KingShield DAT02A User manual

Installation / Operating
Instructions For Mains Trans ormer
DAT02A
Fig.1
INSTALLATION
SAFETY
Use t is transformer in conjunction
wit any of t e KingS ield Hard Wired
Doorc imes w en you want to ave an
illuminated door pus .
For use wit illuminated doorpus es or
w en converting a doorpus to an
illuminated pus .
Please read the instructions ully be ore
attempting installation. Disconnect electrical
supply be ore installing.
This unit sh uld be installed by a
c mpetent pers n in acc rdance with the
current IEE Wiring Regulati ns.
If in d ubt c nsult a qualified electrician.
T is transformer is designed to to be
DIN rail mounted.
1. Connect mains cable to Mains in
terminals and secure cable to prevent
movement. Mains in s ould be
supplied by a 3A fuse or M.C.B, see
Fig .1below.
2. Connect t e c ime bellwire to t e 8V
terminals on t e transformer and
terminals D and C on a KingS ield
wired doorc ime. See Fig.2below.
T is gives t e required 8V output.
3. Switc t e power on to transformer
and c eck operation.
Doorc ime
230V AC
Bell wire
Door Pus
DAT02A
Fig.2
12V
4V 8V
Mains in 230V
DAT02A Ins:Layout 1 4/4/13 15:07 Page

Input: 230V,50Hz
Output: 4,8,12V AC, 1A
TECHNICAL INFORMATION
PLEASE KEEP THESE
INSTRUCTIONS SAFE
FOR FUTURE REFERENCE
Issue no: 703148
WEST ROAD . HARLOW
ESSEX . CM20 2BG . UK
sales@gree nbrook.co.uk
W W W. G R E E N B R O O K . C O . U K
GUARANTEE
Your Mains Trans ormer
is guaranteed or 12 months.
Please retain receipt as
proof of purc ase.
