KING WATER FILTRATION KW-ECOX 1235 User manual

ECO-X
7-Stage Non Backwashing
Municipal Water Treatment System
O W N E R ' S M A N U A L
M O D E L S : K W - E C O X
1 2 3 5 / 1 0 5 4 / 1 2 5 2

TABLE OF CONTENTS
K I N G W A T E R F I L T R A T I O N
K W - E C O X - 1 2 3 5 / 1 0 5 4 / 1 2 5 2 A L L - I N - O N E
W H O L E H O U S E W A T E R F I L T R A T I O N A N D C O N D I T I O N I N G S Y S T E M
Table of Contents
Important Information
Product Specifications and Operation Parameters
Water Supply Compatibility
Parts List
How to Properly Level Your ECO-X System
Installation Preparation
Bypass Valve Installation
Installation Overview
Water Filter - Media Soaking Procedure
Water Filter - Water System Flushing Procedure
Installation Procedures
Bypass Valve Fittings
Bypass Valve Settings
Post Installation "TO DO's
Clean your Hot Water Heater
Expectations
Tips for Maximum Performance and FYI'S
Testing for Water Hardness and TDS
Does the Eco-X remove TDS from water?
Troubleshooting
Shipping Policy
Return Policy
Return Procedure
Warranty
Warranty Registration Form
Claim Information
2
3
4
4
5
6
7
7
7
8
9-10
11
11
12
13
13
14-15
16
17
18
19
20
21
22
23
24
24
2

• A pressure regulator, such as a slow-flow regulator, must be installed in front of the unit's water inlet
if the water pressure (including any possible pressure spikes) could exceed the most common operating
water pressure range of 35-70 psi. Failure to comply will void the warranty. King Water
Filtration™ assumes no liability for damage caused by excessive water pressure.
• Check all the connections (i.e. water hose/tubing, connections/fittings) to ensure proper connection
and to avoid leaks.
• After prolonged periods of non-use (such as during a vacation), it is recommended that the system be
flushed thoroughly by running the water in your home from the bath tub for approximately 15 minutes.
• Check plumbing inlet and outlet to ensure the proper flow of water through the system.
• Do not use the systems on the cold water supply line with more than 70 psi.
• Do not use the system where water is microbiologically unsafe or with water of known quality.
• All water treatment installations must conform to local plumbing, electrical and sanitation codes.
• These codes are established for your protection. Check with your local public works department for
current plumbing codes.
• Installation errors can cause property damage. King Water Filtration® assumes no liability
whatsoever for systems improperly installed or those installed by someone other than a
licensed plumber or qualified contractor.
• The contaminants or other substances removed or reduced by the selected filtration system(s) are not
necessarily in your water. Ask your local water municipality for a copy of their water analysis or have
your water tested by a reputable water lab.
• The King Municipal Filtration system not only removes harmful contaminants, but will also reduce
harmful scale buildup, extend the life of your plumbing and appliances and most importantly provide
pure alkaline quality drinking water for the needs of you and your family from every faucet
in your home.
IMPORTANT INFORMATION
Installation must be made within an area protected from the elements and freezing.
The unit must be protected from rain, dust, flooding, snow, freezing, and direct
sunlight (the system's exposure to direct sunlight may cause algae growth).
Failure to comply will void the warranty.
3

*** WARNING:
When installed onto a metal (conductive) piping system (such as copper or galvanized plumbing), the plastic materials used
within your water treatment system may disrupt the continuity of the piping system. As a result, improperly grounded
equipment or appliances downstream or potential galvanic activity in the plumbing system can no longer ground properly due
to the plumbing system not being contiguous. Some homes are built to accommodate building codes that require electrical
equipment to be grounded through the plumbing system. Before the system is put into service, a bypass made of the same
material as the existing piping or a grounded "jumper wire" that creates a bridge will need to be installed to restore continuity
to the plumbing system ensuring proper grounding, as per building code.
***CAUTION:
When installing water treatment equipment in applications that use well water, the water treatment equipment should be
installed AFTER the pressure tank and booster pump.
If you have any questions, please call customer service at 855-957-2166.
Carefully read this manual and determine the best location for installation and familiarize yourself with all the
components before proceeding with installation.
Verify all applicable plumbing, building, and electrical codes for installation compliance. It is recommended
that equipment be installed by a licensed plumbing contractor.
It is recommended for installation of the system to be on the Main Water Supply. Water softener loop
installations most often WILL NOT treat kitchen cold water feed.
For use with municipally treated potable water supplies
Water must be free of iron, manganese, and bacteria. These contaminants are often found in well water. If
any of the aforementioned contaminants are in your water supply, please call a King Water Specialist at 855-
957-2166 as additional treatment options may be necessary.
If you are using on a well water application, it is imperative that you perform a comprehensive water
treatment analysis before installation to ensure system compatibility. Call King Water Customer Support with
any questions at 855- 957-2166.
Important Information
Water Supply Compatibility
ECOX-1252
15 GPM
18 GPM
20 PSI
80 PSI
32°F - 120°F
6.5 to 8.5
ECOX-1054
10 GPM
12 GPM
20 PSI
80 PSI
32°F - 120°F
6.5 to 8.5
ECOX-1235
10 GPM
12 GPM
20 PSI
80 PSI
32°F - 120°F
6.5 to 8.5
Specification Description
Rated Service Flow Rate
Peak Flow Rate
Min Water Pressure
Max Water Pressure
Operating Temperatures
Recommended pH Range
PRODUCT SPECIFICATIONS AND OPERATION PARAMETERS
4

MODELS:
KW-ECOX-1235 / 1054 / 1252
Note:
Images above are for representation purposes only and are not intended to be depicted to scale. Additional fittings,
materials and supplies will likely be needed for your installation.
***PLEASE TAKE NOTE:
Valve head on top of tank may loosen during transit. Please ensure valve head is properly
seated onto tank by rotating clockwise, Hand-Tight, ensuring o-ring is fully seated between
valve head and tank.
Please ensure valve head is securely seated by HAND ONLY, DO NOT USE TOOLS!
PARTS LIST
Note: King Water supplies the following items below:
Table 1: Parts List
5

Note that the black base of the filtration tank is not permanently attached to the rest of the tank.
If your tank appears to be crooked, the base has likely been knocked out of alignment during
shipping.
This can be corrected by picking the tank up and tapping it firmly on the floor on the high side to
help level it out. A few light taps on the floor will generally straighten it out and make it plumb to
the floor.
There will be a small amount of “play” in the bypass valve assembly to allow for minor
misalignments. This is normal and will prevent undue stress on the components. Make sure that
the tank sits as plumb as possible, taking note that your floor may not be level, but your system
should be placed as vertical as possible using the adjustable base.
If the tank is leaning to one side, you can lift the tank up approx. 4"- 6" inches and tap the high
side on the ground. The base is an adjustable fitting that is designed to move a little to ensure the
tank remains vertical, even on surfaces that may not be completely level.
HOW TO PROPERLY LEVEL THE ECO-X SYSTEM
It is important to do this step BEFORE you fill the tank with water as it
will be very difficult to lift once it i s full.
6

The Bypass Valve comes assembled and ready to install with the O-Rings, Split Rings, and Quick Connect
Fittings in place. Apply food grade silicone grease to the o-rings and push the Bypass Valve all the way
into the valve head, hand-tighten the Quick Connect Toolless Connectors until they are fully seated and
secured to the bypass valve, (Use a firm grasp with both hands to ensure secure fitment). The bypass
valve should now be properly attached for the next step of the installation process.
The bypass valve included with this system are intended to be used with various system types. This may
result in the arrows on the bypass valve pointing in a different orientation that what is shown. If the
arrows on your bypass valve do not match the diagram above, remove the knobs by pulling them straight
up, rotate them 180° to match the diagram, and push them back down into place so the face the desired
orientation.
INSTALLATION PREPARATION
Bypass Valve Installation
Installation Overview Figure 2
7

The carbon should be soaked for 48 hours prior to flushing.
Here are the steps:
1. Install the included "Hose Bib Purge Kit w/ flow adaptor" as shown on the “UPFLOW or
INLET” side of the bypass assembly.
2. Connect a garden hose to the fitting and VERY slowly fill the tank with water until all
the air is purged out and water starts coming out of the INLET side of the bypass.
3. When water comes out of the tank “DOWNFLOW INLET” side, turn off the water
immediately. (See Figure 3)
Allow the carbon to soak for 48 hours prior to flushing.
WATER FILTER- MEDIA SOAKING PROCEDURE
VERY IMPORTANT STEP
8

DO NOT Flush the system until it has been soaking for a
minimum of 48 hours as instructed in previous page.
Perform the following in an area where running water can flow on the
the ground, or into a drain, for an extended period.
WATER SYSTEM FLUSHING PROCEDURE
1. Attach the garden hose to the Hose Bib Adaptor on the OUTLET side of the Bypass
Valve.
2. Slowly turn on the water supply, until it is all the way open and water is flowing out of
the "INLET" Side of the bypass valve.
3. Allow water to run for a full 30 minutes to expel any loose media fines or debris. IF
after 30 minutes the water is still not clear, then keep water running until water runs clear,
No longer than 60 minutes total.
4. Once water has started running clear, turn off the water supply.
Continue Steps 5-9 On Next Page
9

WATER SYSTEM FLUSHING PROCEDURE
5. Remove the Hose Bib Assembly from the OUTLET side of the Bypass Valve and attach
it to the INLET side of the Bypass Valve. (By doing this we will be flushing the media
downward, resetting the systems media and preparing it for operation).
6. Now you can SLOWLY open the hose spigot until it is fully open.
7. Continue running the water through the outlet side for for 6-8 minutes, ensuring
water flow is clear and media is properly reset.
8. Now turn off the water supply to the system.
9. Remove the Hose and Bib Adaptor from the Bypass Valve and locate system to its
installation location.
