Klipsch SW-350 User manual

SW Subs
Owner's Manual
SW-350 and SW-450

The exclamation point, within an equilateral triangle, is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electrical shock to persons.
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. DO NOT install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. DO NOT defeat the safety purpose of the polarized or
grounding type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wider blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles,
and the point where it exits from the apparatus.
11. ONLY USE attachments/accessories specified by the
manufacturer.
12. USE only with a cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/ apparatus combination to
avoid injury from tip-over.
13. UNPLUG this apparatus during lightning storms or when
unused for long periods of time.
14. REFER all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
15. DO NOT expose this apparatus to dripping or splashing
and ensure that no objects filled with liquids, such as
vases, are placed on the apparatus.
16. To completely disconnect this apparatus from the AC Mains,
disconnect the power supply cord plug from the AC receptacle.
17. The mains plug of the power supply cord shall remain
readily operable.
Important Safety Information
WARNING: To reduce the risk of fire or electrical shock, do not expose
this apparatus to rain or moisture.
WARNING: No naked flame sources – such as candles – should be
placed on the product.

WARNING
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this
equipment are hazardous to life. No user-serviceable parts inside.
Refer all servicing to qualified service personnel.
Klipsch powered subwoofers are designed to reproduce deep bass
and deliver the impact that makes your movies and music come
alive. For optimum performance, place your subwoofer in a corner of
the room on the same wall as your front channel speakers. (refer to
Figures 1 and 2). Please note that room placement can have a dra-
matic effect on the performance of your powered subwoofer. Corner
placement, as suggested above, will increase the amount of bass
output, while placing the subwoofer along the middle of a wall, or
out in the room will decrease the amount of bass output. Experiment
with a number of different placement options and control settings
to find the one that best suits your particular room and taste. When
choosing your subwoofer’s location, keep in mind that you will need
to connect the subwoofer’s built-in amplifier to an AC power outlet.
Positioning Your Subwoofer
Optimal Connections – Klipsch SW powered subwoofers can be
connected to the subwoofer output of your electronics via the RCA
jack inputs (“LINE IN”) on the subwoofer’s rear panel (refer to
Figure 3). This can be in place of the conventional speaker wire
connections (“SPEAKER LEVEL IN”). For more information on the
controls mentioned in this manual and on bass management, see
your dealer or visit www.klipsch.com.
Conventional Speaker Wire Connections – Using 16-gauge or
larger speaker wire, connect the RED “positive” (+) terminal of
your amplifier’s LEFT channel to the RED (+) terminal of your
subwoofer’s LEFT channel input (“SPEAKER Level IN”). Connect
the BLACK “negative” (-) terminal of your amplifier’s LEFT channel
to the BLACK “negative” (-) terminal of your subwoofer’s LEFT
channel input (“SPEAKER Level IN”). Repeat this procedure for
connecting your amplifier’s RIGHT channel to your subwoofer’s
RIGHT channel input (refer to Figure 4). Take care to en0sure
Connections and Controls
WARNING: Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
Place the equipment near a main power supply outlet and make sure
that you can easily access the power breaker switch.
WARNING: This product is intended to be operated ONLY from the
AC Voltages listed on the back panel or included power supply of the
product. Operation from other voltages other than those indicated
may cause irreversible damage to the product and void the product’s
warranty. The use of AC Plug Adapters is cautioned because it can
allow the product to be plugged into voltages in which the product was
not designed to operate. If the product is equipped with a detachable
power cord, use only the type provided with your product or by your
local distributor and/or retailer. If you are unsure of the correct
operational voltage, please contact your local distributor and/or retailer.

that no bare wires from any of the connections touch any other
terminals, as this could cause a short and damage your equipment.
“LINE IN/LFE” – This input is filtered by the built-in “Low Pass”
(LP) crossover and is designed as a general purpose input for
the subwoofer. It accepts the LFE signal output of your digital
surround electronics.
“LOW PASS” (LP) Control – This control allows the user to select
the upper frequency cutoff of the subwoofer. Frequencies above
the control setting are filtered out, allowing you to blend the
subwoofer’s output with that of your main speakers. The frequency
is selectable from 40-150Hz. For sources with an LFE output
or that use an internal crossover, the lowpass filter should be
defeated by setting the control to “BYPASS”.
“VOLUME” – This control serves as an overall volume control for
the subwoofer. It is used to match the output level of the subwoofer
to the main speakers.
“PHASE” 0/180 – This control is used to acoustically match the
subwoofer’s output to your main speakers. Select the position
either 0˚ or 180˚ in which your subwoofer has more output at the
listening position.
“Power” ON/OFF– Klipsch SW subwoofers use a detachable power
cord and do not have a main power switch. To fully remove power
from the subwoofer, the power cord must be disconnected from
the unit.
Auto/On – When this switch is in the “ON” position, the subwoofer
will remain on at all times. When this switch is in the “AUTO”
position, the subwoofer will automatically turn “on” when it senses
a signal. It will automatically turn “off” after 15 minutes with no
signal. When this switch is in the “OFF” position, the subwoofer will
remain “off” until the switch is manually turned back to the “ON” or
“AUTO” position.
LED indicator– Klipsch SW subwoofers have an LED indicator
on the front that indicates the status of the built in amplifier. The
LED will light blue when the amplifier is on and receiving a signal.
When the unit is in standby mode or turned off, the LED indicator
will turn off.
Your subwoofer has a durable vinyl finish that should only require
dry dusting or cleaning with a dry cloth. Avoid the use of abrasive or
solvent-based cleaners and harsh detergents. The brush attachment
of your vacuum should remove any dust from your subwoofer
enclosure.
Care and Cleaning

Figure 1 - Stereo Placement
Figure 2 - Surround LCR and Rears Placement
Sub
Angle Inward
*Less distance will increase bass,
but worsen sound quality.
S
+ Optional
Sub
S
+ Optional
Sub
S
6'-15'
SS
L R
C
TV
Y
XZ
+ Optional
Sub
S
+ Optional
Sub
Sub
X=Y=Z
Alternate
rear placement
AA
BB

LFE Output on Processor/
Pre-Amp/Receiver connected
to LFE input on subwoofer
amplifier
ON / AUTO / OFF
PHASE
VOLUME
LOWPASS (Hz)
+ +
– –
SPEAKER LEVEL IN
0º 180º
40Hz
80Hz
150Hz
120Hz
BYPASS
MIN MAX
LINE IN
RIGHT LEFT / LFE
RIGHT LEFT
Figure 3 - Line Level Connections
Figure 4 - Speaker Level Connections
Left & Right pre-outs on
Processor/Pre-Amp/Receiver
connected to Left & Right
line inputs on subwoofer amplifier
OR
ON / AUTO / OFF
PHASE
VOLUME
LOWPASS (Hz)
+ +
– –
SPEAKER LEVEL IN
0º 180º
40Hz
80Hz
150Hz
120Hz
BYPASS
MIN MAX
LINE IN
RIGHT LEFT / LFE
RIGHT LEFT
Main speaker outputs on receiver
connected to high level inputs on
subwoofer amplifier (Right is
shown, repeat for Left)
