KitchenAid SUPERBA KEMS308 User manual

KITCHENAID
®
Lower Electric Convection Oven
Use and Care Guide
www.kitchenaid.com
Models: KEMC308 KEMC378 KEMS307
KEMS308 KEMS377 KEMS378
4452300B
A Note to You ...........................................2
Electric Oven Safety................................3
Getting to Know Your
Electric Convection Oven.......................5
Using Your Electric Convection Oven...6
Using the electronic oven control..........6
Oven settings.........................................9
Setting the clock ..................................10
Using the timer.....................................10
Baking or convection baking ...............11
Convection baking tips........................12
Convection roasting.............................12
Convection roasting tips......................13
Positioning racks and pans.................13
Bakeware choices ...............................14
Using aluminum foil.............................15
Adjusting oven temperature................15
Using the temperature probe..............16
Using CONVECT FULL MEAL ...........18
Using EASY CONVECT™
Conversion...........................................20
Broiling.................................................21
Convection broiling..............................22
Timed cooking......................................24
Dehydrating..........................................26
Proofing (raising) bread.......................27
The oven vent......................................27
Using the Self-Cleaning Cycle.............28
Before you start ...................................28
Before setting the controls ..................29
Setting the controls..............................29
For best cleaning results.....................30
How the cycle works............................30
Caring for Your
Electric Convection Oven.....................31
Cleaning Chart.....................................31
Removing the oven door.....................32
Using and replacing oven lights..........33
Troubleshooting.....................................34
Requesting Assistance or Service......36
Warranty..................................................40
In the U.S.A. for assistance or service,
call the Consumer Assistance Center:
1-800-422-1230
In Canada for assistance or service,
see page 37.
®
®
4452300Bv09c40 1/21/00 4:36 PM Page 1

2
ANote to You
Thank you for buying a KITCHENAID®appliance!
KitchenAid designs the best tools for the most important room in your house. To
ensure that you enjoy many years of trouble-free operation, we developed this Use
and Care Guide.
It contains valuable information concerning how to operate and maintain your new
appliance properly. Please read it carefully. Also, please complete and mail the
enclosed Product Registration Card.
Please record your model’s information.
Whenever you call our Consumer
Assistance Center at 1-800-422-1230
(in Canada, 1-800-807-6777) or request
service for your appliance, you need to
know your complete model number and
serial number. You can find this information
on the model and serial number plate (see
diagram in the Parts and Features section
for plate location on the lower oven).
Please also record the purchase
information.
NOTE: You must provide proof of purchase
or installation date for in-warranty service.
Keep this book and the sales slip together in a safe place for future reference.
Model Number __________________________
Serial Number __________________________
Purchase/
Installation Date ________________________
Builder/Dealer
Name __________________________________
Address ________________________________
Phone__________________________________
4452300Bv09c40 1/21/00 4:36 PM Page 2

3
Electric Oven Safety
You can be killed or seriously injured if you
don't immediately follow instructions.
You can be killed or seriously injured if you
don't follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the
chance of injury, and tell you what can happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and
others.
All safety messages will follow the safety alert symbol and either the word
“DANGER” or “WARNING.” These words mean:
•Storage in Oven – Flammable materials
should not be stored in an oven.
•Do Not Use Water on Grease Fires –
Smother fire or flame or use dry chemical
or foam-type extinguisher.
•Use Only Dry Potholders – Moist or damp
potholders on hot surfaces may result in
burns from steam. Do not let potholder
touch hot heating elements. Do not use a
towel or other bulky cloth.
•Use Care When Opening Door – Let hot
air or steam escape before removing or
replacing food.
•Do Not Heat Unopened Food Containers
– Build-up of pressure may cause
container to burst and result in injury.
•Keep Oven Vent Ducts Unobstructed.
WARNING: To reduce the risk of fire,
electrical shock, injury to persons, or
damage when using the oven, follow basic
precautions, including the following:
•Proper Installation – Be sure the oven is
properly installed and grounded by a
qualified technician.
•Never Use the Oven for Warming or
Heating the Room.
•Do Not Leave Children Alone – Children
should not be left alone or unattended
in area where oven is in use. They
should never be allowed to sit or stand
on any part of the oven.
•Wear Proper Apparel – Loose-fitting or
hanging garments should never be worn
while using the oven.
•User Servicing – Do not repair or
replace any part of the oven unless
specifically recommended in the manu-
al. All other servicing should be referred
to a qualified technician.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
4452300Bv09c40 1/21/00 4:36 PM Page 3

4
Electric Oven Safety
•Placement of Oven Racks – Always
place oven racks in desired location
while oven is cool. If rack must be
moved while oven is hot, do not let
potholder contact hot heating element
in oven.
•DO NOT TOUCH HEATING ELE-
MENTS OR INTERIOR SURFACES
OF OVEN – Heating elements may be
hot even though they are dark in
color. Interior surfaces of an oven
become hot enough to cause burns.
During and after use, do not touch, or
let clothing or other flammable
materials contact heating elements or
interior surfaces of oven until they
have had sufficient time to cool. Other
surfaces of the oven may become hot
enough to cause burns – among
these surfaces are oven vent
openings and surfaces near these
openings, oven doors, and windows of
oven doors.
•Do Not Clean Door Gasket – The door
gasket is essential for a good seal. Care
should be taken not to rub, damage, or
move the gasket.
•Do Not Use Oven Cleaners – No
commercial oven cleaner or oven liner
protective coating of any kind should be
used in or around any part of the oven.
•Clean Only Parts Listed in Manual.
•Before Self-Cleaning the Oven –
Remove broiler pan and other utensils.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor
of California to publish a list of substances known to the State of California to cause
cancer, birth defects, or other reproductive harm, and requires businesses to warn of
potential exposure to such substances.
WARNING: This product contains a chemical known to the State of California to cause
cancer, birth defects, or other reproductive harm.
This appliance can cause low-level exposure to some of the substances listed,
including benzene, formaldehyde, carbon monoxide, and toluene.
4452300Bv09c40 1/21/00 4:36 PM Page 4

CONVERSION
CONVECT
QUICK
REHEAT
5
Automatic oven
light switch
(on latch
assembly)
(p. 33)
Oven
light
(on right
oven wall)
(p. 33)
Temperature
probe jack
(p. 16)
Oven lock latch
Convection fan
and element
(not shown)
Model and
serial number plate
(on right
mounting rail)
Upper microwave
oven
Oven vent
(above oven
door) (p. 27)
Dual broil elements
(not shown)
Oven light
(on left oven wall)
(p. 33)
Gasket
(p. 28)
Bake element
(hidden under
oven cavity floor)
Lower convection oven
electronic oven controls
(p. 6)
Upper microwave oven
electronic oven controls
(see “Upper Microwave Oven
Use and Care Guide”)
Getting to Know Your
Electric Convection Oven
Oven parts and features
4452300Bv09c40 1/21/00 4:36 PM Page 5

6
CONVERSION
CONVECT
QUICK
REHEAT
Celsius/Fahrenheit
To set your oven to cook in Celsius
instead of Fahrenheit:
PRESS
(Hold for 5 seconds)
You will know you are in Celsius when “F”
disappears. To switch back to Fahrenheit,
press and hold BROIL again for 5 seconds.
(“F” will reappear.)
If you need to convert temperatures from
Celsius to Fahrenheit or vice versa, you
can refer to this chart:
Temperature replacement values
Using Your Electric
Convection Oven
Display/clock
•When you first plug in the oven, both
displays will be fully lit for a few seconds.
Then the microwave oven display will show
the set time and the lower oven display will
show “PF” (power failure).
•If you make an incorrect entry, you will
hear the following:
– For clock entry, you will hear one short
tone and see “CLOCK” on the display.
– For Timer entry, you will hear three
short tones.
– For cook time entry, you will hear three
short tones and see “Err” on the display.
– For stop time entry, you will hear three
short tones and see “Err” on the display.
– For temperature entry, you will hear
three short tones and see “Err” on the
display.
BROIL
MAXI
ECONO
Using the electronic oven control
Timed and
delayed
cooking pads
(pp. 7, 24, 25,
30)
Upper microwave
oven control
panel (see Upper
Microwave Oven
Use and Care
Guide)
Oven
light
pad
(p. 33)
Oven display
(see below)
Oven setting
pads
(pp. 6, 8, 11,
12, 15, 16,
22, 24, 25,
26, 29)
38°C to 100°F
60°C to 140°F
66°C to 150°F
77°C to 170°F
93°C to 200°F
121°C to 250°F
135°C to 275°F
149°C to 300°F
163°C to 325°F
177°C to 350°F
191°C to 375°F
204°C to 400°F
218°C to 425°F
232°C to 450°F
246°C to 475°F
260°C to 500°F
Time of
day/timer
display
(pp. 10, 11)
Number
pads
CLOCK
SET-START
pad
(p. 10)
Timer
pads
(pp. 7, 11)
Lower oven start and
cancel pads
(pp. 7, 8,
10, 12, 13, 15, 17, 18,
20, 22-25, 27, 29, 30
EASY
CONVECT™
conversion
pads
(pp. 20, 27)
Convect full
meal pad
(p. 18)
4452300Bv09c40 1/21/00 4:36 PM Page 6

7
Starting an operation
After programming a function, you must
press START to start the
function. If you do not press
START within 5 seconds of
programming, “START?” will show on the
display as a reminder.
Canceling an operation
LOWER OVEN CANCEL will cancel any
lower oven function. When you
press LOWER OVEN
CANCEL, the large display will
not show anything, unless the oven is too
hot after canceling a Self-Cleaning cycle.
NOTE: You may hear a fan blowing in the
oven after you press LOWER OVEN
CANCEL. This is the cooling fan. It will turn
off when the oven has cooled down.
Changing audible signals
Audible signals tell you if a function is
entered correctly or not. They also tell you
when a cycle is completed.
To change pitch and loudness of key tone:
PRESS
(Hold for 5 seconds)
A short tone will sound and “Snd” and “Hi” or
“Lo” will appear on the display. Repeat the
step above to change to the other setting.
To turn on and off oven reminder tones:
PRESS
(Hold for 5 seconds)
To turn on and off timer reminder tones:
PRESS
(Hold for 5 seconds)
To turn on and off key pad entry and
end-of-cycle tones:
PRESS
(Hold for 5 seconds)
A short tone will sound and “Snd” and “ON”
or “OFF” will appear on the display to tell
you the signals have been changed. Repeat
the step above to turn the signals back on.
Using the control lock
The control lock prevents unwanted use of
the oven by disabling the control panel
command pads.
NOTES:
•Control lock is available only when both
the lower oven and the microwave oven
are not in use. It is not available during the
Self-Cleaning cycle or the Sabbath mode.
•Control lock does not disable the Timer
or Clock.
•Set control lock when cleaning the control
panel to prevent oven from accidentally
turning on.
To lock or deactivate the control panel:
PRESS
(Hold for 5 seconds)
A single tone will sound and “CONTROL
LOCK ” will appear on the display.
To unlock the control panel:
PRESS
(Hold for 5 seconds)
A single tone will sound after 5 seconds and
“CONTROL LOCK ” will disappear from
the display.
Prompt for start
If “START?” is lit, this means that START
has not been pressed. If you do not press
START, the programmed function will
automatically be canceled in 5 minutes.
7
COOK
TIME
START
3
CONTROL
LOCK
3
CONTROL
LOCK
Using Your Electric Convection Oven
4452300Bv09c40 1/21/00 4:36 PM Page 7

8
Setting your oven for the
Sabbath
The Sabbath mode is an oven operation
designed for the special needs of Orthodox
Jews on the Sabbath or holy days. It is only
available to provide a continuous untimed
bake function or, if desired, a timed bake
function. (See below)
NOTE: The Sabbath mode must be set
before it can be activated and remains set
until canceled.
To SET the Sabbath mode:
1. PRESS
2. Press Number Pads to set the
temperature you want.
Example for 325°F (163°C):
3. PRESS
4. To go into the Sabbath mode,
PRESS
(Hold for 5 seconds)
What your oven will/will not do
while in the Sabbath mode:
•The oven will not shut off automatically.
•The temperature display of the lower
oven will show “Sab.”
•To prevent accidental key pad presses,
only the 0 to 9 and START keypads will work.
•No tones will sound.
•No error messages or temperature changes
will be displayed.
•The ON indicator remains lit.
•Heating element icons flash before oven
heating elements turn on or turn off.
•With the oven door closed, heating ele-
ment icons light when the oven is heating
and go off when the oven stops heating.
NOTE: If you open the oven door when the
elements are off, the elements will not turn on.
Elements will not turn on immediately after the
door is closed. If you open the oven door
when the elements are on, the elements will
turn off after a delay. Again, elements will not
turn on immediately after the door is closed.
BAKE
3
CONTROL
LOCK
6
START
25
To change the temperature during
the Sabbath mode:
1. Press a Number Pad for the
desired temperature. Each
Number Pad is programmed for
a specific set temperature:
2. PRESS
(Hold for 1 second)
NOTES:
•It may take the oven up to one half hour
to reach the desired temperature.
•Changing the temperature will not turn
the heating elements on or off immediately.
Also, the display will not show the tempera-
ture change immediately.
To end the Sabbath mode and turn
off oven:
PRESS
(Hold for 5 seconds)
If a power failure occurs during
the Sabbath mode:
The oven will automatically return to the
Sabbath mode at the desired temperature
when power returns.
NUMBER PAD
1
2
3
4
5
6
7
8
9
SET
TEMPERATURE
170°F (75° C)
200°F (95° C)
250°F (120° C)
300°F (150° C)
325°F (163° C)
350°F (177° C)
375°F (191° C)
400°F (204° C)
475°F (245° C)
6
START
Using Your Electric Convection Oven
4452300Bv09c40 1/21/00 4:36 PM Page 8

Oven settings
Using Your Electric Convection Oven
SETTING
BAKE
Use this setting for
standard baking and
roasting.
BROIL (MAXI/ECONO)
Use Maxi Broil setting
for food that covers
most or all of the broiler
grid. Use Econo Broil
setting for food that
covers only the center
of the broiler grid.
CONVECTION BAKE
Use this setting for deli-
cate foods and for bak-
ing breads and cakes.
Use also when baking
large quantities of food
on more than one oven
rack.
CONVECTION BROIL
Use this setting for
broiling thick cuts
of meat.
SETTING INFORMATION
•The bottom element and both top
elements heat up.
•The elements will turn on and off to
maintain the oven temperature.
•Opening the door during Bake will
cause the broil elements to turn off im-
mediately and the bake element
to turn off after 2 minutes.
•Both top elements heat during
Maxi Broil. (Maximum browning
coverage.)
•Only the inner element heats up
during Econo Broil. (Browning
coverage in center only.)
•The elements will turn on and off to
maintain the oven temperature.
•Opening the door during Broil will cause
the broil elements to turn off immediately.
•For faster preheating, both top (and in
some models also the bottom) elements
heat up until oven reaches desired tem-
perature. After preheat, only the rear ele-
ment heats up (and in some models the
bottom element heats up).
•For even heating, the fan at the back of
the oven circulates air in the oven cavity.
•The elements will turn on and off to
maintain the oven temperature.
•Opening the door during Convection
Bake will cause the broil elements, con-
vection fan, and rear element to turn off
immediately. The bake element will turn
off after 2 minutes.
•Both top elements heat up.
•For even heating, the fan at the back of
the oven circulates air in the oven cavity.
•The elements will turn on and off to
maintain the oven temperature.
•Opening the door during Convection
Broil will cause the broil elements and
convection fan to turn off immediately.
DIAGRAM
Bake element
(not visible)
continued on next page
9
4452300Bv09c40 1/21/00 4:36 PM Page 9

Setting the clock
NOTE: You can only set the clock when the
lower oven and the microwave oven are not
cooking food and when the timer is not
counting down.
1. PRESS
2. Set time.
Example for 5:30:
AUTOSENSOR
CLOCK
SET START
CLOCK
SET START
SETTING INFORMATION
•The bottom element and both top
elements heat up.
•For even heating and faster cooking,
the fan at the back of the oven circulates
air in the oven cavity.
•The elements will turn on and off to
maintain the oven temperature.
•Opening the door during Convection
Roast will cause the broil elements and
convection fan to turn off immediately.
The bake element will turn off after
2 minutes.
•The bottom element and both top
elements heat up.
SETTING
CONVECTION ROAST
Use this setting for
roasting and baking
on one rack.
CLEAN
Use this setting for
self-cleaning only.
DIAGRAM
Bake element
(not visible)
Bake element
(not visible)
Using Your Electric Convection Oven
PRESS
5
CONTROL
LOCK
3
0
QUANTITY
3. PRESS
If time has not been entered correctly,
one short tone will sound and “CLOCK”
will reappear on the display. Repeat
Steps 2 and 3 to re-enter the time of day.
To disable the display clock:
You can clear the time of day from the
display by pressing and holding CLOCK
SET/START for 5 seconds. Repeat to see
time of day on display again.
START
OR
CLOCK
SET START
Using the timer
The Timer does not start or stop the oven.
It works like a regular kitchen timer. It can
be set in hours and minutes up to 99 hours,
59 minutes or in minutes and seconds up to
99 minutes, 59 seconds.
10
4452300Bv09c40 1/21/00 4:36 PM Page 10

NOTES:
•Before turning oven on, position oven
rack(s) in desired location.
•Be sure the rack(s) is level.
•Use pot holders or oven mitts to
protect hands if rack(s) must be moved
while oven is hot.
•Do not let pot holder or oven mitt touch
oven bottom.
2. Choose baking setting.
BAKE
PRESS
AUTOSENSOR
CANCEL
SET START
TIMER
Using Your Electric Convection Oven
Baking or convection
baking
NOTE: If you need to convert temperatures
from Celsius to Fahrenheit or vice versa,
see “Celsius/Fahrenheit” in the “Using the
electronic oven control” section.
1. Position racks.
For correct rack placement, see the
“Positioning racks and pans” section.
Your lower oven has 2 racks and 5 rack
positions. Rack position 5 is the highest
position, or farthest from the bottom of the
oven. Rack position 1 is the lowest posi-
tion, or closest to the bottom of the oven.
OR
To cancel the timer during
its operation:
You can cancel the Timer any time during
its operation.
PRESS
1. PRESS
•Once to set minutes and seconds
•Twice to set hours and minutes
2. Enter time to be counted down.
Example for 10 minutes:
3. PRESS
The Timer will begin counting down
immediately after you press TIMER
SET/START or START.
4. When time is up, turn off Timer.
When time is up, you will hear four tones
unless end of cycle tone is disabled.
(See “Changing audible signals” in the
“Using the electronic oven control”
section.) Press TIMER CANCEL to clear
the display. Also, four tones will sound
every minute as an audible reminder
unless they are disabled.
To change the timer during
its operation:
1.Press TIMER SET/START.
2.Enter new desired time.
3.Press TIMER SET/START.
TIMER
SET START
1
0
0
0
QUANTITY QUANTITY
QUANTITY
PRESS
TIMER
SET START
A UTO S ENSOR
BAKE
BAKE
CONVECTION
continued on next page
11
4452300Bv09c40 1/21/00 4:36 PM Page 11

12
3. Set temperature (optional).
Do this step if you want to set a tempera-
ture other than 350°F (177°C) for Bake.
NOTE: See a reliable cookbook or your
convection oven cookbook for tempera-
ture recommendations.
4. PRESS
The temperature display will show LO until
the temperature reaches 170°F (77°C).After
that, the temperature display will show the
actual oven temperature at each 5°F (3°C)
increase and stop at the set temperature.
One long tone will sound when the oven is
preheated.
5. Put food in oven.
NOTE: If you want to change the baking
temperature after baking has begun,
repeat Steps 2, 3, and 4.
6. After cooking, PRESS
PRESS
START
Using Your Electric Convection Oven
7
5
3
CONTROL
LOCK
Convection baking tips
•Do not use aluminum foil when convection
baking. Aluminum foil may block airflow.
•Reduce recommended recipe oven
temperature by approximately 25°F
(16°C). Use EASY CONVECT™
CONVERSION (see the “Using EASY
CONVECT CONVERSION” section).
•For some recipes, you can reduce con-
vection baking time compared to standard
baking times. Use EASY CONVECT™
CONVERSION.
NOTE: Cooking time may be longer when
you use more than one rack.
•When baking on two or three racks, use
the CONVECTION BAKE setting for more
even results. (You can also use only one
rack when convection baking.)
•To use three racks during convection
baking, place one rack in position 5 (the
highest position), another rack in position
1 (the closest to the oven bottom), and the
third rack in position 3. This allows all
three racks to be an equal distance apart
for better baking.
•Stagger cake pans or other cookware in
opposite directions on each rack when
three racks are used. This will make sure
pans are not directly over each other.
Convection roasting
NOTE: See the “Roasting tips” in the “Cook-
ing tips” section.
1. Prepare oven.
Position the rack properly. For correct
rack placement, see “Baking or convec-
tion baking” earlier in this section. Place
food in the oven. For large roasts and
turkeys, place rack in position 1 or 2.
(Preheating is not necessary when
roasting.)
AUTOSENSOR
ROAST
CONVECTION
2. Choose setting.
PRESS
4452300Bv09c40 1/21/00 4:36 PM Page 12

•Check pork and poultry with a
thermometer in 2 to 3 places to ensure
adequate doneness.
•Poultry and roasts will be easier to
carve if loosely covered with foil and
allowed to stand 10 to 15 minutes after
removal from the oven.
•You can reduce roasting times and
temperatures for most standard recipes
when using the Convection Roast setting.
See convection roasting chart in your
convection oven cookbook for recom-
mended roasting times and temperatures.
•Use the convection roasting rack on the
broiler pan and grid (all included with your
oven). (The convection roasting rack rests
on the broiler pan and grid.) The long side
of the rack should be parallel with the oven
door for best heat distribution and airflow.
Using Your Electric Convection Oven
Positioning racks and
pans
Place the oven racks where you need them
before turning on the oven.
•To move a rack, pull it out to the stop
position, raise the front edge and lift it out.
•Be sure the rack(s) is level.
•Use pot holders or oven mitts to protect
your hands if rack(s) must be moved while
the oven is hot.
•For best perfor-
mance, cook on
one rack. Place
the rack so the
3. Set temperature (optional).
Do this step if you want to set a
temperature other than 300°F (149°C).
NOTE: See your convection oven cook-
book for temperature recommendations.
4. PRESS
NOTES:
•After the temperature reaches 170°F
(77°C), the temperature display will
show the actual oven temperature at
each 5°F (3°C) increase and stop at
just about the set temperature.
•If you want to change the roasting
temperature after roasting has begun,
repeat Steps 2, 3, and 4.
5. After cooking, PRESS
3
CONTROL
LOCK
2
5
START
Convection
roasting tips
•Spatter can be reduced by lining the bot-
tom of the roasting pan with lightly crushed
aluminum foil.
•Use an accurate meat thermometer or
temperature probe (see the “Using the
temperature probe” section) to determine
when meat has reached desired degree of
doneness. Insert the thermometer or probe
into the center of the thickest portion of the
meat or inner thigh or breast of poultry. For
an accurate reading, the tip of the ther-
mometer or probe should not touch fat,
bone, or gristle.
•After reading the thermometer once,
push it further into the meat 1⁄2inch
(1.7 cm) or more and read again. If the
temperature drops, return the meat to the
oven for more cooking. continued on next page
13
PRESS
4452300Bv09c40 1/21/00 4:36 PM Page 13

14
Where to place pans:
WHEN YOU
HAVE
1 pan
2 pans
3 or 4 pans
PLACE
In center of the oven rack.
Side by side or slightly
staggered.
In opposite corners on
each oven rack. Stagger
pans so no pan is directly
over another.
Rack placement for specific foods:
FOOD
Frozen pies, large
roasts, turkeys,
angel food cakes
Bundt cakes, most
quick breads, yeast
breads, casseroles,
meats
Cookies, biscuits,
muffins, cakes,
nonfrozen pies
RACK POSITION
1st or 2nd rack
guide from bottom
2nd rack guide
from bottom
2nd or 3rd rack
guide from bottom
NOTE: For information on where to place
your rack when broiling, see “Broiling
guidelines” later in this section.
Bakeware choices
Baking performance is affected by the type of bakeware used. Use the bakeware size
recommended in the recipe.
BAKEWARE TYPE
Light colored aluminum • Light golden crusts
• Even browning • Use temperature and time
recommended in recipe.
Dark aluminum and other
bakeware with dark, dull,
and/or non-stick finish
• Brown, crisp crusts
• May reduce baking temperature 25°F (16°C).
• Use suggested baking time.
• Use temperature and time
recommended in recipe for pies,
breads, and casseroles.
• Place rack in center of oven.
Ovenproof glassware,
ceramic glass, or ceramic • Brown, crisp crusts •
May reduce baking temperature 25°F (16°C).
Insulated cookie sheets
or baking pans • Little or no bottom browning • Place in the bottom third of oven. • May need to increase baking time.
Stainless steel • May need to increase baking time.
• Crisp crusts
Stoneware • Follow manufacturer's instructions.
• Light, golden crusts
• Uneven browning
BEST USED FOR GUIDELINES
Using Your Electric Convection Oven
top of the food
will be centered
in the oven.
•When cooking with two racks, arrange
the racks on the 2nd and 4th rack guides.
Two sheets of cookies may be baked if
sheets are switched at approximately
three quarters of the total bake time.
Increase baking time, if necessary.
•For best results allow 2 inches (5 cm) of
space around each pan and between
pans and oven walls. Hot air must
4452300Bv09c40 1/21/00 4:36 PM Page 14

Using Your Electric Convection Oven
BAKE
Using aluminum foil
•Do not line the oven bottom with any
type of foil,
liners, or
cookware.
Permanent
damage will
occur to the
oven bottom
finish.
•Do not cover
the entire rack
with aluminum
foil. Doing so will reduce air circulation
and overall oven performance.
•To catch spillovers from pies or
casseroles place foil on the oven rack
below. Foil should be turned up at edges
and be at least 1 inch (2.5 cm) larger than
dish.
•Place tent-shaped foil loosely over meat
or poultry to slow down surface browning
for long term roasting. Remove foil for the
last 30 minutes.
•Use narrow strips of foil to shield
piecrust edges if browning too quickly.
Adjusting oven
temperature
Although your new oven is properly adjusted
to provide accurate temperatures, it may
cook faster or slower than your old oven.
If, after using the oven for a period of
time, you are not satisfied with the
baking/roasting results, you can change the
offset temperature by following the steps
below. The control will “remember” the
selected offset even after the power has
been interrupted or lost.
A UTO S ENSOR
BAKE BROIL
MAXI
ECONO
BROIL
MAXI
ECONO
NOTE: DO NOT measure oven temperature
with a thermometer. Opening the oven door
will lower the oven temperature and give
you an inaccurate reading. Also, the ther-
mometer temperature reading will change
as your oven cycles.
1. PRESS
Release the pad when a number and
CAL appear on the temperature display
and you hear a tone.
2. Set new offset temperature.
You can set the offset temperature
adjustment as low as -35°F (-21°C) or as
high as +35°F (21°C). Each time you
press BAKE, the displayed temperature
will increase by 5°F (3°C). Each time you
press BROIL, the displayed temperature
will decrease by 5°F (3°C). (To determine
the amount of adjustment needed, see
the chart later in this section.)
NOTE: If there is no “F” after the
temperature, you are in the Celsius
mode.
3. PRESS
NOTE: If you press LOWER OVEN
CANCEL instead of START, the offset
temperature will stay the same.
(Hold for 5 seconds)
BAKE
PRESS
OR
START
15
continued on next page
4452300Bv09c40 1/21/00 4:36 PM Page 15

16
Using Your Electric Convection Oven
Using the temperature
probe
The Temperature Probe is the most accurate
guide to the degree of doneness of meat. Use
it when baking, roasting any type of meat or
poultry, or cooking casseroles with liquid.
NOTES:
•Do not use the Temperature Probe when
broiling, convection broiling, dehydrating, or
raising bread.
•Unplug the Temperature Probe before self-
cleaning the oven.
1. Insert probe into food.
Insert the probe into the center of the thick-
est portion of meat or into the inner thigh
or breast of poultry, away from fat or bone.
2. Put food in oven.
Place meat on the convection roasting
rack, place rack on broiler pan and grid,
and place pan in the center of the oven.
3. Connect probe to oven.
Locate the Temperature Probe jack on the
right side of the oven wall. Insert plug into
jack. (Keep the top of the probe as far as
possible from the heat source.)
4. Close oven door.
5. Set temperature (optional).
Do this step if you want to set an internal
food temperature (from 130°F [54°C]
to 190°F [88°C]) other than 160°F (72°C).
NOTE: See a reliable cookbook or your
convection oven cookbook for internal
food temperature recommendations.
6. Choose cook setting:
•BAKE,
•CONVECTION BAKE, or
•CONVECTION ROAST.
NOTE: If you press BROIL,
CONVECTION BROIL, or CLEAN
pads, the display will show “pull prb out.”
PRESS
PRESS
BAKE
(example
for Bake)
5
1
8
AUTOSENSOR
BAKE
TO COOK
FOOD …
A little more
Moderately more
Much more
A little less
Moderately less
Much less
ADJUST BY THIS
NUMBER OF DEGREES
+ 5°F to +10°F
(+3°C to +6°C)
+15°F to +20°F
(+8°C to +11°C)
+25°F to +35°F
(+14°C to +19°C)
-5°F to -10°F
(-3°C to -6°C)
-15°F to -20°F
(-8°C to -11°C)
-25°F to -35°F
(-14°C to -19°C)
How to determine the amount of
adjustment needed
The following chart tells you how much to
adjust the offset temperature to get the
desired cooking results. You can determine
cooking results by amount of browning,
moistness, and rising times for baked foods.
4452300Bv09c40 1/21/00 4:36 PM Page 16

17
7. Set temperature (optional).
Do this step if you want to set an oven
temperature other than the one dis-
played.
NOTE: See a reliable cookbook or your
convection oven cookbook for oven tem-
perature recommendations.
PRESS
3
CONTROL
LOCK
7
5
8. PRESS
NOTES:
•If you do not choose a cook setting
and press START, the oven will default
to bake at 350°F (177°C) and start.
If you want to cook with another setting
or at another temperature, do Steps 6
and 7 and press START.
•The temperature display will show
the set oven temperature throughout
temperature probe cooking.
•After the food temperature reaches
130°F (54°C), the probe display will
show the actual food temperature at
each 5°F (3°C) increase and stop at
the set temperature. Four tones will
sound and “End” will show when food
reaches the set temperature. The oven
then shuts off.
•If you want to change the probe
temperature after cooking has begun:
– Unplug the probe, then plug it back
in. You will be prompted for a new
probe temperature. Next, repeat
Steps 4, 5, and 8 in that order. You
may also change the oven tempera-
ture at this point by pressing the
desired cook setting pad again.
OR
START
– You may change the cook setting at
this point by pressing the desired
cook setting pad again.
wWARNING
Burn Hazard
Use an oven mitt to remove
temperature probe.
Do not touch broil element.
Failure to follow these instructions
can result in burns.
9. After cooking, unplug probe.
The probe symbol will remain lit until
you unplug the Temperature Probe.
10. Remove food from oven.
(This prevents overcooking.)
11. Clean probe.
Wash with a soapy sponge and dry thor-
oughly. Use a plastic scouring pad to
remove cooked-on foods. You can also
clean the probe in a dishwasher.
Using Your Electric Convection Oven
4452300Bv09c40 1/21/00 4:36 PM Page 17

18
Using CONVECT FULL
MEAL
CONVECT FULL MEAL lets you choose
from among ten preset oven convection
cooking cycles, all using the convection fan.
These cycles store commonly used cooking
times, cooking temperatures, and probe
temperature settings. CONVECT FULL
MEAL saves you time by limiting the num-
ber of pads you have to press when cooking
at a favorite setting. CONVECT FULL MEAL
also lets you set your own favorite cycle
(either convection or nonconvection).
1. Place food in cold oven.
If you need the Temperature Probe for
your cycle (settings 6 to 0 in the
“Convect full meal chart” later in this sec-
tion), insert probe into food. Place food in
oven and plug probe into jack.
2. PRESS
Using Your Electric Convection Oven
AUTOSENSOR
CONVECT
FULL
MEAL
3. Press desired Number pad.
Use the “Convect full meal chart”
later in this section as your guide for se-
lecting a cycle.
NOTES:
•You can change the Convect full meal
cycle any time before pressing the Start
pad by repeating Step 3.
•You can program your own setting,
which you can then select in the future
by pressing just CONVECT FULL MEAL
and START pads. (See “To program
your own setting” later in this section for
more information.)
4. PRESS
5. When the CONVECT FULL
MEAL cycle is done:
Four tones will sound, and the display will
show “End.” (Unless they have been
disabled) Four reminder tones will sound
every minute until you open the door,
remove the probe, or press LOWER
OVEN CANCEL.
PRESS
1
START
4452300Bv09c40 1/21/00 4:36 PM Page 18

19
Convect full meal chart
FOOD OR MEAL
Meal#1: Spinach and
ricotta stuffed meat loaf,
Baked potatoes, Fall
apple cake
Meal#2: Pesto stuffed
turkey breast, Caramel-
sweet potato casserole,
Rhubarb-pineapple crisp
Meal#3: Pork chops
with currant-nut stuffing,
Cherry cobbler
Meal#4: Herb and pecan
fried chicken, Crispy
potato wedges, Apple-
sauce rhubarb muffins
Meal#5: Spicy red snap-
per, Gruyere pecan
biscuits
Beef, rare
Beef, medium
Pork
Beef, well done
Ham, fully cooked
Casseroles
SETTING
NUMBER
1
2
3
4
5
6
7
8
9
0
CONVECTION
CYCLE
Conv. Bake
Conv. Roast
Conv. Roast
Conv. Bake
Conv. Bake
Conv. Roast
Conv. Roast
Conv. Roast
Conv. Roast
Conv. Bake
oven temp
325°F (163°C)
325°F (163°C)
350°F (177°C)
375°F (191°C)
425°F (218°C)
325°F (163°C)
325°F (163°C)
325°F (163°C)
300°F (149°C)
325°F (163°C)
TIME or
PROBE TEMP
1 hr
11⁄2hrs
40 min
45 min
20 min
140°F (60°C)
155°F (68°C)
165°F (74°C)
135°F (56°C)
160°F (71°C)
NOTE: For the recipes for Meals #1 – #5 see the cookbook that comes with your oven.
To program your own setting:
1. Press CONVECT FULL MEAL.
2. Press the Command Pad to the cook
setting you want (for example, BAKE).
3. Enter the temperature and cook time
you want. (The default is Bake at 170°F
(75°C) for 2 hours.) Entering a cook time
of 0 minutes lets you do untimed cooking.
4. To save only, press CONVECT FULL
MEAL.
To cook with this setting immediately
and save it, press START.
When programming your own setting:
1. Start with meat or main dish items (times
are more critical with these items).
2. Choose baked goods with bake tempera-
tures similar to those of meat or main
dish items. Convection baking time of +/-
10 to 15 minutes and temperatures of +/-
25 to 50 degrees are acceptable.
3. Choose vegetables and fruits last.
Using Your Electric Convection Oven
4452300Bv09c40 1/21/00 4:36 PM Page 19

20
Using EASY CONVECT™
CONVERSION
EASY CONVECT Conversion lets you
convection cook without entering convection
cook temperatures and times. Simply enter
the standard cook temperature and time for
the food to be cooked. The oven will reduce
the temperature, or the temperature and
time, for convection cooking. (Convection
temperatures and times are not as long
because the heated air is circulated in the
oven cavity for quicker cooking.)
NOTE: The converted temperatures and
times are not precise because the food
categories you choose from are general.
(See “EASY CONVECT Conversion setting
chart” later in this section for which foods
you can cook in each category.) To ensure
proper cooking, the oven will prompt you to
check food at the end of cook time. If food
needs more cooking, the oven will continue
to cook. If food does not need more cooking,
press LOWER OVEN CANCEL.
1. Place food in oven.
NOTE: For Baked Goods and Other
Foods, place food in the oven after the
oven has been preheated.
2. Press one of three EASY
CONVECT CONVERSION pads.
Example for Meats:
AUTOSENSOR
BAKED
GOODS MEATS OTHER FOODS
CONVERSION
EASYCONVECT
PRESS
MEATS
3. Enter standard cook
temperature.
4. Enter standard cook time.
NOTE: To delay convection cooking, after
Step 4, press STOP TIME and enter the
desired stop time. Cooking will start at the
time equal to the stop time less the cook
time. (Example: A cook time of 1 hour and
a stop time of 4:00 would give you a start
time of 3:00.)
5. PRESS
NOTES:
•The actual temperature reduction and
time savings are different for each food
category and oven type.
•For Baked Goods and Other Foods,
place food in the oven after the oven
has been preheated.
6. At end of cook time (nonde-
layed cooking):
7. Open door and check food
(nondelayed cooking).
If you want to continue cooking, close
door and the oven will continue cooking.
If you do not want to continue cooking,
press LOWER OVEN CANCEL.
8. When stop time is reached (de-
layed cooking only):
Four tones will sound, and the display
will show “End.” Four reminder tones will
sound (unless they have been disabled)
every minute until you open the door or
press LOWER OVEN CANCEL.
PRESS
3
CONTROL
LOCK
2
5
1
0
QUANTITY
PRESS
START
Using Your Electric Convection Oven
0
QUANTITY
wWARNING
Food Poisoning Hazard
Do not let food sit in oven more than
one hour before or after cooking.
Doing so can result in food poisoning
or sickness.
4452300Bv09c40 1/21/00 4:36 PM Page 20
