KISANKRAFT KK-PE4-163 User manual

KisanKraftTM
Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 1 of 36
Product PETROL ENGINE –
4 STROKE
KisanKraftTM
Invoice Date
Brand KisanKraft KisanKraftTM
Invoice No.
Model KK-PE4-163
KK-PE4-203
WARRANTY
PERIOD 6MONTHS
FOR THE SPECIFIED PERIOD FROM THE
DATE OF SALE OR DELIVERY
WHICHEVER IS EARLIER.
Dealer’s
Invoice Date Dealer’s
Invoice No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN,
etc.):
Buyer’s
Sign Dealer’s
Sign
What is covered: KisanKraft Machine Tools Private Limited and its manufacturers
warrant this product to be free from defects in material or workmanship. All parts
defective in material and workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Machine Tools Private
Limited or its manufacturers at the premises of Authorized Dealers, of such parts as
appear to KisanKraft or its manufacturers, upon inspection, to be defective in material
and/or workmanship. KisanKraft or its manufacturers make no warranty with respect
to trade accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither
KisanKraft Machine Tools Private Limited nor any of its manufacturers, nor its
authorized dealers assumes any responsibility, if the failure was caused by the
following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of
machine or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical
damage, (6) Repairs made by unauthorized parties and/or with unauthorized parts,
(7) Improper set up, adjustments, tampering or altered products

KisanKraftTM
Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 2 of 36
Important: (1) Normal maintenance and adjustments to the product is the
responsibility of the customer. (2) Normal wear and tear is not covered under warranty
(3) Rubber/plastic parts and consumables such as blades, clutch and clutch-bell,
spark-plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the
warranty.
No Warranty On Electrical Motor / Electrical Parts Etc.
Incidental / Consequential Loss: KisanKraft Machine Tools Private Limited or its
manufacturers will not be liable for general damages, including bodily injuries, or for
incidental or consequential damages including, but not limited to, loss of use, loss of
profits, loss of production, expense of substitute equipment or other commercial loss
or damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including, but
not limited to, any implied warranty of merchantability shall be limited in duration to
the applicable warranty period. Any action for breach of any warranty hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Machine Tools Private Limited or any of its manufacturers has the authority
to increase or alter the obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended
to the first end user (original purchaser), and no warranty is made, nor authorized to
be made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of
any obligation under this warranty for failure during the applicable warranty period,
deliver the defective product, to the nearest Authorized Dealer. KisanKraft Machine
Tools Private Limited, its manufacturers and its dealers reserve the right to inspect
the claimed defective part(s) to determine if the malfunction is the result of a defect
covered by this warranty. Please note that the decision of KisanKraft Machine Tools
Pvt Ltd with respect to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGarden Tools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines 

KisanKraftTM
PETROL ENGINE - 4 STROKE
KK-PE4-163 / 203

: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 3 of 36
Operation Manual
KisanKraft Machine Tools Pvt. Ltd.
Sri Huchhanna Tower, #4,1st Main,7-A Cross, Maruthi Layout, Dasarahalli,
HAF Post, Hebbal, Bangalore 560024,Karnataka,INDIA
♦Bangalore (HO) ♦ Ahmedabad ♦ Bhopal ♦ Bhubaneswar ♦ Coimbatore ♦
♦Ernakulam ♦ Guwahati ♦Hinudpur ♦ Hubli ♦ Hyderabad ♦
♦Jaipur ♦ Karnal ♦ Kolkata ♦ Lucknow ♦ Nagpur ♦ Patna ♦ Pune ♦ Raipur ♦

KisanKraftTM
PETROL ENGINE - 4 STROKE
KK-PE4-163 / 203

: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 4 of 36
CONTENTS
BEFORE GETTING STARTED.............................................................. 7
SAFETY LABELS................................................................................ 7
SAFETY INSTRUCTIONS .................................................................... 7
PRE-OPERATION CHECKS ................................................................. 8
A. Check the oil level ................................................................ 8
B. Fuel level ............................................................................. 9
C. Air cleaner ......................................................................... 10
STARTING THE ENGINE .................................................................. 11
STOPPING THE ENGINE.................................................................. 12
MAINTENANCE ............................................................................. 13
STORAGE ...................................................................................... 15
TRANSPORTATION ........................................................................ 15
TROUBLESHOOTING ...................................................................... 15
TECHNICAL SPECIFICATIONS .......................................................... 16
ENGINE PARTS DIAGRAM & LIST- KK - PE4-163 / 203 ...................... 17

KisanKraftTM
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 5 of 36
Product PETROL ENGINE –
4 STROKE
KisanKraftTM
Invoice Date
Brand KisanKraft KisanKraftTM
Invoice No.
Model KK-PE4-163
KK-PE4-203
WARRANTY
PERIOD 6MONTHS
FOR THE SPECIFIED PERIOD FROM THE
DATE OF SALE OR DELIVERY
WHICHEVER IS EARLIER.
Dealer’s
Invoice Date Dealer’s
Invoice No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN,
etc.):
Buyer’s Sign Dealer’s
Sign
What is covered: KisanKraft Machine Tools Private Limited and its manufacturers
warrant this product to be free from defects in material or workmanship. All parts
defective in material and workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Machine Tools Private
Limited or its manufacturers at the premises of Authorized Dealers, of such parts as
appear to KisanKraft or its manufacturers, upon inspection, to be defective in material
and/or workmanship. KisanKraft or its manufacturers make no warranty with respect
to trade accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither
KisanKraft Machine Tools Private Limited nor any of its manufacturers, nor its
authorized dealers assumes any responsibility, if the failure was caused by the
following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of
machine or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical
damage, (6) Repairs made by unauthorized parties and/or with unauthorized parts,
(7) Improper set up, adjustments, tampering or altered products

KisanKraftTM
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 6 of 36
Important: (1) Normal maintenance and adjustments to the product is the
responsibility of the customer. (2) Normal wear and tear is not covered under
warranty.(3) Rubber/plastic parts and consumables such as blades, clutch and clutch-
bell, spark-plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under
the warranty.
No Warranty On Electrical Motor / Electrical Parts Etc.
Incidental / Consequential Loss: KisanKraft Machine Tools Private Limited or its
manufacturers will not be liable for general damages, including bodily injuries, or for
incidental or consequential damages including, but not limited to, loss of use, loss of
profits, loss of production, expense of substitute equipment or other commercial loss
or damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including,
but not limited to, any implied warranty of merchantability shall be limited in duration
to the applicable warranty period. Any action for breach of any warranties hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Machine Tools Private Limited or any of its manufacturers has the authority
to increase or alter the obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended
to the first end user (original purchaser), and no warranty is made, nor authorized to
be made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of
any obligation under this warranty for failure during the applicable warranty period,
deliver the defective product, to the nearest Authorized Dealer. KisanKraft Machine
Tools Private Limited, its manufacturers and its dealers reserve the right to inspect
the claimed defective part(s) to determine if the malfunction is the result of a defect
covered by this warranty. Please note that the decision of KisanKraft Machine Tools
Pvt Ltd with respect to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGarden Tools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines 

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 7 of 36
BEFORE GETTING STARTED
Thank you for your purchase and use of our products. In order to avoid accidents or injury,
please read this manual carefully before using the machine. After reading, preserve it
for further reference. This manual is a part of the gasoline engine and should be transferred
when the machine is resold.
SAFETY LABELS
DANGER Indicates a hazard, if not avoided, can result in human injury or
death.
WARNING Indicates a hazard, if not avoided, could result in human injury
and/or property damage.
CAUTION Indicates a hazard, if not avoided, might result in slight injury
and/or property damage.
Please read and understand this owner’s manual before
operation of the engine to avoid accidents by familiarizing
yourself with your engine’s controls and safe operation
procedures.
SAFETY INSTRUCTIONS
1. Please perform some pre-operation checks before operation to avoid human
injury and equipment damage.
2. Keep the engine in good ventilated places at least 1 meter away from buildings
and other equipment’s during operation and keep the flammable substances
away from the engine to avoid fire.
3. Keep children and pets away from the operation area.
4. Make sure that the person who operates the engine receives proper instruction.
5. Keep the flammable substances (gasoline, matches) away from the operating
engine.
6. As gasoline is extremely flammable and explosive under certain conditions,
please refuel in a well-ventilated area with the engine stopped.
7. Do not fill above the shoulder of the fuel strainer.
8. Make sure the fuel cover is tightened.
9. Make sure that any spilled fuel has been wiped off before starting the engine.
10. Do not smoke or allow flames or sparks where the engine is refueled or where
gasoline is stored.
11. Exhaust contains poisonous carbon monoxide, a colorless and odorless gas.
Breathing exhaust can cause loss of consciousness and may lead to death. Do
not operate the engine without good ventilation or in enclosed room.
12. If you run the engine in an area that is confined, or even partially enclosed, the
air you breathe could contain a dangerous amount of exhaust gas. Provide
adequate ventilation so as to keep exhaust gas from accumulation.
13. Place the engine on flat (level) surface, tilting angle of the engine should not be

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 8 of 36
more than 20º, otherwise it will lead to fuel spilling out.
14. Do not cover the engine so as to avoid fire occurrence.
15. The muffler becomes very hot during and immediately after operation. Be careful
not to touch the muffler while it is hot. Let the engine cool down before storing
the engine indoor.
PRE-OPERATION CHECKS
A. Check the oil level
Lubricating oil:
Engine lubricant oil is a major factor affecting engine performance and service
life.
The use of the lubricating oil free of cleaning agent or the lubricating oil for the
two-stroke engine will shorten the life of the gasoline engine.
The operating temperature range recommended for the gasoline engine is -
5℃~40℃.
Use 4-stroke motor lubricant oil. 20W-40 is recommended in general, at all
temperature use. Other viscosities shown in the chart may be used when the
average temperature in your area is within the indicated range.
Ambient temperature
Before checking engine lubricant oil, place the engine on level surface
Turn out the oil filler cap and clean the dipstick with a clean cloth.
Insert the dipstick back into the oil filler hole without turning it in.
If oil level is below the lower mark of the dipstick, fill oil to the upper level of the
dipstick.
Reinstall the oil filler cap properly.

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 9 of 36
Engine oil alert system (optional function):
The oil alert system is designed to prevent engine damage caused by insufficient oil in
the crankcase. When the oil level in the crankcase falls below the safe limit, the oil alert
system will automatically stop the engine even if the engine switch remains at the ON
position. If the engine stops and cannot be restarted, check the engine oil level before
troubleshooting in other areas.
(1) Drain plug (2) Engine switch (3) Lower level
B. Fuel level
Check the fuel gauge, and refill the tank if the fuel level is low. Do not fill above
the shoulder of the fuel strainer. The fuel 90# gasoline is recommended.
Unleaded gasoline produces less engine and spark plug fouling and extends
exhaust system life.
Never use stale or contaminated gasoline or oil/gasoline mixture. Avoid dirt,
rubbish and water from getting into the fuel tank.
If spark knock or pinging occurs at a steady engine speed under normal load,
change brands of gasoline. If spark knock or pinging persists, see an
authorized dealer.
WARNING:
Running the engine with persistent spark knock or pinging can cause engine
damage.
Upper level
Dipstick
Lower level

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 10 of 36
If persistent spark knocks or pinging is caused by improper usage of the unit,
the Distributor’s Limited Warranty does not cover parts damaged by that.
(1) Fuel tank (2) Fill in hole (3) Red line level
C. Air cleaner
The air cleaner is a dry type including paper element and foam element.
Remove the clip and dismantle the air cleaner housing or remove the wing nuts
and air cleaner cover.
Wash the element in solution of household detergent and warm water, then
rinse thoroughly, or wash in nonflammable or high flash point solvent. Allow
the element to dry thoroughly
1) Butterfly nut
2) Air cleaner cover
3) Butterfly nut
4) Paper element
5) Foam element
6) Seal washer
7) Silencer plate
WARNING:
Do not run the engine without air cleaner.
DANGER
Using gasoline or flammable solvent to clean the filter element can cause a fire or
explosion.
CAUTION:
Do not run the engine without air cleaner core, otherwise dust and/or other foreign
matters may get into the engine through carburetor, and results in rapid engine worn-out.

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 11 of 36
STARTING THE ENGINE
Turn the fuel valve to ON position, unscrew the drain plug on carburetor
bottom, and fasten the drain plug until oil spills out.
Pull the choke rod to the CLOSE position. Adjust throttle to proper position. Pull
the starter grip lightly until resistance is felt, then pull it rapidly
(1) Fuel Valve (2) Start Level (3) Drain Plug
NOTE:
Do not allow the starter grip to snap back against the engine. Return it gently to
prevent damage to the starter.
Once the engine got started, let it run for 1~3 minutes at idle speed, check
whether it is balanced, cracked, then pull the throttle to open position, adjust
choke rod to OPEN.
(1) Auto-Throttle (2) Off Position (3) Starter Knob

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 12 of 36
Electrical Starting:
Turn the engine switch to START
position and hold a while until the engine
started
ENGINE SWITCH
NOTE:Restrict the starting time within 5 seconds to avoid engine damage. If engine
cannot be started, release starter knob, retry after 10 seconds.
STOPPING THE ENGINE
Adjust throttle to proper position. Reduce engine speed, close the choke. Turn engine
switch to OFF position.
(1) Throttle knob (2) Throttle is at OFF
DANGER:
Gasoline is extremely flammable and explosive under certain conditions.
Refuel in well-ventilated places with the engine stopped. Do not smoke or allow
flames or sparks near the places where the engine is refueled or gasoline is
stored.
Do not add fuel over the shoulder of strainer. After fueling, tighten the tank
cover.
Fuel vapors are extremely flammable and may ignite after the engine has
started. Make sure that any fuel spillage has been wiped off before starting the
engine.

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 13 of 36
Avoid skin coming in contact with gasoline for a long time, avoid breathing in
gasoline vapors. Keep children away from them.
NOTE:
Fuel can damage paint and plastics. Be careful when refueling. Damage caused by
spilling fuel is not covered under warranty.
MAINTENANCE
Do periodic maintenance to keep the engine in good condition. Always follow the
inspection and maintenance recommendation and schedules given in this manual.
WARNING:
Stop the engine before doing any maintenance work. If the engine must be operated,
provide adequate ventilation. Breathing in exhaust can cause loss of consciousness and
even lead to death.
Everyday Maintenance:
1. Air cleaner: A dirty air cleaner will restrict air flow into the carburetor. To prevent
carburetor malfunction, service the air cleaner regularly. Service more frequently
when operating the generator in extremely dusty areas.
Check air cleaner core, get rid of fouling, and keep the core clean.
Check bolts, fasten the loose ones.
Check whether lubricant oil level is within the limits.
2. Clean the core after 25hrs of engine run
3. Clean carbon fouling of the spark plug after working up to 50hrs. Check the
clearance, and adjust the gap to 0.6-0.7mm (see figure 4-1). Check radiator, and
clean fouling among radiators.
Drain the oil while the engine is warm to assure rapid and complete
draining.
Remove the drain plug and sealing washer, remove the oil filler cap, and
drain the oil.
Reinstall the drain plug and sealing washer. Tighten the plug securely.
Refill with the recommended oil and check the oil level.

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 14 of 36
(1) Dismantle Spark Plug (2) Adjust Clearance
4. Clean the fuel tank and filter when working time reaches 100hrs: Remove the fuel
cover, drop out filter, and wash it with brush slightly. Remove fuel tank, clean the
fouling and water inside fuel tank. Reinstall fuel tank, place filter from fill-in hole,
filling the clean fuel to red line level.
1) Drain plug 2) Engine switch 3) Lower level
Check aging of fuel pipe every 2 years. If ageing, hardening and cracking is detected,
have it replaced. Tighten the joints, and check leakage.
Before storing the unit for an extended period:
1. Make sure the storage area is free of excessive humidity and dust.
2. Service according to the table below.
Storage Time Recommended Service Procedure To Prevent Hard Starting
Less than 1 month No preparation required
1 to 2 months Fill with fresh gasoline and add gasoline conditioner
2 months to 1 year
Fill with fresh gasoline and add gasoline conditioner
Drain the carburetor float bowl
Drain the fuel sediment cup

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 15 of 36
STORAGE
If the engine is not used for a long time, do the necessary maintenance before its
storage.
Firstly, take off the fuel tank, drain out all fuel, and clean the dirt and water
inside the tank. Open the fuel cock, unscrew the drain plug at the bottom of
carburetor, drain out fuel in carburetor thoroughly, and then tighten the drain
plug.
Secondly, unscrew the drain plug at the bottom of the crankcase and drain out
the lubricant oil in the crankcase thoroughly, then tighten the drain plug.
Finally, clean the surface of the engine with clean cloth, remove the dirt and
dust etc. Then store the engine in a well-ventilated, dirt-free place.
TRANSPORTATION
Contact with the hot engine or exhaust system can cause serious burns or
fires. Allow the engine to cool down before transporting or storing the engine.
During transport of the engine, turn the engine switch and the fuel valve to
OFF. Keep the engine cool.
TROUBLESHOOTING
1. The Engine Can’t Startup
Have the engine checked if it is hard to or cannot be started.
Firstly, check the fuel level of the fuel tank. Turn fuel valve to (2), Fuel should
flow from the drain when the fuel valve is turned ON. Tighten the drain plug.
(Refer to starting of the engine)
2. Spark Plug
Check the spark plug. Remove the spark plug cap and clean any dirt around it. If the
engine still cannot be started after repeating several times, please see the authorized
dealer. Users are not allowed to dismantle or reassemble the unit by themselves.
3. Not Enough Power
Check the air-cleaners. Please refer the maintenance inspection book to clear
the air-cleaner.
Check the fuel. Please strain out the gasoline in fuel tank and in carburetor,
and fill in new gasoline.
For any other trouble, please contact our dealer.

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 16 of 36
TECHNICAL SPECIFICATIONS
Model KK-PE4-163 KK-PE4-203
Engine Type OHV,Single-cylinder,4-stroke,forced air cooling
Fuel tank capacity 3.6L
Engine oil capacity 0.6L
Displacement 163cc 196cc
Rated theoretical power
2.3kW 3kW
At 3600rpm
Max. torque 10N.m/2500rpm 11N.m/2500rpm
Specific fuel consumption ≤ 450 g/kWh
Lubricant oil consumption ≤ 0.01 (g/kWh)
Ignition system Transistor magneto
Starting system Recoil start or Electric start(Optional )
N.W./G.W 15 / 17kg
Dimension(L×W×H) 400×375×380
Bore × Stroke 68 × 45mm 68 × 54mm
Compression Ratio 8.5:1
Note: The Engine KK-PE4-163.and KK-PE4-203 are BIS: ISI certified.

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 17 of 36
ENGINE PARTS DIAGRAM & LIST- KK –PE4-163 / 203
Cylinder Head
SL-No KK-No KK-Name Qty
1 E3-01 Spark plug 1
2 E3-02 Cylinder head cover 1
3 E3-03 Cylinder head Assy 1
4 E3-04 In. valve guide 1
5 E3-05 Ex. valve guide 1
6 E3-06 Valve guide clip 1
7 E3-07 Gasket Cylinder head cover 1
8 E3-08 Gasket Cylinder head 1

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 18 of 36
SL-No KK-No KK-Name Qty
9 E3-09 Air duck/Pipe 1
10 E3-10 Stud Intake Port M6 x 113 2
11 E3-11 Stud Exhaust Port M8 x 32 2
12 E3-12 Set pin 10x14 2
13 E3-13 Bolt M6x12 4
14 E3-14 Bolt M8 x 60, 4
Crankcase Assembly

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 19 of 36
SL-No KK-No KK-Name Qty
1 E4-01 Crankcase Body 1
2 E4-02 0-ring 14mm 1
3 E4-03 Drain bolt 2
4 E4-04 N/A 1
5 E4-05 Sway bar 1
6 E4-06 N/A 1
7 E4-07 Split Clip 1
8 E4-08 Washer Drain bolt 2
9 E4-09 N/A 1
10 E4-10 Centrifugal gear Parts 1
11 E4-11 N/A 1
12 E4-12 Plain washer 6mm 2
13 E4-13 N/A 2
14 E4-14 N/A 1
15 E4-15 N/A 2
16 E4-16 Oil sensor Assy 1
17 E4-17 Oil seal crankcase(25*41.25*6) 1
18 E4-18 Ball Bearing 6205 1
19 E4-19 Bolt M6 x 14 2
20 E4-20 Nut M10 1

KisanKraft
TM
PETROL ENGINE - 4 STROKE
KK –PE4-163 / 203
: www.kisankraft.com
: [email protected]om
: +91.80. 22178200
Page 20 of 36
Crankcase Cover
SL-No KK-No KK-Name Qty
1 E5-01 Crankcase cover 1
2 E5-02 Oil Gauge 1
3 E5-03 Oil Plug assembly 1
4 E5-04 seal-oil guage 2
5 E5-05 Gasket crankcase 1
6 E5-06 Set pin 8X14 2
7 E5-07 Oil Seal 25x41.25x6 1
8 E5-08 Ball Bearing 6205 1
9 E5-09 Bolt M8 x 30 6
