EN ORIGINAL INSTRUCTIONS
IMPORTANT - These instructions are for your safety.
Please read through them thoroughly prior to handling
the product and retain them for future reference.
5063022106117_MNL_IN_V03.indd 15063022106117_MNL_IN_V03.indd 1 31-03-2023 00:27:3931-03-2023 00:27:39

2
EN Parts
EN You will need
x1
EN Contents
EN
Product description 3
Safety 4
Technical specication 17
Before you start 19
Functions & Settings 23
Operation 24
Care and maintenance 26
Guarantee 29
Declaration of conformity 30
01. x1 02. x1 03. x1 04. x1 05. x1
06. x1 07. x1 08. x1
5063022106117_MNL_IN_V03.indd 25063022106117_MNL_IN_V03.indd 2 31-03-2023 00:27:4031-03-2023 00:27:40

3
EN Product description
1. Lower vacuum tube
a. Nozzle
b. Location hole* (x2)
2. Middle vacuum tube
a. Latch* (x2)
b. Sliding pin*
c. Location hole* (x2)
3. Upper vacuum tube
a. Latch* (x2)
b. Sliding pin*
c. Connection part*
4. Blower / Collection bag port*
5. Front handle
a. Locking knob
6. Locking knob
7. On/off switch / Speed dial
8. Main handle
9. Air vents
10. Motor housing
a. Motor*
11. Battery docking port
12. Snap-in button
13. Hanging loop
14. Vacuum port
15. Collection bag
a. Securing clip
b. Zipper*
c. Location hole*
16. Impeller wheel cover
a. Spigot* (x4)
17. Upper blower tube
a. Location hole
b. Latch* (x2)
18. Middle blower tube
a. Location hole* (x2)
b. Latch* (x2)
19. Lower blower tube
a. Location hole* (x2)
b. Flat nozzle
20. Battery pack
a. Release button
b. Battery capacity button
c. Battery capacity indicators
21. Charger
NOTE: Parts marked with * are not shown in this overview. Please refer to the
respective part in the instruction manual.
20
20c
20b
20a
16
15
14
15a13
12
11
10
9
8
7
6
5a
5
4
3
2
1
1a
17a
17
18
19
19a
21
5063022106117_MNL_IN_V03.indd 35063022106117_MNL_IN_V03.indd 3 31-03-2023 00:27:4231-03-2023 00:27:42

4
EN Safety
General power tool safety warnings
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with this
power tool. Failure to follow all instructions listed
below may result in electric shock, re and/or serious
injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres, such
as in the presence of ammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
Electrical safety
a) Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.
5063022106117_MNL_IN_V03.indd 45063022106117_MNL_IN_V03.indd 4 31-03-2023 00:27:4231-03-2023 00:27:42

5
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
Personal safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the inuence of drugs,
alcohol or medication. A moment of inattention while operating
power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the
o󰀨-position before connecting to power source, picking
up or carrying the tool. Carrying power tools with your nger
on the switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery.
Keep your hair and clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
5063022106117_MNL_IN_V03.indd 55063022106117_MNL_IN_V03.indd 5 31-03-2023 00:27:4231-03-2023 00:27:42

6
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within a
fraction of a second.
Power tool use and care
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on
and o󰀨. Any power tool that cannot be controlled with the switch
is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove
the battery pack, if detachable, from the power tool before
making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of
parts and any other condition that may a󰀨ect the power
tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
5063022106117_MNL_IN_V03.indd 65063022106117_MNL_IN_V03.indd 6 31-03-2023 00:27:4231-03-2023 00:27:42

7
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of
the power tool for operations dierent from those intended could
result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the tool in
unexpected situations.
Battery tool use and care
a) Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of battery
pack may create a risk of re when used with another battery
pack.
b) Use power tools only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
c) When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
d) Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
e) Do not use battery pack or tool that is damaged or
modied. Damaged or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk
of injury.
f) Do not expose a battery pack or tool to re or excessive
temperature. Exposure to re or temperature above 130 °C
may cause explosion.
5063022106117_MNL_IN_V03.indd 75063022106117_MNL_IN_V03.indd 7 31-03-2023 00:27:4231-03-2023 00:27:42

8
g) Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specied in the instructions. Charging improperly or at
temperatures outside the specied range may damage the
battery and increase the risk of re.
Service
a) Have your power tools serviced by a qualied repair person
using only identical replacement parts. This will ensure that
safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery
packs should only be performed by the manufacturer or
authorized service providers.
Safety instructions for garden blower / vacuum
Training
a) Read the instructions carefully. Be familiar with the controls and
the proper use of the product.
b) Never allow children, persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge or
people unfamiliar with these instructions to use the product.
Local regulations may restrict the age of the operator.
c) Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their property.
Preparation
a) Obtain ear protection and safety glasses. Wear them at all times
while operating the product.
b) While operating the product, always wear substantial footwear
and long trousers. Do not operate the product when barefoot or
wearing open sandals. Avoid wearing clothing that is loose tting
or that has hanging cords or ties.
c) To prevent dust irritation the wearing of a face mask is
recommended.
d) Do not wear loose clothing or jewellery that can be drawn into
the air inlet. Keep long hair away from the air inlets.
5063022106117_MNL_IN_V03.indd 85063022106117_MNL_IN_V03.indd 8 31-03-2023 00:27:4231-03-2023 00:27:42

9
e) Operate the product in a recommended position and only on a
rm, level surface.
f) Do not operate the product on a paved or gravel surface where
ejected material could cause injury.
g) Before using, always visually inspect to see that the bolts and
other fasteners are secure, the housing is undamaged and that
guards and screens are in place. Replace worn or damaged
components in sets to preserve balance. Replace damaged or
unreadable labels.
h) Never operate the product while people, especially children, or
pets are nearby.
CAUTION! Do not touch a rotating impeller fan.
Operation
a) Before starting the product, make certain that the feeding
chamber is empty.
b) Keep your face and body away from the feed intake opening.
c) Do not allow hands or any other part of the body or clothing inside
the feeding chamber, discharge chute, or near any moving part.
d) Keep proper balance and footing at all times. Do not overreach.
Never stand at a higher level than the base of the product when
feeding material into it.
e) Always stand clear of the discharge zone when operating this
product.
f) When feeding material into the product be extremely careful that
pieces of metal, rocks, bottles, cans or other foreign objects are
not included.
g) If the cutting mechanism strikes any foreign objects or if the
product should start making any unusual noise or vibration,
immediately shut off the power source and allow the product
to stop. Remove the battery pack and take the following steps
before restarting and operating the product:
• Inspect for damage;
• Replace or repair any damaged parts;
• Check for and tighten any loose parts.
5063022106117_MNL_IN_V03.indd 95063022106117_MNL_IN_V03.indd 9 31-03-2023 00:27:4231-03-2023 00:27:42

10
h) Do not allow processed material to build up in the discharge
zone; this may proper discharge and can result in kickback of
material through the intake opening.
i) If the product becomes clogged, shut-off the power source and
remove the battery pack before cleaning debris.
j) Never operate the product with defective guards or shields, or
without safety devices, for example debris collector in place.
k) Keep the air vents clean of debris and other accumulations to
prevent damage to the power source or possible re.
l) Do not transport this product while the motor is running.
m) Stop the product and remove the battery pack. Make sure that
all moving parts have come to a complete stop
• whenever you leave the product,
• before clearing blockages or unclogging chute,
• before checking, cleaning or working on the product,
• after striking a foreign object to inspect the product for
damage,
• if the product starts to vibrate abnormally, for immediate
check.
n) Operate the product only in daylight or in good articial light.
o) Always be sure of your footing on slopes.
p) Walk, never run.
q) Keep all cooling air inlets clear of debris.
r) Never blow debris in the direction of bystanders.
s) Do not tilt the product while the motor is running.
Recommendations for operation
a) Operate the product only at reasonable hours - not early in the
morning or late at night when people might be disturbed.
b) Use rakes and brooms to loosen debris before blowing /
vacuuming.
c) Slightly dampen surfaces in dust conditions or use mister
attachment.
d) Use the full blower nozzle extension so the air stream can work
close to the ground.
5063022106117_MNL_IN_V03.indd 105063022106117_MNL_IN_V03.indd 10 31-03-2023 00:27:4331-03-2023 00:27:43

11
Maintenance and storage
a) Keep all nuts, bolts and screws tight to be sure the product is in
safe working condition.
b) Check the debris collector frequently for wear or deterioration.
c) Use only genuine replacement parts and accessories.
d) When the product is stopped for servicing, inspection, or
storage, or to change an accessory, shut off the power source,
remove the battery pack and make sure that all moving parts
are come to a complete stop. Allow the product to cool before
making any inspections, adjustments, etc. Maintain the product
with care and keep it clean.
e) Always allow the product to cool before storing.
f) When servicing the impeller wheel be aware that, even though
the power source is switched off due to the interlock feature of
the guard, the impeller wheel can still be moved.
g) Replace worn or damaged parts for safety. Use only genuine
replacement parts and accessories.
h) Never attempt to override the interlocked feature of the guard.
i) When not in use, store the product in a dry place out of the
reach of children.
Additional safety warnings
a) Do not touch moving hazardous parts before the product is
disconnected from the battery pack and the moving hazardous
parts have come to a complete stop.
b) Switch-off the product before attaching or removing the
collection bag.
c) Do not operate the product near open windows, etc.
d) Do not blow hard objects such as nails, bolts, or rocks.
e) Apply extra care when cleaning debris from stairs or other tight
areas.
f) Keep all parts of your body away from the suction/blowing
device. Do not remove blockages or jams when the product is
switched on. Make sure the switch is off when clearing jammed
material. One moment of inattentiveness while operating the
product may result in serious personal injury.
5063022106117_MNL_IN_V03.indd 115063022106117_MNL_IN_V03.indd 11 31-03-2023 00:27:4331-03-2023 00:27:43

12
g) Carry the product by the handle with the motor off. Handling the
product properly reduces the possibility of personal injury.
h) Never use the product standing on steps or a ladder. Do not
work above shoulder height.
i) If the product starts to vibrate abnormally, check it immediately.
Excessive vibration can cause injury.
j) Always ensure the product is fully assembled before using it.
Never attempt to use an incomplete product or one tted with an
unauthorised modication.
k) Check the suction/blowing device regularly for damage, and if
damaged repair immediately.
l) Do not overload the product.
m) Follow the maintenance and repair instructions for this product.
Never carry out any modications to the product. Information
about maintenance and repair is provided in this user manual.
Additional safety warnings for battery pack
a) Battery pack needs to be charged before use. Always refer
to the charger’s instruction and charge it properly.
b) Remove the battery pack from the product when not in use.
c) Don’t maintain the battery pack on the charger when not
in use.
d) After extended periods of storage, it may be necessary
to charge and discharge the battery pack several times to
obtain the maximum performance.
e) Longer life and better performance can be obtained if the
battery is charged when the air temperature is between
18°C and 24°C. Do not charge the battery in air temperature
below 5°C or above 40°C. This is important as it can prevent
serious damage to the battery.
f) Do not charge battery in a damp or wet location. Following
this rule will reduce the risk of electric shock.
g) Do not disassemble the battery and avoid mechanical
damage to the battery. Risk of short circuit and fumes may
be emitted. Ensure fresh air and seek medical assistance in the
event of discomfort.
5063022106117_MNL_IN_V03.indd 125063022106117_MNL_IN_V03.indd 12 31-03-2023 00:27:4331-03-2023 00:27:43

13
h) When disposing of battery pack, keep the battery pack
of di󰀨erent electrochemical systems separate from each
other.
Health surveillance
All employees should be part of an employer’s health surveillance
scheme to help identity any vibration related diseases at an early
stage, prevent disease progression and help employees stay in
work.
Vibration and noise reduction
To reduce the impact of noise and vibration emission, limit the
time of operation, use low-vibration and low-noise operating
modes as well as wear personal protective equipment.
Take the following points into account to minimise the vibration and
noise exposure risks:
a) Only use the product as intended by its design and these
instructions.
b) Ensure that the product is in good condition and well maintained.
c) Use correct attachments for the product and ensure they are in
good condition.
d) Keep tight grip on the handles/grip surface.
e) Maintain this product in accordance with these instructions and
keep it well lubricated (where appropriate).
f) Plan your work schedule to spread any high vibration tool use
across a longer period of time.
g) Prolonged use of the product exposes the user to vibrations that
can cause a range of conditions collectively known as hand-arm
vibration syndrome (HAVS) e.g. ngers going white; as well as
specic diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective gloves
and keep your hands warm.
5063022106117_MNL_IN_V03.indd 135063022106117_MNL_IN_V03.indd 13 31-03-2023 00:27:4331-03-2023 00:27:43

14
Emergency
Familiarise yourself with the use of this product by means of
this instruction manual. Memorise the safety directions and
follow them to the letter. This will help to prevent risks and
hazards.
a) Always be alert when using this product, so that you can
recognise and handle risks early. Fast intervention can
prevent serious injury and damage to property.
b) Switch o󰀨 and disconnect from the power supply if there
are malfunctions. Have the product checked by a qualied
professional and repaired, if necessary, before you operate it
again.
Residual risks
Even if you are operating this product in accordance with all
the safety requirements, potential risks of injury and damage
remain. The following dangers can arise in connection with the
structure and design of this product:
a) Health defects resulting from vibration emission if the product is
being used over long periods of time or not adequately managed
and properly maintained.
b) Injuries and damage to property due to broken attachments or
the sudden impact of hidden objects during use.
c) Danger of injury and property damage caused by ying objects.
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with active
or passive medical implants! To reduce the risk of
serious or fatal injury, we recommend persons with
medical implants to consult their doctor and the
medical implant manufacturer before operating this
product!
5063022106117_MNL_IN_V03.indd 145063022106117_MNL_IN_V03.indd 14 31-03-2023 00:27:4331-03-2023 00:27:43

15
Symbols
On the product, the rating label and within these instructions you will nd among others the following
symbols and abbreviations. Familiarise yourself with them to reduce hazards like personal injuries and
damage to property.
V Volt, (direct current voltage) mAh Milliampere per hour
V~ Volt, (alternating voltage) Hz Hertz
WWatt °C Degree Celsius
/min or min-1 Per minute gGram
kg Kilogram mm Millimetre
mMetre km Kilometre
/h Per hour LLitre
dB(A) Decibel (A-rated) m/s2Metres per second squared
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction manual.
Note / Remark. Caution / Warning.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of manufacturing
(Wxx).
Always wear hearing protection.
Always wear eye protection.
Wear a dust mask.
Wear face shield.
Wear protective gloves.
5063022106117_MNL_IN_V03.indd 155063022106117_MNL_IN_V03.indd 15 31-03-2023 00:27:4331-03-2023 00:27:43

16
Wear protective, slip-resistant footwear.
Wear tight-tted protective clothes.
Switch the product off and remove battery pack before assembly, cleaning,
adjustments, maintenance, storage and transportation.
Protection class II (Double insulation), only for charger.
This product is of protection class III.
Do not expose the product to rain or wet conditions (moisture).
Keep bystanders away!
Objects thrown by the product could hit the user or other bystanders. Always ensure
that other people and pets remain at a safe distance from the product when it is in
operation. In general, children must not come near the area where the product is.
Danger of rotating parts. Keep hands away from blowing device! Danger of injuries.

Guaranteed sound power level value in 104 dB.
WEEE symbol. Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local Authority or local
store for recycling advice.
Crossed out dust bin. Batteries and battery packs should not be disposed of with
household waste. Please recycle where facilities exist. Check with your Local Authority
or local store for recycling advice.
Do not dispose of battery packs in rivers or immerse in water.
5063022106117_MNL_IN_V03.indd 165063022106117_MNL_IN_V03.indd 16 31-03-2023 00:27:4431-03-2023 00:27:44

17
Do not dispose of battery packs in re. They will explode and cause injury.
Do note expose battery packs to heat in excess of 40 °C. Do not charge or store the
battery pack in temperatures below 5 °C (41 °F) and above 40 °C (104°F).
The product complies with the applicable European directives and an evaluation
method of conformity for these directives was done.
UK Conformity Assessed.
Rating label explanation
Garden Blower Vacuum: MBV36-Li / TTBC36-Li
M = Brand name (MAC Allister) / TT = Brand Name (Titan)
BV = Blower Vacuum / BC = Blower Vacuum
36 = Rated voltage (V) / 36 = Voltage (36V)
Li = Lithium-Ion / Li = Lithium ion
Battery pack: MDVB36-4 / TTB812BAT
M = Brand name (MAC Allister) / TTB = Titan
DVB = Dual voltage battery / 812 = Sequential Code
36 = Battery output voltage (V) / BAT = Battery
4 = Battery capacity (Ah)
Charger: MFC36 / TTB815CHR
M = Brand name (MAC Allister) / TTB = Titan
FC = Fast charger / 815 = Sequential Code
36 = Battery output voltage / CHR = Charger
EN Technical specications
General :
> Rated voltage :36 V
> Rated no load speed n0:8000-16000 min-1
> Collection bag capacity :25 L
> Max. suction volume :10.6 m3/min
> Max. air speed : 223 km/h
> Mulching ratio :10:1
> Degree of protection : IP20
> Weight :approx. 3.7 kg
> Dimensions :approx. 1220 x 340 x 270 mm
5063022106117_MNL_IN_V03.indd 175063022106117_MNL_IN_V03.indd 17 31-03-2023 00:27:4431-03-2023 00:27:44

18
Battery pack:
> Model no. : MDVB36-4 / TTB812BAT
> Capacity :8000/4000 mAh
> Voltage :18/36 V
> Weight :approx. 1.02 kg
Charger :
> Model no. : MFC36 / TTB815CHR
> Rated input voltage :220-240 V~, 50/60 Hz
> Rated input power : 190 W
> Rated output voltage :21 V
> Rated output current : 8 A
> Protection class : II /
> Weight :approx. 690 g
> Ambient temperature range for charger and
battery use :5°C to 40°C
Sound values
> Sound pressure level LpA :88.5 dB(A)
> Uncertainty KpA :3 dB(A)
> Sound power level LWA :101.99 dB(A)
> Uncertainty KWA :1.52 dB(A)
> Guaranteed sound power level LWA :104 dB(A)
Hand arm vibration values : 3.743 m/s2MAX
> Uncertainty K : 1.5 m/s2
The sound value(s) have been determined according to noise test code given in EN 60335-1 and
EN 50636-2-100, using the basic standards EN ISO 11094 and EN ISO 3744.
The sound intensity level for the operator may exceed 80 dB(A) and ear protection measures are necessary.
The declared total vibration value(s) and the declared noise emission value(s) have been measured in
accordance with a standard test method and may be used for comparing one tool with another;
The declared total vibration value(s) and the declared noise emission value(s) may also be used in a
preliminary assessment of exposure.
WARNING! The vibration and noise emission during actual use of the power
tool can differ from the declared total value depending on the ways in which the
tool is used especially what kind of workpiece is processed;
The need to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of
the operating cycle such as the times when the tool is switched off and when it is
running idle in addition to the trigger time).
5063022106117_MNL_IN_V03.indd 185063022106117_MNL_IN_V03.indd 18 31-03-2023 00:27:4431-03-2023 00:27:44

19
EN Before you start
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If you nd that parts are missing
or show damage do not use the product but contact your dealer. Using an incomplete or damaged
product represents a hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and operation. This also
includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys! Children
must not play with plastic bags, sheets and small parts! There is a danger of
choking and suffocation!
You will need
(items not supplied)
Suitable personal protective equipment
(items supplied)
Vacuum tube assembly (1,2, 3)
Blower tube assembly (17, 18, 19)
Collection bag (15)
Battery pack (20)
Charger (21) and its manual
NOTE: The accessories required depend on the intended application. Ask your
dealer for advice.
Assembly
WARNING! The product must be fully assembled before operation! Do not use
a product that is only partly assembled or assembled with damaged parts!
Follow the assembly instructions step-by-step and use the pictures provided as
a visual guide to easily assemble the product!
Before using the product, familiarise yourself with the operating features read
the entire instruction manual paying particular attention to the safety rules and
operating procedures.
Do not connect the product to battery pack (20) before it is completely assembled!
Blower tube assembly
1. Align and insert the upper blower tube (17) into the middle blower tube (18) all the way to the stop.
Ensure that the two latches (17b) engage in the location holes (18a) (Fig. 1, step 1).
2. Align and insert the lower blower tube (19) into the middle blower tube (18) all the way to the stop. Ensure
that the two latches (18b) engage in the location holes (19a) (Fig. 1, step 2).
3. Press the right side of the locking knob (6) and hold it in place, then insert blower tube assembly into the
blower port (4) all the way to the stop. Release the locking knob (6) afterward. Ensure that the locking
button (6) engages in the location hole (17a) (Fig. 1, steps 3, 4).
4. Ensure that the impeller wheel cover (16) snaps in place so that the built-in switch will be activated for
blowing operation.
5063022106117_MNL_IN_V03.indd 195063022106117_MNL_IN_V03.indd 19 31-03-2023 00:27:4431-03-2023 00:27:44

20
19 19a
18
18b
18a
17b
17 17a 4
6
16
2
14
3
Fig. 1
NOTE: To detach the blower tube assembly from the blower port (4), depress
the right side of the locking knob (6) and hold it in place, then pull the blower
tube assembly out from the blower port (4).
Vacuum tube assembly
1. Align the slot of the middle vacuum tube (2) with the sliding pin (3b) of the upper vacuum tube (3) and
insert it all the way to the stop (Fig. 2, step 1). Ensure that the two latches (3a) engage in the location
holes (2c).
2. Align the slot of the lower vacuum tube (1) with the sliding pin (2b) of the middle vacuum tube (2) and
insert it all the way to the stop (Fig. 2, step 2). Ensure that the two latches (2a) engage in the location
holes (1b).
3. Push forward the snap-in button (12) and hold it in place, then pull off the impeller wheel cover (16).
Store impeller wheel cover in a safe place to avoid loss (Fig. 3).
11b 2a
22c 3a
3
3b
2b 1
1
Fig. 2
12
16
2
1
Fig. 3
4. Align the four spigots of the connection part (3c) with the slots of the vacuum port (14) and insert the
vacuum tube assembly to the vacuum port (14) all the way to the stop with an audible click. Ensure that
the snap-in button (12) is properly engaged so that the built-in switch will be activated (Fig. 4).
5063022106117_MNL_IN_V03.indd 205063022106117_MNL_IN_V03.indd 20 31-03-2023 00:27:4631-03-2023 00:27:46
