Kobold Henschen MAN-SF Series User manual

Operating Instructions
for
Digital Pressure Gauge
Model: MAN-SF...
MAN-BF..

MAN-SF (-BF)
page 2 MAN-SF(-BF) 01/1006
1.Contents
1. Contents........................................................................................................2
2. Note 3
3. Regulation Use..............................................................................................4
4. Operating Principle........................................................................................4
5. Instrument Inspection....................................................................................5
6. Mechanical Connection.................................................................................5
7. Electrical Connection ....................................................................................7
8. Operation......................................................................................................8
9. Function of Key Button..................................................................................9
10. Functions Settings.......................................................................................10
10.1. Zero-Point Adjustment of the Display ................................................10
10.2. Serial Number Indications..................................................................11
10.3. Setting the Limit Contacts (optional)..................................................11
10.4. Access to Level 1 (Master Level).......................................................14
11. Enabling / Disabling the Menu Items in Level 0...........................................15
11.1. Enabling/Disabling the Zero-Point Adjustment...................................15
11.2. Setting the user display......................................................................15
11.3. Changing the password for Level 1.....................................................16
11.4. Disabling the optional limit contacts...................................................16
12. Adjustment of the Additional Option............................................................17
12.1. Access to Level 2...............................................................................17
12.2. Adjustment of the Maximum Peak Memory (optional) .......................18
12.3. RS 232 Interface (optional)................................................................22
12.4. Scaling of the Analogue Signal (optional)..........................................23
12.5. Scaling of the Display (optional) ........................................................25
13. Dimensions .................................................................................................28
14. Maintenance ...............................................................................................28
15. Communication with RS 232 Interface........................................................29
16. Technical Information..................................................................................31
17. Declaration of Conformance .......................................................................32
Manufactured and sold by:
KOBOLD Instruments Inc.
1801 Parkway View Drive
Pittsburgh PA, 15205-1422
Tel.: [phone] Fax:
412-788-4890
E-Mail: [email protected]
Internet: www.koboldusa.com

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 3
2.Note
Please read these operating instructions before unpacking and putting the unit
into operation. Follow the instructions precisely as described herein.
The devices are only to be used, maintained and serviced by persons familiar
with these operating instructions and in accordance with local regulations
applying to Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EWG-machine guidelines.
as per PED 97/23/EG
In acc. with Article 3 Paragraph (3), "Sound Engineering Practice", of the
PED 97/23/EC no CE mark.
Pipe
Model P max/bar Diagram 7
Group 2
no dangerous media
Diagram 6 Group 1
dangerous media
MAN-SF (-BF) < 200 Art. 3, § 3 Art. 3, § 3
MAN-SF (-BF) < 500 Art. 3, § 3 Cat. I
MAN-SF (-BF) < 1000 Art. 3, § 3 Cat. I
MAN-SF (-BF) > 1000 Cat. I Cat. I

MAN-SF (-BF)
page 4 MAN-SF(-BF) 01/1006
3.Regulation Use
The model MAN-SF devices are used to display, monitor and transmit pressure-
dependent production processes in machines and plants.
MAN-SF relative pressure measurement (option: absolute)
MAN-BF differential pressure measurement
The devices comprise the following components:
4-digit display
The devices are fitted with a 4-digit, 14 mm high LED to display the measured
pressure.
4 alarm LEDs
To display the control state of limit contacts (available as an optional extra).
Illuminated dialogue display
The 10-digit illuminated LCD serves to display limit values or hysteresis.
Functions and parameters are displayed in the programming mode.
Analogue output
The devices are fitted with an analogue output. The analogue output can be set
at the factory for 0–20 mA, 4–20 mA, or 0–10 V.
2 or 4 limit value relays (optional)
Up to four programmable limit contacts can be supplied as an option for
monitoring and control purposes.
4.Operating Principle
The pressure to be measured is sensed by a piezo-resistive sensor, and
displayed by the electronics. An analogue signal is also available for remote
control. The devices are fitted with a microprocessor. The various functions and
parameters may be set via keypad at the front.

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 5
5.Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of
the delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
•Digital Pressure Gauge
•Pressure transmitter (mounted in non-detachable way for MAN-SF26)
•Mounting angle (MAN-SF20, MAN-BF20)
•Ring for panel mounting (MAN-SF28V, MAN-BF28V)
6.Mechanical Connection
Before installation:
•Make sure that the maximum pressure in your process is within the measuring
range of the Digital Pressure Gauge. The measuring range is written on the
nameplate.
•Make sure that the approved maximum operating temperatures for the device
are not exceeded.
•Make sure that the electrical supply for the devices is in accordance with the
operating data for the device.
•Remove all transport safety locks.

MAN-SF (-BF)
page 6 MAN-SF(-BF) 01/1006
Installation
•Ensure that the line is de-pressurised.
•The Digital Pressure Gauge is mounted like a mechanical pressure gauge.
•For standard threaded connection: sealing is with a suitable gasket
(22.5 x 25.7 x 1.3 flat gasket, or sealing washer according to DIN 16258).
•Do not screw in the device using the case, but rather by using the at hexagon
(SW 27).
•If possible, check that the connection screwing/pipe joint is sealed after
mechanical installation.

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 7
7.Electrical Connection
Attention! Make sure that the voltage values of your system
correspond with the voltage values of the Digital Pressure Gauge.
Make sure that the supply wires are powerless during installation.
•Remove the plastic cap at the
rear of the device.
•Insert the cable in the cable
gland and mount. Check the PG
fitting for tightness.
•Remove the push-on terminal
strip, and connect the cable
according to the wiring diagram
X103
1Supply + Channel-2 /extern (Option) for external sensor only
4-20 mA
2Not used
3Supply - Channel-2 /extern (Option)
4Not used
5Not used
6Supply + Channel-1 /extern (Option)
for external sensor only
4-20 mA
7Not used
8Supply - Channel-1 /extern (Option)
9Not used
10 Not used
X113
1Not used
2Not used
3Not used
4Data Transfer RS 232 (option)
5Data Receive RS 232 (option)
6Ground RS 232 (option)
7Ground Output (-)
8Signal Output (+)
9Ground Supply (-)
10 24 VDC Supply (+)
•Plug the terminal strip onto the socket of the device.
•Put on the plastic cap and tighten. Make sure the sealing washer is correctly
positioned in the plastic cap.

MAN-SF (-BF)
page 8 MAN-SF(-BF) 01/1006
8.Operation
Functions and parameters are divided into three levels.
LEVEL 0 User Level
This level may be accessed by any user (a password is not required).
The following functions are available.
•Zero-point adjustment of the display (inPUt ↓ S-ZEro)
•Service (SErVicE)
•View serial number (SErVicE n)
•Enter master password to view the passwords
(SErVicE  MAStr) (see 10.3)
•Limit contacts (option) (rELAiS 1-4)
•Setpoint (rELAiS 1-4 SPt1-4)
•Setpoint hysteresis (rELAiS 1-4  HyS1-4)
•Delay time for setpoints (rELAiS 1-4  dEL1-4)
•Auxiliary functions (option)
•Scaling the analogue output (outZP)
•Scaling the display (diSPLAY)
•Setting the peak memory unit (Pdu)
•Setting the relay rotation (rotAtE)
•Setting the RS 232 interface (bAud)
All menu items in LEVEL 1 and LEVEL 2 (except the menu item service) can be
enabled or disabled for LEVEL 0.
LEVEL 1 Master Level
A password must be entered to access this level. All LEVEL 1 functions (for
LEVEL 0) may be enabled/disabled in this level. LEVEL 0settings may also be
assigned in LEVEL 1 (useful when LEVEL 0 is disabled).
The following functions are also available:
•Service (SErVicE)
•Displaying the dialog display in operating mode (SErVicE ↓SEE-Lcd)
•Changing the LEVEL 1 password (SErVicE  PA-1)
LEVEL 2 Auxiliary functions Level
(see section 12. Adjustment of the Additional Option)
Access to this level is via LEVEL 1 with password entry.
All optional auxiliary functions may be enabled/disabled in this level. Settings for
auxiliary functions may also be assigned in LEVEL 2 (useful when LEVEL 0 is
disabled).
The following functions are also available:
•Service (SErVicE)
•Changing the LEVEL 2 password (SErVicE  PA-2)

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 9
9.Function of Key Button
In measuring mode
•Access to user levels
In the levels
•Access to menu items
•Access to functions in menu items
•Escape from the level and return to the operating mode
In the functions
•Access to setting (right-hand digit flashes)
•Next digit with right-hand overflow
•Decrement the selected digit
•Increment the selected digit.
•Abort setting, reload old value, and return
to the selected function.
•Accept setting and select the next function
in the menu item.
Access to LEVEL 1
with password entry Function
Operating mode
LEVEL 0 Menu item Function
setting

MAN-SF (-BF)
page 10 MAN-SF(-BF) 01/1006
10. Functions Settings
Note! Each digit is individually set in the setting mode. Each digit
has a particular significance: the first digit from the right has a
significance of 1; the second digit 10; the third 100; and the leftmost
digit 1000. Please note that an overflow occurs with each digit. For
example, a pre-set value of 01.52: if the leftmost digit is
decremented with the "↓" key, the new value is -08.48, as the old
value has been reduced by 1000.
10.1. Zero-Point Adjustment of the Display
(May not be visible, if disabled in Level 1)
For correcting the zero-point. This value may be corrected up to approximately
25% of the full-scale value.

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 11
10.2. Serial Number Indications
The device serial number may be read here for service purposes; it may be read
but not altered.
10.3. Setting the Limit Contacts (optional)
(May not be visible, if disabled in Level 1)
As an option, the devices may be fitted with up to four independently adjustable
limit contacts. The following setting examples apply to relay No. 1.
Relays 2 to 4 are set in the same manner.
Select the relay menu display in Level 0. The following values may be set for
each relay:

MAN-SF (-BF)
page 12 MAN-SF(-BF) 01/1006
Switching value
Note:
When adjusting the set-points, remember that the hysteresis may be
above the new set-point, and may be enabled until the relay set-point is
accepted. The hysteresis is only loaded when accepted.
2...4 for relay 2...4

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 13
Limit-contact hysteresis
Delay time for limit contacts
Adjustable between 0.03 and 99.99 seconds.
2...4 for relay 2...4

MAN-SF (-BF)
page 14 MAN-SF(-BF) 01/1006
10.4. Access to Level 1 (Master Level)
All above menu items may be set in Level 0and Level 1, as well. This is
necessary if the menu item in Level 0has been disabled. Access to Level 1
is with password entry via Level 0. The unit automatically returns to the
operating mode after three incorrect entries. The password set at the factory
is "0001". This password may be changed by the operator (see section 11.3).

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 15
11. Enabling / Disabling the Menu Items in Level 0
11.1. Enabling/Disabling the Zero-Point Adjustment
Enter the password and go to Level 1 (see section 10.4)
11.2. Setting the user display
Enter the password and go to Level 1 (see section 10.4)
The set-points and hysteresis display in the operating mode may be set
in Level 1.
Settings:
0= Setpoint 1 and 2 are displayed beside one another
1= All set-points are alternatively displayed every 1.5 s
2= All set-points and hysteresis are alternatively displayed every 1.5 s
3= Set-point and hysteresis for relay 1 are simultaneously displayed.

MAN-SF (-BF)
page 16 MAN-SF(-BF) 01/1006
11.3. Changing the password for Level 1
Enter the password and go to Level 1 (see section 10.4)
Password factory setting is "0001"
11.4. Disabling the optional limit contacts
Enter the password and go to Level 1 (see section 10.4)
2...4 for relay 2...4

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 17
12. Adjustment of the Additional Option
All following menu items may be set in Level 2. In addition, some of the
menu points respective functions can be enabled for Level 0. Access to Level
2 is via Level 0 and Level 1 with password entry. The unit automatically
returns to the operating mode after three incorrect entries. The password for
Level 1, set at the factory, is "0001" and for Level 2 “0002”.
This password may be changed by the operator (see section 11.3).
12.1. Access to Level 2

MAN-SF (-BF)
page 18 MAN-SF(-BF) 01/1006
12.2. Adjustment of the Maximum Peak Memory (optional)
12.2.1. Reset Time of the Maximum Peak Memory (Pdut)
(Adjustable in LEVEL 2 or if enabled in LEVEL 0)
The reset time of the maximum peak memory can be adjusted with an internal
timer. Response time 1...99999 sec.
12.2.2. Specification of the Minimum or Maximum Peak Memory (PduFct)
(Adjustable in LEVEL 2 or if enabled in LEVEL 0)
In this function the maximum peak memory can be adjusted as minimum
or maximum peak memory.
Minimum peak memory = "PduFct uFL" adjust
Maximum peak memory = "PduFct oFL" adjust

MAN-SF (-BF)
MAN-SF(-BF) 01/1006 page 19
12.2.3. Initial Value for Minimum or Maximum Peak Memory
(Adjustable in LEVEL 2 or if enabled in LEVEL 0)
12.2.4. Enabling/Disable of the Menu Item in LEVEL 0 (PdurEL)
(Adjustable only in LEVEL 2)
The functions 12.1.1 to 12.1.4 can be enabled or disabled for LEVEL 0.
PdurEL on = enabling in LEVEL 0
PdurEL off = disabling in LEVEL 0

MAN-SF (-BF)
page 20 MAN-SF(-BF) 01/1006
12.2.5. Direction of Action of the Maximum Peak Memory (PduSEL)
(Adjustable only in LEVEL 2)
000 = Maximum peak memory non-active
001 = affects on display
010 = affects on the output signal
100 = affects on the relay
multiple selection is possible
e.g.: 011 = affects on display and output signal
press several times – runs through all possible options in ascending order:
001 010 011 100 101 110 111
