Knpaimly BS5 User manual

BS5 Wireless Earbuds
User Manual
Thank you for purchasing our product. This manual addresses
the safety guidelines, warranty, and operating instructions.
Please review this manual thoroughly before operating your
device.
Knpaimly

Please note before use
There is a static sticker on the charging
connector at the bottom of the
Headphones. Please tear the static
stickers before using the Headphones.
- 1 -
Correct way of taking
out earbuds
Incorrect way of taking
out earbuds

● Wireless Earbuds - 1 pair (left and right)
● 1x Charging Case
● 1x Type-C Charging Cable
● 1x User Manual
Package Contents
At a Glance Earbuds
Microphone
Touch Button
LED Indicator
Charging Contacts
- 2 -

How to Wear
Insert the earbud into your ear and rotate to fit
comfortably.
Charging Pins
Micro USB Charging Port
Charging
Case Indicator
Charging Case
- 3 -

Earbuds LED Indicator Guide
System State
Power on
Power off
Pairing mode
Charging
Fully Charged
Indicator Activity
The LED indicator stays Red and
blue lights flash alternately
The LED indicator flashes red.
The LED indicator flashes red and
blue alternately.
The LED indicator stays red.
The LED indicator goes off.
Charging Case Indicator Guide
System State
Charging
Fully charged
Indicator Activity
The charging case bottom indicator
flashes orange slowly.
The charging case bottom indicator
stays orange.
- 4 -

Using Your BS5
Charge the earbuds
Put the earbuds into the charging case.
Note:
When your earbud battery life is low, you will hear a
voice reminder.
Charge the charging case
1) Plug the small end of the Type-C cable into the
Micro USB port of the charging case.
2) Plug the other end into a USB wall charger or
computer (DC 5V) that is powered on.
- 5 -

Note:
It takes approximately 2 hours to fully charge the
charging case. A fully charged charging case can
charge the earbuds approximately 6-7 times.
Power on & off
Automatic operation
Power on: Open the lid of the charging case and take
the earbuds out.
Power off: Put the earbuds back into the charging
case.
Note:
When the charging case is out of power, putting the
earbuds back in the charging case will not turn the
earbuds off.
Manual operation
Power on/off: Tap and hold the touch button on the
left/right earbud for 5 seconds.
Note:
When the two earbuds are paired with the phone, turn
off one earbud manually will make the other one be
off at the same time.
- 6 -

1) Take the earbuds out of the charging case and the LED indicator on
the earbud will flash red and blue alternately.
Pairing & Connectivity
- 7 -
Notes:
● There is a static sticker on the charging connector at
the bottom of the Headphones. Please tear the static
stickers before using the Headphones.
● Knpaimly BS5 Bluetooth earbuds are compatible with
all bluetooth enabled devices of Android / iOS /
Windows. IPods, Ipads and Tablet are also supported.
LED

Notes:
● If pairing failed, put the earbuds back into the charging
case make sure that they have been turned off. Then
pair the earbuds with your Bluetooth device again.
● When the earbuds are on but not paired with a
Bluetooth device, they will be automatically off after 5
minutes.
- 8 -
2) Turn on bluetooth in your phone, Choose "BS5" from the list of found
Bluetooth devices on your Bluetooth device to pair.
BS5
Settings B luetooth
Bluetooth
BS5 Connected

Please following the steps as below
when only one earbud works:
1. Long press the function touch button for 10 seconds (flashes red) to remove
the pairing;
Primary/Secondary mode
These earbuds have primary-secondary switch function.
● When the earbuds have been connected to a
Bluetooth device, take out either of the two earbuds, it
can be connected and used normally. During this
period, you can take out the other one and they will
pair with each other so you can use both of the
earbuds.
● When both earbuds are connected to your phone, no
matter which one is put back to the charging case,
you can use the other one without interruption.
- 9 -
Power off
10S
LED

2. Put the L / R earbuds into the charging box at the same time to reset
and the two earbuds will connect to each other automatically again;
3. Put the earplugs into the charging box for 5 seconds After , then
take out two earplugs, Resetting successfully.
- 10 -
Voice Prompt:Pairing
BS5
Setting s Bluet ooth
Bluetoo th
BS5 Connected
LED

Smart touch Control usage
Decline Incoming call: click one earbud.
Play/ Pause: Short touch of one earbud.
Pick up/ Hang up phone call: double click one earbud.
Siri: Touch and hold for 2s.
Volume +: Touch 2 times of Left Earbud.
Volume -:Touch 2 times of Right Earbud.
Previous Song: Touch 3 times of Left earbud.
Next Song: Touch 3 times of Right earbud.
Power on: Long press L/R touch button for 3 seconds, red and
blue lights flash alternately
Power off: Hold down the L/R touch button for 5 seconds and the
red light will go on for 1 second
- 11 -

Specifications
Model
Bluetooth Version
Battery
Charging Time
Input Rating
Music Playing/Call Time
Bluetooth Connection
Distance
Supporting Protocols
Working Temperature
BS5
V5.0
45mAh (each earbud),
650mAh (charging case)
Approximately 1 hour
(earbuds),
2 hours (charging case)
DC 5V 1A
4-5 hours per charge
Up to 35 hours
(with charging case)
Up to 50 feet (No obstacle
between)
A2DP/HFP/HSP/AVRCP
-10°C to 40°C
- 12 -

- 13 -
Safety and Warranty
Important safety instructions
● Use of earbuds will impair your ability to hear other
sounds. Use caution while using your earbuds when
you are engaging in any activity that requires your
full attention.
● If you have a pacemaker or other electrical medical
devices, you should consult your physician before
using this product.
● This package contains small parts that may be
hazardous to children and should be kept out of
reach from children. This product is not a toy ?never
allow children to play with this product. Always store
the product out of reach from children. The bags
themselves or the many small parts they contain
may cause choking if ingested.
● Never try to dismantle the product yourself, or push
objects of any kind into the products, as this may
cause short circuits which could result in a fire or
electric shock.
● None of the components can be replaced or repaired
by users. Only authorized dealers or service centers
may open the product. If any parts of your product

- 14 -
require replacement for any reason, including normal
wear and tear or breakage, please contact us.
● Avoid exposing your product to rain, moisture or
other liquids to protect against damage to the product
or injury to you.
● Keep all products, cords, and cables away from
operating machinery.
● If the product overheats, if the product has been
dropped or damaged, if the product has a damaged
cord or plug, or if the product has been dropped in a
liquid, discontinue use and contact us.
● Do NOT use in areas where there are explosive
hazards.
● Do NOT submerge the earbuds in water. Do NOT
expose the earbuds to moving water (e.g., from a
faucet, etc.).
● Do NOT wear the earbuds while showering or
bathing, or when participating in water sports, e.g.,
swimming, water skiing, surfing, etc.
● This product contains magnetic material. Consult
your physician on whether this might affect your
implantable medical device.

- 15 -
● Leaving the product in hot or cold places, such as in
a closed car in the summer and winter conditions,
will reduce the capacity and lifetime of the earbuds.
● Dispose of the product according to local standards
and regulations.
Note: Always drive safely, avoid distractions and follow
local laws!
● Using the earbuds while operating a motor vehicle,
motorcycle, watercraft or bicycle may be dangerous,
and is illegal in some jurisdictions, just as use of the
earbuds with both ears covered while driving is not
permitted in certain jurisdictions. Check your local
laws.
● Use with caution while using your earbuds when
you are engaging in any activity that requires your
full attention. While engaging in any such activity,
removing the earbuds from your ear or turning off
your earbuds will keep you from being distracted, so
as to avoid accident or injury. Do not take notes or
read documents while driving.
● When using and charging this product, basic
precautions should always be followed, including
the following:
※Read all the instructions before using the charging
case.

※ To reduce the risk of injury, close supervision is
necessary when the charging case is used near
children.
※ Do not expose charging case to water, rain, liquids
or snow.
※ Use of a power supply or charger that is not
recommended or sold by power pack manufacturer
may result in a risk of fire or injury.
※ Do not use the charging case in excess of its output
range.
※ Do not use a charging case that is damaged or
modified. Damaged or modified batteries may
exhibit unpredictable behavior resulting in fire,
explosion or risk of injury.
※ Do not disassemble the charging case. Incorrect
reassembly may result in risk of fire or injury.
※ Do not open, crush or expose a charging case to
fire or excessive temperature. Exposure to fire or
extreme temperature may cause explosion.
※ Have servicing performed by a qualified repair
person using only identical replacement parts.
- 16 -

- 17 -
Seller Warranty Description
We strive to build our products with the
highest attention to detail and
craftsmanship. However, sometimes
there are occurrences of defect.
18-month quality warranty time, friendly
customer service, If you have any questions
about the product, please contact us, We will
solve the problem for you as soon as
possible.
Knpaimly
Please contact us at any time 24/ 7 / 365
if you have any questions or concerns:
email: [e-mail]
