KingShield HDM2400 User manual
• Thank you or purchasing our HDM2400 Automatic Hand Dryer
• Please read this instruction manual care ully and keep or uture
re erence.
1. The appliance automatically turns on and delivers warm air when hands approach the underside o the
unit within 12cm. The power will be cut o within 2seconds a ter the hands leave the air outlet.
2. The sensor operates with a 0.5 second delay to avoid the sensor starting up by mistake.
3. The appliance will cut power when continuously operated or over 1minute to avoid overheating and
activation by mistake.
Instruction Manual
2400W Automatic Hand Dryer
Model: HDM2400
Please read the in ormation contained in these instructions care ully. It provides important advice regarding
the sa e installation, use and maintenance o the unit. These instructions should be kept in a sa e place and
passed on to the new owner should the unit be resold.
The ma ufacturer will accept o liability or damage resulti g from failure to observe the
followi g:
• Ensure packing materials are disposed o properly.
• Any damage to the hand dryer on delivery should be reported to the supplier be ore the unit is
connected.
• This product should be installed by a competent person and in accordance with the current IET Wiring
Regulations. I in doubt consult a quali ied electrician.
• The hand dryer should only be used or the purpose or which it is intended.
• Repairs to the hand dryer should only be carried out by a trained specialist.
IMPORTANT INFORMATION
Should the power lead become damaged, it must o ly be replaced by the ma ufacturer, the ma ufacturer’s
customer service u it, or a similarly qualified specialist to avoid risk of i jury.
CLEANING & MAINTENANCE
OPERATION
Always switch o at the mains be ore any cleaning or maintenance. I repairs or other works are to be
carried out these should be carried out by a ully quali ied electrician.
1. The housing can be wiped with a so t and lightly moist cloth or sponge and i necessary, with some
mild cleaning solution.
2. Clean the two lenses o the proximity sensor at regular intervals, or this purpose use a clean so t dry
cloth.
3. The hand dryer must undergo a thorough cleaning every 3months or more requent as usage dictates.
Issue no: 704208
PLEASE KEEP THESE INSTRUCTIONS
SAFE FOR FUTURE REFERENCE
WEST ROAD . HARLOW
ESSEX . CM20 2BG . UK
www.greenbrook.co.uk
TECHNICAL INFORMATION
Rated voltage: 230V AC - 50Hz
Wattage 2400W
IP Rating: IP21
Earthing Sa ety Class: I
Operation: Automatic operation (on/o ) controlled
by electronic proximity sensor
Max. uninterrupted
operation: 1min
‘Stand by’ consumption: < 1W
Dimensions: 240W x 240H x 190D (mm)
GUARANTEE
Your KingShield 2400W Hand Dryer is guaranteed
or 12 months rom the date o purchase.
This is in addition to your statutory rights.
HDM2400 Ins July 15.qxp_Layou 1 08/07/2015 15:46 Page 1
1. Read all the instructions care ully be ore using the appliance.
2. Suitable or installation on solid walls only.
3. Do not install the appliance within range o people using baths or showers.
4. Be ore installing the unit, check that the electrical voltage o your main
supply corresponds to the voltage marked on the rating label o the appliance.
5. Be ore installing the appliance, check that there are no obstructions within 50cm o the
sensor.
6. Be ore maintenance or repair, make sure that the unit is unplugged.
7. Do not insert any objects into the appliance.
8. Prevent water rom getting into the housing o the appliance during operation or
in storage. Hazard o electric shock, always store in dry area with no moisture.
9. Do not use outdoors
10. The appliance is not intended or use by young children or in irm persons without supervision.
SAFETY PRECAUTIONS
PARTS DESCRIPTION
Front enclosure
In rared automatic
sensor
Fixing screw
Air outlet
Air inlet
Feet
Base Cover
Always ensure that the installation con orms to the current edition o the wiring regulations.
Ensure that the unit is separately used with a 13A use, we recommend connecting to a RCD double pole
spur unit (suggest the PowerBreaker H92 model).
Care should be taken that single insulated conductors cannot come into contact with the mounting
sur ace.
INSTALLATION INSTRUCTIONS
Installation o unit
1. Remove the ixing screw rom the ront enclosure
as shown in Dia.1.
2. Place the installation template onto the wall (Dia.2), where the hand dryer is to be secured. Drill our
holes with a diameter o 6.5mm through the template card.
3. Insert rawl plugs provided into the holes and knock in with a hammer, then remove the template card.
4. Make sure the air outlet is acing downwards and ix the base o the appliance to the wall with the
ixing screws provided.
5. Remove the P.C.B. upper cover and adjust the sensor to required setting (Dia.3).
6. Replace the ront enclosure to the base o the unit with the ixing screw that was removed at the
beginning (Dia.4).
7. Wire the unit into a suitable power supply via a used spur unit (suggest the PowerBreaker H92
model).The hand dryer is now ready to use.
Dia.1
212mm
212mm
Installation
Template
AB
DC
193mm
Dia.2
Dia.3
Adjust the sensor distance
by moving the knob.
_+
Press the ront enclosure irmly to it the base cover.
Base Cover
Front Enclosure
Dia.4
