KNF FL 10 User manual

FL 10
INSTALLATION INSTRUCTIONS
DIAPHRAGM PUMP
FL 10 DC-P FL 10 AC
Before operating the pump, please read the Installation Instructions and safety precautions.

Table of Contents
KNF Flodos 173856_MA_FL10_EN_01.docx
2
Contents Page
1 General ...................................................................................... 3
1.1 Information about the instructions 3
1.2 Warnings 3
1.3 Disclaimer 4
1.4 Manufacturer’s address 4
1.5 Supporting documents 4
2 Safety ........................................................................................ 5
2.1 Intended use 5
2.2 Reasonably foreseeable misuse 5
2.3 Responsibility of the user 5
2.4 Product-specific risks 5
3 Installation ................................................................................ 7
3.1 Installation location 7
3.2 Mechanical mounting 7
3.3 Connecting the fluid system 7
3.4 Electrical connection 8
4 Initial start-up ........................................................................... 9
5 Maintenance ........................................................................... 10
6 Rectifying transfer problems ................................................ 10
7 Returning the pump ............................................................... 11

Installation Instructions FL 10 General
KNF Flodos 173856_MA_FL10_EN_01.docx1
3
1 General
1.1 Information about the instructions
The Installation Instructions describe the requirements for installing
the product correctly and safely into the complete machine.
These Installation Instructions are a part of the product. The safety-
relevant information should be taken over for the documentation of
the complete machine.
With customer-specific project pumps (pump types which begin
with "PL" or "PML"), there may be differences from the Installation
Instructions.
1.2 Warnings
Warnings in the Installation Instructions are marked by the hazard
symbol, the keywords, and the color. These features provide
information about the extent of the hazard.
DANGER
Indicates a dangerous situation, which will directly cause death or
serious injury if not prevented.
WARNING
Indicates a dangerous situation, which may cause death or seri-
ous injury if not prevented.
CAUTION
Indicates a dangerous situation, which may cause moderate or
slight injuries if not prevented.
NOTICE
Indicates a situation, which may cause damage to property if not
prevented.
Table of Contents
Storage location
Project pumps

General Installation Instructions FL 10
KNF Flodos 173856_MA_FL10_EN_01.docx1
4
1.3 Disclaimer
The manufacturer accepts no liability for damage or malfunctions
that are caused by non-compliance with the Installation Instruc-
tions.
The manufacturer accepts no liability for damage or malfunctions
that are caused by modifications to or conversions of the device or
by improper handling.
The manufacturer accepts no liability for damage or malfunctions
that are caused by using spare parts or accessories that are not
approved by the manufacturer.
1.4 Manufacturer’s address
KNF Flodos AG
Wassermatte 2
6210 Sursee, Switzerland
Phone [phone]
Fax [phone]
www.knf.com
1.5 Supporting documents
The listed documents must also be observed. The valid versions
are available on www.knf.com/downloads.
 Data sheet
 3D model
Further attention must be paid to:
 Local T&Cs
 Sales documents and agreement between KNF and the cus-
tomer

Installation Instructions FL 10 Safety
KNF Flodos 173856_MA_FL10_EN_01.docx1
5
2 Safety
2.1 Intended use
The pump is intended solely for the following uses:
 Transferring liquids and gases
 For operation in accordance with the operating parameters
specified in the technical data of the supporting documents
2.2 Reasonably foreseeable misuse
The pump must not:
 be operated in an explosive atmosphere
 be used to transfer explosive media
 be used to transfer media whose compatibility with the pump
head, valves, diaphragms, and seals has not been proven
2.3 Responsibility of the user
The user is responsible for ensuring that the safety precautions in
these Installation Instructions are complied with. Applicable, safety,
accident prevention, and environmental protection regulations must
be complied with.
2.4 Product-specific risks
Remaining risks that were determined in a risk assessment are
described in this section. Safety precautions and warnings in this
section and in the other sections of the Installation Instructions
must be observed to prevent dangerous situations.
DANGER
Danger of injuries and damage to property due to dangerous
substances
Poisoning and chemical burns or unintended reactions caused by
leaking dangerous substances
 Observe the safety data sheets of the transferred media
 Before transferring a medium, check whether it can be
transferred safely in the specific application case.
 Ensure that the system is not subject to any risks of explo-
sion, also in extreme operating conditions (temperature,
pressure) or in case of malfunctions.
 Ensure the pump is used only by suitably trained, skilled
employees
 Clarify the wear resistance of the head material
 Check that the pump and the system do not leak at the op-
erating temperature of the transferred medium
 Regularly check the pump for damage
 Operate the pump only when you are sure it has no tech-
nical malfunctions
 Operate the pump in accordance with the technical data
 Work on the pump or fluid circulation system only after they
have been decontaminated and/or a decontamination decla-
ration is present

Safety Installation Instructions FL 10
KNF Flodos 173856_MA_FL10_EN_01.docx1
6
DANGER
Danger of injuries and damage to property due to leaks at the
interfaces to the pump head
Poisoning and chemical burns or unintended reactions caused by
leaking dangerous substances
 Wear personal protective equipment
 Connect the pump correctly
 Operate the pump only when you are sure it has no tech-
nical malfunctions
 Operate the pump in accordance with the technical data
DANGER
Danger of injuries and damage to property due to uncon-
trolled flow while the pump is not in operation
Poisoning and chemical burns or unintended reactions caused by
leaking dangerous substances
 Install a shut-off valve in the fluid circulation system
WARNING
Danger from magnetic field
The pump generates a strong local magnetic field, which may
cause pacemakers or other devices that are affected by magnetic
fields to malfunction.
 Ensure that these devices are kept at least 10 cm away
from the pump when it is operating
 If necessary, attach additional shielding devices

Installation Instructions FL 10 Installation
KNF Flodos 173856_MA_FL10_EN_01.docx1
7
3 Installation
WARNING
Danger from incorrect installation
Injuries or damage to property from leaking media
 After installation, check the system for leaks with a safe
medium
 Observe the requirements for intended use
 Take precautions in the design of the end device so that
leaking liquids cannot come into contact with live compo-
nents
The following requirements apply to all activities described in this
section:
3.1 Installation location
The installation location must:
 protect the pump against immersion
 keep aggressive and flammable liquids and vapors away
 allow hoses to be connected without tensile or bending stress
 take account of cooling the pump drive
 ensure that any leaks can be handled
 have appropriate precautions if flammable media are used
3.2 Mechanical mounting
 Protect the product against impacts, knocks, and strong vibra-
tions
 For dimensions, installation positions, fluid connections, please
refer to the product data sheet
3.3 Connecting the fluid system
Use suitable means to check the fluid connection for leaks.
For more information regarding dimensions, please refer to the
data sheet.

Installation Installation Instructions FL 10
KNF Flodos 173856_MA_FL10_EN_01.docx1
8
3.4 Electrical connection
For terminal assignment, output data, and control requirements,
please refer to the data sheet
Observe the regulatory requirements for electrical installations:
 Overload protection and separating protective devices
 Contact protection and additional insulation
 Ground connections
 Protection against vibrations, tensile stress, and corrosion
3.4.1 DC coils
CAUTION
Danger from burns or fire, poisoning from flue gases
If the pump is connected incorrectly, it may overheat and catch
fire.
 Connect the pump to the correct voltage
 Operate the pump in accordance with the technical data
 Take suitable precautions to limit maximum power con-
sumption.
3.4.2 AC coils
DANGER
Danger from electric shock
 Connect the pump to the correct voltage
 Wear personal protective equipment
 Operate the pump only when you are sure it has no tech-
nical malfunctions
 Operate the pump in accordance with the technical data
 Ensure that the fluid circulation system is grounded
 Check the pump for damage regularly
 Disconnect the pump from the power supply when carrying
out maintenance work
 In case of fixed installation, install a maintenance switch
 Installation only by trained, skilled personnel who have
knowledge of the applicable international regulations
 Ensure contact protection for live parts (persons, cable, and
device protection)

Installation Instructions FL 10 Initial start-up
KNF Flodos 173856_MA_FL10_EN_01.docx1
9
4 Initial start-up
The product must not be started up until it has been ensured that
the machine in which the product is to be installed meets the
requirements of the Machinery Directive 2006/42/EC, if applicable.
CAUTION
Danger of bursting of the fluid system due to overpressure.
The pump builds up pressure. With a closed system, the max.
permitted operating pressure may be exceeded, which can dam-
age the pump and the system.
 Prevent operation against a closed system
 Use only parts that come into contact with the fluid that are
designed to at least withstand the operating pressure of
the pump
 If necessary, take suitable measures to limit the maximum
system pressure
CAUTION
Danger of unexpected chemical reactions with water
Residues of water in the pump that come from testing in the
factory may react with the transferred medium.
 Before starting the pump for the first time, rinse it with a
medium that is uncritical as regards water
CAUTION
Danger from hot surfaces
The pump becomes hot during operation Burns from hot surfaces
or injuries from uncontrolled movements are possible.
 Do not touch the pump while it is operating.
 Ensure a sufficient supply of cool air and keep a safe dis-
tance between the pump and neighboring components.
 Operate the pump in accordance with the technical data
 If the temperature of the medium is above 50°C, take pre-
cautions to prevent burns from fluid components.
Before switching on the pump, check the following points:
 All hoses attached properly
 Specifications of the power supply correspond with the data on
the pump’s type plate
 Pump discharge not blocked
 All cables attached properly
 Contact protection for electrical connections and moving parts
installed

Maintenance Installation Instructions FL 10
KNF Flodos 173856_MA_FL10_EN_01.docx1
10
5 Maintenance
This product contains no parts that can be replaced and it cannot
be maintained.
6 Rectifying transfer problems
Symptom Cause Remedy
Pump does not work,
no movement or
sounds detectable
No or incorrect control Check that voltage and signal form comply
with the specification
Pump does not work,
drive is very hot
The coil is controlled with
DC voltage or another,
incorrect signal form
Check that voltage and signal form comply
with the specification
The pump does not
suck or vacuum is
insufficient
External valve is closed Check external valve
Counter pressure on
pressure side is too high
Change the pressure conditions on the
pressure side
Particles in the pump head Rinse the pump head
Use a preventive preliminary filter
Pump does not trans-
fer
External valve is closed or
filter is clogged or too
small
Check external valves and filter
Connections or hoses are
blocked
Check connections and hoses
Remove blockage.
Flow rate is insuffi-
cient or unstable
Incorrect control Check that voltage and signal form comply
with the specification
Cross-section of hydraulic
hoses or connectors too
narrow or restricted
Disconnect the pump from the system and
determine output values
Remove restriction (e.g. valve) if neces-
sary.
If applicable, use larger-diameter hoses or
connectors
Higher counter pressure in
the system than assumed
for the design
Contact KNF representative
Particles in the pump head Rinse the pump head
Use a preventive preliminary filter
Pump has reached the
end of its service life
Replace the pump
Leak of pump head Diaphragm or oscillating
diaphragm defective
Replace the pump
If the malfunction cannot be rectified, contact your local KNF
representative (www.knf.com)

Installation Instructions FL 10 Returning the pump
KNF Flodos 173856_MA_FL10_EN_01.docx1
11
7 Returning the pump
KNF undertakes to repair the pump only under the condition that
the customer provides a certificate of the pumped medium and
cleaning of the pump. For this purpose, please follow the instruc-
tions on www.knf.com/repairs.
Please contact your KNF sales representative directly if you need
additional support for your return service.

www.knf.com
