Knox MedVault Manual

MedVault®
Larger Capacity - Narcotics Locker
Hardware Installation Guide
1601 W. Deer Valley Road, Phoenix, AZ 85027
Phone: [phone] ● Fax: [phone]
www.knoxbox.com
OPE-MVHDWR-0202-H
Warning
Treat this manual as a confidential document.
Limit access to authorized personnel.

OPE-MVHDWR-0202-H The Knox Company ▪ MedVault®
▪ ii
Copyright ® 2019 by The Knox Company. All rights reserved.
The Knox Company, the Knox logo and all other Knox Company product or service names are
registered trademarks or trademarks of the Knox Company.
Restricted Rights Legend
U.S. GOVERNMENT RESTRICTED RIGHTS. UNPUBLISHED—RIGHTS RESERVED
UNDER THE COPYRIGHT LAWS OF THE UNITED STATES. Use, duplication, or disclosure
is subject to restrictions set forth in the FAR Section 52.227-14 Alt. III(g)(3), FAR Section
52.227-19, DFARS 252.227-7014(b), or DFARS 227.7202, as amended from time to time.
The Knox Company
1601 W. Deer Valley Road
Phoenix, AZ 85027 USA
[phone] General Information, [phone] Electronic Support, [phone] Fax
Contacting the Knox Company, Limited Warranty and Order Terms
and Conditions
You can access the Knox Company web site at http://knoxbox.com. From this web site, you can
obtain general information about the company, customer support, products and career
opportunities. You can also register and log into the system to obtain software updates and new
manuals. Your installation and use of the product is subject in all respects to Knox’s limited
warranties for products and Knox’s Order Terms and Conditions which are also available at
http://knoxbox.com.
Important Information for MedVault WiFi Units
FCC NOTICE
The RF module contained within this device complies with the rules set forth in Part 15 by the
Federal Communications Commission.
Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
3. An approved antenna must be directly coupled to the module's RP-SMA connector.
4. The module must not be modified in any way. Coupling of external circuitry must not bypass
the provided connectors.
5. The antenna used for this transceiver must not be co-located or operated in conjunction with
any other antenna or transmitter.
Any changes or modifications could void the user's authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This Device Contains: FCC ID: R68MTCHDRCT, IC ID: 3867A-MTCHDRCT or FCC ID:
YOPGS2100MIE, IC ID: 9154A-GS2100MIE. Refer to product label to determine which
module is installed.

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault®
▪ 1
Contents
Installing the MedVault® Unit ........................................................................................................ 2
Installing the Hardware ............................................................................................................... 2
Mounting Options ................................................................................................................... 3
Installing the Electronics............................................................................................................. 4
Specifications .................................................................................................................................. 5
Contacting Electronic Support ........................................................................................................ 6
Removing the Door ..................................................................................................................... 6
Attaching the Door ...................................................................................................................... 7
Index ............................................................................................................................................... 9

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault®▪ 2
Please thoroughly read all
instructions before
mounting the MedVault®
unit.
Installing the MedVault® Unit
Although the MedVault® unit is manufactured to provide
secure storage of medical narcotics, follow these installation
instructions for maximum security.
Determine the mounting location. Be certain there is
adequate space to open and close the MedVault® door.
Allow a minimum of 1 inch to the left of the door for room to remove the door from the
MedVault. (see page 6)
Installing the Hardware
Because we do not know how or where our customers will be installing the MedVault® unit, it is
not pre-drilled and does not include mounting hardware.
BOTTOM
Warning
Only drill mounting holes in the reinforced areas along the edges (as
indicated above).
Placing mounting holes in any other location may warp the unit and
cause failures.

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault®▪ 3
Assemble the following hardware and equipment:
 Four (4) quarter-inch (1/4”) bolts and washers
 Drill and bit
 Center punch
We recommend the following mounting guidelines:
1. Insert bolts from the inside of the unit.
2. Place mounting holes on the edge of the unit bottom where the unit construction is
reinforced.
3. Place the mounting holes at least three-quarters of an inch (3/4”) from the edge of the
unit.
4. Use a center punch to start the mounting holes.
5. Ensure that the cable is not pinched or pulled during mounting, and it will not be
damaged during operation.
6. Make sure the mounting holes do not interfere with the opening damper or any other
component inside the box.
7. Do not mount anything to the MedVault® door.
8. Do not use a hammer to fit the unit in place. Doing so may warp the unit.
9. Do not over-tighten the mounting bolts—it will distort the flange and may warp the unit.
10. Clean up shavings after drilling the mounting holes.
11. Do not mount the unit face-down from a ceiling or overhang area.
12. The door hinge of the mounted unit must be on the bottom.
13. When the door is open, it should not rest on any surface.
14. If you install the unit on a thin or hollow wall/surface, use a solid backing for
reinforcement.
15. We recommend mounting the unit to solid studs or steel supports.
Mounting Options
Surface-mounted models are designed for mounting on a flat surface.
Recess-mounted models are designed for flush mounting. You can adapt the unit to fit a variety
of wall or compartment types.

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault®▪ 4
Note: The MedVault®
contains a polarity diode to
prevent damage to the unit
if the wires are attached in
reverse.
Installing the Electronics
Wire Connection Table
Red +12 Volts DC
Black Ground
Assemble the following tools and supplies:
 Electrical tape
 Wire stripper
Follow these steps to install the MedVault® electronics:
1. Establish the desired location of the unit in the vehicle.
2. Determine the source of the MedVault® power. Ensure that the power supply is filtered,
fused and capable of supplying three (3) amps.
3. Run the supplied 2-conductor cable to the power connection.
4. Connect the black wire in the ten-foot (10’) cable to ground.
5. Connect the red wire to a 12-volt power source.
6. Ensure that the power can be turned off with the vehicle’s master power switch.
7. If you are connecting the unit with continuous power:
A. First, connect ground to the black wire.
B. Second, power +12 volts to the red wire.
8. Test the installation by turning on the power. The
keypad should be lighted and a banner should scroll
above it, displaying the time, date. and door status.
A. Enter a PIN code.
B. The MedVault should unlock, allowing you to turn the knob from the vertical position
to the horizontal position.
9. You or your administrator can set the MedVault® date and time from the laptop PC
containing the Knox Units Administrator® software.
10. Congratulations! You have successfully installed the hardware and electronics.

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault®▪ 5
Specifications
Hardware
Weight Approximately eighteen (18) pounds
Exterior Dimensions 9 ¼” Height X 12” Width X 9” Depth
Interior Dimensions 7 ½ Height X 10 ½” Width X 6 ½ Depth
Versions  Surface mount
 Recessed version (one-inch flange around the box perimeter)
4-Pin Din Connector USB port, which collects Audit Trail history information. It also
downloads new configuration information into the box, such as PIN
codes.
RP-SMA Connector Connect a WiFi antenna for wireless network if equipped.
RJ-45 Dongle Connect a Cat5 Ethernet cable for wired networking if equipped.
Override Manual Key If the electronics fail or the vehicle loses power, the unit can ONLY be
opened using the manual override key. For security purposes, the
manual override key is shipped separate from the unit. If you do not
receive your manual override key, contact Knox immediately.
Electronics
Temperature Range -40º C to +80 º C (-40 º F to 176V F)
Power Supply
Input Range
10 to 15 volts DC @ 3 amps
Current Drain
(Standby)
120 milliamps
Current Drain
(Door Release)
Up to 3 amps
Current Drain
(Door Open)
150 milliamps
Initial Power
Stabilization Time
5 seconds
Absolute Max Input 20 volts DC

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault® ▪ 6
Contacting Electronic Support
If you experience difficulties with the MedVault® unit that are not addressed in this literature,
please call Knox Electronic Support at [phone]. Our technicians will review your issues
and attempt to resolve them over the phone.
Please, do not return the MedVault® or any parts without first calling Support. By calling
Support, we may be able to resolve any difficulties without you having to send the unit or parts
to us. If you do have to make a return, our technicians can:
1. Assign an RMA number so we can track your unit.
2. Provide the correct mailing address.
3. Provide customized help for your particular issue.
We take pride in our products and endeavor to keep our customers satisfied. We provide a
support staff who does an outstanding job of providing our customers with prompt, courteous
service.
Removing the Door
You have the capability of removing the door if comprehensive serving is needed and you need
Knox to service your MedVault. Perform the following steps to remove the door on your
MedVault.
1. Open the door with a PIN code. If you are unable to do so:
A. Turn off power to the unit.
B. Open the door with the override key.
2. Use a screwdriver to remove the wire access panel.
3. Disconnect the coax connector (if WiFi equipped) and the Microfit connector.
4. Use a phillips screwdriver to disconnect gas damper from door.
5. Use the Knox security screw removal bit to unscrew the three screws in the hinge lock.

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault® ▪ 7
6. Lift up the hinge lock. Set aside the hinge lock and screws for safe-keeping.
7. Slide the door to the left and pull toward you to remove the door from the hinge pins.
8. Reattach wire access panel with screws to door for shipping.
9. If a replacement door is long in coming, reattach the hinge lock to the door with the three
security screws, tightened finger-tight, for safe-keeping.
10. Retain the Knox security screw removal bit for reassembly.
Attaching the Door
Follow these instructions when you are ready to attach the replacement door to the MedVault:
1. Remove the temporarily attached hinge lock by removing the three security screws (if
attached).
2. Position the door, interior side up, hinges facing away from you, with the hinge knuckles
just to the left and touching the hinge pins.
3. Push the knuckles in and to the right to slip the knuckles over the three hinge pins
simultaneously. A rubber mallet may be used to assist sliding the door on the pins. Avoid
using metal tools as these could damage the door and affect door security.
4. Reinstall the hinge lock by placing it back in its original position, with its knuckles
inserted between the door hinge knuckles.
1
2
3

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault® ▪ 8
5. Install the hinge lock security screws and finger-tighten.
6. Use the Knox security screw removal bit to further tighten the security screws. DO NOT
OVER-TIGHTEN.
7. Use a Phillips screwdriver to reattach the gas damper to the door.
8. Use a screwdriver to open the door wire cover.
9. Reconnect both halves of the coax cable and connector (if so equipped).
10. Reconnect both halves of the Microfit connector.
11. Secure the cables inside the door wire cover insuring that the wires are not kinked.
12. Use screwdriver to close the door wire cover.
13. Close the door, energize the unit, and verify the keypad lights up and the scrolling LED is
operational.
14. Keep the Knox Security Bit in a secure location.

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault® ▪ 9
Index
+
+ 12 volts ............................................................................ 4
1
10-foot cable ....................................................................... 4
2
2-conductor cable ................................................................ 4
4
4-Pin Din connector ............................................................ 6
A
Absolute max input ............................................................. 7
antenna ........................................................................... ii, 6
Audit Trail .......................................................................... 6
B
Black wire ........................................................................... 4
C
Configuration information .................................................. 6
Contact Information ........................................................... ii
Continuous power ............................................................... 4
Copyright ........................................................................... ii
Current drain
Door open ...................................................................... 7
Door release ................................................................... 7
Standby .......................................................................... 7
D
Date ................................................................................ 4, 5
Dimensions
Exterior .......................................................................... 6
Interior ........................................................................... 6
E
Electrical installation .......................................................... 4
Electronic Support ......................................................... ii, 7
Electronics specifications ................................................... 6
Exterior dimensions ............................................................ 6
G
Ground ................................................................................ 4
H
Hardware installation ......................................................... 2
Hardware specifications ..................................................... 6
I
Initial power stabilization time ........................................... 7
Input, absolute maximum ................................................... 7
Install
Electronics .................................................................... 4
Hardware ....................................................................... 2
MedVault ...................................................................... 2
Surface-mounted units .................................................. 3
Interior dimensions ............................................................. 6
K
Key ................................................................................. 6, 8
O
Override key ................................................................... 6, 8
P
PIN codes ................................................................... 4, 6, 8
Power supply ...................................................................... 4
Power supply input range ................................................... 7
R
Range
Power supply input ....................................................... 7
Temperature .................................................................. 6
Recessed mount .............................................................. 3, 6
Red wire ............................................................................. 4
S
Specifications ..................................................................... 6
Electronics .................................................................... 6
Hardware ....................................................................... 6
Supplies .............................................................................. 4
Support ....................................................................... ii, 7, 8
Surface mount .................................................................... 6
Surface-mounted units ........................................................ 3
T
Technical Support .............................................................. 7
Temperature range.............................................................. 6
Time ............................................................................... 4, 5
Tools .............................................................................. 4, 9

MedVault® Hardware Installation Instructions
OPE-MVHDWR-0202-H The Knox Company ▪ MedVault® ▪ 10
V
Versions .............................................................................. 6
Recessed ........................................................................ 6
Surface mount ................................................................ 6
W
Weight ................................................................................ 6
Wire connection table ......................................................... 4
