) Remove the cover/motor assembly and lay it aside, being careful not to damage the filters
and dump the tank contents into a suitable waste disposal container. Airborn dust will be
produced when cleaning, wear dust mask!
Warning!
ever use the disposable dust bag, cartridge and re-usable filters for vacuuming wet materials.
When vacuuming fine dust, it will be necessary to clean the foam, re-usable and cartridge filters
at more frequent intervals.
WET VACUU ING OPERATIONAL STEPS
Before vacuuming wet materials, it is important that you have read and understood the
safety rules in this manual.
1) Unplug the power cord from the power source.
2) Remove the cover/motor assembly and install a clean and dry foam filter. If wet vacuuming
under normal conditions (small amounts of liquid pick-up) or when vacuuming large amounts
of liquid, only install the foam filter, see Fig.11. The dust bag can not be used for wet
vacuuming. Make sure the inside of the tank is clean.
3) Reposition and secure the cover/motor assembly to the tank.
4) Attach the hose to the inlet on the front of the vacuum.
5) Assemble the 2 extension wands together and then attach one end of the extension wand
assembly to the hose.
6) Attach either the floor sweep or the crevice tool to the other end of the extension wand
assembly. For wet applications, turn the brush/squeegee assembly around so the squeegee
is facing outwards, this can be done by pressing the 2 snap points at each end of the floor
sweep, the assembly will pop out, flip the assembly around and snap it back into place.
7) Plug the power cord to a power source.
8) Start the vacuum by pushing the On/Off waterproof switch to the On position as shown in
Fig.12. The On position is indicated by the international symbol “I” on the switch.
9) When vacuuming large amounts of liquid, do not completely immerse the nozzle accessory
in the liquid, leave a gap at the top of the nozzle accessory opening to allow air inflow.
10) Once the vacuuming operation is finished, push the switch to the Off position indicated by
the international symbol “O” on the switch and unplug the power cord from the power source.
Warning!
ever use the disposable dust bag, cartridge and re-usable filters for vacuuming wet materials.
The foam filter should be cleaned after each wet vacuuming operation.
Should it become necessary to pick up the vacuum to move it, DO OT pick up the vacuum by
the top handle unless the tank is empty. Do not pull the vacuum by the hose, this may tip the
vacuum over if the wheels are obstructed in any way.
FIGURE 8
FIGURE 10
FIGURE 11
FIGURE 9
FIGURE 12

OPERATION & AINTENANCE
AUTO ATIC SUCTION SHUT-OFF AND E PTYING LIQUID FRO TANK
This section relates to wet vacuuming operations. This vacuum is fitted with an automatic
suction shut-off float cup (A) Fig.14 which floats up when the liquid level increases in the tank,
it then stops the suction action when the tank has reached its maximum capacity of liquid. Make
sure the float cup is clean at all times.
The user will notice an increased motor speed, when this happens;
1) Turn off the vacuum immediately and unplug the power cord from the power source.
2)
3)
Remove the cover/motor assembly and lay it aside, being careful not to damage the filters
and empty the tank contents into a suitable waste disposal container by removing the drain
cap (B) Fig.14 found on the lower front of the tank.
The inside of the tank should be cleaned, also check the foam filter and clean it from the
inside out if necessary.
4) To continue vacuuming wet materials, reposition and secure the cover/motor assembly, plug
the power cord to a power source and proceed.
BLOWERFEATURE
This vacuum can be used as a powerful blower. To use the blower feature, disconnect the end
of the hose and reconnect it to the blower outlet as shown in Fig.15. Turn the vacuum On, your
vacuum is now a blower to clear work tables of debris, blow leaves etc...
STANDARD AND OPTIONAL ACCESSORIES
The following chart lists the standard accessories included and the available optional
accessories for this wet•dry vacuum. Please note that these accessories are not covered under
warranty and are available at your nearest King Canada distributor.
ON-BOARD ACCESSORY STORAGE
When the 10” floor sweep or crevice tool is not in use, they can be stored in the on-board storage
as shown in (A or B) Fig.16.
AINTAINING YOUR VACUU AND ACCESSORIES
Warning! To reduce the risk of injury and electrical shock, unplug the power cord from
the power source. Airborn dust will be produced when cleaning, wear dust mask!
To maintain peak vacuum performance, the cartridge, foam and re-usable filters must be cleaned often.
Filter maintenance- Clean the foam filter and re-usable filter by washing them inside out in a mild soapy water and then rince with clean water.
Allow these filters to dry completely before using.
General aintenance and Inspection- The inside of the tank, hose, extension wands and accessories should be cleaned after every use, this
cleaning should only be done outdoors with the power cord disconnected from the power source. Check the condition of the power cord and
make sure it is not damaged. Also check the condition of the filters for tears and small holes. Do not use filters with tears or small holes, replace
with new filters.
TROUBLESHOOTING
Dust comes from the motor cover-
Place/replace the dust bag if dust bag is missing or damaged.
Reduced efficiency/increased motor speed-
Inlet is block or tank is full- Unblock inlet or empty tank through tank drain.
FIGURE 13
FIGURE 14
FIGURE 16
FIGURE 15
odel
KVAC-1010
KVAC-1040
KVAC-1060
KVAC-1075
KVAC-1083
KVAC-1095
KVAC-1101
KVAC-1103
KVAC-1105
KVAC-1107
KVAC-1111
KVAC-1130
KVAC-1132
KVAC-1145
Description
30L Dust bags- 3pc. kit
Foam Filter- 1pc.
Re-usable Filter- 1pc.
Cartridge Filter- 1pc.
6ft. x 1-1/4” hose
6ft. x 1-1/4” hose extension
1-1/4” Round Brush- 1pc.
1-1/4” Gulper Tool- 1pc.
1-1/4” Crevice Tool- 1pc.
10” x 1-1/4” Floop Sweep- 1pc.
2pc. 1-1/4” extension wand kit
High Efficiency Cartridge Filter
30L High Efficiency Dust bags- 3pc. kit
HEPA Cartridge Filter
Included/Optional
1pc. Included
1pc. Included
1pc. Included
1pc. Included
1pc. Included
Optional
Optional
Optional
1pc. Included
1pc. Included
1 kit Included
Optional
Optional
Optional
Usage
Dry Vacuuming Applications
Wet•Dry Vacuuming Applications
Wet•Dry Vacuuming Applications
Dry Vacuuming Applications
Wet•Dry Vacuuming Applications
Wet•Dry Vacuuming Applications
Upholstery and car interiors
General purpose
General purpose
General purpose-reversible attachment
Wet•Dry Vacuuming Applications
Drywall and fine dust applications
Drywall and fine dust applications
Drywall and fine dust applications
PARTS DIAGRA & PARTS LISTS
Refer to the Parts section of the King Canada web site for the most updated parts diagram and parts list.
