King Technology Aqua Smarte Plus 7700 User manual

1
Aqua Smarte Plus™
Mineral Dispensing System
Model 7700
For Pools up to 25,000 Gallons
w
i
t
h
A
q
uaS
mart
ePlusMin
eralSystem
*
W
A
T
ER
MA
NAGEM
ENTSY
STE
M
Customer Service 800-222-0169
www.kingtechnology.com
System Includes the
Aqua Smarte Plus
Mineral Activator™
Patented Mineral Disinfectant

2
TABLE OF CONTENTS
Aqua Smarte Plus Introduction 3
Swimming Pool Tips 4
Start-up and Operation 5-6
Replacing Aqua Smarte Plus Mineral Activator 7
Using Aqua Smarte Plus Shine, Optimize, MizerMax Pac 8
Using Aqua Smarte Plus CANNONBALL! 9
Troubleshooting 10
Parts List 11
Replacing Control Dial O-Rings 12
Replacing Cap O-Rings and Knobs 12
Winterizing 13
Above Ground Filter Installation 14
Above Ground Base Installation 15
Warranty 16
For information on King Technology’s entire product
line, visit our website at www.kingtechnology.com

3
Welcome to easier pool care courtesy of Aqua Smarte Plus. With Aqua
Smarte Plus, your pool water will look and feel better without a lot
of work or a lot of chlorine. This system+ controls bacteria using a
combination of minerals and reduced chlorine levels – Chlorine lasts
2X longer with Aqua Smarte Plus Mineral System. There are 3 parts to
the Aqua Smarte Plus System: The Above Ground Aqua Smarte Plus
Docking Station, the Aqua Smarte Plus Mineral Activator and the Aqua
Smarte Plus MizerMax Pac!
Aqua
Smarte
Plus™
Part 1
Aqua Smarte Plus
Docking Station™
The water treatment center that
controls the flow of water to each
part of the Aqua Smarte Plus System.
Part 2
Aqua Smarte Plus
Mineral Activator™
Holds the minerals and fits inside the
Docking Station.
For Above Ground Pools
up to 25,000 gallons.
Part 3
Aqua Smarte Plus
MizerMax Pac™
Pre-filled with chlorine tablets and
fits inside Aqua Smarte Plus Mineral
Activator.
Aqua Smarte Plus MizerMax Pac along with the Aqua Smarte Plus Pool Awake! and Aqua Smarte Plus Pool Asleep
are sold separately.
+Aqua Smarte Plus Mineral System consists of the Aqua Smarte minerals silver chloride and carbonate used in conjunction with 0.5 ppm chlorine. The
Aqua Smarte Plus Mineral Activator must be used in conjunction with the Aqua Smarte Plus MizerMax Pac (EPA Reg. No.: 53735-2), an EPA registered
chlorine pool product or a chlorine delivery device.
w
i
t
h
A
q
uaS
mart
ePlusMin
eralSystem
*
W
A
T
ER
MA
NAGEM
ENTSY
STE
M
E
S
T
S
T
R
I
P
S
THE AQUA SMARTE PLUS MINERAL
ACTIVATOR MUST BE REPLACED EVERY
SIX MONTHS OR AFTER ONE POOL
SEASON WHICHEVER IS SHORTER.
C
A
N
NO
NB
A
L
L!
ALL
-OU
T90
-Da
y
A
lg
aePr
ote
ctio
n
CAU
TION
C
A
N
NO
NB
A
L
L!
ALL
-OU
T90
-Da
y
A
lg
aePr
ote
ctio
n
CAU
TION
OPTIMIZE™
E
sta
blish
anIn
itial C
hlori
ne
L
ev
elwit
hPre
ciseFe
edin
g
SHINE“
El
imi
nate
sCon
tamina
nts
for
Cryst
alCle
arWa
ter
SHINE“
El
imi
nate
sCon
tamina
nts
for
Cryst
alCle
arWa
ter
Aqua Smarte Plus
Pool Awake!™ Kit
An easy 3-step pool
opening program that
effectively removes
contaminants, prevents
algae and sets a chorine
residual with precise
dispensing and no
touching chemicals!
Aqua Smarte Plus
Pool Asleep™ Kit
An easy 2-step pool closing
program that effectively
removes contaminants and
prevents algae all winter
with precise dispensing and
no touching chemicals!
OPTIMIZE, SHINE AND CANNONBALL! SHINE AND CANNONBALL!

4
Swimming Pool Tips
Start-up and Yearly Maintenance
1.
Make sure the pool has adequate circulation. The pool
water must completely circulate through the pump and
filter at least 1 to 2 times per day. This usually requires
8 to 12 hours. Check with your dealer for the proper
circulation time for your pool.
2.
3.
Before beginning with any pool care program, you must
first balance your pool water. Take a water sample to your
local pool professional or use a complete test kit that will
test for the following important elements.
If your fill water is high in metals, use a sequestering
agent or metal out product at start-up only before using
the Aqua Smarte Plus Mineral Activator. See your local
dealer for details on using these products and always
follow manufacturers directions carefully.
4. After your pool is up and running
smoothly, continue to test your
water for pH, total alkalinity
and chlorine with Aqua Smarte
Brand Test Strips and maintain
its balance by adding any
necessary adjustment products
(see your dealer for details).
5.
Check the pool’s filter gauge often and periodically clean
filter per the manufacturer’s directions. A dirty filter
will slow the flow of water which could hamper proper
circulation.
Water Balance Guidelines
pH: 7.2 – 7.8
Total Alkalinity: 60 – 120 ppm
Calcium Hardness: 150 – 400
Total Dissolved Solids: <1500
Stabilizer: 20 – 80 ppm
Free Chlorine: 0.5 – 1.0 ppm
T
E
S
T
S
T
R
I
P
S

5
For a 90-day algae protection
guarantee, insert Aqua Smarte
Plus CANNONBALL! into the Aqua
Smarte Plus Mineral Activator in the
Aqua Smarte Plus Docking Station.
(See page 9 for directions.)
Start-up and Operation - Aqua Smarte Plus Mineral Activator now with 25% greater clarifying power for easier start up.
Add a stabilizer or conditioner to the
pool at the beginning of the season if
the stabilizer level is below 20 ppm.
This will prevent chlorine burn off. Follow
manufacturer’s directions carefully.
Install Aqua Smarte Plus Mineral
Activator into the Aqua Smarte Plus
Docking Station. (See page 7 for
directions.)
REPLACE THE AQUA SMARTE PLUS
MINERAL ACTIVATOR EVERY 6 MONTHS
OR AFTER ONE POOL SEASON
WHICHEVER IS SHORTER.
Replace cap and run Aqua Smarte Plus
Docking Station, with Aqua Smarte
Plus Mineral Activator inserted, for 10
minutes at Setting 5.
When chlorine reading is down to
1.0 ppm, which may take a few
days, insert Aqua Smarte Plus
MizerMax Pac. (See page 8 for
directions.)
Create a chlorine residual with Aqua
Smarte Plus Optimize or a chlorine
shock (see page 8 for directions).
THIS STEP IS VERY IMPORTANT TO
START-UP. Always begin with chlorine
in the pool water.
1.
3.
2.
5.
4.
6.
Shock the pool with Aqua Smarte
Plus Shine to rid the water of all
contaminants. (see page 8 for
directions)
Stabilizer
WARNING
If using standard chlorine shocks do not add in or near the skimmer
or into the Aqua Smarte Plus Docking Station as it could damage
equipment, risk potential explosion or discolor your pool surface.
WATER MANAGEMENT SYSTEM

6
Start-up and Operation
Set control dial by matching up the parameters of your pool on the chart below. THIS IS A STARTING POINT ONLY and may
need to be adjusted to fit your individual pool needs. See #8 below for directions. IMPORTANT: Pump run times less than
8 hours could result in under chlorination due to inadequate flow through the System.
7.
For the first week test the pool water daily
for free chlorine with Aqua Smarte Brand
Test Strips to ensure correct dial setting.
Continue to test weekly throughout the
season.
8.
After each testing, adjust the dial
up by 1/2 increment if the free
chlorine reading has dropped
below 0.5 ppm or adjust down by
1/2 increment if the reading has
risen above 1.0 ppm. Continue
this process each day until the free
chlorine reading stabilizes to at
least 0.5 ppm.
Remember to adjust dial by 1/2 increments only in
order to prevent over chlorination which may bleach pool
surfaces.
Shock pool every two weeks or as needed
to maintain water quality. Follow label
directions on the shock treatment used.
6.
Set dial to Setting 5. Maintain a
minimum chlorine reading of 0.5
ppm with a chlorine delivery device
or hand feeding.
7. Shock pool every two weeks or as needed
to maintain water quality. Follow label
directions on the shock treatment used.
If using another means of chlorine support, follow
steps 1-5 on page 5 then continue below.
Find your starting dial setting by matching up the
parameters of your pool on the above chart. An above
ground pool with approximately 12,000 gallons with a 1
horse pump running 12 hours a day would require a starting
setting of 4.5. See example at right.
* – Bypass installation recommended. RECOMMENDED FLOW RATE: 20-60 gpm
NR – This pump size is not recommended for this size pool. Most common pool sizes
9.
WARNING
Do not add shock in or near the skimmer or
into the Aqua Smarte Plus Docking Station
as it could damage equipment, risk potential
explosion or discolor your pool surface.
WARNING
Do not add shock in or near the skimmer
or into the Aqua Smarte Plus Docking
Station as it could damage equipment, risk
potential explosion or discolor your pool
surface.
Above Ground
POOL SIZE
Gallons Diameter
8 HOUR PUMP RUN TIME 12 HOUR PUMP RUN TIME 24 HOUR PUMP RUN TIME
PUMP SIZE
1/2 hp 3/4 hp 1 hp 1 1/2 hp
PUMP SIZE
1/2 hp 3/4 hp 1 hp 1 1/2 hp
PUMP SIZE
1/2 hp 3/4 hp 1 hp 1 1/2 hp
7,000 (18’) 5.0 4.5 4.0 3.5 4.5 4.0 3.0 5.0* 3.5 3.0 2.5 4.0*
9,000 (21’) 5.5 5.0 4.5 4.0 5.0 4.5 4.0 5.5* 4.0 3.5 3.0 4.5*
12,000 (24’) 6.0 5.5 5.0 4.5 5.5 5.0 4.5 4.0 4.5 4.0 3.5 5.0*
15,000 NR 6.0 5.5 5.0 6.0 5.5 5.0 4.5 5.0 4.5 4.0 3.5
20,000 NR NR 6.0 5.5 NR 6.0 5.5 5.0 5.5 5.0 4.5 4.0
Above Ground
POOL SIZE
Gallons Diameter
8 HOUR PUMP RUN TIME
12 HOUR PUMP RUN TIME
PUMP SIZE
1/2 hp 3/4 hp 1 hp 1 1/2 hp
PUMP SIZE
1/2 hp 3/4 hp 1 hp 1 1/2 hp
7,000 (18’) 5.0 4.5 4.0 3.5 4.5 4.0 3.0 5.0*
9,000 (21’) 5.5 5.0 4.5 4.0 5.0 4.5 4.0 5.5*
12,000 (24’) 6.0 5.5 5.0 4.5 5.5 5.0 4.5 4.0
15,000 NR 6.0 5.5 5.0 6.0 5.5 5.0 4.5
20,000 NR NR 6.0 5.5 NR 6.0 5.5 5.0
T
E
S
T
S
T
R
I
P
S

7
Replacing an Aqua Smarte Plus Mineral Activator™
(Aqua Smarte Plus Mineral Activator MUST be Replaced Every Season)
1.
Check the top of the box and back label of product to make
sure you have the correct Aqua Smarte Plus Mineral Activator
to fit your Aqua Smarte Plus Docking Station.
THE AQUA SMARTE PLUS MINERAL ACTIVATOR MUST
BE REPLACED EVERY 6 MONTHS OR AFTER ONE POOL
SEASON WHICHEVER IS SHORTER.
IMPORTANT: Remove and read the
information card.
Please note: Complete instructions for
inserting a Aqua Smarte Plus Mineral
Activator, and all other Aqua Smarte Plus
products are included inside the Aqua
Smarte Plus Mineral Activator.
WARNING
Use ONLY the factory recommended Aqua Smarte Plus
replacement products. DO NOT USE bulk chemical tablets
in the Aqua Smarte Plus Docking Station or put anything
inside the Aqua Smarte Plus Docking Station other than
the appropriate Aqua Smarte Plus products as directed in
the product instructions. Use of any other product could
result in damage to pool equipment or surface, unsafe
pool conditions, fire or explosion. Warranty will be VOID if
the correct Aqua Smarte Plus products are not used.
2.
3.
Turn off pump and turn dial
to Setting 0. This reduces
the flow of water into the
unit when the cap is open.
4.
Open cap. Stand back
to avoid inhaling chlorine
fumes from the the Aqua
Smarte Plus MizerMax Pac.
5.
Find slot on side of
the Aqua Smarte
Plus Mineral Activator
and line up with
fin inside the Aqua
Smarte Plus Docking
Station. Lower the
Aqua Smarte Plus
Mineral Activator into
the Aqua Smarte
Plus Docking Station
until secure.
6.
Series 7700 (Order #01-13-7712)
NOW FITS THE FOLLOWING SYSTEMS:
Aqua Smarte Models 5700, 6700 and 7700
Mark your calendar for the six month replacement of the Aqua
Smarte Plus Mineral Activator. Once wetted, the time-released
mineral coating of this product is effective up to 6 consecutive
months or one pool season whichever is shorter. After that time
even if you hear the spent media inside it is no longer effective
and must be replaced.
7.
SLOT IN
MINERAL
ACTIVATOR
FIN INSIDE
OF DOCKING
STATION
L
E
S
S
W
O
R
K
•
M
O
R
E
F
U
N
!
T
E
S
T
S
T
R
I
P
S

8
Replace cap by hand only.
DO NOT OVER TIGHTEN.
Line up the small leg of the pac
with the small opening in the Aqua
Smarte Plus Mineral Activator
and the large leg with the large
opening. Lower pac into the Aqua
Smarte Plus Mineral Activator until
secure.
COLORED
CAPS
Turn pac over and shake slightly until
ingredients fall into tower areas.
To remove colored caps, grab onto
the lip of one cap with a pliers and
pull up until cap releases. Repeat
the process for the other cap.
1.
2.
3.
4.
Run the pump and filter for each pac according to the
directions on the product label. Remove from the Aqua
Smarte Plus Docking Station when empty and discard or
offer for recycling.
5.
Replacing Aqua Smarte Plus Shine™, Aqua Smarte Plus Optimize™
or Aqua Smarte Plus MizerMax™ Pac
PAC
TOWERS
PAC
TOWERS
PAC
Aqua Smarte
Plus Mineral
Activator
Avoid sparks, open flame or smoking when handling Aqua Smarte
Plus Shine, Aqua Smarte Plus Optimize or Aqua Smarte MizerMax Pac.
Aqua Smarte Plus Shine is a one time start-up product used to rid the water
of all contaminants. Aqua Smarte Plus Optimize - also used at start up, sets
the chlorine residual to help find the proper dial setting for maintaining up to
50%* less chlorine while using the Aqua Smarte Plus MizerMax Pacs (EPA
Reg. No.: 53735-2). All three products sold separately.
WARNING
Aqua Smarte
Plus Shine
Aqua Smarte
Plus Optimize
Aqua Smarte Plus
MizerMax Pac

9
Using Aqua Smarte Plus CANNONBALL! for an 90-Day Algae Protection Guarantee
1.
I f you are not using a Aqua Smarte Plus CANNONBALL! proceed
to inserting Aqua Smarte Plus MizerMax Pac. See Aqua Smarte
Plus CANNONBALL! product labeling for complete directions for
use (EPA Reg. No. 53735-9).
For a preventive dose add:
•One CANNONBALL! Pac for pools up to 15,000 gallons.
•Two CANNONBALL! Pacs for pools between 15,000 and 30,000 gallons.
*NOTE: Wait 24 hours after shocking before using this product. Avoid using other chemicals until this product has been circulated
(filtered) for at least 24 hours.
Remove cap from the
Aqua Smarte Plus
CANNONBALL! without
removing seal.
Insert upside down into
center of Aqua Smarte Plus
Mineral Activator pushing
down firmly on key to
puncture seal.
Replace cap by hand only.
DO NOT OVER TIGHTEN.
Turn control dial on
Docking Station to
Setting 5.
2.
3.
4.
5. Turn pump on for 90 minutes
allowing Aqua Smarte Plus
CANNONBALL! to circulate
through pool.
6. To remove Aqua Smarte Plus
CANNONBALL!, turn pump off.
Turn dial to Setting 0.
7. Remove Aqua Smarte Plus
Docking Station cap.
8. Lift Aqua Smarte Plus
CANNONBALL! up and allow
any water in the container to
drain through the Aqua Smarte
Plus Docking Station before
discarding in trash.
NOTE: If water shows more
than a hint of blue inside the
Aqua Smarte Plus Docking
Station, replace the the Aqua
Smarte Plus Docking Station
cap, turn dial to Setting 5 and
run the pump for one minute.
14a. If pool size requires
additional Aqua Smarte Plus
CANNONBALL!, repeat steps
1-8.
14b. When water is clear
in the Aqua Smarte Plus
Docking Station, proceed to
inserting the Aqua Smarte Plus
MizerMax Pac.

10
1.
3.
4.
5.
2.
Troubleshooting
1. Make sure your filtration
system is working properly
(i.e. clean filter, skimmer and
pump basket).
2. Make sure circulation time
is adequate – increase pump
time if not.
3. Make sure the pool is
properly balanced (see page 4).
4. Shock the water to
eliminate build up of any
organic matter.
5. Make sure pool has a
free chlorine reading of
0.5 to 1.0 ppm.
6. Check with your dealer
for more information.
1. Metals in the fill water may
have been oxidized. Have the
pool tested. Shock the pool
and clean the filter until water
clarity returns.
2. Algae may be trying to
form – shock the pool,
increase circulation time if
needed and clean the filter.
3. Check with your dealer for
more information.
1. Use a nonmetallic (polyquat)
algaecide per the directions on
the bottle and brush the sides
of the pool often.
2. Clean the filter and shock
the pool with chlorine daily
until water clarity returns.
3. Check with your dealer for
more information.
1. If you are unable to
maintain 0.5 to 1.0 ppm,
first make sure there are
chlorine tablets in the tower
areas of the Aqua Smarte
Plus MizerMax Pac and it
is installed properly. If a
correction was made, test
the water in 24 hours.
2. If still low, turn the dial up
one setting and test the
water again in 24 hours.
Continue raising the setting
by one increment each day
until the proper reading is
achieved.
3. Shock the pool if the
reading has been lower than
0.5 ppm for more than one
day.
4. Make sure pump run time
is at least 6 hours on high
speed (40 gpm or higher) or
if not, bleed the air from the
back knob each time cap is
open.
5. Contact your dealer to have
your back pressure tested to
ensure it is at least 4 psi.
6. Check for a suction side
leak by looking for air bubbles
in your pump basket or at
the return jet. Contact dealer
for help in correcting this
situation.
7. Contact King Technology’s
Customer Service Department
at 800-222-0169.
1. If the chlorine reading is
over 3.0 ppm, remove the
Aqua Smarte Plus MizerMax
Pac from the Aqua Smarte
Plus Mineral Activator and
test the water daily until the
reading is down to 1.0 ppm.
2. Reinsert the Aqua Smarte
Plus MizerMax Pac, lower the
dial one setting and test the
water again in 24 hours. If
the reading has risen, lower
the dial one setting again.
Continue this process until
proper reading is achieved.
3. If over-chlorinating at the
lowest possible setting,
consider decreasing the
circulation time. Depending
on your pump size, you may
be circulating the water more
than is necessary.
4. Contact your dealer to
have your back pressure
tested. If over 8 psi consider
a larger eye-ball fitting in the
return jet.
5. Check to see if the
pressure relief valve is loose
or missing and replace.
It is a clear plastic piece
approximately 1” long
installed inside near the
base. If loose or missing, it
can provide another avenue
for water to reach the
chlorine.
6. Contact King Technology’s
Customer Service Department
at 800-222-0169.
What do I do
if I am over
chlorinating with
the Aqua Smarte
Plus MizerMax
Pac?
What do I do
if I am under
chlorinating with
the Aqua Smarte
Plus MizerMax
Pac?
What do I do
if algae forms in or
on my pool?
What do I do
if the water turns
color?
What do I do
if the water looks
cloudy?
Problem Remedy
For more in-depth troubleshooting, go to www.kingtechnology.com

11
Parts List Model 7700
Included with Aqua Smarte Plus Docking Station 7700
REF. # DESCRIPTION QTY. INCLUDED
1 & 2 Cap w/O-Ring 1
3 Body 1
4 Pressure Relief Valve 1
5, 6, 7 Control Dial with O-Rings
and Locking Pin 1
8 & 9 Knob with O-Ring 2
10 Silicone Lubricant 1
11 Nipple Kit 1
12 Mounting Base 1
Replacement parts for Aqua Smarte Plus Docking Station 7700
REF. # PART NO. DESCRIPTION
1 & 2 01-22-1418 Cap w/O-Ring
2 01-22-1920 Cap O-Ring
4 01-22-9480 Pressure Relief Valve
5, 6, 7 01-22-1443 Control Dial with O-Rings
and Locking Pin
6 01-22-1450 Control Dial O-Ring Set
8 & 9 01-22-9940 Knob with O-Ring
10 01-22-9971 Silicone Lubricant
11 01-22-1710 Nipple Kit
12 01-22-1485 Mounting Base

12
S
IL
I
C
O
N
E
L
U
B
R
I
C
A
N
T
Replacing Cap O-Ring
Replacing Knobs
C
OP
Y
C
OP
Y
C
O
PY
C
O
P
Y
x
xxx
x
S
L
I
CO N
E
L
U
B
R
I
C
A
N
T
Back of
Aqua
Smarte
Plus
Docking
Station
Front of
Aqua
Smarte
Plus
Docking
Station
1.
2.
3.
4.
5.
1.
2.
3.
Replacing the Control Dial O-Rings
Center of locking pin
Aqua Smarte Plus Docking Station Maintenance
In the back of the Aqua
Smarte Plus Docking Station
depress center of locking pin
with a finger and pull pin out
of dial.
Turn control dial back and
forth as you pull it out of the
housing.
Replace both o-rings. Apply
silicone lubricant that came
with your Aqua Smarte Plus
Docking Station on o-rings.
Carefully insert control dial
back into housing.
Replace locking pin by pushing
it through the slots on the dial
until it locks into place.
Hold cap in front of you
upside down with the o-ring
groove facing up. Place
one end of o-ring into cap
groove at the point closest
to you. Hold o-ring down
with the thumb and index
finger of one hand.
Take hold of the far end of
the o-ring with the thumb
and index finger of the
other hand. Roll o-ring
slightly back towards you
as you stretch the o-ring
into the remainder of the
cap groove.
Lubricate o-ring often with
silicone lubricant that came
with your Aqua Smarte
Plus Docking Station. DO
NOT USE petroleum based
lubricants.
To replace, simply unscrew
old knob and replace with
the new one.

13
Winterizing
1.
3.
4.
5.
2.
6.
Turn pump off and turn dial
to Setting 0.
Remove cap.
Unscrew knob from the
front of Aqua Smarte Plus
Docking Station. Allow all
water to drain.
If Aqua Smarte Plus MizerMax
Pac still contains chlorine,
wrap in plastic bag and store
in shed or cool well-ventilated
location away from children,
pets, cars, motorcycles or
anything metal that can rust,
pit, etc. Make sure Aqua
Smarte Plus MizerMax Pac is
away from open flame.
Remove the Aqua Smarte Plus
Mineral Activator and discard
in trash. Even if you hear spent
minerals inside, it is no longer
effective.
Replace the cap and
knob loosely.
WATER MANAGEMENT SYSTEM

14
HOSE ADAPTER
TOOLS NEEDED
Screwdriver
Pipe Wrench
INCLUDED WITH Aqua
Smarte Plus Docking
Station
Pipe Thread Tape
or Sealant
One 6” X 1 1/2” TBE
PVC Nipple
MATERIALS NEEDED
One Hose Adapter
1 1/2” X 1 1/2” X 1
1/4”
One Section of
1 1/2” Flex Hose
(provided with filter)
One
Hose Clamp
RECOMMENDED
Corrosion Resistant
Check Valve
Above Ground, Filter Installation
Apply pipe thread tape or
sealant to each threaded
end of nipple.
Screw one end of nipple
into the filter return.
1. 2.
Tighten turning 1 to 2
revolutions with wrench.
DO NOT OVER TIGHTEN.
Screw either side of
the Aqua Smarte Plus
Docking Station on to
open nipple end until
upright and secure.
Apply pipe thread tape or
sealant to threaded end
of hose adapter.
3.
4.
Screw adapter into the other
side of the Aqua Smarte
Plus Docking Station.
Hand tighten. Finish
tightening by turning 1 to 2
revolutions with wrench.
DO NOT OVER TIGHTEN.
5.
6.
Attach return section of hose to
the adapter with clamp. Tighten
clamp with screwdriver.
7.
If using a Aqua Smarte Plus
MizerMax Pac, installing a
corrosion resistant check valve
is recommended.

15
HOSE
CLAMP
HOSE
ADAPTER
HOSE
CLAMP
HOSE
ADAPTER
TO POOL
1 1/2" OR 1 1/4"
FLEX HOSE
1 1/2" X 1 1/2" X 1 1/4"
HOSE ADAPTER
HOSE
CLAMP
FILTER &
PUMP
TOOLS NEEDED
Screwdriver
Pipe Wrench
Materials Needed
Pipe Thread
Tape
or Sealant
One 6” X 1 1/2” TBE
PVC Nipple
Two Sections
of 1 1/2” Flex Hose (one
provided with filter)
Two
Hose Clamps
Recommended
Corrosion Resistant
Check Valve
10 X 1 1/4” Phillips
Pan Head Screws with
Washers
Option
1 1/2” Male Adapter
(slip x MPT)
or
2” Female Adapter
(slip x FPT)
When installing with hard
PVC pipe, use either a
female adapter on the
outside port threads or
a male adapter on the
inside port threads.
Apply pipe thread tape or
sealant to the threaded end of
both hose adapters.
1.
The Aqua Smarte Plus Docking Station should
always be installed between the filter and pool
(or between heater and pool if applicable).
Above Ground, Base Installation
Screw adapters into each end of the
Aqua Smarte Plus Docking Station.
Hand tighten. Finish tightening by
turning 1 to 2 revolutions with wrench.
DO NOT OVER TIGHTEN.
2.
Attach the filter section of flex hose to one hose adapter
and the return section of flex hose to the other hose
adapter with clamps and tighten with screwdriver. Bi-flow
valve design allows water flow in either direction.
3.
If using a Aqua Smarte Plus MizerMax Pac
installing a corrosion resistant check valve is
recommended.
4. For better stability, Aqua
Smarte Plus Docking Station
may be mounted on a base
using Phillips pan head screws.
One in front and two in back.
5.
TO POOL
PUMP
FILTER
• Never install Aqua Smarte Plus
before the heater.
• Any additional sanitizing equipment
that is installed with Aqua Smarte Plus
must be installed after Aqua Smarte
Plus (never before) on the return line to
the pool.
WARNING

16
Aqua Smarte Plus™ Docking Station™ Two-Year Limited Warranty
King Technology, Inc. warrants to the original purchaser this unit
will be free from any defects in workmanship and/or material, for
a period of two (2) years from the date of original purchase. This
warrantycoversbody,capandcontroldial,butspecificallyexcludes
o-rings. King Technology at its option may replace any defective
parts or the entire unit without charge after it is determined
what is needed to correct any deficiency. Replacement parts
with the exception of o-rings are warranted for the remainder
of the original warranty. To extend the limited warranty from two
years to ten years, simply complete the warranty card that came
with your unit and return it to King Technology within 30 days of
purchase and installation.
1. To obtain warranty service, you must deliver the unit to King
Technology or its nearest authorized dealer. Shipping expenses
are the purchaser’s responsibility. The name of the nearest
authorized dealer can be obtained by writing or calling King
Technology at the address and telephone number provided
below. Proof of purchase is required when requesting warranty
service. Purchaser must present the sales receipt or other
documentation verifying proof of purchase.
2. This warranty does not cover defects caused by:
Modification, alteration, repair or service of the unit contrary
to the accompanying instructions; physical abuse to or misuse
of the product or operation or installation in a manner contrary
to the accompanying instructions. This warranty also excludes
all costs arising from the installation, adjustment, removal or
replacement of defective units or parts. This warranty also
excludes any and all claims arising out of the chemicals used
in the product or their characteristics.
3. CAUTION - Read carefully – Failure to follow these
instructions will void the warranty. Do not add shock in or
near skimmer.
A. This unit is not designed for shock treatment of pools.
See your pool dealer or distributor for further information
concerning shock treatments.
B. Control dial settings higher than needed can result in
excess sanitizers being discharged into the pool. If the
sanitizer level goes unmonitored, it can result in bleaching or
discoloration of areas around the pool inlet or in some cases
bleaching or discoloration of the entire pool liner or paint.
C. Excess trichlor in the pool can create health hazards to
bathers. Consult each chemical manufacturer’s warnings and
cautions for specifics.
D. Misuse or failure to use the proper Aqua Smarte Plus
Mineral Activator and Aqua Smarte Plus MizerMax Pac
may cause damage to equipment or personal injury. This
warranty will be null and void, if this unit is not used with the
recommended Aqua Smarte Plus Mineral Activator and Aqua
Smarte Plus MizerMax Pac.
4. This warranty is the exclusive warranty for the Aqua Smarte
Plus Docking Station. This warranty is not transferable.
KING TECHNOLOGY MAKES NO REPRESENTATION OR
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, AS TO
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
OR ANY OTHER MATTER CONCERNING THE AQUA SMARTE
PLUS DOCKING STATION. Any express warranty not provided
herein, and any remedy for breach of contract but which for
this provision might arise by implication or operation of law
is hereby excluded and disclaimed. THE EXCLUSIVE REMEDY
FOR ANY CUSTOMER IS THE REPAIR OR REPLACEMENT
OF THE UNIT, AND THE RECOVERY OF DAMAGES WILL NOT
EXCEED THE PURCHASE PRICE OF THE UNIT. IN NO EVENT
WILL KING TECHNOLOGY BE LIABLE FOR ANY INCIDENTAL,
CONSEQUENTIAL, SPECIAL OR PUNITIVE DAMAGES FROM ANY
CAUSE.
5. Under no circumstance shall King Technology be liable to
purchaser or any other person for any damage or loss incurred
because of any chemicals used in the product or their physical
characteristics, or interruption of service of the product, or
any resulting special, incidental or consequential damages or
losses. Some states do not allow the exclusion or limitation of
incidental consequential damages, so the above limitation or
exclusion may not apply to you.
Manufactured by: KING TECHNOLOGY, INC.
530 11th Avenue South, Hopkins, MN 55343 U.S.A.
952-933-6118 • 800-222-0169 • FAX [phone]
www.kingtechnology.com
Made in U.S.A.
U.S. Patents D540,906; D551,971; 6,190,547; 6,210,566;
6,217,892; 6,383,507; 6,544,415; 6,551,609; 6,652,871;
7,604,018 and other U.S. and Foreign patents pending.
20-48-0153E
553091143R?N
