KitchenAid Architect Series II KGRS205T User guide

30" (76.2 cm) Freestanding Gas Range
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
CABINET OPENING DIMENSIONS
KGRS205T
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Gas supply: This range is design-certified by CSA International for
use with Natural gas or, after proper conversion, for use with LP
gas.
This range is factory set for use with Natural gas. The model/serial
rating plate located behind the storage drawer on the right-hand side
oven door frame has information on the types of gas that can be
used. If the types of gas listed do not include the type of gas
available, check with the local gas supplier.
Provide a gas supply line of 3/4" (1.9 cm) rigid pipe to the range
location. A smaller size pipe on longer runs may result in insufficient
gas supply. With LP gas, piping or tubing size can be 1/2" (1.3 cm)
minimum. Usually, LP gas suppliers determine the size and
materials used in the system.
NOTE: Pipe-joint compounds that resist the action of LP gas must
be used. Do not use TEFLON®tape.*
If local codes permit, a new CSA design-certified, 4 to 5 ft (122 to
152.4 cm) long, 1/2" (1.3 cm) or 3/4" (1.9 cm) I.D., flexible metal
appliance connector may be used for connecting range to the gas
supply line.
A 1/2" (1.3 cm) male pipe thread is needed for connection to the
female pipe threads of the inlet to the appliance pressure regulator.
The supply line must be equipped with a manual shutoff valve. This
valve should be located in the same room but external to the range.
It should be in a location that allows ease of opening and closing.
Electrical: 120-volt, 60-Hz, AC-only, 15-amp, fused electrical
circuit is required. A separate circuit serving only this range is
recommended. A time-delay fuse or circuit breaker is recommended.
*TEFLON is a registered trademark of E.I. Du Pont De Nemours and
Company.
Ref. W10188242
08-07-08
*Range can be raised approximately 1" (2.5 cm) by adjusting the leveling legs.
A. 28¹⁄₂" (72.4 cm) depth with handle
to backguard standoffs.
29" (73.7 cm) depth with handle
(KitchenAid models only)
B. 35⁵⁄₈" (90.5 cm) cooktop height
(minimum) with leveling legs
screwed all the way in*
C. 47¹⁄₈" (119.7 cm) overall height
(minimum) with leveling legs
screwed all the way in*
D. 29⁷⁄₈" (75.9 cm) width
E. 26³⁄₄" (67.9 cm) depth to
background standoffs
F. Model/serial number plate
(located behind the
storage drawer on the
left-hand side of the oven
frame)
G. Rating number plate
(located behind the
storage drawer on the
right-hand side of the
oven frame)
B
E
D
A
G
F
C
B
D
C
E
A
F
I
H
J
K
G
G
J
H
H
L
M
N
Cabinet opening dimensions shown are for 25" (64.0 cm)
countertop depth, 24" (61.0 cm) base cabinet depth and
36" (91.4 cm) countertop height.
IMPORTANT: If installing a range hood or microwave hood
combination above the range, follow the range hood or
microwave hood combination installation instructions for
dimensional clearances above the cooktop surface.
Range may be installed with zero clearance to combustible
construction at the rear and on the sides below the cooktop.
NOTE: 24" (61.0 cm) minimum when bottom of wood or metal
cabinet is protected by not less than ¹⁄₄" (0.64 cm) flame retardant
millboard covered with not less than No. 28 MSG sheet steel,
0.015" (0.4 mm) stainless steel, 0.024" (0.6 mm) aluminum or
0.020" (0.5 mm) copper.
30" (76.2 cm) minimum clearance between the top of the cooking
platform and the bottom of an unprotected wood or metal
cabinet.
A. 18" (45.7 cm) upper cabinet to countertop
B. 13" (33.0 cm) upper cabinet depth
C. 30" (76.2 cm) min. opening width
D. For minimum clearance to the top of the cooktop, see NOTE.
E. 30" (76.2 cm) min. opening width
F. 3" (7.6 cm) min. clearance from both sides of the range to the side
wall or other combustible material
G. 6" (15.2 cm) width of H (area for gas and electric)
H. Recommended area for gas and electric installation
I. 6" (15.2 cm) height of notched area in H
J. 3¹⁄₄" (8.3 cm) distance from side of range to H
K. 3" (7.6 cm) width of notched area in H
L. 3" (7.6 cm) distance from wall
M. Cabinet door or hinges should not extend into the cutout.
N. 19" (48.3 cm) height of H
®
