FlexStat 1 Operation Guide, Rev. K
Operation Guide
FlexStat™
BACnet Programmable Thermostats
Contents
Overview ................................................................3
Applications and Installation ...................................3
Operation (Basic) ....................................................4
Home, Main Menu, and Override Screens .......... 4
Navigation ..........................................................4
Main Menu and Settings ...................................... 4
Room Temp. Setpoint Adjustment .......................4
H/C, Fan, Occupancy, and Override ...................4
Configuration (Initial Setup) ...................................5
Main Menu Overview .........................................5
About the FlexStat ............................................... 5
Advanced Menu ..................................................6
(Advanced) Application Options ......................6
(Advanced) CB (Control Basic) Programs .........7
(Advanced) BACnet Communications ..............8
(Advanced) Date/Time .....................................8
(Advanced) BACnet Device Properties .............9
(Advanced) Inputs ............................................9
(Advanced) Temp. Setpoint Limits ....................9
(Advanced) Motion Sensor ...............................9
(Advanced) Security Levels and Passwords ..... 10
(Advanced) Trend Logs ...................................11
(Advanced) Test ..............................................11
(Advanced) User Interface (UI) Modes .......... 12
Alarms ............................................................... 13
Date/Time .........................................................13
Schedules .......................................................... 14
Setpoints ...........................................................15
System Setup .....................................................15
Trend Viewer .....................................................15
Resetting the FlexStat ............................................16
Types of Reset ....................................................16
Warm and Cold Starts .......................................16
Restore Factory ................................................. 17
Network Connection .............................................18
BACnet MS/TP Network Communication ......18
PC Data Port Connection ............................... 18
Maintenance ......................................................... 19
Firmware Upgrade ................................................19
Programming (Custom) .........................................19
Specifications, design, and operation are subject to change without notice.

FlexStat 2 Operation Guide, Rev. K
Accessories ...........................................................19
Troubleshooting .................................................... 20
Alarm Issues ...................................................... 20
Alarm, (False) Fan Fail .................................... 20
Alarm, (False) Low Limit (Freeze Stat) ............20
Alarm, (False) Space Temp. or Humidity ........20
Communication Issues ......................................20
KMD-5576 Communication Issues .................20
MS/TP Network Communication Issues .........20
Cover, Display, and Reset Issues ........................21
Cover Binds on Backplate ..............................21
Display Is Blank (or Erratic) ...........................21
Display Freezes (Buttons Have No Effect) ......21
Display Keeps Resetting .................................21
Custom Programming and Web Issues ............... 22
Control Basic Programs Do Not Work ............22
Custom Web Graphics Do Not Work .............22
Input, Sensor, and Value Issues .......................... 22
Input Values Are Outside the Expected Range 22
Motion/Occupancy Sensor Does Not Work ...22
Temperature Reading Is Incorrect ..................23
Temperature Setpoint Is Not Maintained .......23
Output, Fan, and Relay Issues ........................... 23
Analog Output Does Not Work ......................23
Fan Does Not Run .......................................... 24
Relay (External) Does Not Work ....................24
Relay (Internal) Does Not Work .....................24
Upgrading Firmware Issues ...............................25
Firmware Upgrade Failures ............................ 25
FlexStat Malfunctions After Upgrade ............. 25
Wiring Issues ..................................................... 26
Installation Wiring Considerations ................. 26
Troubleshooting Wiring Problems ..................26
Support ................................................................. 27
Important Notices .................................................27
Reference ..............................................................28
Acronyms and Abbreviations .............................28
Definitions of Terms .......................................... 29
Index .....................................................................30

FlexStat 3 Operation Guide, Rev. K
Overview Applications and Installation
1. WiretheFlexStat’sbackplatetothedesired
equipmentandsettheFlexStat’send-of-lineand
inputpull-upresistorswitches.
2. Selecttherelevantapplicationandoptionsfrom
the(Advanced)Applicationsubmenuofthe
AdvancedMenuandotherappropriatemenus.
3. ConguretheFlexStatfortheBACnetnetwork.
(SeeNetwork Connection on page 18.)
For general mounting and connection details,
including network wiring, EOL termination, power
connections, input/output connections, pull-up
resistor switch seings, see the relevant model’s
Installation Guide. For extended information about
wiring and sequences for specic applications, see
the FlexStat Application Guide.
• AHU
• FCU
• HPU
• RTU
Dimensions in
inches (mm)
EIA-485 Data Port for
Quick Network Access
Terminal Blocks
on Removable
Backplate for
Easy Wiring
3 Analog
Inputs
for Other
Sensors or
Contacts
24 Volts AC
Power
Up to 9
Outputs
(Analog
and/or
Relays)
Quick (Temporary) Network/
Programming Access
Communication with
Other BACnet Devices
Temperature
Sensing
Optional
Humidity
and
Motion
Sensing
Applications
5.551
(141)
4.192 (106)
1.125
(28.6)
Theaward-winningKMCFlexStatseriesofintelli-
genttemperature/humidity/occupancy-sensing,wall-
mounted,thermostat/controllersarenativeBACnet
AdvancedApplicationControllers(B-AAC)foruse
inaBACnetsystem.TheFlexStatsimpliesnet-
workedzonecontrolforcommonpackagedHVAC
equipment,suchaspackagedrooopunits,fancoil
units,heatpumps,andothersimilarapplications.In
addition,applicationssuchaspressuredependent
VAV,terminalreheat,andmedium-sizedcentral
stationairhandlingequipmentapplicationsmay
alsobeaddressedthroughtheon-boardlibrariesof
programsbuiltintothedevices.
Theon-boardlibraryofprogramspermitsrapid
congurationofawiderangeofHVACcontrolap-
plications.
TheFlexStatseriesalsoprovidesthecapabilityto
customizethestandardlibraryofsequencesusing
KMC’sBACstageprogrammingtool.Thisenablesa
localauthorizedKMCinstallingcontractortoadapt
thestandardlibrarytotheuniquesiteneedsandap-
plicationspecicrequirementsofaparticularproject.
CAUTION
To avoid damage from ground loops and other
communication issues in networked FlexStats,
correct phasing on network and power
connections on ALL the networked controllers
is critically important.

FlexStat 4 Operation Guide, Rev. K
WED 11/19 3:20 PM
COOL:
OCC:
FAN:
HUM: 36% RH
Operation (Basic)
Enter
Home, Main Menu, and Override Screens
Menu
Override
Setpoint
Home Screen
Configuration Screens
MAIN MENU
ABOUT
ADVANCED
ALARM
DATE/TIME
SCHEDULE
SETPOINTS
SYSTEM
Navigation
Navigatethemenusandchangeseingsbypress-
ingacombinationofvariousarrowbuonsandthe
Enterbuon.Pushthe:
• Enterbuontoselectand/orexitvalueediting.
• UporDownbuontomoveamongentries.
• RightorLebuontomoveamongvalueelds.
• LebuontoreturntotheHomescreen.
Room Temp. Setpoint Adjustment
FromtheHome(temperaturedisplay)screen,press
theUporDownarrowbuononcetoviewtheexist-
ingsetpoint.
Totemporarilychangethesetpoint,presstheUp
orDownarrowbuonrepeatedlyuntilthedesired
seingisdisplayedandpressEnter.(IfEnterisnot
pressed,thedisplaywillreturntotheHomescreen
aerabouttensecondsandthenewsetpointvalue
willstillbesaved.)Thenewsetpointwillholduntil
thenextschedulechange.
Topermanentlychangethesetpointforoccupied
mode,gototheSetpointssectionundertheMain
Menu.(IntheSetpointsmenu,heating/coolingset-
points/setbacksanddeadbandcanbechangedwith,
ifrequired,thecorrectpasswordaccess.SeeSet-
points on page 15.)
H/C, Fan, Occupancy, and Override
When the fan is commanded to run, the animated
“FAN” icon rotates (if programmed to). When the
fan command stops, the fan icon is motionless.
The “OCC” icon shows a sun when in Occupied
mode and a quarter moon when in Unoccupied
mode.
HEAT or COOL will show (and be animated when
there is an active command), depending on the cur-
rent mode. This can also be turned OFF.
To override these modesfromtheHome(tempera-
turedisplay)screen,presstheLearrowbuon.
PressUporDowntogettothedesiredlineandthen
Enter(twice)toeditthemodeseing.PressLeto
exittoHome.
Main Menu and Settings
FromtheHome(temperaturedisplay)screen,press
theRightarrowbuontoentertheMainMenu.You
mayneedtoenterapasswordtochangeanyseings.
FAN MODES
UNOCC:
OCC: AUTO
AUTO
Override Screens
NOTE: AccesstotheMainMenu,setpointadjust,
andSystem/Occupancy/Fanoverridemay
requireapassword.
Right
(Menu)
Left
(Override)
Down (Setpoint)
Up (Setpoint)

FlexStat 5 Operation Guide, Rev. K
Configuration (Initial Setup)
NOTE: Menus shown in this document reect
rmware version R1.3.0.4 or later. Actual
context-sensitive screens are dependent
on rmware version, FlexStat model, and
options selected.
NOTE: If appear at the top of the screen
(such as in the Main Menu), scroll up or
down to see the rest of the menu’s o-
screen choices.
Main Menu Overview
MAIN MENU
ABOUT
ADVANCED
ALARM
DATE/TIME
SCHEDULE
SETPOINTS
SYSTEM 
Navigatethemenusandchangeseingsbypressing
acombinationofbuons.Pressthe:
• Enterbuontoselectand/orexitvalueediting.
• Up/Downbuontomoveamongentries(up/
downlines).
• Le/Rightbuontomoveamongvalue elds
(le/rightspaces).
• LebuontoreturntotheHomescreen.
NOTE: Alog-inmayberequiredtoaccessmenu
items.
SETPOINTS
COOL SETPT:
HEAT SETPT: 67° F
COOL SETBACK: 80° F
SAVE CHANGE?
NO
YES
When prompted about a change (on any menu),
press Right/Le to select the desired choice and
then Enter.
About the FlexStat
ABOUT FLEXSTAT
FW: FLEXSTAT
VERSION: R1.3.0.0
BUILT: DEC 11 2009 @13:55:07
ASV: BAC_1xx63 R1.3.0.0 +6
MODEL: BAC–11163C
APP: AIR HANDLER
OPT: MOD H / MOD C
Thisdisplay-onlyscreenshows(scrolltoseeall):
• Firmwareversion(FW)
• Builddate
• Applicationsowareversion(ASV)
• Modelnumber
• Applicationcongurationandoptions(setinthe
Applicationmenu)
• Deviceinstance(setintheDevicemenu)
• MACaddress(setintheCommunicationsmenu)
• Serialnumber
• Boardrevision
NOTE: ASVwillshowCUSTOMifanybuilt-in
ControlBasicprogram(1–5)isnotrunning
orhasauto-rundisabled.

FlexStat 6 Operation Guide, Rev. K
Advanced Menu
ADVANCED
APPLICATION
CB PROGRAMS
COMMUNICATION
DATE/TIME
DEVICE
INPUTS
LIMITS
TheAdvancedMenudisplaysvarioussubmenus.
Notallsubmenuscanbeseenonthescreenatone
time.Scrollupordowntoseeadditionalsubmenus.
Toselectthedesiredsubmenu,press:
1. Up/Downtomove.
2. Entertoselect.
NOTE: TheAdvancedMenuhasmoresubmenus
thancanappearonthescreenatonce.Keep
scrollingupordowntoseealltheoptions.
(Advanced) Application Options
APPLICATION
DEGREES SCALE: °F
APP:
OPT: 4-PIPE
ADDITIONAL SETUP
FAN COIL
ADDITIONAL SETUP
DAMPER
FAN
HUMIDITY
SENSORS
VALVE
Tochange°ForC,preprogrammedapplicationtype,
andoptions,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
Be sure to select the correct °F/°C temperature scale
rst! To change the temperature scale aer the
application is congured, the selected application
will need to be reset to Not Congured.
NOTE: InHospitalitymode(only),the°F/°C
temperaturescalecanbetoggledby
pressingtheEnterbuon.See(Advanced)
User Interface (UI) Modes on page 13.
The type of application (as well as the model of
FlexStat) aects the context-sensitive options under
Additional Setup.
Auxiliary Heat (Heat Pump Only)
AUX HEAT SETUP
AUX HEAT:
DELAY (MINS): 60
COMP LOCKOUT
Damper Setup
DAMPER SETUP
ECON:
MIN POSITION (%): 10
CNTRL (0–100%): 2–10 V
ECON ENBLE TEMP: 55° F
LOW LIMIT ALARM: 45° F
MODULATING
NOTE: IftheEconomizeroptionisselectedwhen
thereisnomixedairtemperaturesensor
connected,aLowLimitAlarmwillresult.
SeeAlarms on page 13.
Fan Setup
FAN SETUP
SPEEDS:
OFF DELAY (SECS): 180
UNOCC: AUTO
OCC: AUTO
CONSTANT SPEED
NOTE: ForaFanFailAlarm,seeSensor Setup on
page 7andAlarms on page 13.
Humidity Setup
HUMIDITY SETUP
DEHUMIDIFICATION
HUMIDIFICATION DEHUMIDIFICATION
DEHUM:
ALLOW HTG DEHUM: NO
DEHUM SETPT: 60%RH
DEHUM DEADBAND: 5%RH
ENABLE
NOTE: Ifadehumidicationoptionisenabled,the
SpaceHumidityAlarmwillalsobeenabled.
SeeAlarms on page 13.

FlexStat 7 Operation Guide, Rev. K
Sensor Setup
SENSOR SETUP
IN 2: DISCH AIR TEMP
TheInput2sensor(AI2)canbeconguredfor
dischargeairtemperature(TypeIIIthermistoristhe
default),fanstatus(drycontact),orunused.
• Ifsetfordischargeairtemperature,thesensor
canbecalibratedandchangedfromthedefault
TypeIIIthermistortoaTypeII.See(Advanced)
Inputs on page 9.
• Ifsetfordischargeairtemperature,TrendLog
#2isautomaticallycreatedandmonitorsthe
dischargeairtemperature,butithasnoeecton
operation.
• Ifsetforfanstatusandnoclosedcontactis
detectedwhenthereisacallforfanoperation,a
FanFailAlarmiscreated.SeeAlarms on page 13.
• Ifsetforunused,built-inapplicationswillnot
useAI2,buttheinputwouldbeavailableto
customprogramming.
Staging Setup
STAGING
STG DELAY (MINS): 3
Valve Setup
VALVE SETUP
TYPE:
ACTION: NRM OPEN
2–POSITION
Seealso(Advanced) Motion Sensor on page 9.
(Advanced) CB (Control Basic) Programs
CB PROGRAMS
PROG1:
PROG2: RUNNING
PROG3: RUNNING
PROG4: RUNNING
PROG5: RUNNING
PROG6: HALTED
PROG7: IDLE
RUNNING PROGRAM #1
SETPOINTS & MODES
AUTO-RUN: TRUE
CHANGE: READY
STATE: RUNNING
HALT REASON: NORMAL
HALT DESC:
OUT OF SERVICE: FALSE
Tohaltorload/runthebuilt-in(1–5)andcustom
(6–10)ControlBasicprograms,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
NOTE: IfcustomControlBasicprogramsare
installedanda restore to factory seings
is performed, all factory programs are
restarted but all custom Control Basic
programs are halted. Changethestate
ofeachprogrambyloading/runningthe
programfromtheCBProgramsmenu(or
BACstage).
NOTE: IfcustomControlBasicprogramsare
installedand set to autorun,wheneverthe
rmware is updated,ALL (factory and
custom) programs are halted.
 IfcustomControlBasicprogramsare
installedbut NOT set to autorun,
whenever the rmware is updated, factory
programs are restarted but any (manual)
running custom programs are halted at
restart.
Changethestateofeachcustomprogram
byusingtheUpdateManagerorloading/
runningeachprogramfromtheCB
Programsmenu(orBACstage).
UPDATE MANAGER
PROGRAM CONFIG ERROR
ENABLE FACTORY:
ENABLE CUSTOM: NO
EDIT CB PROGRAMS
DONE
NO
NOTE: Customized programs are the responsibility
of the user.KMCControlsdoesnotprovide
supportforsuchprograms.

FlexStat 8 Operation Guide, Rev. K
(Advanced) BACnet Communications
COMMUNICATIONS
MAC ADDRESS:
BAUD RATE: 38400
MAX MASTER: 127
1
TosetparametersforBACnetMS/TPEIA-485
communications,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
NOTE: TheMaxMasteristhehighestMAC
addressadevicewillaempttolocate
whenpollingformasterdeviceson
thelocalnetwork.Toavoidpossible
communicationissueswiththenetwork
oracomputerconnectedthroughaKMD-
5576USBCommunicator,the Max Master
number should be the lowest number
needed for that network.
(Advanced) Date/Time
DATE/TIME
DATE:
TIME: 1:43:59 PM
UTC OFFSET: 300
DST ENABLE: TRUE
DST AUTO: TRUE
DST START:
>2ND SUN MAR 2:00 AM
APRIL 11 2009
Toenterdateandtimeinformation,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
ForareasthatobserveDaylightSavingTime,select
True/OnforDSTENABLE.
IftheFlexStatisusedinaBACnetnetworkwithUTC
(CoordinatedUniversalTime)synchronization(via
broadcastingoraddressingasinglethermostat)set
theUTCOsetvalue.TheUTCOsetvalueisin
minutesandcorrespondstothedistanceofthelocal
timezonetothezerodegreemeridian.Instand-alone
operationornetworksthatdonothaveUTCbroad-
casts,seingthisvalueisnotnecessary.
Sample Time Zones Oset to Equal UTC
Alaska 9hours=540minutes
USA/CanadaPacic
StandardTime
8hours=480minutes
USA/CanadaMountain
StandardTime
7hours=420minutes
USA/CanadaCentral
StandardTime
6hours=360minutes
USA/CanadaEastern
StandardTime
5hours=300minutes
Bolivia,Chile 4hours=240minutes
Argentina,Uruguay 3hours=180minutes
UnitedKingdom,
Portugal
0hours=0minutes
Europe(mostcountries) –1hours=–60minutes
Egypt,Israel,Turkey –2hours=–120minutes
Kuwait,SaudiArabia –3hours=–180minutes
UnitedArabEmirates –4hours=–240minutes
India,SriLanka –5.5hours=–330minutes
China,Mongolia –8hours=–480minutes
Korea,Japan –9hours=–540minutes
NewZealand –12hours=–720minutes
NOTE: TheBACnetstandardforthisosetvalue
is:“Thetimezonestothewestofthezero
degreemeridianshallbepositivevalues,
andthosetotheeastshallbenegative
values.”Thevalueisinminutes,nothours.

FlexStat 9 Operation Guide, Rev. K
(Advanced) Temp. Setpoint Limits
LIMITS
OCC MIN CLG:
OCC MAX HTG: 76° F
UNOCC MIN CLG: 77° F
UNOCC MAX HTG: 65° F
71° F
Tosettheminimumandmaximumalloweduser/
operatorsetpointvalues,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
(Advanced) Motion Sensor
MOTION SENSOR
MOTION OCC:
STATE: OCCUPIED
ENABLE
InBAC-11xxxmodels,amotion/occupancysensor
maybeenabledtotriggeroccupancyoverride.
Duringscheduled“o”times,themotionsensorwill
startoccupancyoverride(for1hourasadefault)
whenitdetectsmotion.Occupancyoverridewillend
(withthedefaultseing)1houraermotionwas
lastdetected.Thelengthofoccupancyoverrideis
congurableintheSystemmenu.SeeSystem Setup
on page 15.
Toenable/disableormonitorthemotion/occupancy
sensor(ifinstalled),press:
1. Entertoselect.
2. Right/Letomoveamongvalueelds.
3. Up/Downtoincrement/decrementvalue.
TheStateeldmonitorswhethermotionhasbeen
detectedduringthelastscanofthemotionsensor
input(BI6).Detectedmotionwillshowan“occu-
pied”state.Thiscanbeusedduringtroubleshooting
todetermineifmotionisbeingdetected.
(Advanced) BACnet Device Properties
DEVICE
INSTANCE:
NAME: FlexStat_101
LOCATION: KMC Controls
RESTART: NO
RESTORE FACTORY: NO
1
TosettheBACnetdeviceinstance,name,and
location,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
The FlexStat can also be restarted or restored to
factory defaults from this menu.SeeReseing the
FlexStat on page 16formoreinformationaboutthat
function.
(Advanced) Inputs
INPUTS
1: SPACE TEMP
2:
3: MIXED AIR TEMP
4: OUTSIDE AIR TEMP
4: SPACE HUMIDITY
DISCH AIR TEMP
INPUT #2
DISCH AIR TEMP
VALUE: 60.0° F
CAL. OFFSET: 0.0
OUT-OF-SERVICE: FALSE
SENSOR: 10K TYPE III
Inputsvaryaccordingtomodel,selectedapplication,
andselectedapplicationoptions.See(Advanced) Ap-
plication Options on page 6.
Tochangesensortypeandcalibrationoset,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
Valuewillshowatemperaturereadingoravoltage
(0.0to3.0),dependingonthesensor.Analogsensors
canbecalibratedusingtheCalibrationOsetoption.

FlexStat 10 Operation Guide, Rev. K
(Advanced) Security Levels and Passwords
SECURITY
ACCESS LEVELS
PASSWORDS
ACCESS LEVELS
SETPOINT ADJ:
MAIN MENU: ADMIN
SYSTEM MODE: OPER
OCC OVERRIDE: USER
FAN OCC/UNOCC: OPER
NONE PASSWORDS
USER:
OPERATOR:
ADMIN:
1 0 0 0
1 2 3 4
5 6 7 8
AccesstotheMainMenu,SetpointAdjust,and
System/Occupancy/Fanseingshaveadefault
passwordlevelofUser.Thislevelcanbechangedfor
eachfunctiontoNone,Operator,orAdministrator
throughtheAccessLevelsmenu.Passwordsareset
inthePasswordsmenu.
Anypersoncanviewthedisplaybutmightnotbe
abletochangeanyseingswithoutlogginginwith
oneofthethreelevelsofpasswords:
• None(Level“0”):Nopasswordisrequired
(everyonehasaccess).(Forexample,anyonecan
adjustasetpointwithAccessLevelNoneevenif
allotherfunctionsrequireapassword.)
• User(Level1):SeetheMenuItemsAccessLevels
chart.
• Operator(Level2):SeetheMenuItemsAccess
Levelschart.
• Administrator(Level3): Canaccessallmenus
andchangealleditablevalues.DO NOT
FORGET THIS PASSWORD!
NOTE: Seing a password to (the default) 0000
eliminates the password prompt and
allows full access for that level. If no
password is set for ADMIN, no password
prompt will occur. If any password is set
for ADMIN, the menu items accessible
at the various levels are shown in the
following chart.
NOTE: Changes in security levels and/or
passwords take eect when the current
Administrator log-in has timed out. Log-
inslastuntil60seconds(default)aer
thelastbuonpress.Desiredlengthof
inactivitytime-outcanbechangedinthe
Systemssubmenu.
NOTE: Whenseingapassword,theUpbuon
increasesthealphanumericvalue(0
through9andthenAthroughZ).The
Downbuondecreasesthevalue.DO NOT
FORGET THE ADMIN PASSWORD!
Toenteranalphanumericpasswordattheprompt:
1. Up/Downtomove.
2. Entertoselect.
3. Up/Downtoincrement/decrementvalue.
Therequiredpasswordlevelisspeciedinthe
prompt.
Tolock the buonsaercongurationiscomplete
(anddisablefurtherchanges),selectLockedUI
mode.See(Advanced) User Interface (UI) Modes on
page 12.
Foradditional physical security and protection
from vandalism,installtheFlexStatinsideathird-
partylockingthermostatguard/cover(butproper
airowmustbemaintained).
Menu Items Access Levels
Menus User Operator Administrator
Home Screen * = Selectable, Default is User
Setpoint Adjust (Up/Down) x* x* x*
System Mode (Auto/Heat/Cool/Off) x* x* x*
Occupancy Override (On/Off) x* x* x*
Fan Modes (Auto/On/Off) x* x* x*
Main Menu* (Default is User)
About x x x
Advanced x x
Alarm x x
Date/Time x x
Schedule x x
Setpoints x x
System x x
Trend Viewer x x x
Advanced Menu
Application x
Additional Setup x
Control Basic Programs x x
Communication x
Date/Time x x
Device x
Inputs x x
Limits x x
Motion Sensor x x
Security x
Trend Logs x x
Test x x
This chart shows conditions in which an administrator password is set
(is not 0000) and default password levels are used.
NOTE!
To erase a forgotten password:
1. Connect to the FlexStat using TotalControl (BACstage won’t work).
2. Open File Object [FILE133001] ui.cfg.
3. Change File Size to 0 and Save Changes.
4. Restart the FlexStat.

FlexStat 11 Operation Guide, Rev. K
(Advanced) Test
TEST
LCD/KEY TEST
Thetestmenumerelyteststhedisplay’spixelsand
keyfunctions.
1. Up/Downtomoveamongentries.
2. Entertoselectandexit.
(Advanced) Trend Logs
TREND LOGS
TREND 1:
TREND 2: TRUE
TREND 3: FALSE
TREND 4: FALSE
TREND 5: FALSE
TREND 6: FALSE
TREND 7: FALSE
TRUE
TREND #1
SPACE TEMPERATURE LOG
OBJECT REF: AI1
LOG ENABLE: TRUE
INTERVAL (MINS): 10
STOP W/FULL: FALSE
RESET COUNT: NO
COUNT: 256
TOTAL CNT: 613
VIEW LOG BUFFER
TL #1–SPACE TEMP
APR17 1:27PM, 71.4
APR17 2:27PM, 71.5
APR17 3:27PM, 71.6
APR17 4:27PM, 71.8
APR17 5:27PM, 76.3
APR17 6:27PM, 81.2
APR17 7:27PM, 82.3
NOTE: Spacetemperature(AI1)isthedefaulttrend
log#1.IfAI2isconguredfordischargeair
temperature,thatwillbecomethedefault
trendlog#2.SeeSensor Setup on page 7.
Tosetthedesiredobjecttotrack,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
Thetrendlogbuermaybeviewedbyscrolling
downandselectingViewLogBuer.Thebuermay
alsobeviewedfromtheMainMenubyscrolling
downtotheTrend Viewer(seepage 15).
NOTE: TheBACnetstandardforlogintervals
ishundredthsofseconds.Thesimplied
displayontheFlexStatconvertsthevalue
tominutes.However,BACstage™and
TotalControl®dodisplayhundredthsof
secondsbutindierentways.Fora“10”
(minute)intervalonaFlexStatdisplay,
TotalControlwouldshow“00:10:00.00”
(hours:minutes:seconds.hundredthsof
seconds)andBACstagewouldshow
“60000”(hundredthsofseconds)instead.
NOTE: Ifapplicabletothemodel,thehumidity
sensorisAI5andthemotion sensorisBI6,
whichcanalsobeconguredfortrendlogs.
SeetheFlexStatApplicationGuide(P/N
913-019-03)orrelevantFlexStatInstallation
Guideforotherdesiredinputandoutput
objectsinanapplication.

FlexStat 12 Operation Guide, Rev. K
(Advanced) User Interface (UI) Modes
USER INTERFACE
MODE: STANDARD
TheUserInterfacetogglesthehomescreenandother
menusbetweenthedefaultStandardmodeandother
(morerestricted)modes.
1. Up/Downtooptions.
2. Entertoselectandexit.
NOTE: COMPLETE ALL OTHER NECESSARY
CONFIGURATION BEFORE SELECTING
HOSPITALITY OR LOCKED UI MODE!
Aer Hospitality or Locked UI mode is
selected, it is intentionally dicult to
revert to Standard mode!
NOTE: As additional security against
unauthorized bypass of Hospitality or
Locked UI mode from the FlexStat, set
at least an Operator level password. See
(Advanced) Security Levels and Passwords
on page 10.
NOTE: To further congure the FlexStat or
revert to Standard mode, see the FlexStat
Application Guide (downloadable from
the FlexStat product pages aer logging in
to the KMC Controls Partner site hps://
partners.kmccontrols.com).
Locked UI mode(alsoknownasMode3)appears
likeStandardModeontheHomescreen,butallbut-
tonfunctions(exceptthebacklight)arelocked.
Hospitality mode(alsoknownasMode2)has
limitedmenusandistypicallyusedinhotelrooms.
Userstypicallycanchangeonlythesetpoint,system
mode,andfanspeed.
InHospitalitymode,pushingtheLeandRight
buonsdisplayscustomizable menu selections
(dependentontheconguration).ForFCUandHPU
applications,System(Auto,Heat,Cool,andO)and
Fan(Auto,High,Medium,andLow)menusappear
asadefault.
NOTE: Menusdependontheconguredoptions.
Athree-speedfaninanFCUwilldisplay
Auto,Low,Medium,andHigh,butaone-
speedfanwillonlydisplayAutoandOn.
Pushing Left Button
Goes to Field A Screen
(Field A Selection)
(Field B Selection)
(Field C Message)
(Pushing
Right
Button
Goes to
Field B
Screen)
(No Field C Screen Exists)
WED 10/01 3:20 PM
COOL
HIGH
WELCOME
HUM: 46% RH
SYSTEM MODE
AUTO
HEAT
COOL
OFF
+
(Hospitality Mode Sample Screens)
Pushing Enter Button Toggles
°F/°C Temperature Scale
CustomHospitalitymodeprogrammingisrequired
for:
• Creatingadditional/alternateoptionswiththe
FCUorHPUapplications.
• AnyuseofAHUorRTUapplications.
• UseofFieldCfordisplayingmessages.
SeetheFlexStatApplicationGuideformoreinfor-
mationaboutcustomprogrammingforHospitality
mode.
NOTE: Ifthisnewfeaturedoesnotwork(is
“Inactive”)aerupgradingthermware
fromR1.3.0.4orearlier,youmayneed
torestorethefactorydefault(especially
ifthereiscustomprogrammingor
congurationintheFlexStat)and
reconguretheFlexStat.SeeRestore
Factory on page 17.
NOTE: AutoinSystemModedoesnotcurrently
haveaniconimplementedwithit.
ManuallyselectingHeatorCoolwill
displayaniconontheHomescreen.

FlexStat 13 Operation Guide, Rev. K
Date/Time
DATE/TIME
DATE:
TIME: 1:43:59 PM
APR 11 2009
Toenterdateandtimeinformation(only),press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
Moreoptions(suchasUTCosetanddaylightsav-
ingtimeoptions)areavailableinthe(Advanced)
Date/Timemenu(seepage 8).
Alarms
SAT 4/11 3:20 PM
COOL:
OCC:
FAN:
SERVICE HUM: 20%RH
ALARMS
* SPACE TEMP ALARM 04/11
04/11/09 08:37:56
<AI1> SPACETEMP
PRESENT VALUE = 90.1
EXCEEDS HIGH_LIMIT
<EE1>
SPACETEMPALARM
DELETE ALARM?
NO
YES
Aashing“SERVICE”ontheHomescreenindicates
analarm.Toviewanddeletealarms,press:
1. Righttomoveamongelds.
2. Entertoselect.(EnteronAlarmDetailsscreento
deletethealarm.)
3. Letogobackonepage.
Built-inalarmsaretriggeredundertheseconditions:
• Space Temp Alarm—temperatureoutsidethe
rangeof56to86°Fforover300seconds.
• Space Humidity Alarm—humidityabove65%
forover300seconds.Thisisavailableonlyin
FlexStatmodelswithahumiditysensoranda
dehumidicationoptionselectedintheHumid-
itysetup).SeeHumidity Setup on page 6.
• Fan Fail Alarm—nofanstatussignalwithinve
secondsofcallforfan(andInput2iscongured
forthefanstatussensoroption).SeeSensor Setup
on page 7.
• Low Limit Alarm (freeze stat)—space
temperatureisbelowtheadjustable(under
DamperSetup)lowlimitalarmtempforone
second(whenconguredfortheeconomizer
option).Aer a low limit alarm is generated,
the fan will not run until aer the FlexStat
is restarted. See Restart underReseing the
FlexStat on page 16. See also Damper Setup on
page 6.
(Uptosixadditionalalarmsmaybeaddedwith
customprogramming.)
NOTE: Timedelaysandlimitscanbemodiedin
thecorrespondingEventEnrollmentobjects
usingTotalControl.

FlexStat 14 Operation Guide, Rev. K
HOLIDAYS
HOL1:
HOL2: MAR 21 2009
HOL3: MAY 26 2009
HOL4: JULY 4 2009
HOL5: SEPT 1 2009
HOL6: NOV 27 2009
HOL7: NOV 28 2009
JAN 1 2009
TheHolidayentrieswilloverridethenormal
occupiedweeklyscheduleentriesandkeepthose
days’seingsattheirsetbackvalues.Setback
valuesareenteredintheSetpointssectionofthe
MainMenu.(Seealsothemaximumandminimum
setpointvaluesintheLimitssectionoftheAdvanced
Menu.)
Toenterupcomingholidays,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
Schedules
SCHEDULE
WEEKDAYS [MON–FRI]
WEEKEND [SAT–SUN]
ENTIRE WEEK [MON–SUN]
INDIVIDUAL DAYS
HOLIDAYS
Toselectthedesiredschedule,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Letogobackonepage.
WEEKDAYS
1:
2: 5:15:00 PM OFF
3:
4:
5:
6:
[—>] DELETES ENTRY
7:30:00 AM ON
Toenterweeklyschedulesforoccupied(ON)and
unoccupied(OFF)times,press:
1. Right/LetomoveamongdaysandEnterto
select.
2. Up/DowntomoveamongentriesandEnterto
selectandedit.
3. Right/Letomoveamongvalueelds.
4. Up/Downtoincrement/decrementvalue.
5. Entertoexitvalueediting.
6. Letomovebacktodaysorbackonepage.

FlexStat 15 Operation Guide, Rev. K
System Setup
SYSTEM
SYSTEM ENABLE:
OCC OVRIDE (HRS): 1.0
INACTIVITY (SECS): 60
DISPLAY BLANKING: NO
AUTO
Toadjustthesystemcongurationvalues,suchas
systemenable(auto,o,heat,orcool),occupancy
overridetime,anddisplayinactivitytime-out:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Up/Downtoincrement/decrementvalue.
Occupancy Override on this menu istheamountof
time(inhours)amanualchangeinthesetpoint(via
theUpandDownbuons)willbeallowedtoover-
ridethescheduledsetpoint.When the time is set to
0, the override state will last until the next schedule
change.
NOTE: Occupancyoverridecanalsoberemoved
whileontheHomescreenbypushingthe
lebuon,navigatingtoOCC,hiingEnter
twice,andchangingONtoOFF.SeeH/C,
Fan, Occupancy, and Override on page 4.
When Display Blanking is enabled (Y),thedisplay
turnsoatthesametimethebacklightgoeso
(aerreset,initialpower-up,ortime-out).Whenany
buonispressed,thedisplaywillreappearuntilthe
time-outisreachedagain.
The menu/display/backlight time-out(seconds
sincethelastbuonispushed)issetinInactivity.
AccesstotheMainMenu,setpointadjust,and
System/Occupancy/Fanoverridehaveadefault
passwordlevelofUser.Thislevelcanbechangedfor
eachfunctiontoNone,Operator,orAdministrator
throughthisscreen.Passwordsaresetinthe(Ad-
vanced)Passwordsmenu.See(Advanced) Security
Levels and Passwords on page 10.
Trend Viewer
TREND VIEWER
1:
2: SPACE HUMIDITY 27
3: FAN 19
4: COOL 1 18
5: COOL 2 21
6:
7:
SPACE TEMP 34
TL #1 SPACE TEMP
APR11 1:27PM, 70.3
APR11 2:27PM, 71.3
APR11 3:27PM, 71.6
APR11 4:27PM, 71.8
APR11 5:27PM, 76.3
APR11 6:27PM, 81.2
APR11 7:27PM, 82.3
Toviewtrendlogbuers,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
Trendlogsaresetupinthe(Advanced) Trend Logs
menus(seepage 11).
Setpoints
SETPOINTS
COOL SETPT:
HEAT SETPT: 67° F
COOL SETBACK: 80° F
HEAT SETBACK: 64° F
MIN SETPT DIFF: 2° F
DEADBAND: 2° F
DEHUM SETPT: 60 % RH
74° F
IntheSetpointsmenu,deadband,setbacks,and
setpointsforvariousvaluesareset.(Theroom
temperaturesetpointcanalsobemanuallychanged
fromtheHomemenu.)
Toadjustthesetpoints,press:
1. Up/Downtomoveamongentries.
2. Entertoselect.
3. Up/Downtoincrement/decrementvalue.

FlexStat 16 Operation Guide, Rev. K
Resetting the FlexStat
Types of Reset
IftheFlexStatisnotoperatingcorrectlyorif a low
limit alarm has occurred,theFlexStatshouldbe
reset(reinitialized).Anyresetinterruptsnormalop-
eration,andthreetypesofresetexist:
• Awarm startisgenerallytheleastdisruptiveop-
tion(restartingnormaloperationthequickest).
• Ifproblemsstillpersist,tryacold start.(This
shouldalsobeusedaeranewControlBasic
programisloadedandcompiled.)
• Ifproblemsstillpersist(ormajorchangesina
rmwareupdatehavetakenplace)restoring fac-
tory defaults(andreconguringandreprogram-
mingtheFlexStat)mayberequired.
Warm and Cold Starts
CAUTION
During a restart, the analog outputs go to zero,
and relays go to their normally open state. A re-
start is a process that lasts around ten seconds,
and it may result in several changes of state
for an output, turning equipment off and on
abruptly. Before resetting the FlexStat, manually
override equipment as needed. If a large fan
is controlled by the FlexStat, for example, set
a minimum off time. See Fan Setup on page 6
(built-in, selectable applications with compres-
sors have a default programmed minimum off
time of 300 seconds).
Awarm startdoesthefollowingintheFlexStat:
• (Aer zeroing out objects during the restart
process) restores present values of objects to
their last values before the restart (untiltheyare
updatedbytheFlexStat’sprograms).
• Restartsthecontroller’sControlBasicprograms.
• Leavescongurationandprogrammingintact.
CAUTION
If the checksum test in RAM fails during a warm
start, a cold start is performed instead.
Acold startdoesthefollowingintheFlexStat:
• (Aer zeroing out objects during the restart
process) returns all object values to their relin-
quished defaults(untiltheyareupdatedbythe
FlexStat’sprograms).
ADVANCED
APPLICATION
CB PROGRAMS
COMMUNICATION
DATE/TIME
DEVICE
LIMITS
SECURITY
DEVICE
INSTANCE: 1
NAME: FlexStat_101
LOCATION: KMC Controls
RESTART:
RESTORE FACTORY: NO
WARM START
• Restartsthecontroller’sControlBasicprograms.
• Leavescongurationandprogrammingintact.
NOTE: Menuchangesmaytakeuptoabouttwo
minutestowritetononvolatileFlash
memory.IfpowertotheFlexStatislost
duringthistime,changesmaybelost.
Restarting the FlexStat from its menu,
TotalControl, or BACstage are the
recommended methods.
NOTE: Whenpowerisrestoredaeranoutage,
theFlexStatwillaempttodoawarm
startaslongasthevaluesinRAMare
retained(uptoaboutfourhours).If
thetheRAMchecksumtestfails,acold
startwillbedoneinstead.(Incustom
ControlBasicprogramming,usingthe
POWERLOSScommandmaybedesirable
todeterminestart-upconditionsandtotake
appropriateactions—seetheHelpsystem
inTotalControlorBACstageformore
information.)
To perform a WARM start, do one of the following:
• FromtheFlexStatmenu,selectAdvanced>De-
vice>Restart>WarmStart.
• FromTotalControlorBACstage,selectReinitial-
izeDevice>WarmStart.
• MomentarilyremovepowertotheFlexStat.
To perform a COLD start, do one of the following:
• FromtheFlexStatmenu,selectAdvanced>De-
vice>Restart>ColdStart.
• FromTotalControlorBACstage,selectReinitial-
izeDevice>ColdStart.

FlexStat 17 Operation Guide, Rev. K
Restore Factory
Restore Factory (restoring the FlexStat to the factory
seings)doesthefollowing:
• Clearspresentvalues.
• Restorestheobjectdatabase/congurationtothe
defaults.
• Restartsthecontroller’s(factoryinstalled)Con-
trolBasicprograms.
NOTE: TheMACaddressanddeviceinstanceare
notrestoredtotheiroriginaldefaults,and
customControlBasicprogramsarenot
deleted.IfcustomControlBasicprogramsare
installed, allfactoryprogramsarerestarted
but all custom Control Basic programs are
halted.Customprogramsmayberestartedby
loading/runningtheprogramsfromtheCB
Programsmenu.See(Advanced) CB (Control
Basic) Programs on page 7.
CAUTION
When returned to factory defaults, analog out-
puts will go to zero and relays will go to their
normally open state. Before restarting the ther-
mostat, manually override equipment as needed.
ADVANCED
APPLICATION
CB PROGRAMS
COMMUNICATION
DATE/TIME
DEVICE
LIMITS
SECURITY
DEVICE
INSTANCE: 1
NAME: FlexStat_101
LOCATION: KMC Controls
RESTART: NO
RESTORE FACTORY: YES
RESTART REQUIRED!
CANCELRESTART
CAUTION
After a return to factory defaults, applications are
unconfigured. You must select the desired appli-
cation and appropriate settings before connected
equipment will operate properly. (See (Advanced)
Application Options on page 6.)
TorestoretheFlexStattofactoryseings:
1. SelectRestoreFactoryfromtheAdvanced>De-
vicemenu.
2. Whenpromptedfortherequiredrestart,press
Enter.(ToCancel,presstherightbuonandthen
Enterorjustletthedisplaytime-out).
3. AertheFlexStathasrestarted,reviewtheset-
tingsandrecongureasneeded.

FlexStat 18 Operation Guide, Rev. K
BACnet MS/TP Network Communication
ConnectthenetworkwiringandsettheEOLswitch-
esaccordingly.(SeetheInstallationGuideforwiring
andend-of-lineswitchinformation.)
FromtheFlexStatmenus,adjustthedeviceinstance
number,theMACaddress,andbaudratefromthe
defaultsasnecessary.SettheMaxMastertothe
minimumnecessaryforthenetwork.See(Advanced)
BACnet Device Properties on page 9and(Advanced)
BACnet Communications on page 8.)
NOTE: ThecurrentFlexStatMACaddressand
deviceinstancenumberscanbeviewedin
theAboutmenu.EachBACnetdeviceona
networkmusthaveauniqueMACaddress
anddeviceinstance.
Network Connection
PC Data Port Connection
TheFlexStatisequippedwithaPCdataportlocated
attheboomofthethermostathousing.Thisport
providesatemporaryEIA-485(formerlyRS-485)
connectiontothedigitalnetworkfornetworksetup
ortroubleshooting.
Toconnectacomputertotheport,ameansof
convertingtheEIA-485signaltoaUSBorEIA-232
(formerlyRS-232)signalwillbeneeded.ForUSB,
useaKMCKMD-5576USBCommunicator.For
EIA-232,useathird-partyinterface.(Seetheinstruc-
tionsincludedwiththosedevicesandsoware.)To
connecttothePCdataport:
1. Connectthekeyed,atendoftheKMD-5624
interfacecable(includedwiththeKMD-5576)to
theportontheboomoftheFlexStat.
2. Connectthemodularplugofthecabletothe
interfacedevicethatconvertstheEIA-485signal
fromtheFlexStatintoaUSBorEIA-232signal.
3. Connectthesuitablecablefromtheinterface
devicetothecomputer’sserialorUSBport.
Installanyrequiredsowareandcongurethe
portasnecessary.
NOTE: To avoid faulty communication with the
KMD-5576 USB Communicator, the Max
Master number may need to be reduced
to the minimum required for the network
and the driver and latency seings on
the computer may need to be checked or
updated. See Troubleshooting on page 20.
   
KMD-5624
Cable
KMD-5576

FlexStat 19 Operation Guide, Rev. K
Firmware Upgrade
Theexistingversionofrmwarecanbeviewedfrom
theAbouttheFlexStatscreen.(SeeAbout the Flex-
Stat on page 5).
FirmwareintheFlexStatcanbeupgradedusinga
PCandanHTO-1103FirmwareFlashUpgradeKit
availablefromKMCControls.(Forfullupgrade
instructions,seetheHTO-1103InstallationGuide,
P/N913-019-04.)(TheoldKMD-5699partnumber
waschangedtoHTO-1103inAug.2010tobeer
reectits“tool”identity.)
Programming (Custom)
TheFlexStathasalibraryofbuilt-inapplicationsand
optionsthatareconguredthroughtheFlexStat’s
display.Beyondthesestandardcongurations,cus-
tomchangescanbeaddedtoaFlexStatusingKMC’s
BACstage(ver.2.4.0.26orlater)orTotalControl(ver.
2.0.5orlater).SeetheFlexStatApplicationGuide
(P/N913-019-03)formoreinformation.
NOTE: Customized programs are the responsibility
of the user.KMCControlsdoesnotprovide
supportforsuchprograms.
Maintenance
Removedustasnecessaryfromtheholesinthetop
andboom.Cleanthedisplaywithso,dampcloth
andmildsoap.
Tomaintainmaximumsensitivityofoptionalbuilt-in
motionsensors,occasionallywipedustordirtothe
lens—butdonotuseanyuidonthesensor.
HMO-10000 Horizontalor4x
4handyboxwall
mountingplate,
lightalmond
HMO-10000W HMO-10000in
white
HPO-0044 Replacementcover
hexscrew
HTO-1103 FlexStatrmware
ashupgradekit
KMD-5567 Networksurge
suppressor
KMD-5575 Networkrepeater/
isolator
KMD-5576 EIA-485toUSB
Communicator
KMD-5624 PCdataport
(EIA-485)cable
(FlexStattoUSB
Communicator)—
includedwiththe
KMD-5576(buyfor
third-partyEIA-
232interfaces)
SP-001 Flatbladeandhex
endscrewdriver
(withKMClogo)
forcoverhex
screws
XEE-6111-040 Transformer,120-
to-24VAC,40VA,
single-hub
XEE-6112-040 Transformer,120-
to-24VAC,40VA,
dual-hub
Accessories
(formerly
KMD-5699)*
*NOTE: TheKMD-5699partnumberwaschanged
toHTO-1103inAug.2010.

FlexStat 20 Operation Guide, Rev. K
Troubleshooting
Alarm Issues
Alarm, (False) Fan Fail
• Checkconguration.BesuretheFanStatus
optionisnotselectedwhenthereisnosensor/
switchforit.
• CheckthattheIN2(fanstatus)inputpull-up
resistorswitchesarefullylatchedinthecorrect
positions.Anypassive,drycontactshoulduse
the10KOhmseing.(SeetheConnectionsand
WiringsectionoftherelevantFlexStatInstalla-
tionGuide.)
• CheckIN2(fanstatus)inputwiring.
• Checktheconnectedfanstatussensor/switch.
• UsingBACstageorTotalControl,checkthatAI2
(fanstatus)isnotconguredas“OutOfService.”
Alarm, (False) Low Limit (Freeze Stat)
• ChecktheLowLimitAlarmseing—seeDamper
Setup on page 6.
• Checkconguration.BesuretheEconomizer
optionisnotselectedwhenthereisnomixedair
temperaturesensor.
• CheckthattheIN3(mixedairtemp.)input
pull-upresistorswitchesarefullylatchedinthe
correctpositions(seetheConnectionsandWir-
ingsectionoftherelevantFlexStatInstallation
Guide).
• CheckIN3(mixedairtemperature)inputwiring.
• Checktheconnectedmixedairtemperaturesensor.
• UsingBACstageorTotalControl,checkthatAI3
(mixedairtemp.)isnotconguredas“OutOf
Service.”
NOTE: Aer a low limit alarm is generated, the
fan will not run until aer the FlexStat is
restarted.(SeeReseing the FlexStat on
page 16.)
Alarm, (False) Space Temp. or Humidity
• SeeAlarms on page 13.
• SeeTemperature Reading Is Incorrect on page 23.
• SeeTemperature Setpoint Is Not Maintained on
page 23.
• UsingTotalControl,adjustthelimitsortime
delay.
Communication Issues
KMD-5576 Communication Issues
• UpgradetothelatestversionofBACstage(ver.
2.4.0.25orlaterrequired).
• ChecktheseingsfortheUSBportonthe
computer(DeviceManager>Ports)andthe
MS/TPportinBACstage(Access>Connection
Parameters).
• ReducetheMaxMasternumberdowntothe
minimumneededforthatnetwork—see(Ad-
vanced) BACnet Communications on page 8.
• Installlatestdriverandchecklatencyseings.
SeeLatencySeingsforKMD-5576ServiceBul-
letin(SB0308A)ontheKMCwebsite.
• SeealsoMS/TP Network Communication Issues
below.
MS/TP Network Communication Issues
• CheckMACaddressanddeviceinstancenum-
bers(especiallyforduplicatenumbersonthe
network)—see(Advanced) BACnet Communica-
tions on page 8and(Advanced) BACnet Device
Properties on page 9.
• CheckthatEOLswitchesarefullylatchedinthe
correctpositions(seetherelevantFlexStatInstal-
lationGuide).
• Checkbaudrate—see(Advanced) BACnet Com-
munications on page 8.
• ReducetheMaxMasternumberdowntothe
minimumneededforthatnetwork—see(Ad-
vanced) BACnet Communications on page 8.
• SeeWiring Issues on page 26.
