KitchenAid KECC502GBL05 User manual

COOKTOP PARTS
1
For Models: KECC502GBL05, KECC502GWH05
(Black) (White)
9−03 Litho in U.S.A. (cre) Part No. 8186135
30" ELECTRIC
BUILT−IN
COOKTOP

COOKTOP PARTS
2
For Models: KECC502GBL05, KECC502GWH05
(Black) (White)
8186135
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT8285316 Installation
Instructions
LIT4456012 Wiring Diagram
LIT8285368 Use & Care Guide
LIT3191638 Tips−Safer Cooking
LIT4455462 Energuide Label
2 Cooktop, Glass
4455549 Black
4455300 White
3 246119 Screw
4 4455421 Bracket, Switch
Mounting
6 3191791 Spring Locator (8)
7 Switch, Infinite
3191049 LR − RF
4456027 RR − LF
8 3183956 Seal, Switch Shaft
9 3191945 Light, Indicator
10 Knob, Control (4)
9750372FF Black
9750372FW White
11 4456959 Box, Burner
12 4455917 Bracket, Mounting
3400093 Screw
14 3196537 Screw
16 8285469 Seal, Switch
17 311865 Screw
20 8285104 Rail, Element (2)
21 3192268 Rail, Element (1)
22 3191343 Lamp, Hot
Surface Indicator
24 Element, Surface
8523698 1200W − RF
8523697 1500W − LR
4456507 1000/1800W − RR
8523693 1000/2400W − LF
25 4455468 Shield−Heat,
Control
26 3191839 Seal, Heat Shield
3192737 Seal, Heat
3192439 Seal, Limiter

MISCELLANEOUS PARTS
3
For Models: KECC502GBL05, KECC502GWH05
(Black) (White)
8186135
Illus. Part
No. No. DESCRIPTION
Miscellaneous
3172515 Mtg. Hardware Kit
3192408 Bracket,
Support (2)
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
4456028 Wire, Jumper
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
3191048 Cleaner, Glass
WIRING HARNESS PARTS
4456763 Wiring Harness
3400015 Screw, 10−32 x 3/8
4456512 Conduit, Harness
