MOTOR AND DRIVE PARTS
For Models: KUCS03FSSS0
(Stainless)
5−06 Litho in U.S.A. (ebk) Part No. 882798
TRASH COMPACTOR
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
9871923 Tech Sheet
9872215 Guide, Use & Care
2 9870343 Motor, Drive
(Includes No. 13)
3 9871067 Screw,
1/4−20 x 3/4 (4)
4 776327 Plate, Drive
Mount
5 776338 Locknut, 10−32 (4)
6 4149667 Gear, Drive
7 454512 Pin, Slotted
Spring
8 776035 Washer, Wave
9 297462 Washer, Thrust
10 777124 Gear, Driven
11 776036 Clip, Ring
12 780477 Chain, Drive
13 777971 Switch, Motor
Parts Not Illustrated and
Optional Parts (Not Included)
9870118 Undercounter
Conversion Kit

FRAME PARTS
2
For Models: KUCS03FSSS0
(Stainless)
882798
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Frame (Not A
Serviceable Part)
2 9870867 Shield, Slide
Track (2)
3 9870976 Frame, Slide (R.H.)
9870975 Frame, Slide (L.H.)
4 4153788 Bearing, Roller (2)
5 776356 Locknut,
3/8−24 (2)
6 777458 Screw,
6−32 x 3/8 (4)
7 3400938 Nut
8 9870167 Pan, Bottom
9 489478 Screw, 8 x 1/2
10 4149659 Shield, Harness
11 777070 Screw,
8−32 x 5/16
12 780434 Cover, Motor
13 608009 Plate, Motor
Cover
14 9872154 Insulation
15 4149377 Switch, Drawer
Safety
16 775668 Anble, Top
Support
18 777811 Switch, Top
Limit &
Directional
19 777849 Screw,
6−20 x 1" (2)
20 777850 Plate, Nut
21 9872118 Wiring Harness &
Power Cord
22 776119 Bushing, Cord
23 777035 Clamp, Wire
24 776118 Grommet, Motor
Cover
25 775526 Leveler,
Front (2)
27 9870585 Wheel,
Leveler (2)
28 780034 Screw,
10−24 x 3/8 (2)
30 9870444 Panel, Inner
33 777180 Spring,
Container

POWERSCREW AND RAM PARTS
3
For Models: KUCS03FSSS0
(Stainless)
882798
Illus. Part
No. No. DESCRIPTION
1 9870500 Screw, Power
Complete
Assembly (2)
2 Screw, Power
(Available Only
As Complete
Assembly)
3 779121 Plate, Bearing (2)
4 775482 Bearing, Needle (2)
5 776941 Hub, Power
Screw (2)
6 775481 Race, Thrust (2)
7 777385 Sprocket,
Washer (2)
8 4154842 Nut, Power
Screw (2)
9 777332 Washer, Cone (2)
10 9871067 Screw,
10−24 x 3/4 (4)
11 9871251 Ram Assembly
12 9870163 Nut, Power (2)
14 9870187 Stud (2)
16 9870037 Stop, Ram (2)
17 9870498 Bracket, Top Limit
Switch
18 489399 Screw, (2)
19 9870775 Cap, Stop (2)
20 9870169 Slide, Ram (4)

CONTAINER PARTS
4
For Models: KUCS03FSSS0
(Stainless)
882798
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4152204 Screw (2)
2 9871976 Actuator Switch
3 489290 Screw
4 9872232S Panel, Container
Front
5 9870996 Container
Assembly
6
W10021850 Nameplate
7 Pedal, Foot
9871989B Black
8 780263 Screw, Shoulder
#8−32 x 3/8 (2)
9 776395 Guide, Rear Latch
10 9870066 Latch Assembly
11 2004333 Nut
12 9871125 Spring,
Safety Switch
13 9872206S Handle
14 3196175 Screw
15 246131 Screw
16 9871602 Container, Bearing
Roller
17 776356 Locknut,
3/8−24 (2)
18 Plate, Toe Guard
777328 Black
19 9871563 Spacer, Handle
20 776654 Pin
21 775736 Spring, Latch
22 775735 Ring, ‘‘E’’
23 775665 Plate, Latch
24 9872153 Insulation
25 4147703 Retainer, Bag
(Contains 4 Each)

PANEL AND CONTROL PARTS
5
For Models: KUCS03FSSS0
(Stainless)
882798
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Panel, Front
Frame
9871977 Black
2 608572 Cover, Top
3 9871993 Bracket, Retainer
4 9871893 Fan Mount Assembly
5 780239 Bracket, Retainer
(Alternate) (2)
6 489478 Screw,
8 x 1/2AB (6)
7 Escutcheon,
Control
9871906B Black
8 246131 Screw,
6−20 x 3/8 (2)
9 4152703 Strap, Fan
10 9871971 Switch, Rotary
Start−Run
11 9871920 Knob, Rotary
Switch
12 777383 Nut, Rotary
Switch
13 9871829 Switch,
Drawer
14 9871984 Switch, Pushbutton
15 4151442 Compartment,
Air Freshener
17 780034 Screw,
10−24 x 3/8
18 Switch Assembly
9871973 Black
19 Cover,
Air Freshener
9871099 Black
20 4151750 Filter,
Charcoal
23 9871051 Fan,
Filter
24 4151897 Clip,
Wire
25 4151897 S−Clip

Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
The Accessory Parts Listed Below
May or May Not Be Included With
Your Compactor.
1 Panel, Container
Front/Handle
4396297 White/White
4396296 Black/Black
4396298 Biscuit/Biscuit
4396299 Cobalt Blue/SSt.
4396300 Empire Red/SSt.
9871805 Majestic Yellow
w/SSt. Handle
2 Bag, Trash
(15" Plastic)
4318921 15 Pack
4318922 60 Pack
94318921 12 Boxes of
15 Pack
(15" Paper)
675186 12 Pack
882652 48 Pack
3 777635 Deodorizer,
Solid Stick−Ups
(2−Pack)
4 Deodorizer Block
9872166LG Lemongrove
9872166GA Green Apple
9872166L Lavender
5 13030 Carrier, Bag
(Includes No. 6)
6 777108 Handle, Bag
Carrier
7 675351 Grease, 4 Oz.
(Use on Power
Screw & Ram
Pressure Pads
8 Wire, 25’ Roll
10875 Blue 16 Ga.
242820 Black 14 Ga.
242825 Red 14 Ga.
242826 White 14 Ga.
47261 Black 12 Ga.
299885 Red 12 Ga.
47263 White 12 Ga.
9 279368 Adhesive,
Insulation
(2oz Tube)
10 Paint,
Touch−Up 1/2 Oz.
72107 Almond
72017 White
72032 Black
4892899 Biscuit
8171571 Cobalt Blue
8171651 Hunter Green
8171652 Empire Red
8171653 Majestic Yellow
11 Paint,
Spray 13 Oz.
350956 Almond
285006 Black
4392901 Biscuit
350930 White
OPTIONAL PARTS
NOT ILLUSTRATED
Framed Trim Kits
9871382 White
9871383 Black
9871600 Biscuit
6
For Models: KUCS03FSSS0
(Stainless)
882798
