Kingship ASW Series User manual

Digital Weighing Scales
User’s
Manua
l
User Manual
Digital Weighing Scale
ASW Series

ASW Weighing Scale
User Manual

ASW Weighing Scale
User Manual
Cautions
Upon receiving the scale, please take at least 8
hours to recharge the battery before you start to
operate this scale.
Please recharge the battery after a long period of
storage (more than one month). It takes 8~10
hours to fully recharge the battery.
Please assemble the platter before powering on
the scale.
Do not keep the weight placed on the platter for a
long period.
Keep the scale away from the environment with
high temperature, high humidity, heavy press,
and heavy bump.
Always make sure the scale is located in a flat
and plane surface.
1

ASW Weighing Scale
User Manual
Dimension
The below panel & keypad are suitable for
table scale/ Indicator/bench scale/floor scale.
※Installation Diagram of Bench Scale: please see page 7.
2

ASW Weighing Scale
User Manual
Symbols on LCD
Zero Symbol (O):
Oappears on the left-bottom corner of LCD, and
indicates the scale is at zero-point.
NET Weight Symbol (Net):
Net appears on the bottom edge of LCD, and indicates
the tare weight has been deducted.
Indication of Weighing Range () :
Cursor appears on the bottom edge of UNIT
WEIGHT LCD (above of W1 or W2 printed on the
display-overlay), and indicates the present weighing
range to be Weighing Range 1 (W1) or Weighing
Range 2 (W2).
!! Notice: The indication of weighing range is
only available for the scale / indicator with
multiple range (2 ranges).
3

ASW Weighing Scale
User Manual
Battery Symbol ( ) :
When LCD indicates and the scale sounds
beep for four times, it means the battery is running
in low-voltage status. LCD will indicate
continuously for reminding the user to recharge the
battery. If the battery is still running in low-voltage
status without being recharged, LCD will indicate
-OFF-and the scale will sound beep for eight times.
Please power off the scale and recharge the battery
immediately.
Operation Instructions
Backlight <optional function> :
Press and hold key till the scale sounds
beep to enable / disable the Backlight.
 UNIT:
kg only
 :
Press this key to make the scale be at zero point.
LCD will indicate O on the left-bottom corner.
-
-
-
4

ASW Weighing Scale
User Manual
 :
Press this key to deduct the tare weight. Put the package
or container on the platter and then press [TARE] key.
LCD will show Oand Net.
RS232 Interface Connection: <optional device>
RS232 Wiring Configuration:
Baud Rate: 9600
Parity: None
Stop Bit: 1
Data Bit: 8
5
GND
5
4
3
2
1
9
8
7
6
5
4
3
2
1
9
8
7
6
DATA OUT

ASW Weighing Scale
User Manual
Recharge the Battery
Power off the scale and connect the power cord to
an AC outlet. CHARGE LED will indicate the
ongoing status of the battery. It takes about 8~10
hours to fully recharge the battery.
CHARGE LED:
Color of LED
Status of the battery
RED
Initial connection
ORANGE
Charging
GREEN
Fully-charged
Power Requirements
AC: 220V±10%, 50Hz
DC: 6V/4Ah rechargeable battery;
P=0.2W(max)
6

ASW Weighing Scale
User Manual
Installation Diagram of Bench Scale
List of Components:
No.
Item
<1>
Indicator
<2>
Regulator
<3>
Stainless Steel Tube
<4>
Tube Base
<5>
Stainless Steel Platter
<6>
Main Structure
<7>
Cable of Load Cell
<8>
Connector
5
1
8
2
3
4
6
7
Installation Procedure:
A. Screw <4> Tube Base and <6> Main Structure together (with 2 screws
of Tube Base).
B. Insert <3> Stainless Steel Tube into <4> Tube Base (with 2 screws of
Stainless Steel Tube).
C. Screw <2>Regulator and <3> Stainless Steel Tube together (with 1
screw and 1 clip of Regulator).
D. Please refer to the Diagram; pull <7> Cable of Load Cell, from the
bottom to the top, through <3> Stainless Steel Tube; and then screw
the Clip on the bottom of <4> Tube Base (with 1 screw of Clip).
E. Connect <1> Indicator with <2> Regulator. Notice the direction.
Please refer to the arrow on the diagram for proper direction.
F. Put <5> Platter on <6> Main Structure.
G. Insert <8>Connector into the socket of <1>Indicator. Complete
installation
※ Before using this scale, please unscrew the protecting-screw fixed
on the bottom side of the steel-welding base structure.
7

ASW Weighing Scale
User Manual
Note:
8
