KitchenAid KUIS185EBL User manual

1 2175696 Shell
2 2175619 Front, Shell
3 756330 Door, Inner Bin
4 758655 Liner, Door
5 593192 Plug, Hinge
6 593104 Strip, Tapping (2)
7 2175684 Trim, Door (2)
8 593184 Rail, R.S.
593185 Rail, L.S.
9 681459 Screw, 8-32 x 5/8 (6)
10 758492 Washer (2)
11 759213 Tube, Water Fill
12 2180752 Liner (Includes Illus. 10, 11, 17, 19, 21, and 35)
13 2172898 Gasket, Bottom
14 596023 Clamp (2)
15 758921 Gasket
16 487909 Screw #8 x 1/2
17 596807 Grommet
18 756891 Insulation, Bottom, Foam
19 681542 Nut
21 758220 Stud (2)
22 593183 Well, Bin Thermostat
23 596812 Clip, Panel (12)
24 2175686 Pocket, Handle
25 758746 Panel, Exterior
26 758720 Panel, Outer
28 593577 Connector, Hose
29 585158 Scoop
30 680811 Screw, 10-32 x 3/8
31 2175685 Handle, Recessed
32 2174781 Harness, Cabinet
34 680930 Thumbscrew, 10-1/2
35 596715 Well Nut (3)
36 2175688 Trim, Side (2)
37 758608 Insulation, Door
38 681196 Screw
39 681419 Thumbscrew
42 681613 Washer
44 2175689 Trim, Top And Bottom
47 758769 Grill, Front
48 758770 Panel, Filler
49 758771 Panel, Inner
51 2175683 Trim, Door (Lower)
52 2175604 Support, Front
53 489482 Retainer, Wire
FOLLOWING PARTS NOT ILLUSTRATED
503695 Sealer, Cork (1/4 Pound)
797403 Cement, Insulation (1 Oz.)
505587 Sealer, Mastic (1 Qt.)
212643 Sealer, Gum (22 Pcs. 3/16" x 7")
479976 Kit, Insulation (5 Pcs. 3" x 24" x 48")
978025 Valve, Access (1/4")
978026 Valve, Access (5/16")
978027 Valve, Access (3/8")
978028 Valve, Access (1/2")
978029 Valve, Access (5/8")

978030 Valve, Access (3/4")
LITERATURE PARTS
LIT2175674 Use & Care Guide
LIT2175675 Instructions, Installation
LIT2180830 Service and Wiring Sheet

1 759296 Valve, Complete Water
2 585856 Tube, Plastic
3 758597 Plug (2)
4 1129798 Dispenser, Water
5 2181076 Evaporator
6 2174726 Spacer, Adjustable (Side)
7 2174724 Spacer, Adjustable (Front)
8 759213 Tube, Water Fill
9 489049 Screw 10-12 x 1/2
10 756564 Bracket, Grid Mounting (2)
11 489013 Washer, Plain
12 489443 Screw
13 585853 Shelf, Water Pan
15 759109 Hose, Overflow
16 596037 Screw, 10-32 x 1/2
17 2174725 Spacer, Fixed (Rear)
18 2174727 Spacer, Fixed (Side)
19 2174750 Harness, Grid
20 587662 Clamp
21 681676 Nut, Wing
22 841707 Insert
23 627018 Nut & Sleeve Assembly
24 758488 Harness, Light
25 758490 Bracket, Lamp
26 681611 Thumbscrew
27 745362 Bulb
28 2174752 Grid Assembly (Complete)
29 758489 Shield, Light
37 681245 Washer
38 2165477 Adapter
39 2174754 Wire, Grid Cutter
41 593171 Panel, Grid
42 681534 Thumbscrew, 10-32 x 5/8
43 756659 Pan
44 681419 Thumbscrew, 10 x 1/2
45 759043 Stopper, Water Pan

2 756124 Cover, Plug
3 681391 Screw, 8-18 x 3/4
4 583155 Housing, Motor
5 587096 Blade, Fan
6 1127834 Motor, Pump
7 583424 Washer
8 756122 Bracket, Pump
9 596016 Grommet (2)
10 593229 Sleeve
11 681390 Screw, 8-32 x 3/8
12 756782 Pump, Water (Complete)
13 583518 Pump
14 583426 Impeller (Includes Retaining Ring 15)
15 681301 Ring, Retainer

2 2165483 Transformer
3 2165530 Escutcheon, Panel
4 2172893 Switch, Service
5 2172846 Bracket, Control
7 595005 Screw, 8-32 x 1/4
8 2175680 Decal, Control Panel
9 2175678 Escutcheon
10 2175679 Decal, Escutcheon
11 759308 Thermostat, Evaporator
12 759309 Thermostat, Bin Control
13 681245 Washer
14 487909 Screw #8 x 1/2
15 681036 Screw
19 758567 Harness, Grid
20 2175681 Knob
21 759007 Latch
22 680964 Screw, 8-32 x 1/2

1 2180948 Shroud
2 680811 Screw
3 572728 Blade, Fan
4 1108089 Motor, Fan
5 560817 Bracket
6 681305 Screw, 1/4-20 x 1/2 (6)
7 2176659 Compressor
8 680233 Screw (4)
9 595230 Washer (4)
10 585564 Sleeve (4)
11 596355 Grommet (4)
14 489472 Screw
15 759112 Coil, Solenoid
16 759113 Valve, Body
18 2183404 Overload
20 2183410 Relay, Start
21 2162358 Cover, Terminal
23 2180801 Drier
24 2180808 Condenser
25 2180807 Accumulator
27 758811 Deflector, Front
29 681167 Screw,8x3/8
30 2180938 Base, Unit
32 681650 Conical Washer 1/4-20 Hex
33 489199 Screw
REFRIGERANT CHARGE 6.75 OZ. (R134A)
