30" Freestanding and Slide-In Gas Range
®
PRODUCT MODEL NUMBERS OVERALL DIMENSIONS
CABINET OPENING DIMENSIONS
KGRS807S
KGRS807X
KGSK901S
KGSS907S
KGSS907X
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
The cooktop sides of the slide-in range fit over
the cutout edge of your countertop.
If you have a square finish (flat) countertop and
the opening width is 30" (76.2 cm), no
countertop preparation is required.
Formed front-edged countertops must have
molded edge shaved flat ³⁄₈" (1.0 cm) from each
front corner of opening.
Tile countertops may need trim cut back ³⁄₈"
(1.0 cm) from each front corner and/or rounded
edge flattened.
If countertop opening width is greater than 30"
(76.2 cm), adjust the ³⁄₈" (1.0 cm) dimension.
Countertop must be level. Place level on
countertop, first side to side; then front to back.
If countertop is not level, range will not be level.
Range must be level for satisfactory baking
conditions.
Use ³⁄₄" (1.9 cm) rigid pipe gas supply line to
the range location. A smaller size pipe on long
runs may result in insufficient gas supply. With
LP gas, piping or tubing size can be ¹⁄₂"
(1.3 cm) minimum. If local codes permit, it is
recommended that new flexible metal tubing,
design-certified by CSA, 4-5 ft (122-152.4 cm)
long, ¹⁄₂" (1.3 cm) or ³⁄₄" (1.9 cm) I.D., be used
for connecting the range to the rigid gas supply
line. A ¹⁄₂" (1.3 cm) male pipe thread is needed
for connection to pressure regulator female
pipe threads. An easily accessible individual
manual shutoff valve must be located in the
same room, but external to the range.
120-volt, 60 Hz, AC-only, 15 amp, fused
electrical circuit is required. A separate circuit
is recommended. A time-delay fuse or circuit
breaker is recommended.
Ref. W10246118C
1/28/11
18" (45.7 cm)
upper cabinet
to countertop
18" (45.7 cm)
upper cabinet
to countertop
13" (33 cm) upper
cabinet depth
13" (33 cm) max.
upper cabinet depth
30" (76.2 cm) min.
opening width
30" (76.2 cm) min.
opening width
For minimum
clearance to top
of the cooktop,
see NOTE.
For minimum
clearance to top
of the cooktop,
see NOTE.
30" (76.2 cm)
min. opening
width
30" (76.2 cm)
min. opening
width
This shaded area
recommended for
installation of
rigid gas pipe.
This shaded area
recommended for
installation of
rigid gas pipe.
This shaded area
recommended for
installation of
outlet or
junction box.
This shaded area
recommended for
installation of
outlet or
junction box.
Available area
for gas and electric
installation.
Available area
for gas and
electric
installation.
6"
(15.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)
Grounded
outlet Grounded
outlet
7" (17.8 cm) 7" (17.8 cm)
5" (12.7 cm) min.
clearance from
both sides of the
range to the side
wall or other
combustible
material.
Cabinet door
or hinge
should not
extend into
the cutout.
Cabinet door
or hinge
should not
extend into
the cutout.
5" (12.7 cm) min.
clearance from
both sides of the
range to the side
wall or other
combustible
material.
22 " (58.3 cm)
opening depth
Freestanding Range
*Range can be raised approximately 1" (2.5 cm) by adjusting
the leveling legs.
**When installed in a 24" (61 cm) base cabinet with 25" (63.5 cm)
countertop; front of oven door protrudes 1" (2.5 cm) beyond
24" (61 cm) base cabinet.
Slide-in Range
*Range can be raised approximately 1" (2.5 cm) by adjusting
the leveling legs.
**
A. " (14.6 cm)
B. 30" (76.2 cm)
C. 41 " (106 cm) overall height
with leveling legs screwed all
the way in.
D. 36" (91.4 cm) cooktop trim
height with leveling legs
screwed all the way in*
E. Model/serial number plate
(located on the right-hand
side oven door trim)
F. 2 7 " (69.2 cm) max. from
handle to standoff at back
of range**
A
B
D*
C
F**
A. 30 " (77.6 cm)
B. 35 " (90.5 cm) height to
underside of cooktop edge
with leveling legs screwed
all the way in*
C. Model/serial number plate
(located on the right-hand
side oven door trim)
D 30" (76.2 cm)
F. 23" (58.4 cm) countertop
notch to rear of cooktop
B*
D
A
E**
F
on models KGRS807XSP and
KGSS907XSP) from handle to
standoff at back of range**
30"
(76.2 cm)
30 "
(78.1 cm)
"
(1.0 cm)
NOTE: 24" (61 cm)
minimum when bottom of
wood or metal cabinet is
covered by not less than ¹⁄₄"
(0.64 cm) flame retardant
millboard covered with not
less than No. 28 MSG sheet
steel, 0.015" (0.4 mm)
stainless steel, 0.024"
(0.6 mm) aluminum or
0.020" (0.5 mm) copper.
30" (76.2 cm) minimum
clearance between the top of
the cooking platform and the
bottom of an uncovered
wood or metal cabinet.
If installing a range hood or
microwave hood combination
above the range, follow the
range hood or microwave
hood combination installation
instructions for dimensional
clearances above the cooktop
surface.
GAS SUPPLY REQUIREMENTS
ELECTRICAL REQUIREMENTS
SLIDE-IN RANGE COUNTERTOP PREPARATION
