KitchenAid KSSS42FMB01 User manual

1
CABINET PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
9−05 Litho In U.S.A. (mek) Part No. 8199103
42" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
2309068 Use & Care Guide
2307363 Energy Label
2306324 Service & Wiring
Sheet
2306337 Icemaker and
Ingredient Care
Center
Service Sheet
2302865 Service Sheet,
Main Control
2266811 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2005004 Grommet, Crossover
Tube
4 1112023 Roller, Front &
Rear (4)
5 Support, Leveler
Assembly
2004506 Refrigerator Side
2004505 Freezer Side
6 2005006 Grommet, Wiring
7 2005007 Grommet,
Flexible
8 Cap, Water Filter
2186494B Black
9 2006442 Mounting Stud,
Grill
10 2004514 Clamp, Tube
11 2005783 Cam, Door Closer
12 2209022 Housing, Water
Filter
14 3400525 Screw
15 2255709 Filter, Water
16 489399 Screw
17 3400230 Screw, Door Stop
18 2257644 Hinge (Top)
20 489464 Screw
21 2004994 Lock, Adjustable
Bushing
22 2002903 Bushing
23 2209090 Clamp, Filter
Housing
24 Spring, Door
Closure
2221242 Right Side
2004517 Left Side
25 486194 Screw
26 2005008 Retaining Ring,
Adjustable Bushing
27 1113227 Fastener (3)
28 2006342 Gap, Cover
Assembly (Bottom)
29 Hinge (Bottom)
2006779 Freezer Side
2006780 Refrigerator Side
30 2302876 Bushing,
Adjustable
31 8533913 Screw 1/4−20 x 5/8
32 Skirt−Grille,
Bottom
2209025B Black
33 Extension Arm,
Door Closer
2266882 Right
2266881 Left
34 Grille Bottom,
Front
2209428B Black
35 2005921 Screw
36 Bracket, Support
Base (Front)
2006616 Left
2006556 Right
37 1157158 Screw
38 2006617 Bracket, Support
Base (Rear) (2)
39 2006346 Washer
40 2266880 Bushing,
Extension Arm
41 1163283 Screw
44 Switch, Rocker Arm
1118894 Refrigerator Door
Side
1115373 Freezer Door Side
45 2215938 Cover, Switch (2)
46 487415 Screw (2)
47 Bracket, Switch
2221097 Right
2221096 Left
48 2215612 Cover, Rear

3
CABINET TRIM PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 Cabinet, Trim
(Right Side)
2222552B Black
2222552X Etched Aluminum
3 Screw
8281252 Black
8281250 Stainless Steel
4 2254725 Cabinet, Trim
(Bottom)
5 486194 Screw
6 2257367 Cabinet, Trim Top
7 Cabinet Trim
(Left Side)
2222553B Black
2222553X Etched Aluminum
9 2005925 Seal−Trim, Side
10 489464 Screw

4
FREEZER SHELF PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 2302868 Wire, Shelf
2 2302871 Cover, Shelf
3 2302883 Shelf, Fixed (2)
4 2259082 Basket
5 2256270 Front, Basket
6 Slide, Basket
2259317 Right Side
2259318 Left Side
7 8533928 Screw
8 2266934 Door, Ice
9 2266931 Bucket, Ice
10 2266955 Spacer, Ice Door
11 8533929 Screw

5
REFRIGERATOR LINER PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103

6
REFRIGERATOR LINER PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2306010 Thermistor
3 2208970 Air Duct
4 2209204 Clip, Thermistor
5 2259077 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 2006475 Screw
8 487539 Screw
9 2302937 Thermistor
10 2302986 Lid, Baffle
11 2302987 Baffle, Control
Assembly
12 2171846 Release Valve
13 2187619 Jumper, Air Baffle
14 488357 Screw
15 486194 Screw
17 2221296 Air Baffle
Assembly
21 2208997 Diffuser Assembly
22 1116793 Cover, Thermistor
23 2188820 Thermistor
24 2302992 Spacer, Air−
Baffle
25 2309087 Cover, Diffuser
26 2259066 Cover, Air Return
27 2259412 Seal, Air Duct
(Round Hole)
28 2259398 Seal, Air Duct
(Square Hole)

7
CONTROL PANEL PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 2302772 Control Box
2 2303938 Insert, Control
Box
3 2302913 Circuit Board,
Housing Control
4 2187424 Control Box
Wire Harness
6 2221121 Support, Control
Box
7 489006 Screw (2)
9 2306086 Display Board,
Ingredient
Care Center
10 2302717 Shield, Light
11 2162085 Socket, Light
12 2255743 Light Bulb (2)
13 486194 Screw
14 8281185 Screw
15 2257519 Overlay

TOP GRILLE AND UNIT COVER PARTS
8
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 Top Grille
Assembly
2257402B Black
2257402X Etched Aluminum
2 2259320 Cover, Unit
3 486194 Screw
4 2256466 Back Panel
5 2302974 Cover, Unit Front
6 487415 Screw
7 2187429 Wire Assembly
RC/FC Light Switch
8 2215910 Grommet, Flexible
9 489348 Clamp

REFRIGERATOR SHELF PARTS
9
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103

REFRIGERATOR SHELF PARTS
10
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 2222592 Shelf Assembly
5 2179404 Rack, Wine
6 2221071 Egg Bin
9 2302842 Meat Pan Cover
Assembly
10 2302835 Crisper Cover
Assembly
11 2257611 Trim, Glass Rear
Side
12 2169935 Cover
13 2257582 Trim, Glass Rear
14 2252412 Crisper Pan (2)
17 Slide, Meat Pan
2302954 Left Side
2302955 Right Side
18 Trim, Glass Front
(Not Serviceable)
19 2256254 Trim, Glass Rear
21 2256248 Front, Crisper
Pan
23 2252255 Trim, Glass Side
Crisper Pan
24 2256250 Trim−Glass, Side
Meat Pan
25 Spacer, Crisper
2256222 Right Side (2)
2256223 Left Side (2)
27 Slide, Crisper
2302957 Right Side (2)
2302956 Left Side (2)
28 Spacer, Meat Pan
2256243 Left Side
2256244 Right Side
29 Screw
8533929 Right Side
8533928 Left Side
30 2256369 Pan Assembly
Meat
31 2256366 Front, Meat Pan

11
FREEZER LINER AND AIR FLOW PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103

12
FREEZER LINER AND AIR FLOW PARTS
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 2259385 Fan Motor
2 2266801 Deflector, Air
3 2169142 Fan Blade
4 2223733 Retainer,
Fan Motor
5 2302817 Gasket, Cover
6 2223986 Grommet
7 486194 Screw
8 2259464 Wedge, Air Duct
9 488500 Screw, Ground
10 2162085 Socket, Light (2)
11 488937 Clamp, Nylon
12 2255743 Light Bulb
13 2302777 Seal, Light Socket
14 2182120 Scroll, Fan
15 2259465 Wedge, Air Duct
16 2302925 Bracket, Vent Tube
17 2306043 Air Duct
18 2302932 Tube, Vent
19 Block, Fan Scroll
2209480 Right
2209066 Left
20 2302850 Support, Air Duct
21 Liner (Not A
Serviceable Part)
23 2259025 Cover, Air Outlet
24 2259367 Light Shield
25 2306049 Cover, Evaporator
27 487539 Screw
29 2306038 Deflector, Air
Duct
30 1112260 Support,
Evaporator
31 2196483 Shelf, Stud (20)
32 8281158 Screw
33 Evaporator,
Cover Rail
2221107 Left Side
2259355 Right Side
34 2220904 Gasket (2)
Evaporator Cover
37 2187673 Harness, Evap Fan
(Includes Item 55)
38 2220241 Insulation (4)
39 2188820 Thermistor
40 2209204 Clip, Thermistor
41 1116793 Cover, Thermistor
42 2006475 Screw
43 2306052 Gasket, Air Duct
44 2257571 Bracket, Light
46 2259032 Ladder, Shelf
47 2259445 Support, Screw
55 2306462 Defrost, Bi−Metal
56 8281185 Screw

REFRIGERATOR DOOR PARTS
13
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103

REFRIGERATOR DOOR PARTS
14
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 2252330 Refrigerator
Door Panel
(Includes
Item #9)
3 2266854 Hinge Assembly,
Top
4 2256381 Spacer−Door,
Top
5 489282 Screw
6 2302878 Hinge Assembly,
Bottom
7 2222796 Rail, Lid
8 2222982 Gasket, Utility
Bin
9 2222811 Door Gasket,
Magnetic
11 Handle, Door
2256473B Black
2256473 Etched Aluminum
12 2001230 Washer
13 2257637 Door, Spacer
Bottom
15 Screw, 8−15 x .500
8281252 Black
8281250 Stainless Steel
16 Trim (Top)
2005840 Black
2005011 Etched Aluminum
18 Trim (Side)
2005971 Black
2005967 Etched Aluminum
19 Trim (Bottom)
2215994B Black
2215994 Etched Aluminum
21 End Cap
2222919 Right Side
2222920 Left Side
25 2222922 Bin, Utility
Center
26 2222925 Door, Utility Bin
27 2222773 Door Shelf
28 2165792 Butter Tray
30 2222770 Shelf, Gallon
Door

FREEZER DOOR PARTS
15
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103

FREEZER DOOR PARTS
16
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
Panel (Includes
Item #14)
2252327 Black
6 2302879 Hinge, Bottom
7 489282 Screw
8 2266854 Hinge, Top
9 2256381 Spacer−Door,
Top
14 2222814 Door Gasket,
Magnetic
16 Handle, Door
2256472B Black
2256472 Etched Aluminum
18 2257637 Door, Spacer
20 Screw
8281252 Black
8281250 Stainless Steel
21 Trim (Top)
2005886 Black
2005020 Etched Aluminum
23 Trim (Bottom)
2215985B Black
2215985 Etched Aluminum
24 Trim (Side)
2005966 Black
2005962 Etched Aluminum
28 2222776 Bin, Shelf
F.C. (6)

UPPER UNIT PARTS
17
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103

UPPER UNIT PARTS
18
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2306957 Inverter Box
2 489373 Screw, Compressor
Mounting (4)
3 2302967 Compressor
(Includes Items
6 & 9)(Also Order
876765 Tube Kit)
4 2257354 Housing, Control
Board
5 2215641 Bracket, Fan Motor
6 1100826 Grommet, Mounting
7 2266803 Shroud, Condenser
(Right)
8 2302969 Bracket, Switch
9 2215676 Terminal Cover
10 2302973 Shroud, Condenser
(Left)
11 2303934 Control Board
12 2203075 Spacer (5)
13 2256328 Bracket, Inverter
Box
14 8281149 Screw
15 1157158 Screw
16 2259307 Condenser
17 943447 Grommet (4)
18 2187629 Wire, Jumper
19 487522 Screw
20 2155774 Wire Tie
21 2252363 Drier
23 2206036 Motor, Fan
24 2190685 Blade, Fan
25 2003169 Orifice, Fan
26 2259302 Tube, Drier
Transition
27 8281160 Screw
28 2259340 Tube, Heat Loop
Transition
29 486692 Speed Nut
30 2259349 Housing, Power
Supply
31 2259350 Power Supply,
Ingredient
Care Center
32 2000645 Sleeve,
Condenser
34 2194319 Process, Tube
36 2209495 Cover, Fan
37 2259092 Cover, Condenser
38 2307907 Grommet, Edge
39 2259197 Service Cord
41 549193 Clamp, Cord
42 2266802 Switch, Power
Disconnect
43 487294 Screw, Ground
44 486194 Screw
45 2187900 Wiring Harness,
Unit Compartment
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
7.50 oz.
(R−134A)

LOWER UNIT AND TUBE PARTS
19
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103

LOWER UNIT AND TUBE PARTS
20
For Models: KSSS42FMB01, KSSS42FMX01
(Black) (Etched Aluminum)
8199103
Illus. Part
No. No. DESCRIPTION
3 486194 Screw
4 2215508 Bracket
5 2302929 Side Support
6 2259303 Suction Tube
7 2259353 Tube, Discharge
Heat Loop, Assy.
8 2259304 Tube, Connect
(Drier/Restrictor)
9 2259329 Heater, Drain Pan
10 2209450 Hanger, Heater
11 2005908 Shield, Drain Pan
15 9791833 Clip
16 2306093 Evaporator
17 2306388 Heater, Defrost
18 1113048 Clamp, Heater (2)
20 2220832 Gasket, Evaporator
21 2155774 Wire Tie
22 2215691 Clip, Heat
Exchanger
25 2001264 Drain Pan
26 Bracket, Drain Pan
1113206 Left
1113207 Right
27 513942 Dampener
28 2215648 Damper, Heater
