KitchenAid 5KCO211B User manual

Countertop Oven
5KCO211
W11407659A_EN.indd 1W11407659A_EN.indd 1 12/24/2019 5:11:51 PM12/24/2019 5:11:51 PM

2|
Start
Start
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
7
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Start
Cancel
Frozen
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
6
1
2
3
4
5
13
8
12
11
10
9
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
22
21
20 19
18
17
16
15
14
1Cool down surface for removable
Oven Rack
12 Temperature / Timer Knob*
2Chrome-plated Steel Broiling Rack 13 Mode Knob: Cooking mode selector
3Enamel-coated Pan 14 Frozen Icon
4Chrome-plated Steel Oven Rack 15 Fahrenheit Icon
5Door Handle 16 Celsius Icon
6Toughened Glass Window 17 Hours Icon
7Removable Crumb Tray 18 Minutes Icon
8High-contrast LCD Display 19 Slices Icon
9 Start: Start selected cooking mode 20 Shade Number Graphic
10 Cancel: Stops selected cooking mode 21 Shade Icon
11 Frozen: Push for frozen food items 22 Preheating Icon
PARTS AND FEATURES
*Adjust the time by 1 minute for the rst hour and then by 5 minutes for the next hour. Adjust
by 5 °F or 1 °C temperature, depending on the unit selected. Rotate and press to select
desired shade and number of slices while using the Toast or Bagel mode.
NOTE: Press and hold the Frozen button for 3 seconds to switch between the temperature
units Fahrenheit (°F) and Celsius (°C).
W11407659A_EN.indd 2W11407659A_EN.indd 2 12/24/2019 5:11:52 PM12/24/2019 5:11:52 PM

ENGLISH
|3
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against risk of electrical shock, do not put cord, plugs, or any parts of
the Countertop Oven in water or other liquid.
4. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
5. Children should be supervised to ensure that they do not play with the appliance.
6. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts.
7. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Contact the
manufacturer at their customer service telephone number for information on
examination, repair, or adjustment.
8. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
9. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
10. Do not let cord hang over edge of table or counter, or touch hot surfaces.
11. This appliance is not intended to be operated by means of an external timer or a
separate remote-control system.
12. The temperature of accessible surfaces may be high when the appliance is
operating.
13. Do not place on or near a hot gas or electric burner, or in a heated oven.
W11407659A_EN.indd 3W11407659A_EN.indd 3 12/24/2019 5:11:53 PM12/24/2019 5:11:53 PM

4|
14. Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.
15. Bread may burn. Therefore toasters must not be used near or below curtains and
other combustible materials.
16. Use extreme caution when removing Broiling Rack, Multipurpose Pan, Oven
Rack, or disposing of hot grease.
17. Oversize foods or metal utensils must not be inserted in a Countertop Oven as
they may create a re or risk of electric shock.
18. A re may occur if Countertop Oven is covered or touching ammable material,
including curtains, draperies, walls and the like, when in operation. Do not store
any item on top of the appliance when in operation.
19. Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts, creating a risk of electric shock.
20. Extreme caution should be exercised when using containers constructed of
materials other than metal or glass.
21. Do not store any materials, other than manufacturer’s recommended
accessories, in this Countertop Oven when not in use.
22. Do not place any of the following materials in the Countertop Oven: paper,
cardboard, plastic, or anything similar.
23. Do not cover crumb drawer or any part of the Countertop Oven with metal foil.
This will cause overheating of the oven.
24. To disconnect, turn the Countertop Oven “off” by pressing Cancel button, then
remove plug from wall outlet.
25. Do not use the appliance outdoors.
26. Do not use appliance for other than intended use.
27. Refer to the “Care and Cleaning” section for instructions on cleaning the
surfaces in contact with food.
28. This appliance is intended to be used in household and similar application such
as:
- staff kitchen areas in shops, ofces and others working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
CAUTION: Surface may get hot during use.
SAVE THESE INSTRUCTIONS
PRODUCT SAFETY
W11407659A_EN.indd 4W11407659A_EN.indd 4 12/24/2019 5:11:53 PM12/24/2019 5:11:53 PM

ENGLISH
|5
ELECTRICAL REQUIREMENTS
5KCO211B
5KCO211E
Voltage: 220-240 VAC
Frequency: 50-60 Hz
Wattage: 1647-1960 W
5KCO211P
Voltage: 230 VAC
Frequency: 60 Hz
Wattage: 1800 W
NOTE: If the plug does not fit in the outlet,
contact a qualified electrician or service
technician. Do not modify the plug in any
way. Do not use an adapter.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or service technician to install an
outlet near the appliance.
The cord should be arranged so that it will
not drape over the countertop or tabletop
where it can be pulled on by children or
tripped over unintentionally.
PRODUCT SAFETY
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
GETTING STARTED
Before rst use, clean all parts and accessories (see “Care and Cleaning” section). Remove all
packaging materials, if present. Place the Countertop Oven on a dry and at level surface.
10 cm (4")
10 cm (4")
10 cm (4")
Make sure all sides are positioned with 10
cm (4”) distance.
Start
Start
Follow below guidelines to position the
Oven Rack:
1. Top: Use for broiling most meats,
toast and cookies.
2. Bottom: Optimal for most baking and
cooking operations. This position is
suitable for cooking taller food items.
1 2
1
2
W11407659A_EN.indd 5W11407659A_EN.indd 5 12/24/2019 5:11:53 PM12/24/2019 5:11:53 PM

6|
PRODUCT FUNCTIONS
The product features 9 cooking functions for a variety of cooking tasks. Memory settings
allows customisations. All your settings will be remembered for next use (until unplugged).
FROZEN OPTION
Allows proper thawing of frozen food items and thawing time varies depending on the
selected functions.
PREHEATING
Allows your oven to saturate the walls and cooking racks based on oven’s set temperature
to remove cold spots that draw heat away from food. During preheating, a light ring around
the start button will glow with “Preheating” displayed in the LCD. A chime will sound after
reaching preheat set temperature. Now insert the food and begin cooking. To skip the
Preheating and start the timer directly, push the START button again. Refer to recipes for
specic Preheating details.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Toast mode: The oven distributes power
between the top and bottom heating
elements to deliver fast and even toasting.
Use the Toast mode for bread, toaster
pastries, frozen waffles.
If reheating pastries, use the Reheat mode.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Bagel mode: The oven distributes power
between the top and bottom heating
elements to nicely brown the top of cut
bagels while gently warming the outside.
NOTE: NOT available on Broil, Roast, Reheat, or Keep Warm cooking mode.
Refer to the below charts for toasting and cooking functions, or see detailed explanations and
tips provided further for all functions.
TOASTING MODES CHART
Mode Rack
Position
Preset
Shade
Shade Range
(Light to Dark) Preset Slices Range (# of slices)
Toast 1 5 1 - 8 2 1 - 6
Bagel 1 5 1 - 8 2 1 - 6
TOASTING FUNCTIONS
TOASTING MODE
NOTE: Preheating is NOT available on Keep Warm, Reheat, Toast, or Bagel modes.
W11407659A_EN.indd 6W11407659A_EN.indd 6 12/24/2019 5:11:54 PM12/24/2019 5:11:54 PM

ENGLISH
|7
Mode Rack
No.
Preset Temp.
°C (°F )
Temp. Range
°C (°F )
Preset
Time (Mins)
Recommended
Foods
Pizza* 1 - 2 205°C (400°F) 65 °C - 232 °C
(150–450°F) 17 Fresh and frozen Pizza
Cookies* 1 190°C (375°F) 65 °C - 232 °C
(150–450°F) 10 Cookie Dough
Bake* 1 - 2 175°C (350°F) 65 °C - 232 °C
(150–450°F) 30 Cakes, breads, casseroles, mufns
Broil* 1 - 2 230°C (445°F) 175°C (350°F)
232°C (450°F) 8Chops, sh, seafood, browning
Roast* 2 180°C (355°F) 65 °C - 232 °C
(150–450°F) 60 Chicken, meat and vegetables
Keep
Warm 1 - 2 75°C (170°F) 65 °C - 93 °C
(150–200°F) 60 Keeps food warm
Reheat 1 - 2 150°C (305°F) 65 °C - 232 °C
(150–450°F) 15 Leftovers
COOKING MODES CHART
* The Countertop Oven will automatically preheat when these modes are selected.
COOKING FUNCTIONS
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Pizza Mode: The oven distributes power
to the top and bottom heating elements to
maintain the desired oven temperature.
Frozen mode:
Pizza setting will default to Frozen mode.
You may use the Frozen button to provide
extra time for frozen pizzas to cook, or
deselect it when cooking freshly prepared
pizzas.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Cookies mode: The oven distributes power
to the top and bottom heating elements to
maintain the desired oven temperature.
COOKING MODE
W11407659A_EN.indd 7W11407659A_EN.indd 7 12/24/2019 5:11:54 PM12/24/2019 5:11:54 PM

8|
COOKING FUNCTIONS
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Roast mode: The oven distributes power
to the top and bottom heating elements to
maintain the desired oven temperature.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Keep Warm mode: The oven distributes
power to the bottom elements to keep
food warm before serving.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Reheat mode: The oven distributes power
to the top and bottom elements to bring
food to serving temperature. Reheating
too long may overcook or dry out food.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Bake mode: The oven distributes power to
the top and bottom heating elements to
maintain the desired oven temperature.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Broil mode: Broiling uses direct radiant
heat to cook food from above. Oven will
distribute power to the top two heating
elements. To deliver efcient broiling, the
bottom elements will run then shut off
after the oven preheats.
Tips:
Use the 23 cm x 33 cm (9” x 13”)
multipurpose pan and rack.
COOKING MODE
W11407659A_EN.indd 8W11407659A_EN.indd 8 12/24/2019 5:11:54 PM12/24/2019 5:11:54 PM

ENGLISH
|9
ADJUSTING THE RACK POSITION
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
To adjust the Oven Rack position, Open
the door of oven and slide the Oven Rack
out completely.
1
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
Align the sides of the oven rack with the
grooves for the desired position (1 or 2)
and slide the Oven Rack straight in.
2
PRODUCT USAGE
IMPORTANT: Maintain enough clearance between the top of the food item and the top
elements. If necessary, adjust the Oven Rack position.
Start
Start
Make sure there will be enough clearance
between the top of the food item and the
top elements. If necessary, adjust the Oven
Rack position between 1 or 2. Close the
door.
1
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Plug into an earthed outlet. Turn the Mode
knob to select the desired cooking or
toasting mode. The preset temperature will
be shown for a selected cooking mode.
Shade and slices will be shown if selected
Bagel or Toast mode.
2
1
WARNING
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove an earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, re,
or electrical shock.
2
SETTING A COOKING OR TOASTING MODE
W11407659A_EN.indd 9W11407659A_EN.indd 9 12/24/2019 5:11:55 PM12/24/2019 5:11:55 PM

10 |
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
For Cooking mode: Rotate Temperature/
Timer Knob to adjust preset temperature.
Press Knob to show preset time and if
needed, rotate Knob to adjust cooking
time.
(See “Cooking Modes”chart for
temperature ranges.)
3
Start
Cancel
Frozen
Preheating
Slices
Frozen
F
C
Hrs
Min
Shade
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
For Toast and Bagel modes: The shade
icon starts flashing. If desired, rotate
Temperature/Timer Knob to adjust shade.
Press Knob to select slices. The slices icon
will starts flashing. If desired, rotate knob
to adjust number of slices.
(See “Toasting Modes” chart for shade and
slices.)
Start
Cancel
Frozen
Preheating
Preheating
Shade
Shade
Slices
Slices
Frozen
Frozen
F
F
C
C
Hrs
Hrs
Min
Push the FROZEN button, if desired to
add additional cycle time to the selected
cooking mode to allow for thawing and
proper cooking. The additional time varies
depending on the selected cooking mode.
NOTE: The Frozen option is NOT available
on Broil, Roast, Reheat, or Keep Warm
modes.
5
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
For Cooking modes: Press START to
preheat the oven. To skip preheat and
start the timer directly, press START button
again.
NOTE: In Broil mode, the bottom
elements will be on until oven reaches set
temperature.
For Toasting modes: Press START to begin
the toasting process and the timer will start
to countdown.
4
6
SETTING A COOKING OR TOASTING MODE
PRODUCT USAGE
W11407659A_EN.indd 10W11407659A_EN.indd 10 12/24/2019 5:11:56 PM12/24/2019 5:11:56 PM

ENGLISH
|11
SETTING A COOKING OR TOASTING MODE
PRODUCT USAGE
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
PreheatingPreheating
ShadeShade SlicesSlices
FrozenFrozen
FF
CC
HrsHrs
Min
KeepWarm
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
For Cooking modes: A chime sounds
when preheat is complete. The display will
change to show the time counting down.
Open the oven door and place the food on
the rack. Then, close the door.
Rotate temperature/ timer knob to adjust
time, if needed.
7
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Start
Cancel
Frozen
When the cooking cycle is complete, a
chime will sound.
8
NOTE: Always use oven mitts when removing pans or racks.
CARE AND CLEANING
First, unplug the Countertop Oven from
the outlet.
Open the door, then remove all items.
Oven rack, Multipurpose pan, and Broiling
rack are dish-washer safe, but hand
washing is recommended. Wash in warm,
sudsy water. Rinse and dry thoroughly.
NOTE: Allow Countertop Oven and accessories to cool completely before cleaning.
12
CLEANING THE COUNTERTOP OVEN
Pan
Broil rack
Ovan rack
W11407659A_EN.indd 11W11407659A_EN.indd 11 12/24/2019 5:11:57 PM12/24/2019 5:11:57 PM

12 |
CARE AND CLEANING
REMOVING AND CLEANING THE CRUMB TRAY
Empty the crumb tray and wash in warm,
sudsy water, if needed. Dry with a soft
cloth. Open the door and slide it back into
place.
2
INTERIOR: The inside walls of the oven
feature a nonstick coating. Remove heavy
spatter with a nylon or polyester mesh pad,
sponge, or cloth dampened with warm water.
Dry thoroughly.
IMPORTANT: Do not use cleaning agents, abrasive cleansers, or metal scouring pads on
the inner or outer surfaces of the oven. They could scratch the surface.
IMPORTANT: Ensure all parts and surfaces are completely dry before re-use.
EXTERIOR: Wipe the outside of the
Countertop Oven with a clean, damp cloth
and dry thoroughly.
For stainless steel surfaces: KitchenAid
recommends the use of affresh®stainless
steel cleaner for all stainless steel surfaces.
The affresh®cooktop cleaner and scrubbing
pads are also recommended for cleaning the
toughest baked-on residue on stainless steel
and glass surfaces. Ensure all surfaces are
completely dry before using your oven. Please
visit www.affresh.com to learn more.
Unplug your Countertop Oven from the
outlet. Open the door, then remove the
crumb tray.
1
W11407659A_EN.indd 12W11407659A_EN.indd 12 12/24/2019 5:11:57 PM12/24/2019 5:11:57 PM

ENGLISH
|13
TROUBLESHOOTING GUIDE
WARNING
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove an earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, re,
or electrical shock.
Problem Solution
Countertop Oven fails to
operate:
Plug the Countertop Oven into an earthed outlet.
If you have a circuit breaker box, make sure the circuit is
closed. Try unplugging the Countertop Oven, then plug it
back in.
Upon first use, the Countertop
Oven may produce light
smoke:
This is normal.
Upper cooking elements
visibly glow, but bottom
cooking elements do not:
The upper cooking elements use higher power for better
browning performance. The lower cooking elements are on,
but may not visibly glow like the upper cooking elements.
This is normal and your Countertop Oven is working
properly.
If the wrong temperature unit
is displayed:
Press and hold the Frozen button for 3 seconds to switch
between Fahrenheit (°F) and Celsius (°C) temperature units.
IIf “E1 or E2” ashes on the
display and a chime sounds:
The NTC Sensor may not be working.
This issue can not be corrected. Please see the “Warranty
and Service” sections.
W11407659A_EN.indd 13W11407659A_EN.indd 13 12/24/2019 5:11:57 PM12/24/2019 5:11:57 PM

14 |
PRODUCT WARRANTY
CUSTOMER SERVICE
Units that did not conform to the above conditions may still be serviced at any
Authorized Focus Global Inc. and Coleman Service Centers nationwide at a minimal
fee. Shipping fee or transport of unit will be charged to customer.
Length of Warranty: Focus Global Inc. Pay For:
Focus Global Inc. will repair
and service for free under the
following conditions:
Philippines:
1 year full warranty
from date of
purchase.
The replacement parts
and repair labour
costs to correct
defects in materials or
workmanship. Service
will be provided by Focus
Global Inc.
- The unit was purchased from a
local authorised store / dealer.
- Proof of purchase must
be presented to claim the
warranty.
- Unit has been used for normal
household food preparation
purpose only.
- Damage to the unit is not due
to accident, alteration, misuse,
abuse, installation or operation
not in accordance with local
electrical codes.
- Spare part damaged is non-
consumable.
- Replacement of the unit
shall only be made after 3
unsuccessful attempts to
repair /remedy the same issue.
In Philippines:
For any questions, or to find the nearest Authorised Service Centre, please find our
contact details below.
NOTE: All service should be handled locally by an Authorised Focus Global Inc. Service
Centre.
For Warranty / Repair, p/s to contact -
Company: Focus Global Inc.
Address: Pioneer corner Reliance St., Mandaluyong City
Customer Service: [phone] local 118 | [phone]
Email: [email protected]
Facebook: /KitchenAidPHL
Business Hours: Monday to Friday, 7:30AM to 4:30PM
For more information, visit our website at:
www.focusglobalinc.com
Focus Global Inc. DOES NOT ASSUME ANY RESPONSIBILITY FOR INDIRECT
DAMAGES.
Note: The warranty listed is only for the Philippines.
©2019 All rights reserved. Specications subject to change without notice.
W11407659A_EN.indd 14W11407659A_EN.indd 14 12/24/2019 5:11:57 PM12/24/2019 5:11:57 PM

W11407659A_EN.indd 15W11407659A_EN.indd 15 12/24/2019 5:11:57 PM12/24/2019 5:11:57 PM

W11407659A 12/19
©2019 All rights reserved.
Specications subject to change without notice.
W11407659A_EN.indd 16W11407659A_EN.indd 16 12/24/2019 5:11:58 PM12/24/2019 5:11:58 PM
