30" (76.2 CM) GAS DOWNDRAFT COOKTOP
PRODUCT MODEL NUMBERS CUTOUT DIMENSIONS
KGCD807X
A. 28
⁵⁄₈
" (72.7 cm) maximum
B. 19
¹⁵⁄₁₆
" (50.6 cm) maximum
C. 9
⁵⁄₁₆
" (21.6 cm)
D. 6
⁴⁹⁄₆₄
" (17.2 cm)
E. 2
¹⁄₈
" (5.4 cm) minimum space to front edge of cooktop
F. Floor exhaust option
G. 6
¹⁄₈
" (15.6 cm) for 6" (15.2 cm) vent system and 5
¹⁄₈
" (13.1 cm) for
5" (12.7 cm) vent system
H. 9
⁵⁄₁₆
" (21.6 cm)
I. 13
³⁄₈
" (33.9 cm) from the top of the countertop surface
J. Wall exhaust option
AB
CD
E
F
G
H
I
J
30" (76.2 cm) Cooktop
A. 21³⁷⁄₆₄" (54.8 cm) with stainless steel trim or
21½" (54.6 cm) without stainless steel trim
B. 19⁴⁷⁄₆₄" (50.1 cm) screw head to screw head
C. Model/serial rating/clearance plate location
A. 29
¹⁵⁄₁₆
" (76.1 cm) without
stainless steel trim
B. 30
¹⁄₃₂
" (76.3 cm) with
stainless steel trim
C. 12
²⁹⁄₆₄
" (31.6 cm) centerline of
cooktop to centerline of gas
manifold pipe
D. 7
⁵⁄₁₆
" (18.6 cm)
E. 3
³⁹⁄₆₄
" (9.2 cm)
F. 15" (38.1 cm)
G. 2
⁵⁄₃₂
" (5.5 cm) recommended
minimum cabinet to motor
clearance
H. 14
¹¹⁄₃₂
" (36.4 cm)
I. 11
⁴⁹⁄₆₄
" (29.9 cm)
J.
28³⁄₈
" (72.1 cm) screw head to
screw head
A
B
C
A
B
C
D
E
F
G
HI
J
PRODUCT DIMENSIONS
GAS SUPPLY REQUIREMENTS
Type of Gas
Natural Gas:
This cooktop is design-certified by CSA International for use with
Natural gas or, after proper conversion, for use with LP gas.
● This cooktop is factory set for use with Natural gas. If converting to
LP gas, see the “LP Gas Conversion” instructions provided in the
package containing literature. The model/serial rating plate located on
the underside of the cooktop base has information on the types of
gas that can be used. If the types of gas listed do not include the
type of gas available, check with the local gas supplier.
LP Gas Conversion:
Conversion must be done by a qualified service technician.
No attempt shall be made to convert the cooktop from the gas
specified on the model/serial rating plate for use with a different gas
without consulting the serving gas supplier. See the Gas Conversion
instructions provided in the package containing literature.
Gas Supply Line
● Provide a gas supply line of ³⁄₄" (1.9 cm) rigid pipe to the cooktop
location. A smaller size pipe on longer runs may result in insufficient
gas supply. Pipe-joint compounds that resist the action of LP gas
must be used. Do not use TEFLON®† tape. With LP gas, piping or
tubing size should be ¹⁄₂" minimum. Usually, LP gas suppliers
determine the size and materials used in the system.
Flexible metal appliance connector:
● If local codes permit, use a ¹⁄₂" or ³⁄₄" I.D. flexible stainless steel
tubing gas connector, designed by CSA to connect the cooktop to
the rigid gas supply line.
ELECTRICAL REQUIREMENTS
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice. Ref. W10305290A
8/25/10
Page 1 of 2
● A 120 volt, 60 Hz, AC only, 15-amp, fused electrical circuit is
required. A time-delay fuse or circuit breaker is also recommended. It
is recommended that a separate circuit serving only this cooktop be
provided.
†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and
Company.
CABINET DIMENSIONS
A. 30" (76.2 cm)
B. Combustible area above countertop (shown by dashed box above)
C. 30" (76.2 cm) minimum clearance between top of cooktop platform
and bottom of uncovered wood or metal cabinet (24" [61.0 cm]
minimum clearance if bottom of wood or metal cabinet is covered
by not less than ¼" [0.6 cm] flame retardant millboard covered with
not less than No. 28 MSG sheet steel, 0.015" [0.04 cm] stainless
steel, or 0.024" [0.06 cm] aluminum or 0.020" [0.05 cm] copper)
D. 13" (33.0 cm) recommended upper cabinet depth
E. 2
¹⁄₈
" (5.4 cm)
F. 1 9
¹⁵⁄₁₆
" (50.6 cm)
G. 18" (45.7 cm) minimum clearance from upper cabinet to countertop
within minimum horizontal clearances to cooktop
H. Junction box or outlet; 12" (30.5 cm) minimum from bottom of
countertop
I. Junction box or outlet; 10" (25.4 cm) from right-hand side of
cabinet
J. 28
⁵⁄₈
" (72.7cm) on 30" (76.2 cm) models
K. 8" (20.3 cm) minimum distance to nearest left and right side
combustible surface above cooktop
L. 2" (5.1 cm) minimum clearance between back wall and countertop
M. Gas line opening - Wall: anywhere 6" (15.2 cm) below underside of
countertop on the left side. Cabinet floor: anywhere within
6" (15.2 cm) of rear wall on the left side is recommended.
N. 25" (63.5 cm) depth of countertop
B
D
A
EF
H
I
K
L
K
M
C
G
N
J
M
NOTES: After making the countertop cutout, some installations may require
notching down the base cabinet side walls to clear the cooktop base. To avoid this
modification, use a base cabinet with sidewalls wider than the cutout.
● A minimum side clearance of 6" (15.2 cm) is recommended between side of
cooktop and side wall for maximum ventilation performance.
● A minimum clearance of 2" (5.1 cm) is recommended between the motor/blower
and cabinet for proper cooling. A 6" (15.2 cm) clearance is recommended for
servicing access.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice. Ref. W10305290A
8/25/10
Page 1 of 2
