Klipsch Reference Series RW-12d User manual

RW-12d
SPECIFICATIONS
ENCLOSURE TYPE Bass-reflex via front-firing CornerPort™
ACTIVE DRIVERS 12" (30.5cm) Cerametallic™cone,
front-firing woofer
AMPLIFIER TYPE BASH® Digital hybrid
AMPLIFIER POWER FTC Rated Power: 350 watts continuous @
<2% THD / Dynamic Power*: 825 watts
BANDWIDTH 24-120Hz ± –3dB
MAXIMUM OUTPUT 116dB @ 30Hz 1/8 space, 1m
CONTROLS DCS control and feature set w/ 3 system presets
INPUTS L/R Line-level RCA jacks, L/R High-level
speaker binding posts
OUTPUTS None
FINISHES Black Ash wood grain vinyl
WEIGHT 49 lbs. (22.2kg)
HEIGHT 19.2" (48.8cm)
WIDTH 14.6" (37.1cm)
DEPTH 21" (53.3cm)
VOLTAGE 110/120 VAC 60Hz
EXPORT VERSION 220 VAC 50/60Hz
12'' Powered Subwoofer
Capturing all the sonic excitement of low-
frequency effects, the Reference Series
RW-12d Digitally Controlled Subwoofer
(DCS™) delivers rock-solid performances.
With its class-leading technology and superior
design, this hard-hitter perfectly rounds out a
home theater or two-channel stereo
music system.
The RW-12d shakes things up by employing a
12-inch front-firing Cerametallic™ woofer and
a 340-watt RMS amplifier. Exclusive Corner
Port™ Technology allows the subwoofer’s
port tube to be as long as possible without
bending, minimizing turbulence that can cause
port noise and distortion. It also allows the
enclosure to be tuned to a lower frequency
than would otherwise be possible to create
deeper bass from a smaller cabinet. Another
important element is a corner-shaped flange at
the port’s internal opening, which amplifies the
benefits of a longer port.
For quick and easy adjustment of all functions,
the RW-12d features the DCS digital
user-interface that includes three equalization
modes (flat, depth and punch) and three user-
adjustable presets (music, movie and night) to
create specific listening preferences.
Available in a black woodgrain vinyl finish, this
extraordinary subwoofer also comes with an
IR sensor for operation from any learning
remote or control system.
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2006
*Dynamic power indicates the actual power this amplifier will deliver to the woofer under normal operating
conditions. While the FTC power rating indicates power available on a continuous, long-term basis, subwoofers
do not rely on that type of power. Instead, the amplifier is called upon to deliver large, short-term peaks of
power to be able to support the wide dynamics required by today’s digital music and movie formats. In addition
to the required FTC power rating, we’ve provided the dynamic power rating as a better indication of the
product’s true performance.
