KMOUK HSB004 User manual

36 inch 2.1 Channel Soundbar
HSB004 User Guide

TABLE OF CONTENTS
1. WHAT’S IN THE BOX 6
2. OVERVIEW OF THE SOUNDBAR MAIN UNIT 7
3. OVERVIEW OF THE REMOTE CONTROL 8
4. PLACE YOUR SOUNDBAR 10
Wall installation precautions. 11
Wall mount the Soundbar 11
5. INSTALL/REPLACE THE REMOTE BATTERY 13
6. CONNECT YOUR SOUNDBAR 14
Connect with the supplied Power Cord. 14
Connect with the supplied HDMI Cable. 15
Connect with the supplied Optical Cable. 16
Connect with the supplied 3.5mmAUX Cable. 17
Connect with your Bluetooth Device. 17
7. USE YOUR SYSTEM. 19
Operations of the control panel 19
Operations of the remote control. 20
Adjust the sound effect. 21
Select the audio source. 21
8. RESTORE FACTORY SETTING 22
9. TROUBLESHOOTING. 22
10. SPECIFICATION 23
11.ADDITIONAL INFORMATION 24
Care & Maintenance. 24
Compliance Notice. 24
Customer Service 26
Manufacturer 26

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICINGTO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation mark within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
TO REDUCETHE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOTEXPOSETHISAPPLIANCE TO RAIN OR MOISTURE

IMPORTANT SAFETY INSTRUCTIONS
1.Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7.Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10.When using the cart /apparatus combination for handling, be
careful to avoid injury.
11.Unplug this apparatus during lightning storms or when unused
for long periods of time.
12.Refer all servicing to qualified personnel. Servicing is required
when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.

WARNINGS
This symbol on the product means there is uninsulated, dangerous
voltage within the product enclosure that may present a risk of electri-
cal shock.
This symbol on the product means there are important
operating and maintenance instructions in this guide.
Do not ingest battery, chemical burn hazard. The remote
control supplied with this product contains 2 AAA battery.
Do not swallow the battery, it may cause severe risks or lead to death.
Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the remote control
and keep it away from children. If you think batteries might have been
swallowed or placed inside any part of the body, seek immediate
medical attention. To avoid the risk of explosion, fire or chemical burn,
use caution in replacing the battery and replace only with an agency
approved (e.g., UL) battery. Properly and promptly dispose of used
batteries. Do not recharge, disassemble, heat above 212°F (100°C)
or incinerate.
Contains small parts which may be a choking hazard. Not
suitable for children under age 3.
This product contains magnetic material. Consult your physi-
cian on whether this might affect your implantable medical
device.
CAUTIONS
To reduce the risk of fire or electrical shock, do NOT expose this
product to rain, liquids or moisture.
•Do NOT expose this product to dripping or splashing, and do not
place objects filled with liquids, such as vases, on or near the product.

•Keep the product away from fire and heat sources. Do NOT place
naked flame sources, such as lighted candles, fireplaces, radiators,
heat registers or other apparatus (including amplifiers) that produce
heat.
•Do NOT make unauthorized alterations to this product.
•Do NOT use a power inverter with this product.
•The speaker wires and interconnect cables included with this system
are notapproved for in-wall installation. Please check your local
building codes for the correct type of wire and cable required for
in-wall installation.
•Where the mains plug or an appliance coupler is used as the discon-
nect device, the disconnect device shall remain readily operable.
Use at altitude less than 2000 meters only.
•Only use the following hardware to mount this product: KMOUK
Soundbar Wall Bracket.
•Due to ventilation requirements, KMOUK does not recommend
placing the product in a confined space such as in a wall cavity or in
an enclosed cabinet.
BATTERY CAUTION AND DISPOSAL INFOR-
MATION
•Install only new batteries of the same type in your product.
•Failure to insert batteries in the correct polarity, as indicated in the
battery compartment, may shorten the life of the batteries or cause
batteries to leak.
•Do not mix old and new batteries.
•Do not use rechargeable (Nickel Cadmium) or (Nickel Metal Hydride)
batteries.
•Do not mix alkaline, standard (Carbon-Zinc) or rechargeable (Nickel
Cadmium) or (Nickel Metal Hydride) batteries.
≤2000m

•Do not dispose of batteries in fire or water.
•Recycle or dispose of batteries as per state and local guidelines.
•Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type.
•When the remote control is not to be used for a long time (more than
a month), remove the battery from the remote control to prevent it from
leaking.
•If the batteries leak, wipe away the leakage inside the battery
compartment and replace the batteries with new ones.
•Keep away the batteries from heat or moisture.
•Do not carry or store batteries with other metallic objects. Doing so
could cause batteries to short circuit, leak or explode.
•Never recharge a battery unless it is confirmed to be a rechargeable
type.
INSTALLATION LOCATION
•This product is designed to sit on a firm, flat surface. Do not place the
product on built-in installation such as a bookcase or rack because the
ventilation slots around the product will be blocked, resulting in
reduced lifetime from overheating. To assure adequate ventilation for
this product, maintain a spacing of 7.8 inches (20cm) or more around
the product.
•Make sure the product on the furniture is of adequate size and
strength to prevent it from being accidentally tipped over, pushed off,
or pulled off. This could cause personal injury and/or damage to the
product.
•Installation of wall mount must be carried out by qualified personnel
only. Incorrect assembly can result in severe personal injury and
property damage (if you intend to install this product yourself, you
must check for installations such as electrical wiring and plumbing that
may be buried inside the wall). It is the installer’s responsibility to verify
that the wall will safely support the total load of the product and wall
mount brackets.

1
. What’s in the box
36 inch2.1 Channel Soundbar
40 18
10 19 12
16
51 13 50
1A
2A 3A 4A
4C 11
1С
Remote
Control
AAA battery X 2 Power Cable
OPTICAL
Cable
HDMI Cable
3.5m
mAUX Cable
AU
X to RCA
Cable
W
allAnchor X
2
W
all Screw X 2
User Guide
User Guide
Quick Guide
Quick Guide
Wall Mount Template
NOTE
: If any part of the product is damaged, don't use it.
Contact
KMOUK customer
service or mail us at suppo[email protected]m.

LED Display Remote Control
2. Overview of the Soundbar Main Unit
Front side
Back side
HDMI(ARC) AUX IN OPTICAL
HDMI(ARC) Input AUX IN OPTICALInput Power Input
Right Panel (Control Panel)
POWER
SOURCE
VOL +
Volume +/-: Press to
adjust the volume up or down
VOL -
Installation hole
Source: Press to switch the audio source among
AUX IN/BT IN/HDMI(ARC) /OPTICAL modes.
Power: Press to turn on/off or standby
AUXIN OPTICALHDMI(ARC)

3. Overview of the Remote Control
2
5
7
10
11
12
6
1
3
4
7
6
8
9
AUX
BASS
BASS
HDMI

Button
Operation
1
Power
on/ Power off
2
Switch to Bluetooth mode
or connect to the last
paire
d device, if no paired record, the “ ”
light
o
n the LED screen flashes.
Lon
g press the button for 2s, it will disconnect
an
d enter pairing mode.
3HDMI
Switch to
HDMI mode.
4AUX
Switch to
AUX mode.
5
Switch to OPTICAL
mode
6
BASS
BASS
Press to
adjust the bass up or down (Press BASS
to
adjust from 0 to 10, with memory function,
return
to
default “5” after restoring factory settings.)
7
In Bluetooth mode
Skip:
press to skip forward or back a track
Play/Pause:
press to play or pause a track
8
Switch to the
gaming mode.
9
Switch to the music mode.
10
Switch to the movie mode.
11
Press to
increase/decrease the volume
(Maximum volume:30, Minimum:
0) (With an
iPhone
, the volume can be synced)
12
Press to mute/unmute the volume

TV
4. Place your Soundbar
You can choose to place your Soundbar main unit below the center
of your TV or mount it on the wall.
TV
Wall Installation Precautions
1.Make sure you read all the safety information before you mount the
Soundbar main unit on the wall.
2.Make sure you use screws provided or specified by the authorized
manufacturer.
3.KMOUK bears no responsibility for accidents or damage caused by
improper wall mounting and screws installation or insufficient wall
strength, etc.
4.Install on a vertical wall only.
5.Do not install in a place with high temperature or humidity.
6.Verify whether the wall is strong enough to support the product’s
weight. If not, reinforce the wall or choose another installation point.
7.Purchase and use the fixing screws or anchors appropriate for the
kind of wall you have (plaster board, iron board, wood, etc.). If possi-
ble, fix the support screws into wall studs.
•Connect cables from the unit to external devices before you install
the Soundbar on the wall.
•Make sure the unit is turned off and unplugged before you install it.
Otherwise, it may cause an electric shock.

Wall mount the Soundbar
1.Place the supplied wall mount
template on the wall. Make sure the
wall mount template is at least 2
inches (5cm) below the center of the
TV.
2.Use a level to make sure the
Soundbar is positioned accurately.
3.Use the tape to stick the wall
mount template firmly on the wall.
4.Mark on the wall using each marking on the template through the
mounting holes (Fig.1).
5. Take away the wall mount template.
6.Drill a screw hole at each marking on the wall.
7.Insert the supplied wall anchors into 2 screw holes on the wall (Fig. 1).
8.Insert the supplied screws into the wall anchors. Leave 4mm
between the screw heads and the wall (Fig. 2).
9.Fix and tighten the screws on the wall (Fig. 3).
10.Hang the Soundbar main unit on the screws (Fig. 3).
Fig1 Fig2
4mm
Fig3
or more
TV
2inches

5. Install/Replace the Remote Battery
When the Soundbar does not respond by operating with the remote
control, replace two batteries with new batteries. And use R03 (size
AAA) manganese batteries for replacement.
Warning
•Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type.
Caution
•The battery contains perchlorate material, handle it with care.
Steps
1.Open the battery compartment, remove the old batteries if neces-
sary.
2. Insert 2 pieces of AAAsize batteries.Make sure the (+) and (-) ends
of the batteries match the (+) and (-) ends as indicated.
3.Close the battery compartment accordingly.

Connect with the supplied HDMI Cable
1.An HDMI connection supports digital audio and is the best option to
connect to your soundbar. If your TV supports HDMIARC, you can
hear the TV audio through your soundbar by using a single HDMI
cable.
2.Plug the one terminal of HDMI cable into the soundbar HDMI(ARC)
port and another into TV HDMI(ARC) port .
3. Turn on the soundbar.
6. Connect your soundbar
After you have fixed the position of the Soundbar main unit, you can
start connecting it to your TV or other devices and listen to the audio
through your Soundbar. Make sure your TV or device supports the
HDMI ARC feature. For information, check the user manual of your TV
or device.
NOTE: Please do not connect the Soundbar to any power amplifier
products, in case of causing Soundbar damage.
Connect with the supplied power cord
1.Connect the AC power cord on your soundbar to the power cord
socket on the wall.
2. Press " " button to turn on/off the device.
NOTE: Make sure the power supply voltage complies with your
country’s safety standards.
AUX IN O PTICALHDM I(ARC)
1Connect soundbar
2Connect socket

NOTES:
1.When connected to HDMI, if the TV or other devices and Soundbar
both have sound sources at the same time, please manually turned off
the TV or other devices’sound source.
2.The audio transmission via the HDMI(ARC) socket can only work if
all components are ARC-enabled. If the transmission is unsuccessful,
please check if the digital audio output of your TV is activated. Select
audio output PCM. If the audio output PCM is not set on the TV, the
soundbar will not have sound.
Connect with the supplied Optical Cable
1. An Optical connection supports digital audio and is an alternative to
an HDMI audio connection.
4.Press the "HDMI" button on the remote or press the "SOURCE"
button on the soundbar to enter HDMI(ARC) mode.
5.Set up your TV as the following steps: Setting-Sound-Output-HDMI
ARC-Digital output-PCM.
6. The screen will display “Hd”when turning on TV or other devices.
HDMI(ARC)
HDMI (Supplied)
HDMI OUT
HDMI IN
HDMI OUT
HDMI IN
TV
PCM
Support HDMI ARC devices only
HDMI(ARC)
AUX IN OPTICAL

TICAL
2.
Plug the one terminal of OPTICAL cable into the soundbar
OPTI-
CA
L port and another into TV OPTICAL port .
3.
Turn on the soundbar.
4.
Press the "OPT" button on the remote or press the "SOURCE"
butto
n on the soundbar to enter OPTICAL mode.
5.
Set up your TV as the following steps: Setting-Sound-Output-OPT
I-
CAL
-Digital output-PCM
6.
Using the native controls on your connected device, make sure
the
audi
o settings are set to OPTICALAudio and are turned on.
7.
Audio from the connected audio source will be played through
the
speakers.
HDMI(AR
C) AUX IN OP
OPTICALIN
OPTICAL IN OPTICAL (Supplied
）OPTICAL OUT
TV PCM
OPTICAL OUT
NOTE
: Confirm to set your TV or other device audio settings
to support
“external speakers” and disable the built-in TV speakers.
Connec
t with the supplied 3.5mmAUX cable
1.
Plug the one terminal of 3.5 mm AUX cable into the soundbar
AUX
por
t and another into TV audio output port .
2.
Turn on the soundbar.
3.
Press the "AUX" button on the remote or press the "SOURCE
"
butto
n on the soundbar to enter AUX mode.

Connect with your Bluetooth device
1.Make sure your device supports the Bluetooth function.
2.The operational range between the Soundbar main unit and your
Bluetooth device is approximately 32.8ft (10 meters) (without any
obstacle between the Bluetooth device and Soundbar main unit).
3.Only one Bluetooth device can be paired at a time.
4.There is NO password required.
The first connection
1.Press the Bluetooth “”button on the remote control to enter the “BT
PAIRING” mode. Or one to press the “Source”button on the control
panel and then select “”. LED display shows “”flashing rapidly.
SOURCE
KMOUK
KM-HSB004
•••
HDMI AUX
BASS
TV
AUX (LINE OUT)
AUX (LINE IN)
AUX (LINE IN)
AUX (Supplied)
AUX IN OPTICALHDMI(ARC)

2.Switch on the Bluetooth audio device (e.g., smartphone) and start
the Bluetooth connection.
3.The Bluetooth device will now receive the device identification as
“KMOUK KM-HSB004”.
4.When connected, the white LED light will keep on.
Second/ third times connection
1.Power on, the soundbar will connect back to the last paired device
automatically and restore the previous settings.
2.After the successful pairing, the “
flashing.
If the device fails to connect
” will keep on instead of
•• If a previously connected Soundbar listing appears in the list, delete
it.
•• Then repeat steps 1 through 3.
NOTE
•• After you have connected the Soundbar to your device the first time,
it will connect back automatically when powered on.
Disconnecting the Soundbar from your device
Press and hold the“”button on the remote control for more than 2
seconds to disconnect the device from the soundbar.
NOTES:
1.Disconnecting takes time because the device must receive a
response from the Soundbar. (The time required may differ, depend-
ing on the device.)
2.In Bluetooth connection mode, the Bluetooth connection will be lost
if the distance between the Soundbar and the Bluetooth device
exceeds 32.8 ft (10 meters).
•The Soundbar may not perform Bluetooth search or connection
correctly under the following circumstances:
•If there is a strong electrical field around the Soundbar.
•If two or more Bluetooth devices are simultaneously paired with the
Soundbar.
•If the Bluetooth device is turned off, not in place, or malfunctions.

.
•Electronic
devices may cause radio interference. Devices that gene
r-
at
e electromagnetic waves must be kept away from the
Soundbar
main
unit - e.g., microwaves, wireless LAN devices, etc.
7
. USE YOUR SYSTEM
Y
ou can use your Soundbar with the control panel or remote
control
an
d adjust the sound effect or select the audio source.
Operation
s of the control panel
Button Operation LED Indicator
V
oic
e Prompt
Power
Single press
（
Power on）
Indicates
channels and
sound
modes /
Long press 1.
5 seconds
(Power off) /
Source
Click to switch audio
source
The
LED ligh
t corresponding
to
the audio source lights up /
V
olume
＋
Press or hold to add
volume
The
LED displays the
volume.
Maximum volume
is
30
, Return to the current
channel
after 3s.
/
V
olume- Press or hold to
reduce
volume
The
LED displays the
volume.
Minimum volume is
0
, Return to the current
channel
after 3s.
/
NOTES:
1.
Press the " " button to shut down and start up again, keeping
the
settings
before the last shutdown.
2.
After power on, the volume of each mode has memory function,
and
cannot
interfere with each other.
3.
After power off and reboot, the volume will return to the
default
value
of 67% and other settings will remain the state before
shutdown
