KingSmith WalkingPad WPA1F User manual

FCC ID: 2ARDB-WPA1F
Manufacturer : Beijing Kingsmith Technology Co.,Ltd.
Address : Floor 4, Building 25, Area 18, ABP Park, Fengtai, Beijing, China.
After-sale service email : [email protected]
Made in China Model No. :
Read all instructions before using this appliance. WPA1F

IMPORTANT SAFETY INSTRUCTIONS
Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for com-
pliance could void the user's authority to operate the equipment. The appliance is intended for household use.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Electric shock hazard, where the appliance is used without the earth connection.
WARNING
User Manual

User Manual Content
1. Product and Accessories
2. Function schematic diagram
3. Guide for initial operation
4. Learn to use WalkingPad
5. Safety Notice
6. Maintenance and Service
7. Trademark and Legal Declaration
8. Replacement and Disposal
02
03
07
09
13
16
17
18
DANGER – To reduce the risk of electric shock: Always unplug this appliance from the electrical outlet
immediately after using and before cleaning.
WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons: 1) An appliance should
never be left unattended when plugged in. Unplug from outlet when not in use, and before putting on or taking off parts.
2) Close supervision is necessary when this appliance is used by, on, or near children, invalids, or disabled persons. 3)
Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by
the manufacturer. 4) Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water. Return the appliance to a service center for examination and repair.
5) Do not carry this appliance by supply cord or use cord as a handle. 6) Keep the cord away from heated surfaces. 7)
Never drop or insert any object into any opening. 8) Do not use outdoors. 9) Do not operate where aerosol (spray)
products are being used or where oxygen is being administered. 10) To disconnect, turn all controls to the off position,
then remove plug from outlet.
Connect this appliance to a properly grounded outlet only. See Grounding Instructions.
This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of expe-
rience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Keep children under the age of 13 away from this machine.
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug
will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do not change the plug in any way.
To reduce the risk of personal injury, read and understand all the instructions before using this product.
Make sure that the product is connected to an outlet having the same configuration as the plug. No adapter should be
used with this product.

Welcome to use 01 Product and Accessories
Thank you for choosing the WalkingPad Walking device, hereinafter referred to as a WalkingPad, which possess various
advantages including exquisite, foldable, innovative integral design. From now on, enjoy the quality life of walking at home.
Please carefully check whether the contents of the package are complete and intact. If there is any missing or damaged, please
contact the seller.
Performance &indicators
Expansion dimensions
Folding dimensions
Walking Area
Gross weight
Net weight
Maximum load
Applicable age
Applicable height
Minimum speed
Maximum speed
Power Input
Rated voltage
Sport mode
Main Product
Other accessoriesParts
Detailed parameters
1432 x 547 x 129 mm
56.5'' x 21.5'' x 5''
822 x 547 x 129 mm
32.5" x 21.5" x 5"
1200 x 415 mm
47" x 16.5"
31 kg / 68 lbs
28 kg / 62 Ibs
100 kg / 220 lbs
14 ~ 60 years old
Unlimited
0.5 km/hr 0.5 mi/hr
6 km/hr 3.75 mi/hr
746 W
110 - 120 V ~
Standby mode/ Manual
mode/ Automatic mode
Remote Controller Lanyard Wrench Silicone OilPower Cable
User Manual
01 02
Frequency 60 Hz

1. Product main body
02 Function schematic diagram
Walking Belt
Display Panel
Mode Indicator Light
Roller
Power Switch
Power Plug
Roller
Fold Hinge
03 04
Mode Switch

Display Time Display Speed Display Distance Display Steps
Standby Mode Manual Mode Automatic Mode
Fault Warning Light
2. lntroduction of the function of the indicator panel 3. Walkingpad remote control
02 Function schematic diagram
05 06
START/STOP
LANYARD
ACCELERATION
DECELERATION
BATTERY COVER
MODE SWITCH

03 Guide for initial operation
07 08
4. Connect the power cord and
press the button to switch on.
2. Unfold the walkingpad slowly and
press it down to completely flat.
3. Check and adjust the walking belt
to make sure it's centered.
5. Search ''Walkingpad" App from
Apple Store or Google Play and
complete installation.
6. Open the App, follow the prompts
to set up the device.
10. If the belt deviates from the orbit
in use, please adjust properly.
SEE: 06 Maintenance and
service.
8. Complete Novice Guide to unlock
all Functions ( maximum speed
3.75 mi/hr ). Otherwise the speed
limit remains at 1.75 mi/hr.
7. Enter novice guide. 9. Start to use the WalkingPad.1. Choose flat ground to place the
WalkingPad. It is forbidden to
place it on thick and soft cushion.
Please note: Don't connect the
power before the WalkingPad is
fully unfolded.
11. Short press: return to the previous mode.
Long press: switch to Standby mode.
Mode Switch

1. Mode instruction 2. Instructions of the standby
mode control
Standby Mode
04 Learn to use WalkingPad
09 10
Standby Mode
Light of the Standby mode is on;
Motor and sensor stop responding.
Manual mode
Light of the manual mode is on;
Control the speed through the remote
control or APP.
Automatic Mode
Light of the automatic mode is on;
Speed is automatically controlled by
intelligent algorithm.
It follows the speed of walking.
The motor and sensor stop responding
in this mode to prevent nonusers from
accidentally triggering the WalkingPad.
Mode Switch
Short press: return to the previous mode.
3. Instructions of manual mode control (primary mode)
In this mode, the speed of the WalkingPad can be controlled by the remote
control. It is recommended that beginners use the manual mode first and
then use the automatic mode after being skilled in using the WalkingPad.
The manual mode is controlled by remote control by default, that is, the
START/STOP button of the remote control is used to start or stop the Walk-
ingPad, which can be modified in the client "Personalized".
Manual Mode
MODE SWITCH
Short press: switch to automatic mode.
Long press: switch to Standby mode.
ACCELERATION
Short press: increase speed by 0.25 mi.
START/STOP
Short press: Start or Stop the WalkingPad.
DECELERATION
Short press: reduce speed by 0.25 mi.
In the manual mode, set as
the intelligent start and stop,
the WalkingPad will start
automatically to the target
speed (default is 1.75 mi/hr)
while entering this area.

5. Remote Controller Notice 6. Error Warning Light
04 Learn to use WalkingPad
11 12
If the remote controller has no response or you
change a new one, the remote controller and
walking device need to re-establish communica-
tion.
Remote control pairing method:
Restart the WalkingPad, press and hold down the
mode switch button on the remote control immedi-
ately, hearing the sound of "Beep" indicates the
success of pairing. Note: During the operation, the
remote control should be close to the LED display
panel of WalkingPad.
Error Warning Light on the display panel is off when
Walkingpad works well. When error occurs, Error warn-
ing light turns on and shows its error code.
E01: Drive communication fault;
E02: Motor abnormalities;
E05: Overcurrent protection;
E06: Motor Protection;
E08: Sensor Fault;
E10: High temperature protection, automatic recovery
after the end of countdown;
E11: Overload protection, please add lubricating oil, and
resume automatically after countdown.
Short press: stop the WalkingPad.
Mode Switch
Short press: switch to manual mode.
Long press: switch to Standby mode.
Automatic mode
4. Description of automatic mode control (advance mode)
This is a challenging and higher-class mode, User can walk on
the Walkingpad completely out of remote controller. We only
recommend those who have good sports skills or walking-device
experience to take the challenge.
Entering this area, the
WalkingPad will start or
accelerate under the
automatic mode.
Entering this area, the
WalkingPad will slow down
automatically under the
automatic mode.

05 Safety Notice
13 14
Please keep a rear distance of
1000 mm or more.
Please keep a distance of 500 mm
or more for both sides.
Please choose sport shoes. Please do not stand up on the
walking machine when it is
under auto calibration situation.
Anti-pinch.
Anti-involved, please do not
trample.
Please pull out the plug when you
are not using it.
Using on uneven ground is
prohibited.
It is strictly prohibited to walk
up and down the walking
machine when running.
Turn the power off before fold up
the WalkingPad.
Prohibition of vertical placement.
Prohibition of lateral placement.

1. Clean the walking machine - Turn off the machine and unplug the power cord.
- Add several drops of detergent on cotton rag or towel. Don't pour the detergent on the
belt directly, and don't use acid or corrosive cleaners.
- Wipe off dust and stains on the frame, front panel and belt. Do not wipe backside of the
belt.
- After using for a period, dust and stains may appear on the back part, that is normal
situation, and just clean them up.
- Press and hold both Mode Switch Button and Acceleration Button on the remote
control over 3 seconds.
- Front panel shows "CALI" and the speed is 4 km/hr ( 2.5 mi/hr ).
- If belt deviates to the left: Turn the left adjusting screw for a half-circle clockwise.
- If belt deviates to the right: Turn the right adjusting screw for a half-circle clockwise.
- If belt is slipping: Turn both left and right adjusting screw for a half-circle clockwise at
same time.
- Keep the machine running for 1-2 minutes and check whether it needs to readjust.
- Turn off the machine and unplug the power cord.
- Lift up the belt and apply silicone oil on the backside of the belt.
- Turn on the machine again
- Keep the machine running under 4 km/hr ( 2.5 mi/hr ) for 10-20 20 seconds.
- Only apply 5 ml ~ 10 ml lubricant oil each time, too much lubricant oil makes the belt
become slipping.
- Apply for silicone oil once every 3 months.
05 Safety Notice 06 Maintenance and Service
15 16
Children should be
supervised to ensure that
they do not play with the
Walkingpad.
Please do not use the
walking machine if you
are aged people or
pregnant women.
Please keep your sight
horizontal to avoid dizziness.
More than one person
on the Walkingpad is
prohibited.
Using machine with
pet is prohibited.
Walking sideways on
the machine is
prohibited.
Walking backwards on
the machine is
prohibited.
Trampling the machine
head is prohibited.
Horizon
2. Adjust the belt
3. Lubricate the Belt

Beijing Kingsmith Technology Co., Ltd holds the patents of Walkingpad Walking Device series products. Kingsmith edits and
owns the copyright of this manual book. Without Kingsmith's written permission, any form of unauthorized distribution, reproduc-
tion, publication, release or quotation by any institution or individual is prohibited. This manual contains as many as possible of
all the functions and instructions for use. However, due to product imperfections, design changes, etc., the description may still
have discrepancies with what you have purchased. In view of product updates, description in this manual book may differ from
what you have purchased in color, appearance, etc. Actual supplies prevail. This appliance is not intended for persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance. Children aged from 8 years and above and persons can use this
appliance with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understood the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
Product performance standard : Q/FTSMS0001-2017
07 Trademark and Legal Declaration
17 18
08 Replacement and Disposal
The battery contained in this appliance must be removed for or disposal.
When replacing the battery, use only original battery, available from our online parts shop.
The battery compartment is located on the underside of the appliance. Open the compartment by removing the
screw in the cover using a suitable screwdriver, and then press the lower end of the locking catch on the
connectors. In that way, both sides of the connection can be separated by pulling them apart.
When inserting a new battery, push together the two connectors and ensure that the catch locks over the stop.
Never dispose of old battery in domestic garbage, but only through the proper public collection points. This also
applies to the battery of defective appliances.
Devices marked with this symbol must be disposed of separately from your household waste, as they contain
valuable materials which can be recycled. Proper disposal protects the environment and human health. Your
local authority or retailer can provide information on the matter.
