KitchenAid KECC501GAL0 User manual

COOKTOP PARTS
1
For Models: KECC501GBL0, KECC501GWH0, KECC501GAL0
(Black) (White) (Almond)
30" ELECTRIC
BUILT−IN
COOKTOP
10−98 Litho in U.S.A. (rle) Part No. 885411

COOKTOP PARTS
2
For Models: KECC501GBL0, KECC501GWH0, KECC501GAL0
(Black) (White) (Almond)
885411
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2 Cooktop, Glass
3191909 Black
3191878 White
3191879 Almond
3 246119 Screw
4 3192163 Bracket, Switch
Mounting
6 3191791 Spring Locator (8)
7 Switch, Infinite
4454541 Use W/2400W
Left Front Burner
3191050 Use W/1700W
Right Rear Burner
3191049 Use W/1400W
Left Rear Burner
3191049 Use W/1200 W
Right Front Burner
8 3183956 Seal, Switch Shaft
9 3191945 Light, Indicator
10 Knob, Control (4)
9750372FF Black
9750372FW White
9750372FT Almond
11 3191162 Box, Burner
13 9750835 Bumper, Silicone
14 3196537 Screw
15 3182435 Seal, Switch (4)
16 Switch, Limiter
3191991 Use W/3191983
Element
3191990 Use W/3191984
Element
3191988 Use W/3191982
Element
3191989 Use W/3191981
Element
17 311865 Screw
20 3191515 Rail, Element (2)
21 3192268 Rail, Element (1)
22 3191343 Lamp, Hot
Surface Indicator
24 Element, Surface
(Includes # 16)
3191983 2400W Left Front
3191984 1200W Right Front
3191982 1700W Right Rear
3191981 1500W Left Rear

MISCELLANEOUS PARTS
3
For Models: KECC501GBL0, KECC501GWH0, KECC501GAL0
(Black) (White) (Almond)
885411
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
LIT3191771 Installation
Instructions
LIT3191793 Wiring Diagram
LIT3191524 Use & Care Guide
Miscellaneous
3172515 Hardware, Mounting
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
3184477 Cleaner, Glass
3183488 Scraper, Glass
WIRING HARNESS PARTS
3192263 Wiring Harness
Surface Unit
313438 Clip, Harness
3400015 Screw, Ground
3192220 Conduit
