KMA TYLER THE FREQ SPLITTER User manual

Instruction Manual+ Warranty
Safety Instructions
This device is intended to be used for sound
processing of signals from musical instruments.
Any other use or use under other operating
conditions is considered to be improper and may
result in personal injury or property damage.
No liability will be assumed for damages resulting
from improper use.
Operating conditions
This device has been designed for indoor use only.
To prevent damage, never expose the device to
any liquid or moisture. Avoid direct sunlight, heavy
dirt and strong vibrations.
External power supply
Use only with 9V power supply. Failure to do so
could result in damage to the device and possibly
the user. Unplug the external power supply before
electrical storms occur and when the device is
unused for long periods of time to reduce the risk
of electric shock or fire.
Warranty
We offer a 5-year warranty. The warranty expires
immediately if the product is changed, operated
incorrectly, intentionally or negligently damaged,
or if it is damaged by force majeure or use beyond
the permitted operating conditions.
Internal Controls
HP_S
Sets the high-pass channel FX-loop input
impedance
LP_S
Sets the low-pass channel FX-loop input
impedance
IN_S
Sets the general input impedance
More Pedals and Infor ation
KMA Audio Machines
GUITAR AND BASS EFFECT PEDALS
Handmade in Berlin with love since 2013
www.kma-machines.com
MID
LOW HIGH
IN_S
HP_S LP_S

Each channel has its own footswitchable
buffered FX-Loop to process your lows
(WOOD) or your highs (STEEL) independently,
for a parallel processing of your signal.
The MIX control lets you dial in the right ratio
of low- and high-pass processed signal. We
designed the MIX control
totally at to avoid any
notches or bumps in your
frequency response, with equally
chosen cut-off frequencies for the
LP and HP.
The LEVEL control can boost
your signal up to 14 dB, if needed.
We added internal trimpots to control
the impedance for the general
input and each effect-loop, which is
pretty handy when you want
to insert your favorite fuzz pedal.
The phase inverter helps you avoid any
phase cancellation issues with external
pedals inserted.
Controls
Low-Pass
Sets the cut-off frequency of the low-pass
between 3 kHz and 20 Hz
High-Pass
Sets the cut-off frequency of the high-pass
between 3kHz and 20Hz
Mix
Sets the ratio of the low- and high-pass
channel: fully left 100% LP, noon 50/50,
fully right 100% HP
Level
Sets the overall volume with up to 14 dB
Phase Switch
Switches the phase of the high-pass
Tyler –Frequenzy Splitter
Can you hear the sounds coming from the
woods? The steely strokes of his axe echoing
glassy through the forest separated from the
thuds of the chopped trees. It’s TYLER, a man
rough and towering, his annel shirt is spiked
with strands, wielding his steely axe with only
one aim: Splitting up your sound.
KMA Audio Machines
brings you the ultimate
tool, especially for bass
player to develop new
sounds and push your
creativity to new limits.
TYLER – The Frequency
Splitter is an active and
variable two channel
crossover/signal splitter.
It splits up your signal in a
HIGHPASS and a LOWPASS
path. Both lter have a 12dB/Oct. roll-off with a
variable cut-off frequency, which goes from
20Hz to 3kHz.
20 Hz
dB
Freq
20 Hz
450 Hz
3 kHz
450 Hz 3 kHz
dB
Freq
20 Hz
20 Hz
450 Hz
3 kHz
450 Hz 3 kHz
dB
Freq
Noon
LeftRight
LOW-PASS HIGH-PASSLEVEL Phase Switch
-+
LP Led HP Led Bypass Led
MIX
