CABINET PARTS
1
For Models: KBCS24LSBS02
(Black Cabinet)
11−08 Litho In U.S.A. (wam)(bay) Part No. W10241951 Rev.A
BEVERAGE CENTER

CABINET PARTS
2
For Models: KBCS24LSBS02
(Black Cabinet)
W10241951
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
2300276 Use & Care Guide
4344901 Wiring Diagram
2 Cabinet (Not A
Service Part)
3 4344739 Lens, Light
4 4344740 Bulb, Light
5 4344746 Heater, Defrost
6 4344747 Heat Shield
7 4344761 Grille
8 4344762 Plate, Bottom
9 4344763 Foot, Leveling
10
W10204638 Brace, Support
11 4344898 Control Box
12 Frame, Side
4344789 Left Side
4344790 Right Side
13 4344771 Bracket, Grille
14
W10239395 Evaporator Fan
Assembly
15 4344860 Thermostat
16 4344768 Knob, Thermostat
17 4344767 Switch, Plunger
18 4344826 Screw
19
W10243104 Screw
20 4344819 Clip, Grille
21 4344825 Screw
22 4344823 Seal
23 Frame, Support
4344821 Right
4344820 Left
24 4344824 Clip, Harness
25 4344857 Harness, Wire
26 4344826 Screw
27 4344792 Thermal Fuse
28 4344793 Screw
29 4344791 Screw
30 4344783 Fan Blade
31 4344878 Screw
32 4344865 Evaporator Fan
Motor
33 4344877 Harness, Wire
34 4344832 Screw, Ground
35 4344778 Grommet, Fan Motor
36 4344899 Bracket, Motor
37 Evaporator
(Not Serviced)
38 4344858 Switch, Light
39 4344917 Transformer Cable
40
W10238027 Temperature Sensor

SHELF PARTS
3
For Models: KBCS24LSBS02
(Black Cabinet)
W10241951

SHELF PARTS
4
For Models: KBCS24LSBS02
(Black Cabinet)
W10241951
Illus. Part
No. No. DESCRIPTION
1 W10238032 Wine Rack
Top & Middle
2 4344866 Rubber Support
3
W10238029 Rail Assembly
4
W10187313 Wine Rack, Lower
5 Ladder, Shelf
4344842 Left Side
4344843 Right Side
6 4344794 Screw
7 4344795 Washer
8
W10239367 Shelf Support
9 4344851 Screw
10 4344882 Trim, Top And
Middle Racks
11 4344867 Rubber Support
12
W10163279 Trim, Lower Rack
13 Support, Bumper
4344886 Left
4344885 Right
14 Screw
4344915 Left
4344914 Right
15
W10238033 Shelf, Large
16 4344871 Glass, Shelf
17 4344868 Shelf, Small
18 4344869 Glass, Shelf
19 4344872 Trim, Shelf
20 4344873 Seal, Rear
21 4344874 Seal, Side (2)
22 4344875 Seal, Front
23
W10239364 Shelf Support
24
W10239371 Shelf Support
25
W10239368 Shelf Support
26
W10162986 Screw W/Washer
27
W10238187 Top Cover
28
W10238184 Bottom Cover
29
W10238024 Transformer Cable
30
W10238026 Sensor Assy
31
W10238025 Sensor Assy, Top
32
W10238028 Extension Cable
33
W10238180 PCB Display Board
Following Parts Not Illustrated
W10204809 Screw, Cover
W10238031 LED Spacer
W10238384 Seal
W10238189 Support
W10239385 Support Spacer
W10243273 Screw, Support
W10243310 Screw, Support
W10243312 Screw, LED

DOOR PARTS
5
For Models: KBCS24LSBS02
(Black Cabinet)
W10241951
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4344854 Door Assembly
(Includes Gasket)
2
W10162992 Washer−Bottom
3
W10163191 Gasket−Push Plate
4 4344787 Hinge, Bottom
5 4344754 Hinge, Top
6 4344755 Spacer, Top Hinge
7 4344756 Spacer,
Bottom Hinge
8 4344757 Actuator, Switch
9 4344758 Door Stop
10 4344852 Door Gasket
11 4344810 Handle, Door
12 4344856 Door Skin,
Stainless Steel
13 4344760 Washer
14 4344803 Spacer, Door
15
W10238056 Plate
16 4344796 Screw
17 Screw, Lower Hinge
4344906 Quantity 1
W10243104 Quantity 3
18
W10204865 Screw
19
W10243123 Screw
20 4344801 Screw
21 4344808 Screw
22
W10239386 Nameplate
OPTIONAL PARTS
NOT ILLUSTRATED
8171420 Cleaner, Stainless
Steel (12 oz)

UNIT PARTS
6
For Models: KBCS24LSBS02
(Black Cabinet)
W10241951
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10163193 Drain Pan
2 4344773 Bracket,
Defrost Timer
3 4344774 Defrost Timer
4 4344797 Screw
5 4344776 Start Device
6
W10238066 Mounting Plate,
Compressor
7 4344778 Grommet, Fan Motor
8 4344779 Grommet,
Compressor
9 4344780 Bolt, Compressor
10 4344781 Fan Motor,
Condenser
11 4344782 Baffle, Air
12 4344783 Fan Blade
13 4344784 Bracket, Motor
14 4344785 Bracket, Motor
15 4344786 Cover, Rear
16 4344837 Capacitor
17 4344836 Clip
18
W10163276 Trap, Drain
19 4344861 Power Cord
20 4344829 Cable Tie
21
W10163273 Drier
22 4344907 Trim Edge
23
W10238022 Clip
24
W10163274 Pad−Rubber
25 4344826 Screw
26 4344825 Screw
27 4344832 Screw
28 4344775 Compressor
(Includes Items
5, 8, 16, 17 & 21)
29 4344834 Screw
30 4344833 Screw
31
W10238070 Transformer
32
W10163278 Thermostat
33 4344864 Bracket,
Thermostat
REFRIGERANT CHARGE
3.5 Ounces
(R−134A)
