KitchenAid KUCS03FTSS - 15" Trash Compactor User instructions

Without Trim Kit
Compactor
PRODUCT MODEL NUMBERS OVERALL DIMENSIONS
CABINET OPENING DIMENSIONS
CUSTOM PANELS
CLEARANCE DIMENSIONS
KUCS02FR
KUCV02FR KUCS03FS KUCS03FT
Electrical: 115-volt, 60-Hz, AC-only, 15- or
20-amp grounded circuit is required. A separate
circuit is recommended.
18" min.
(45.7 cm)
24" min.
(61 cm)
A
15 min.
(38.7 cm)
34 " min.
(87 cm)
3" min.
(7.6 cm)
" A
B
341⁄8"
(86.7 cm)
24"
(61 cm)
15"
(38.1 cm)
29 ³⁄₈"
(74.6 cm)
15"
(38.1 cm)
1. Grounded electrical outlet
must be a minimum of 3"
(7.6 cm) away from
surrounding cabinets or
nearby walls as shown. It
can be placed either to the
left or the right side of the
product.
1. Leave 6" (15.2 cm) of clearance
space to the right side of the
compactor in order to remove the
compactor bags.
2. Leave 23" (58.4 cm) of clearance in
front of the compactor in order to
fully open or remove the compactor
drawer.
Panel should be a minimum of
1/2" (13 mm) thick.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 9872215
05-04-07
®
