KitchenAid KUI015NNL User instructions

Outdoor Ice Maker
PRODUCT MODEL NUMBERS
CABINET OPENING DIMENSIONS
DRAIN REQUIREMENTS
KUI015NNL KUI015NNT
Electrical: 115 volt, 60 Hz, AC only,
15- or 20 -amp grounded Electrical supply is
required. A time-delay fuse or circuit breaker and
separate circuit is recommended.
Water: A cold water supply using 1/4" (6.35 mm)
OD soft copper tubing with shutoff valve.
Drain: Either a gravity-drain system or
condensate pump to carry water to an existing
drain. The ice maker is provided with a gravity
drain system.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 2225453B
12-04-07
®
15"
(38.1 cm)
24"
(60.1 cm)
8¹⁄₂"
(21.6 cm)
25"
(63.5 cm)
34"
(86.4 cm)
Min.
34
1/2
"
(87.6 cm)
Max.
A
B
A. Recommended location for
electrical and plumbing fixtures.
B. Floor level
Drain lines must have a minimum of 5⁄8" (15.88 mm) inside diameter.
Drain lines must have a 1" drop per 48" (2.54 cm drop per 122 cm) of run or
1⁄4" drop per 12" (6.35 mm per 30.48 cm) and must not have low points
where water can settle.
You must maintain a 2" (5.08 cm) air gap between the drain tube outlet and
the floor drain.
To ensure proper ventilation for your ice maker, the front side must have
at least 15" (38.1 cm) of clearance. The unit may be closed-in on the top
and three sides, but the installation should allow the ice maker to be
pulled froward for servicing if necessary.
Choose a well ventilated area with temperatures above 45°F (7°C) and
below 100°F (38°C). Best results are obtained between 70°F (21°C) and
90°F (32°C). It is recommended that the unit be installed in an area
protected from the elements, such as wind, rain, water spray, or drip.
The ice maker must be shut down if temperatures drop below 45°F
(7°C). Additionally, if temperatures drop below 32°F (0°C) the water
must be drained completely from ice maker and all water lines to avoid
damage.
