Instruction Manual
VDV Scout®Pro 2
Test-n-Map™Remote Kit
VDV770-827
ENGLISH
Français pg. 13
Português pg. 9
Español pg. 5

2
ENGLISH
VDV Scout®Pro 2 Test-n-Map
™
Remote Kit
Instruction Manual
WARNINGS
To ensure safe operation and service of the tester, follow these instructions. Failure to observe these warnings can
result in severe injury or death.
• The VDV Scout
®
Pro 2 is designed for use on unenergized cabling systems. Connecting the VDV Scout
®
Pro 2 to
live AC power may damage it and pose a safety hazard for the user.
• Poorly terminated RJ plugs have the potential to damage the jacks on the VDV Scout
®
Pro 2. Visually inspect an RJ
plug before inserting it into the tester. The contacts should always be recessed into the plastic housing of the plug.
Plugging 6-position plugs into the 8-position jack on the tester has the potential to damage the outer-most contacts
of the jack unless the plug is specifically designed for that purpose.
SYMBOLS:
WARNING: Potential for personal injury.
Caution: Potential for damage or destruction to equipment.
Always wear approved eye protection.
Do NOT use on energized circuits.
Conformité Européenne. Conforms with European Economic Area directives.
This symbol indicates that equipment and its accessories shall be subject to a separate collection
and correct disposal.
COMPATIBILITY
VDV Scout
®
Pro 2 Test-n-Map™ Remote Kit (VDV770-827) is compatible with the following VDV Scout
®
Pro Testers:
Tester Part Number Kit Part Number Button Color Compatibility
VDV Scout
®
Pro Tester VDV501-053 VDV501-809 BLACK NO
VDV Scout
®
Pro LT Tester VDV501-068 VDV501-814
VDV501-816 RED YES
VDV Scout
®
Pro 2 Tester VDV501-098
VDV501-823
VDV501-823R
VDV501-824
BLUE YES
VDV Scout
®
Pro 2 LT Tester VDV501-108 VDV501-825
VDV501-826 RED YES

3
ENGLISH
PORTS AND REMOTES OVERVIEW
RJ45 Port: Data cable, Ethernet cable, 8-wire cable, 4 twisted pair cable, Cat5e, Cat6, Cat6a, Cat7.
F-Connector Port: Video cable, coaxial cable, RG6 cable, RG59 cable.
RJ11/12 Port: Phone cable, POTS (plain old telephone service) cable, 4-wire cable, 6-wire cable,
2 twisted pair cable, 3 twisted pair cable, Cat3.
RJ11/12 port
RJ45 port
Use for cable location identification mapping and continuity testing. Remotes display on tester
as Remote IDs #2 - #8.
Self-Storing Remote
VDV999-109
SELF-STORING REMOTES
TEST-N-MAP™REMOTES
Use for cable location identification mapping and/or continuity testing. Self-storing remotes display on tester
as Remote ID #1.
RJ11/12 port
Front
RJ45 port
F-connector port RJ45 port
Self-Storing Test-n-Map™Remote
VDV999-110
Test-n-Map™Remote ID # Part #
2VDV501-112
3VDV501-113
4VDV501-114
5VDV501-115
6VDV501-116
7VDV501-117
8VDV501-118
Back
F-connector port

4
ENGLISH
TELEPHONE JACK TESTING
The Test-n-Map Remotes #2 - #8 come with an RJ45 port. In order to use these remotes with an RJ11 or RJ12 Jack, an
adapter cable must be used.
CAUTION: Failure to use the Klein Tools Universal RJ12 Jumper Cable (VDV726-125) or an approved equivalent may
result in damaged contact pins in the remote.
VDV726-125
KLEIN TOOLS, INC.
450 Bond Street
Lincolnshire, IL 60069
1-800-553-4676
www.kleintools.com
CUSTOMER SERVICE
1. Remove single screw in the middle of the back of the VDV Scout
®
Pro 2 with a #1 Phillips head screwdriver.
Remove battery door.
2. Disconnect battery cable and recycle exhausted battery.
3. Acquire a 9 volt alkaline battery (IEC 6LR61, ANSI/NEDA 1640A).
4. Connect battery cable to new battery observing polarity and place into battery compartment.
5. Replace battery door and screw, taking care not to over-tighten it.
WARRANTY
www.kleintools.com/warranty
CLEANING
Turn instrument off and disconnect any cables. Clean the instrument by using a damp cloth. Do not use abrasive cleaners
or solvents.
STORAGE
Remove the batteries when instrument is not in use for a prolonged period of time. Do not expose to high tempera-
tures or humidity. After a period of storage in extreme conditions, allow the instrument to return to normal operating
conditions before using it.
DISPOSAL /RECYCLE
Do not place equipment and its accessories in the trash. Items must be properly disposed of in accordance with
local regulations.
Prior to disposal of this product, please contact Klein Tools for proper disposal options.
BATTERY REPLACEMENT
