Kobold DRB-G R Series User manual

Operating Instructions
for
Dosing Electronic
Model: ZED-D
or DF-…DLxxx
or Model-…GxxR

ZED-D
page 2 ZED-D K11/0522
1. Contents
1. Contents........................................................................................................2
2. Note ..............................................................................................................3
3. Instrument Inspection....................................................................................3
4. Regulation Use .............................................................................................3
5. Operating Principle........................................................................................4
6. Electrical Connection ....................................................................................5
6.1 ZED-D, DRB-…GxxR, DPE-…GxxR fieldhousing and control panel
installation............................................................................................5
6.2 DF-…DLxxx, Model-…GxxR cable connection................................5
6.3 Model-…GxxR plug connection .......................................................6
6.4 Connection example............................................................................6
7. Operation / Configuration / Adjustments .....................................................10
7.1 General..............................................................................................10
7.2 Function of the control keys...............................................................11
7.3 Character explanation for main menu................................................12
7.4 General Settings................................................................................13
7.5 Flow and analogue output..................................................................15
7.6 Relay output.......................................................................................17
7.7 Dosing................................................................................................19
7.8 User alignment and Service-Settings.................................................21
7.9 Error report ........................................................................................24
8. Relay Functions ..........................................................................................25
8.1 Dosing (REL S1) with correction amount & fine dosing (REL 2)........25
8.2 Dosing (REL S2) & Pump control (REL S1).......................................26
8.3 Switching characteristic limit value ....................................................27
8.4 Switching characteristic window ........................................................27
9. Technical Information..................................................................................28
10. Order Codes ...............................................................................................29
11. Dimensions .................................................................................................30
12. EU Declaration of Conformance .................................................................31
13. UK Declaration of Conformity......................................................................32
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

ZED-D
ZED-D K11/0522 page 3
2. Note
Please read these operating instructions before unpacking and putting the unit
into operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([e-mail]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
The devices are only to be used, maintained and serviced by persons familiar
with these operating instructions and in accordance with local regulations
applying to Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC-machine guidelines.
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of
the delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
•Dosing Electronic model: ZED-D
4. Regulation Use
Any use of the Dosing Electronic, model: ZED-D, which exceeds the
manufacturer’s specification, may invalidate its warranty. Therefore, any resulting
damage is not the responsibility of the manufacturer. The user assumes all risk
for such usage.

ZED-D
page 4 ZED-D K11/0522
5. Operating Principle
The evaluation unit changes the frequency signal of the pickup into a 3(4)-digit
flow reading with adjustable scale (topline of display), and a scalable analogue
signal. The dosage is displayed in the bottom line of the display. The unit of
measurement can be selected.
Included are two relays with floated output changeover contacts for various
functions. The relay (S1) can be used to execute the flow monitoring, total volume
monitoring, fine dosage or the pump control.
When the flow is being continuously monitored, it checks if the freely adjustable
limits are exceeded or fallen short of. A choice can be made between threshold
value and window monitoring. Switching point, hysteresis, window point, and
switch-on or switch-off delay can be set as desired. If monitoring of the total
volume is selected, a check is made to see if the adjustable quantity limit is
exceeded.
The dosage relay (S2) switches on when the dosage process starts, and then
switches off again, once the dosage has flowed through. The dosage process can
be interrupted by using the Start/Stop switch. By taking a correction quantity into
account, it is possible to take any special features or conditions of the system into
account. By entering a fine dosage, the bypass valve can be controlled with the
relay (S1). A red LED indicates the relay’s switching status.
The Analogue output is available as a current output with 0(4)...20 mA or a
voltage output with 0...10 V. The parameter names in the menu can be displayed
in either German or English. If used where the flow readings change rapidly, the
display can be pacified and the analogue reading averaged by switching on some
software. If the maximum set flow (exceeded range) is exceeded, it will be shown
on the display. The set parameters can be protected against unauthorised
alteration using a password function.
Range of functions
Dosage and flow meter with digital display, switch and analogue output:
•Measurement and display of dosage, total and flow Quantities
•Free scaling using Teach-In or input of frequency and measured value
•Interval counter (number of dosing processes)
•2 control inputs
•1 dosage output
•1 switching output, freely programmable as flow monitor
or for monitoring the total quantity
•Analogue output 0(4)-20 mA or 0-10 V

ZED-D
ZED-D K11/0522 page 5
6. Electrical Connection
6.1 ZED-D, DRB-…GxxR, DPE-…GxxR
fieldhousing and control panel installation
*) Ctrl 1 -- GND => Start
Ctrl 2 -- GND => Stop
Ctrl 1 -- Ctrl 2 -- GND => Reset Dosing
6.2 DF-…DLxxx, Model-…GxxR
cable connection
Wire number
DF Dosing electronics
1
+24 V
DC
2
GND
3
4-20 mA / 0-10 V
4
GND
5
Ctrl 1 *)
6
Ctrl 2 *)
7
Relay S1 N/O
8
Relay S1 COM
9
Relay S2 N/O
10
Relay S2 COM
*) Ctrl 1 -- GND => Start
Ctrl 2 -- GND => Stop
Ctrl 1 -- Ctrl 2 -- GND => Reset Dosing
*)

ZED-D
page 6 ZED-D K11/0522
6.3 Model-…GxxR
plug connection
-G31 R
+ Vs
Ctrl 2 *
0 - 10 V Out
DC
GND
1
30 V / 2 A
AC/DC
3
4
5
1
3
4
5
6
S 2
8
Ctrl 1 *
-G34 R
+ Vs
Ctrl 2 *
0 (4) - 20 mA Out
GND
1
30 V / 2 A
AC/DC
3
4
5
1
3
4
5
6
S 2
8
Ctrl 1 *
*) Ctrl 1 -- GND => Start
Ctrl 2 -- GND => Stop
Ctrl 1 -- Ctrl 2 -- GND => Reset Dosing
6.4 Connection example
PNP-Sensor NPN-Sensor

ZED-D
ZED-D K11/0522 page 7
NAMUR-Sensor
Operation of ZED-D on flow meters with transmitters UMF2B, UMF3 and
UMC4 for dosing applications
The ZED-D dosing device is connected to the UMF2B, UMF3 or UMC4 converter
via the frequency output.
2
1
3
4
5
6
7
8
9
10
11
12
13
14
PNP
GND
NPN
Namur
F-Input
Impulse-
Impulse+
UMF-2 / UMF-3 /
UMC-4
0 - 1000 Hz
ZED-D

ZED-D
page 8 ZED-D K11/0522
The following parameterizations must be made:
Settings on the UMF2B / UMF3 / UMC4 transmitter (see corresponding
operating instructions):
−Enter customer password 0002 (UMF2B, UMF3: Chapter 13.2.1, UMC4:
7.2.2.1).
−In the function class "Pulse output" / "Pulse or frequency output" set the
pulse output to frequency output (UMF2B, UMF3: Chapter 13.6.1; UMC4:
7.2.8.1). Select the unit l/min (UMC4: kg/min) in the function class "Flow" /
"Flow unit". Any other unit can be selected. When calculating K0 later in the
ZOK, however, it must first be converted to l/min. - Read out the end value
in l/min (kg/min) in the function class "Flow" / "Flow end value". If the flow
rate is the same as the final value, the converter outputs 1000 Hz.
−With short filling times, the smallest possible time constant should be set
(UMF2B: Chapter 13.4.1; UMF3: Chapter 13.4.2; UMC4: 7.2.4.1).
−The filter is switched off (UMC4: "weak") (UMF2B: Chapter 13.4.5; UMF3:
Chapter 13.4.1; UMC4: 7.2.4.5). In this way, the measured value can follow
a change in flow rate as quickly as possible. This makes the flow rate
indication in the display more restless, but this is not relevant for the
accuracy of the dosing.
−The low flow rate should be set to a small value, e.g. 1%, so that no pulses
are counted when the medium is standing still (UMF2B: Chapter 13.4.2;
UMF3: Chapter 13.4.3; UMC4: 7.2.4.2).
Settings on the ZED-D:
See chapter 7.8
FlowVal = End value of the UMFx in l/min (or kg/min)
FlowUnit = l/min
Freq.Val = 1000 Hz

ZED-D
ZED-D K11/0522 page 9
Function check:
Activate the simulation for the frequency output on the UMF2B, UMF3 or UMC4
converter:
- Select function class "Simulation" / "Simulation specification Q / direct" =>
"Direct".
- Set the frequency to 1000 Hz under "Simulation direct pulse output".
- Switch on the simulation under "Simulation off / on"
The ZED-D must now display a flow rate that is equal to the final value of the
UMF2B (UMF3, UMC4)
Please note:
If the end value is exceeded, there is a risk that at a frequency above 1100 Hz,
the frequency transmission between the converter and ZED-D will no longer
function properly and pulses will be lost. Please also observe the display of the
UMF2 (UMF3, UMC4) during a sample filling, whether an error "Pulse output
overdriven" or "Current overdriven" is reported. In this case, the final value in
UMF2 (UMF3, UMC4) must be adapted and the FlowVal parameter recalculated
in the ZED-D. The measuring range of the UMF2B (UMF3, UMC4) should be
adapted to the maximum expected flow rate in order to make good use of the
frequency range of 1000Hz. If, for example, the maximum flow rate is 30 l / min,
the end value should be set to e.g. 33 l/min (10% reserve) to allow the end value
to be exceeded slightly.

ZED-D
page 10 ZED-D K11/0522
7. Operation / Configuration / Adjustments
7.1 General
Only the menu items which lines are marked in the selection matrix in grey colour,
are available in the respective instrument version.
Italic written values are blinking in the display, if they have been chosen for
any input.
The parameter can only be changed, if the security code has been
entered correctly! The message „locked“ will appear if the input
has not been activated.

ZED-D
ZED-D K11/0522 page 11
7.2 Function of the control keys
Operating mode >Measure< :
PGM/ENTER
- Press briefly 1x: a) Display dosage interval counter or
b) Reset status reports.
- Press briefly 2x: Display current total quantity, then
Display corresponding scale unit.
- Press for 3 sec: Switch to operating mode >Parameterize<
▼+ ▲
- Press for 3 sec: Enter dosage
(only if parameter DMdirect is switched to “yes”).
START/STOP
- Press briefly: a) Start dosage process.
b) Interrupt dosage process.
- Press for 3 sec: Initialising and then poss. abortion of dosage operation.
Operating mode >Parameterize< :
PGM/ENTER
- Press briefly: a) Open parameter group or
b) Change parameter (go lower in menu level) or
c) Adopt value input.
- Press for 3 sec: Abort input (ESC) and go back one
menu level.

ZED-D
page 12 ZED-D K11/0522
▼
- Press briefly: a) Select parameter group or parameter or
b) Reduce digit position (when entering of numerical value) or
c) Select list value (e.g. ... L/m, L/h, m3/m, ...).
▲
- Press briefly: a) Select parameter group or parameter or
b) Increase digit position (when entering of numerical value) or
c) Select list value (e.g. ... m3/m, L/h, L/m, ...).
START/STOP
- No function in >Parameterize< operating mode.
Note: If no button is pressed for 20 seconds during parameterising, the
instrument automatically switches back into >measuring< mode.
7.3 Character explanation for main menu
( e) -Button PGM/ENTER press shortly.
( E) -Button PGM/ENTER press and hold for approx. 3 seconds.
(▼) -Button ▼press shortly.
(▲) -Button ▲press shortly.

ZED-D
ZED-D K11/0522 page 13
7.4 General Settings

ZED-D
page 14 ZED-D K11/0522
GENERAL SETTINGS
Menu Item Parameter / Function Explanation / Values / Other
Language Select menu language German or English
fUnitFS * Measuring unit for flow
measurement
mL/s, mL/m, L/s, L/m, L/h, m3/m, m3/h,
GPM, GPH, UU/s, UU/m, UU/h
fValueFS * Maximum measuring range value
for flow measurement
Range = 0,00...99,9..._100...9999
fMinVal * Minimum measuring range value
for flow measurement
Basis is fValueFS and fUnitFS
If the level drops below this, the flow indicator goes to 0.
fPls/rev* Impulse per sensor wheel
revolution
Number of impulses per revolution of the sensor wheel or the like
Necessary for long-term period averaging if the readings per revolution vary.
The function is switched off when the input value is 1.
fJumpVD * Flow switch value for attenuation
cut-off
Value in %, basis is fValueFS and fUnitFS.
Attenuation does not function if the switch value is 0%.
fOverflV Flow overflow value (overflow)
Value in %, basis is fValueFS and fUnitFS.
If exceeded, an M100 report is generated and faded in, alternating
with the flow indicator.
The report is saved and can be reset by briefly pressing the
PGM key.
fFactor Select pulse ration
Selection of works calibration or user calibration.
(only for devices Model DF-...DLxxx and Model-...GxxR)
UserUnit. Special volume unit Customer-specific special unit UU. The value entered corresponds to the number of litres of the special unit, e.g.
in the case of the unit Barrel the factor would for example be 115.6271.
*) Only for ZED devices: Device-specific parameter, is only visible after activation in the SecCode menu item in the SERVICE menu
group, and can be changed.

ZED-D
ZED-D K11/0522 page 15
7.5 Flow and analogue output

ZED-D
page 16 ZED-D K11/0522
FLOW
Menu
Item
Parameter / Function Explanation / Values / Other
fUnit Unit of flow indicator
mL/s, mL/m, L/s, L/m, L/h, m3/m, m3/h,
GPM, GPH, UU/s, UU/m, UU/h
fDamping Attenuation of reading fluctuations in the flow indicator
The attenuation pacifies the flow indicator.
The attenuation value is the approximate equivalent of the setting time
of the display value to c. 90 % of a measured value jump in seconds.
(Parameter is blocked at DF-...DLxxx devices).
ANALOGUE OUTPUT
Menu Item Parameter / Function Explanation / Values / Other
aChoice Selection of analogue source Flow: gauged analogue value of flow measurement
Volume: current volume in percentage of dosage
aLIFE 0 Select Life Zero Offset at power output: 0 mA or 4 mA
at 0-10 V ≙0 mA →0 V and 4 mA → 2 V
aLowFlow Flow reading at 0/4 mA or 0/2 V
Lower flow reading of gauged output range,
value has the same unit as the flow indicator,
(only if aChoice is set to Flow)
aHighFlo Flow reading at 20 mA or 10 V
Upper flow reading of gauged output range,
value has the same unit as the flow indicator,
(only if aChoice is set to Flow)
aLoVaDos Percentage the dosage at 0/4 mA or 0/2
V
Lower volume value of gauged output range.
- Range: 0...120 %
- The difference |aHiVaDos – aLoVaDos| may not be less than 10 %.
- aLoVaDos > aHiVaDos is also possible.
(only if aChoice is set to Volume )
aHiVaDos
Percentage the dosage at 20 mA or 10 V
Upper volume reading of gauged output range.
- Range: 0...120 %
- The difference |aHiVaDos – aLoVaDos| may not be less than 10 %.
- aLoVaDos > aHiVaDos is also possible.
(only if aChoice is set to Volume )

ZED-D
ZED-D K11/0522 page 17
7.6 Relay output

ZED-D
page 18 ZED-D K11/0522
RELAY S1
Menu Item
Parameter / Function
Explanation / Values / Other
s1Funct Relay1 Function selection
Flow: Monitoring of an adjustable flow value (s1SPunkt).
GM Limit: Monitoring of an adjustable total volume (s1TA-Lim).
PumpCtrl: Dosage pump control.
FineDose: Fine dosage valve control.
see 8.0 Relay functions
s1Char. Relay1 Switch characteristic
Limit: Monitoring a reading (s1Spunkt).
Window: Monitoring an adjustable measuring range
(s1Spunkt...s1WPoint).
(only if s1Funct. is set to Flow)
s1SPunkt Relay1 Switchpoint
Reading is in the same units as the flow indicator.
(only if s1Funct. is set to Flow)
s1Hyste Relay1 Hysteresis
Reading is in the same units as the flow indicator.
(only if s1Funct. is set to Flow)
s1WPoint Relay1 Windowpoint
Reading is in the same units as the flow indicator.
(only if s1Funct. is set to Flow und s1Char. auf Window )
s1SDelay. Relay1 Switch delay
Value input is always in the following format
Range:_ 0,0...99,9 sec
(only if s1Funct. is set to Flow)
s1RDelay. Relay1 Reset delay
Value input is always in the following format
Range:_ 0.0...99.9 sec
(only if s1Funct. is set to Flow)
s1TA-Lim Relay1 Total volume limit value
Reading is in the same units as the total volume unit in
dosage unit menu group.
(only if s1Funct. Is set to GM Limit )
s1PumpAT Relay1 Pump control lead time
Reading determines pump lead time (Rel 1) before dosage begins
Range = _0.0...99.9 sec
(only if s1Funct. is set to PumpCtrl )
see 8.2 Pump control
s1PumpDT Relay1 Pump control coast down
time
Reading determines pump coast down time (Rel 1) after end of dosage
Range = _0,0...99.9 sec
(only if s1Funct. is set to PumpCtrl )
see 8.2 Pump control

ZED-D
ZED-D K11/0522 page 19
7.7 Dosing

ZED-D
page 20 ZED-D K11/0522
DOSAGE UNIT
Menu Item
Parameter / Function
Explanation / Values / Other
DM-Unit Unit of dosage
Unit of dosage quantity
mL, L, m3, gal, mgal, UU (User Unit, see UserUnit. )
DAmount Dose Numerical value of dosage quantity
FDAmount Fine dose
Numerical value of the fine dosage
Unit set as in DM-Unit.
For activating of fine dosage, the function Fine dose must be setted in the
menu group RELAYS1, under the menu item S1FUNKT.
(Function see 8.1 Dosage)
DACorrct Correction quantity
Numerical value of correction quantity
Unit set as in DM-Unit.
A negative reading causes the dosage relay S2 to switch off before the zero
reading on the dosage meter is reached. Any coast-down quantity needed
can be corrected with this entry.
A positive reading causes the dosage to be increased by the appropriate
constant amount. The dosage relay S2 only switches the dosage meter off
once the reading has exceeded the 0 value. Any quantity lacking can be
corrected with this entry.
(Function see 8.1 Dosage)
DMdirect Dosage – direct input
Activation of direct dosage via the (E),
(+)- und (–)- keys, without having to go into the menu.
Start of input by simultaneously pressing of (> 3sec) the (+)- and the
(–)- keys.
Unit set as in DM-Unit.
yes: Direct input of the dosage activated by keys (default).
no: Input of dosage only possible in the menu.
ICNT =0? Set interval counter
to 0
The interval counter only counts dosage processes that have been carried
out completely.
yes: Interval counter = 0
no: no action
TA-Unit Total quantity display Unit
Total quantity display unit
mL, L, m3, gal, mgal, UU (User Unit, see UserUnit. )
TA =0? Set total quantity display to 0
The total quantity meter counts the total flow quantity (also the non-dosed
flow).
yes: Total quantity meter = 0
no: No action
