Kohler Courage SV470 User manual

1
20 690 01 Rev. F KohlerEngines.com
SV470-SV620
Service Manual
2 Safety
3 Maintenance
5 Specifications
13 Tools and Aids
16 Troubleshooting
20 Air Cleaner/Intake
21 Fuel System
31 Governor System
33 Lubrication System
35 Electrical System
44 Starter System
47 Emission Compliant Systems
50 Disassembly/Inspection and Service
63 Reassembly
IMPORTANT: Read all safety precautions and instructions carefully before operating equipment. Refer to operating
instruction of equipment that this engine powers.
Ensure engine is stopped and level before performing any maintenance or service.

2
Safety
KohlerEngines.com 20 690 01 Rev. F
SAFETY PRECAUTIONS
WARNING: A hazard that could result in death, serious injury, or substantial property damage.
CAUTION: A hazard that could result in minor personal injury or property damage.
NOTE: is used to notify people of important installation, operation, or maintenance information.
WARNING
Explosive Fuel can cause
fires and severe burns.
Do not fill fuel tank while
engine is hot or running.
Gasoline is extremely flammable
and its vapors can explode if
ignited. Store gasoline only in
approved containers, in well
ventilated, unoccupied buildings,
away from sparks or flames.
Spilled fuel could ignite if it comes
in contact with hot parts or sparks
from ignition. Never use gasoline
as a cleaning agent.
WARNING
Rotating Parts can cause
severe injury.
Stay away while engine
is in operation.
Keep hands, feet, hair, and
clothing away from all moving
parts to prevent injury. Never
operate engine with covers,
shrouds, or guards removed.
WARNING
Carbon Monoxide can
cause severe nausea,
fainting or death.
Avoid inhaling exhaust
fumes.
Engine exhaust gases contain
poisonous carbon monoxide.
Carbon monoxide is odorless,
colorless, and can cause death if
inhaled.
WARNING
Accidental Starts can
cause severe injury or
death.
Disconnect and ground
spark plug lead(s) before
servicing.
Before working on engine or
equipment, disable engine as
follows: 1) Disconnect spark plug
lead(s). 2) Disconnect negative (–)
battery cable from battery.
WARNING
Hot Parts can cause
severe burns.
Do not touch engine
while operating or just
after stopping.
Never operate engine with heat
shields or guards removed.
WARNING
Cleaning Solvents can
cause severe injury or
death.
Use only in well
ventilated areas away
from ignition sources.
Carburetor cleaners and solvents
are extremely flammable. Follow
cleaner manufacturer’s warnings
and instructions on its proper and
safe use. Never use gasoline as a
cleaning agent.
CAUTION
Electrical Shock can
cause injury.
Do not touch wires while
engine is running.
CAUTION
Damaging Crankshaft
and Flywheel can cause
personal injury.
Using improper procedures can
lead to broken fragments. Broken
fragments could be thrown from
engine. Always observe and use
precautions and procedures when
installing flywheel.

3
Maintenance
20 690 01 Rev. F KohlerEngines.com
MAINTENANCE INSTRUCTIONS
WARNING
Before working on engine or equipment, disable engine as
follows: 1) Disconnect spark plug lead(s). 2) Disconnect
negative (–) battery cable from battery.
Accidental Starts can cause severe injury or
death.
Disconnect and ground spark plug lead(s)
before servicing.
Normal maintenance, replacement or repair of emission control devices and systems may be performed by any repair
establishment or individual; however, warranty repairs must be performed by a Kohler authorized dealer.
MAINTENANCE SCHEDULE
Every 25 Hours or Annually¹
●Service/replace low-profile precleaner. Air Cleaner/Intake
●Replace air cleaner element (if not equipped with precleaner). Air Cleaner/Intake
Every 100 Hours or Annually¹
●Replace air cleaner element (if not equipped with precleaner). Air Cleaner/Intake
●Change oil and filter. Lubrication System
●Remove cooling shrouds and clean cooling areas. Air Cleaner/Intake
Every 100 Hours
●Replace fuel filter.
●Check that all fasteners are in place and components are properly secured. Reassembly
Every 200 Hours²
●Have valve lash checked/adjusted. Reassembly
Every 500 Hours
●Replace spark plug and set gap. Electrical System
1Perform these procedures more frequently under severe, dusty, dirty conditions.
2Have a Kohler authorized dealer perform this service.
REPAIRS/SERVICE PARTS
Kohler genuine service parts can be purchased from Kohler authorized dealers. To find a local Kohler authorized
dealer visit KohlerEngines.com or call 1-800-544-2444 (U.S. and Canada).

4
Maintenance
KohlerEngines.com 20 690 01 Rev. F
OIL RECOMMENDATIONS
We recommend use of Kohler oils for best performance.
Other high-quality detergent oils (including synthetic)
of API (American Petroleum Institute) service class SJ
or higher are acceptable. Select viscosity based on
air temperature at time of operation as shown in table
below.
FUEL RECOMMENDATIONS
WARNING
Explosive Fuel can cause fires and severe
burns.
Do not fill fuel tank while engine is hot or
running.
Gasoline is extremely flammable and its vapors can
explode if ignited. Store gasoline only in approved
containers, in well ventilated, unoccupied buildings,
away from sparks or flames. Spilled fuel could ignite
if it comes in contact with hot parts or sparks from
ignition. Never use gasoline as a cleaning agent.
NOTE: E15, E20 and E85 are NOT approved and
should NOT be used; effects of old, stale or
contaminated fuel are not warrantable.
Fuel must meet these requirements:
●Clean, fresh, unleaded gasoline.
●Octane rating of 87 (R+M)/2 or higher.
●Research Octane Number (RON) 90 octane minimum.
●Gasoline up to 10% ethyl alcohol, 90% unleaded is
acceptable.
●Methyl Tertiary Butyl Ether (MTBE) and unleaded
gasoline blend (max 15% MTBE by volume) are
approved.
●Do not add oil to gasoline.
●Do not overfill fuel tank.
●Do not use gasoline older than 30 days.
STORAGE
If engine will be out of service for 2 months or more
follow procedure below.
1. Add Kohler PRO Series fuel treatment or equivalent
to fuel tank. Run engine 2-3 minutes to get stabilized
fuel into carburetor (failures due to untreated fuel are
not warrantable).
2. Change oil while engine is still warm from operation.
Remove spark plug(s) and pour about 1 oz. of
engine oil into cylinder(s). Replace spark plug(s) and
crank engine slowly to distribute oil.
3. Disconnect negative (-) battery cable.
4. Store engine in a clean, dry place.

5
Specifications
20 690 01 Rev. F KohlerEngines.com
Dimensions in millimeters.
Inch equivalents shown in [ ].
Engine Dimensions

6
Specifications
KohlerEngines.com 20 690 01 Rev. F
Model. . . . . . . . . . . . . . . . . . . . . SV470
Courage Engine
Vertical Shaft
Numerical Designation
Specification . . . . . . . . . . . . . . . SV470-0001
Serial . . . . . . . . . . . . . . . . . . . . . 3923500328
Year Manufactured Code Factory Code
Code Year
39 2009
40 2010
41 2011
ENGINE IDENTIFICATION NUMBERS
Kohler engine identification numbers (model, specification and serial) should be referenced for efficient repair,
ordering correct parts, and engine replacement.
GENERAL SPECIFICATIONS3.6 SV470-SV480 SV530-SV540 SV590-SV620
Bore
Spec. 00XX:
Spec. 01XX:
Spec. 02XX or higher:
---
84 mm (3.30 in.)
89 mm (3.50 in.)
94 mm (3.70 in.)
---
89 mm (3.50 in.)
---
94 mm (3.70 in.)
94 mm (3.70 in.)
---
---
---
Stroke 86 mm (3.38 in.)
Displacement
Spec. 00XX:
Spec. 01XX:
Spec. 02XX or higher:
---
477 cc (29.1 cu. in.)
535 cc (32.6 cu. in.)
597 cc (36.4 cu. in.)
---
535 cc (32.6 cu. in.)
---
597 cc (36.4 cu. in.)
597 cc (36.4 cu. in.)
---
---
---
Oil Capacity (refill) 1.04-1.30 L (1.1-1.4 qt.)
Maximum Angle of Operation (@ full oil level)425°
TORQUE SPECIFICATIONS3,5 SV470-SV480 SV530-SV540 SV590-SV620
Air Cleaner Base
Hex Nut Fastener 5.5 N·m (48 in. lb.)
Mounting Screw Fastener (install dry) 8.0 N·m (70 in. lb.) into new hole
5.5 N·m (48 in. lb.) into used hole
Balance Weight
Screw 10.9-13.2 N·m (95.0-115.0 in. lb.)
Blower Housing and Sheet Metal
M6 Fastener 11.6 N·m (99 in. lb.) into new hole
7.7 N·m (68 in. lb.) into used hole
Cam Lever
Fastener 8.0-10.5 N·m (70-94.0 in. lb.) into new hole
7.1-8.6 N·m (61.8-74.8 in. lb.) into used hole
3 Values are in Metric units. Values in parentheses are English equivalents.
4Exceeding maximum angle of operation may cause engine damage from insufficient lubrication.
5Lubricate threads with engine oil prior to assembly.
6Any and all horsepower (hp) references by Kohler are Certified Power Ratings and per SAE J1940 & J1995 hp
standards. Details on Certified Power Ratings can be found at KohlerEngines.com.

7
Specifications
20 690 01 Rev. F KohlerEngines.com
TORQUE SPECIFICATIONS3,5 SV470-SV480 SV530-SV540 SV590-SV620
Carburetor
Fuel Bowl Retaining Screw
Walbro
Nikki
5.1-6.2 N·m (45-55 in. lb.)
10.8-12.8 N·m (96-113 in. lb.)
Closure Plate
Fastener 24.5 N·m (216 in. lb.)
Connecting Rod
Cap Fastener (torque in 2 increments) 5.5, 11.5 N·m (50, 100 in. lb.)
Crankcase
Oil Drain Plug 14.0 N·m (125 in. lb.)
Cylinder Head
Fastener (torque in 2 increments) 20.5, 41.0 N·m (180, 360 in. lb.)
Rocker Arm Pivot Stud 13.5 N·m (120 in. lb.)
Rocker Arm Adjustment Nut Set Screw 5.5 N·m (50 in. lb.)
Electric Starter
Thru Bolt 3.3-3.9 N·m (30-35 in. lb.)
Mounting Nut 3.6 N·m (32 in. lb.)
Nut (top) Positive (+) Brush Lead Terminal 1.6-2.8 N·m (15-25 in. lb.)
Nut (flange) Positive (+) Brush Lead Terminal 2.2-4.5 N·m (20-40 in. lb.)
Flywheel
M12 Retaining Screw 88.0 N·m (65 ft. lb.)
M10 Retaining Screw 66.5 N·m (49 ft. lb.)
Governor
Lever Nut 7.0-8.5 N·m (60-75 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Module Fastener 6.0 N·m (55 in. lb.) into new hole
4.0 N·m (35 in. lb.) into used hole
Rectifier-Regulator Fastener 6.0 N·m (55 in. lb.) into new hole
4.0 N·m (35 in. lb.) into used hole
Muffler
Retaining Nuts 24.4 N·m (216 in. lb.)
Oil Filter Pad Pipe Plug
1/8” N.P.T.F. 4.5-5.0 N·m (40-46 in. lb.)
Oil Pump
Mounting Screw 5.0-7.5 N·m (44.4-66.0 in. lb.) into new hole
3.8-4.6 N·m (33.3-40.3 in. lb.) into used hole
Oil Sentry™
Pressure Switch 4.5-5.0 N·m (40-45 in. lb.)
3 Values are in Metric units. Values in parentheses are English equivalents.
5Lubricate threads with engine oil prior to assembly.

8
Specifications
KohlerEngines.com 20 690 01 Rev. F
TORQUE SPECIFICATIONS3,5 SV470-SV480 SV530-SV540 SV590-SV620
Speed Control
Bracket Assembly Fastener 11.0 N·m (95 in. lb.) into new hole
7.5 N·m (65 in. lb.) into used hole
Stator
Mounting Screw 6.0 N·m (55 in. lb.) into new hole
4.0 N·m (35 in. lb.) into used hole
Valve Cover
Fastener 11.0 N·m (95 in. lb.) into new hole
7.5 N·m (65 in. lb.) into used hole
CLEARANCE SPECIFICATIONS3SV470-SV480 SV530-SV540 SV590-SV620
Balance Weight
Bearing Surface I.D.
New
Max. Wear Limit
67.011/67.086 mm (2.6382/2.6412 in.)
67.140 mm (2.6430 in.)
Pin O.D.
New
Max. Wear Limit
11.950/11.975 mm (0.4705/0.4715 in.)
11.900 mm (0.4685 in.)
Guide Shoe Width
New
Max. Wear Limit
17.85/17.90 mm (0.703/0.705 in.)
17.75 mm (0.6988 in.)
Guide Shoe Hole I.D.-First Generation Balance
Weight
New
Max. Wear Limit
12.000/12.025 mm (0.4724/0.4734 in.)
12.050 mm (0.4744 in.)
Linkage Pin O.D. (Crankcase)-Second Generation
Balance Weight
New
Max. Wear Limit
11.964/11.975 mm (0.4710/0.4715 in.)
11.900 mm (0.4685 in.)
Balance Weight Linkage-Second Generation
Balance Weight
New
Max. Wear Limit
11.985/12.010 mm (0.4719/0.4728 in.)
12.035 mm (0.4738 in.)
Cam Gears
End Play 0.5/1.5 mm (0.019/0.059 in.)
Running Side Clearance 0.02/0.13 mm (0.001/0.005 in.)
Cam Gear-to-Cam Shaft Running Assembly 0.02/0.10 mm (0.001/0.004 in.)
Closure Plate
Balance Weight Guide Channel Width
New
Max. Wear Limit
17.95/18.05 mm (0.707/0.711 in.)
18.13 mm (0.714 in.)
Connecting Rod
Connecting Rod-to-Crankpin Running Clearance
New
Max. Wear Limit
0.03/0.055 mm (0.0012/0.0022 in.)
0.07 mm (0.0025 in.)
Connecting Rod-to-Crankpin Side Clearance 0.25/0.59 mm (0.0098/0.0232 in.)
Connecting Rod-to-Piston Pin Running Clearance 0.015/0.028 mm (0.0006/0.0011 in.)
3 Values are in Metric units. Values in parentheses are English equivalents.
5Lubricate threads with engine oil prior to assembly.

9
Specifications
20 690 01 Rev. F KohlerEngines.com
CLEARANCE SPECIFICATIONS3SV470-SV480 SV530-SV540 SV590-SV620
Crankcase
Governor Cross Shaft Bore I.D.
New
Max. Wear Limit
6.025/6.05 mm (0.2372/0.2382 in.)
6.063 mm (0.2387 in.)
Crankshaft
End Play (free) 0.225/1.025 mm (0.0089/0.040 in.)
Bore in Crankcase I.D.
New
Max. Wear Limit
41.965/41.990 mm (1.6521/1.6531 in.)
42.016 mm (1.654 in.)
Bore in Closure Plate I.D.
New
Max. Wear Limit
44.965/44.990 mm (1.7703/1.7713 in.)
45.016 mm (1.7723 in.)
Flywheel End Main Bearing Journal O.D.
New, Before Serial No. 3703200003
New, After Serial No. 3703200013
O.D., Max. Wear Limit
Max. Taper
Max. Out of Round
44.913/44.935 mm (1.7682/1.7691 in.)
44.870/44.895 mm (1.7665/1.7675 in.)
44.84 mm (1.765 in.)
0.0220 mm (0.0009 in.)
0.025 mm (0.001 in.)
PTO End Main Bearing Journal O.D.
New, Before Serial No. 3703200003
New, After Serial No. 3703200013
O.D., Max. Wear Limit
Max. Taper
Max. Out of Round
41.913/41.935 mm (1.6501/1.6510 in.)
41.855/41.880 mm (1.6478/1.6488 in.)
41.83 mm (1.647 in.)
0.020 mm (0.0008 in.)
0.025 mm (0.001 in.)
Bore in Closure Plate Running Clearance
New, Before Serial No. 3703200003
New, After Serial No. 3703200013
0.030/0.077 mm (0.0012/0.0030 in.)
0.070/0.120 mm (0.0027/0.0047 in.)
Bore in Crankcase Running Clearance
New, Before Serial No. 3703200003
New, After Serial No. 3703200013
0.030/0.077 mm (0.0012/0.0030 in.)
0.085/0.135 mm (0.0033/0.0053 in.)
Connecting Rod Journal O.D.
New
Max. Wear Limit
Max. Taper
Max. Out of Round
40.982/41.000 mm (1.6134/1.6141 in.)
40.964 mm (1.612 in.)
0.012 mm (0.0005 in.)
0.025 mm (0.001 in.)
T.I.R.
PTO End, Crankshaft in Engine
Entire Crankshaft , in V-Blocks
0.15 mm (0.0059 in.)
0.10 mm (0.0039 in.)
Eccentrics O.D.
New
Max. Wear Limit
66.940/66.970 mm (2.6354/2.6366 in.)
66.89 mm (2.633 in.)
3 Values are in Metric units. Values in parentheses are English equivalents.

10
Specifications
KohlerEngines.com 20 690 01 Rev. F
CLEARANCE SPECIFICATIONS3SV470-SV480 SV530-SV540 SV590-SV620
Cylinder Bore
Cylinder Bore I.D.
New
--- --- 94.010/94.035 mm
(3.701/3.702 in.)
Spec. 00XX: 84.010/84.035 mm
(3.307/3.308 in.)
89.010/89.035 mm
(3.504/3.505 in.)
---
Spec. 01XX: 89.010/89.035 mm
(3.504/3.505 in.)
--- ---
Spec. 02XX or higher: 94.010/94.035 mm
(3.701/3.702 in.)
94.010/94.035 mm
(3.701/3.702 in.)
---
Max. Wear Limit --- --- 94.073 mm
(3.704 in.)
Spec. 00XX: 84.073 mm
(3.310 in.)
89.073 mm
(3.507 in.)
---
Spec. 01XX: 89.073 mm
(3.507 in.)
--- ---
Spec. 02XX or higher: 94.073 mm
(3.704 in.)
94.073 mm
(3.704 in.)
---
Max. Taper
Max. Out of Round
0.05 mm (0.002 in.)
0.12 mm (0.0047 in.)
Cylinder Head
Max. Out-of-Flatness 0.8 mm (0.003 in.)
Governor
Governor Cross Shaft -to-Crankcase Running
Clearance
0.013/0.075 mm (0.0005/0.003 in.)
Cross Shaft O.D.
New
Max. Wear Limit
5.975/6.012 mm (0.2352/0.2367 in.)
5.962 mm (0.2347 in.)
Governor Gear Shaft -to-Governor Gear Running
Clearance
0.09/0.16 mm (0.0035/0.0063 in.)
Gear Shaft O.D.
New
Max. Wear Limit
5.99/6.00 mm (0.2358/0.2362 in.)
5.977 mm (0.02353 in.)
Ignition
Spark Plug Gap 0.76 mm (0.030 in.)
Module Air Gap 0.203/0.305 mm (0.008/0.012 in.)
Oil Pump
Pump Gears-to-Crankcase Side Clearance 0.165/0.315 mm (0.0065/0.0124 in.)
Piston, Piston Rings, and Piston Pin
Pin Bore I.D.
New
Max. Wear Limit
22.006/22.012 mm (0.8685/0.8666 in.)
22.025 mm (0.8671 in.)
Pin O.D.
New
Max. Wear Limit
21.995/22.0 mm (0.8659/0.8661 in.)
21.994 mm (0.8658 in.)
Top Compression Ring-to-Groove Side Clearance 0.04 mm (0.0016 in.)
Middle Compression Ring-to-Groove Side
Clearance
0.04 mm (0.0016 in.)
3 Values are in Metric units. Values in parentheses are English equivalents.

11
Specifications
20 690 01 Rev. F KohlerEngines.com
CLEARANCE SPECIFICATIONS3SV470-SV480 SV530-SV540 SV590-SV620
Piston, Piston Rings, and Piston Pin (Continued)
Top and Middle Compression Ring End Gap New
Bore
Top Ring
Middle Ring
Used Bore (max.)
0.15/0.40 mm (0.006/0.016 in.)
0.30/0.55 mm (0.012/0.022 in.)
0.77 mm (0.030 in.)
Thrust Face O.D.7
New
--- --- 93.928/93.942 mm
(3.6980/3.6985 in.)
Spec. 00XX: 83.948/83.962 mm
(3.3050/3.3056 in.)
88.948/88.962 mm
(3.5018/3.5024 in.)
---
Spec. 01XX: 88.948/88.962 mm
(3.5018/3.5024 in.)
--- ---
Spec. 02XX or higher: 93.928/93.942 mm
(3.6980/3.6985 in.)
93.928/93.942 mm
(3.6980/3.6985 in.)
---
Max. Wear Limit --- --- 93.828 mm
(3.6940 in.)
Spec. 00XX: 83.828 mm
(3.3003 in.)
88.828 mm
(3.4972 in.)
---
Spec. 01XX: 88.828 mm
(3.4972 in.)
--- ---
Spec. 02XX or higher: 93.828 mm
(3.6940 in.)
93.828 mm
(3.6940 in.)
---
Piston Thrust Face-to-Cylinder Bore7Running
Clearance
0.045 mm (0.0018 in.) 0.0880 mm
(0.0035 in.)
Valves and Valve Lifters
Intake Valve Lash80.127 mm (0.005 in.)
Exhaust Valve Lash80.178 mm (0.007 in.)
Intake Valve Minimum Lift 8.9 mm (0.350 in.)
Exhaust Valve Minimum Lift 8.9 mm (0.350 in.)
Nominal Valve Seat Angle 45°
Intake Valve Stem-to-Valve Guide Running
Clearance
0.038/0.076 mm (0.0015/0.003 in.)
Exhaust Valve Stem-to-Valve Guide Running
Clearance
0.050/0.088 mm (0.0020/0.0035 in.)
Intake Valve Guide I.D.
New
Max. Wear Limit
6.038/6.058 mm (0.2377/0.2385 in.)
6.135 mm (0.2415 in.)
Intake Valve Stem Diameter
New 5.982/6.0 mm (0.2355/0.2362 in.)
Exhaust Valve Guide I.D.
New
Max. Wear Limit
6.038/6.058 mm (0.2377/0.2385 in.)
6.160 mm (0.2425 in.)
Exhaust Valve Stem Diameter
New 5.970/5.988 mm (0.235/0.2357 in.)
3 Values are in Metric units. Values in parentheses are English equivalents.
7 Measure 8 mm (0.314 in.) above bottom of piston skirt at right angles to piston pin.
8Check valve lash every 200 hours, adjust as required.

12
Specifications
KohlerEngines.com 20 690 01 Rev. F
GENERAL TORQUE VALUES
Metric Fastener Torque Recommendations for Standard Applications
Property Class Noncritical
Fasteners
Into Aluminum
Size 4.8 5.8 8.8 10.9 12.9
Tightening Torque: N·m (in. lb.) ± 10%
M4 1.2 (11) 1.7 (15) 2.9 (26) 4.1 (36) 5.0 (44) 2.0 (18)
M5 2.5 (22) 3.2 (28) 5.8 (51) 8.1 (72) 9.7 (86) 4.0 (35)
M6 4.3 (38) 5.7 (50) 9.9 (88) 14.0 (124) 16.5 (146) 6.8 (60)
M8 10.5 (93) 13.6 (120) 24.4 (216) 33.9 (300) 40.7 (360) 17.0 (150)
Tightening Torque: N·m (ft. lb.) ± 10%
M10 21.7 (16) 27.1 (20) 47.5 (35) 66.4 (49) 81.4 (60) 33.9 (25)
M12 36.6 (27) 47.5 (35) 82.7 (61) 116.6 (86) 139.7 (103) 61.0 (45)
M14 58.3 (43) 76.4 (56) 131.5 (97) 184.4 (136) 219.7 (162) 94.9 (70)
Torque Conversions
N·m = in. lb. x 0.113 in. lb. = N·m x 8.85
N·m = ft. lb. x 1.356 ft. lb. = N·m x 0.737
English Fastener Torque Recommendations for Standard Applications
Bolts, Screws, Nuts and Fasteners Assembled Into Cast Iron or Steel Grade 2 or 5 Fasteners
Into Aluminum
Size Grade 2 Grade 5 Grade 8
Tightening Torque: N·m (in. lb.) ± 20%
8-32 2.3 (20) 2.8 (25) — 2.3 (20)
10-24 3.6 (32) 4.5 (40) — 3.6 (32)
10-32 3.6 (32) 4.5 (40) — —
1/4-20 7.9 (70) 13.0 (115) 18.7 (165) 7.9 (70)
1/4-28 9.6 (85) 15.8 (140) 22.6 (200) —
5/16-18 17.0 (150) 28.3 (250) 39.6 (350) 17.0 (150)
5/16-24 18.7 (165) 30.5 (270) — —
3/8-16 29.4 (260) — — —
3/8-24 33.9 (300) — — —
Tightening Torque: N·m (ft. lb.) ± 20%
5/16-24 — — 40.7 (30) —
3/8-16 — 47.5 (35) 67.8 (50) —
3/8-24 — 54.2 (40) 81.4 (60) —
7/16-14 47.5 (35) 74.6 (55) 108.5 (80) —
7/16-20 61.0 (45) 101.7 (75) 142.5 (105) —
1/2-13 67.8 (50) 108.5 (80) 155.9 (115) —
1/2-20 94.9 (70) 142.4 (105) 223.7 (165) —
9/16-12 101.7 (75) 169.5 (125) 237.3 (175) —
9/16-18 135.6 (100) 223.7 (165) 311.9 (230) —
5/8-11 149.5 (110) 244.1 (180) 352.6 (260) —
5/8-18 189.8 (140) 311.9 (230) 447.5 (330) —
3/4-10 199.3 (147) 332.2 (245) 474.6 (350) —
3/4-16 271.2 (200) 440.7 (325) 637.3 (470) —

Tools and Aids
1320 690 01 Rev. F KohlerEngines.com
Certain quality tools are designed to help you perform specific disassembly, repair, and reassembly procedures. By
using these tools, you can properly service engines easier, faster, and safer! In addition, you’ll increase your service
capabilities and customer satisfaction by decreasing engine downtime.
Here is a list of tools and their source.
SEPARATE TOOL SUPPLIERS
Kohler Tools
Contact your local Kohler source of
supply.
SE Tools
415 Howard St.
Lapeer, MI 48446
Phone [phone]
Toll Free 800-664-2981
Fax [phone]
Design Technology Inc.
768 Burr Oak Drive
Westmont, IL 60559
Phone [phone]
Fax [phone]
TOOLS
Description Source/Part No.
Alcohol Content Tester
For testing alcohol content (%) in reformulated/oxygenated fuels.
Kohler 25 455 11-S
Camshaft Endplay Plate
For checking camshaft endplay.
SE Tools KLR-82405
Camshaft Seal Protector (Aegis)
For protecting seal during camshaft installation.
SE Tools KLR-82417
Cylinder Leakdown Tester
For checking combustion retention and if cylinder, piston, rings, or valves are worn.
Individual component available:
Adapter 12 mm x 14 mm (Required for leakdown test on XT-6 engines)
Kohler 25 761 05-S
Design Technology Inc.
DTI-731-03
Dealer Tool Kit (Domestic)
Complete kit of Kohler required tools.
Components of 25 761 39-S
Ignition System Tester
Cylinder Leakdown Tester
Oil Pressure Test Kit
Rectifier-Regulator Tester (120 V AC/60Hz)
Kohler 25 761 39-S
Kohler 25 455 01-S
Kohler 25 761 05-S
Kohler 25 761 06-S
Kohler 25 761 20-S
Dealer Tool Kit (International)
Complete kit of Kohler required tools.
Components of 25 761 42-S
Ignition System Tester
Cylinder Leakdown Tester
Oil Pressure Test Kit
Rectifier-Regulator Tester (240 V AC/50Hz)
Kohler 25 761 42-S
Kohler 25 455 01-S
Kohler 25 761 05-S
Kohler 25 761 06-S
Kohler 25 761 41-S
Digital Vacuum/Pressure Tester
For checking crankcase vacuum.
Individual component available:
Rubber Adapter Plug
Design Technology Inc.
DTI-721-01
Design Technology Inc.
DTI-721-10
Electronic Fuel Injection (EFI) Diagnostic Software
For Laptop or Desktop PC.
Kohler 25 761 23-S
EFI Service Kit
For troubleshooting and setting up an EFI engine.
Components of 24 761 01-S
Fuel Pressure Tester
Noid Light
90° Adapter
In-line "T" Fitting
Code Plug, Red Wire
Code Plug, Blue Wire
Shrader Valve Adapter Hose
Kohler 24 761 01-S
Design Technology Inc.
DTI-019
DTI-021
DTI-023
DTI-035
DTI-027
DTI-029
DTI-037
Flywheel Holding Tool (CS)
For holding flywheel of CS series engines.
SE Tools KLR-82407
Flywheel Puller
For properly removing flywheel from engine.
SE Tools KLR-82408
Flywheel Strap Wrench
For holding flywheel during removal.
SE Tools KLR-82409

Tools and Aids
14 20 690 01 Rev. FKohlerEngines.com
TOOLS
Description Source/Part No.
Hydraulic Valve Lifter Tool
For removing and installing hydraulic lifters.
Kohler 25 761 38-S
Ignition System Tester
For testing output on all systems, including CD.
Kohler 25 455 01-S
Inductive Tachometer (Digital)
For checking operating speed (RPM) of an engine.
Design Technology Inc.
DTI-110
Offset Wrench (K and M Series)
For removing and reinstalling cylinder barrel retaining nuts.
Kohler 52 455 04-S
Oil Pressure Test Kit
For testing/verifying oil pressure on pressure lubricated engines.
Kohler 25 761 06-S
Radiator Tester
For pressure testing radiator and cap on Aegis liquid-cooled engines.
Kohler 25 455 10-S
Rectifier-Regulator Tester (120 volt current)
Rectifier-Regulator Tester (240 volt current)
For testing rectifier-regulators.
Components of 25 761 20-S and 25 761 41-S
CS-PRO Regulator Test Harness
Special Regulator Test Harness with Diode
Kohler 25 761 20-S
Kohler 25 761 41-S
Design Technology Inc.
DTI-031
DTI-033
Spark Advance Module (SAM) Tester
For testing SAM (ASAM and DSAM) on engines with SMART-SPARK™.
Kohler 25 761 40-S
Starter Servicing Kit (All Starters)
For removing and reinstalling drive retaining rings and brushes.
Individual component available:
Starter Brush Holding Tool (Solenoid Shift)
SE Tools KLR-82411
SE Tools KLR-82416
Triad/OHC Timing Tool Set
For holding cam gears and crankshaft in timed position while installing timing belt.
Kohler 28 761 01-S
Valve Guide Reamer (K and M Series)
For properly sizing valve guides after installation.
Design Technology Inc.
DTI-K828
Valve Guide Reamer O.S. (Command Series)
For reaming worn valve guides to accept replacement oversize valves. Can be used
in low-speed drill press or with handle below for hand reaming.
Kohler 25 455 12-S
Reamer Handle
For hand reaming using Kohler 25 455 12-S reamer.
Design Technology Inc.
DTI-K830
Valve Guide Service Kit (Courage, Aegis, Command, OHC)
For servicing worn valve guides.
SE Tools KLR-82415
AIDS
Description Source/Part No.
Camshaft Lubricant (Valspar ZZ613) Kohler 25 357 14-S
Dielectric Grease (GE/Novaguard G661) Kohler 25 357 11-S
Dielectric Grease Loctite®51360
Kohler Electric Starter Drive Lubricant (Inertia Drive) Kohler 52 357 01-S
Kohler Electric Starter Drive Lubricant (Solenoid Shift) Kohler 52 357 02-S
RTV Silicone Sealant
Loctite®5900®Heavy Body in 4 oz. aerosol dispenser.
Only oxime-based, oil resistant RTV sealants, such as those listed, are approved
for use. Loctite®Nos. 5900®or 5910®are recommended for best sealing
characteristics.
Kohler 25 597 07-S
Loctite®5910®
Loctite®Ultra Black 598™
Loctite®Ultra Blue 587™
Loctite®Ultra Copper 5920™
Spline Drive Lubricant Kohler 25 357 12-S

Tools and Aids
1520 690 01 Rev. F KohlerEngines.com
FLYWHEEL HOLDING TOOL ROCKER ARM/CRANKSHAFT TOOL
A flywheel holding tool can be made out of an old junk
flywheel ring gear and used in place of a strap wrench.
1. Using an abrasive cut-off wheel, cut out a six tooth
segment of ring gear as shown.
2. Grind off any burrs or sharp edges.
3. Invert segment and place it between ignition bosses
on crankcase so tool teeth engage flywheel ring
gear teeth. Bosses will lock tool and flywheel in
position for loosening, tightening, or removing with a
puller.
A spanner wrench to lift rocker arms or turn crankshaft
may be made out of an old junk connecting rod.
1. Find a used connecting rod from a 10 HP or larger
engine. Remove and discard rod cap.
2. Remove studs of a Posi-Lock rod or grind off
aligning steps of a Command rod, so joint surface is
flat.
3. Find a 1 in. long capscrew with correct thread size to
match threads in connecting rod.
4. Use a flat washer with correct I.D. to slip on
capscrew and approximately 1 in. O.D. Assemble
capscrew and washer to joint surface of rod.

Troubleshooting
16 20 690 01 Rev. FKohlerEngines.com
Engine Cranks But Will Not Start
●Battery connected backwards.
●Blown fuse.
●Carburetor solenoid malfunction.
●Choke not closing.
●Clogged fuel line or fuel filter.
●Diode in wiring harness failed in open circuit mode.
●DSAI or DSAM malfunction.
●Empty fuel tank.
●Faulty electronic control unit.
●Faulty ignition coil(s).
●Faulty spark plug(s).
●Fuel pump malfunction-vacuum hose clogged or
leaking.
●Fuel shut-off valve closed.
●Ignition module(s) faulty or improperly gapped.
●Insufficient voltage to electronic control unit.
●Interlock switch is engaged or faulty.
●Key switch or kill switch in OFF position.
●Low oil level.
●Quality of fuel (dirt, water, stale, mixture).
●SMART-SPARKTM malfunction.
●Spark plug lead(s) disconnected.
Engine Starts But Does Not Keep Running
●Faulty carburetor.
●Faulty cylinder head gasket.
●Faulty or misadjusted choke or throttle controls.
●Fuel pump malfunction-vacuum hose clogged or
leaking.
●Intake system leak.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Quality of fuel (dirt, water, stale, mixture).
●Restricted fuel tank cap vent.
Engine Starts Hard
●Clogged fuel line or fuel filter.
●Engine overheated.
●Faulty ACR mechanism.
●Faulty or misadjusted choke or throttle controls.
●Faulty spark plug(s).
●Flywheel key sheared.
●Fuel pump malfunction-vacuum hose clogged or
leaking.
●Interlock switch is engaged or faulty.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Low compression.
●Quality of fuel (dirt, water, stale, mixture).
●Weak spark.
TROUBLESHOOTING GUIDE
When troubles occur, be sure to check simple causes which, at first, may seem too obvious to be considered. For
example, a starting problem could be caused by an empty fuel tank.
Some general common causes of engine troubles are listed below and vary by engine specification. Use these to
locate causing factors.
Engine Will Not Crank
●Battery is discharged.
●Faulty electric starter or solenoid.
●Faulty key switch or ignition switch.
●Interlock switch is engaged or faulty.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Pawls not engaging in drive cup.
●Seized internal engine components.
Engine Runs But Misses
●Carburetor adjusted incorrectly.
●Engine overheated.
●Faulty spark plug(s).
●Ignition module(s) faulty or improperly gapped.
●Incorrect crankshaft position sensor air gap.
●Interlock switch is engaged or faulty.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Quality of fuel (dirt, water, stale, mixture).
●Spark plug lead(s) disconnected.
●Spark plug lead boot loose on plug.
●Spark plug lead loose.
Engine Will Not Idle
●Engine overheated.
●Faulty spark plug(s).
●Idle fuel adjusting needle(s) improperly set.
●Idle speed adjusting screw improperly set.
●Inadequate fuel supply.
●Low compression.
●Quality of fuel (dirt, water, stale, mixture).
●Restricted fuel tank cap vent.
Engine Overheats
●Cooling fan broken.
●Excessive engine load.
●Fan belt failed/off.
●Faulty carburetor.
●High crankcase oil level.
●Lean fuel mixture.
●Low cooling system fluid level.
●Low crankcase oil level.
●Radiator, and/or cooling system components clogged,
restricted, or leaking.
●Water pump belt failed/broken.
●Water pump malfunction.
Engine Knocks
●Excessive engine load.
●Hydraulic lifter malfunction.
●Incorrect oil viscosity/type.
●Internal wear or damage.
●Low crankcase oil level.
●Quality of fuel (dirt, water, stale, mixture).

1720 690 01 Rev. F KohlerEngines.com
Troubleshooting
Engine Loses Power
●Dirty air cleaner element.
●Engine overheated.
●Excessive engine load.
●Restricted exhaust.
●Faulty spark plug(s).
●High crankcase oil level.
●Incorrect governor setting.
●Low battery.
●Low compression.
●Low crankcase oil level.
●Quality of fuel (dirt, water, stale, mixture).
Engine Uses Excessive Amount of Oil
●Loose or improperly torqued fasteners.
●Blown head gasket/overheated.
●Breather reed broken.
●Clogged, broken, or inoperative crankcase breather.
●Crankcase overfilled.
●Incorrect oil viscosity/type.
●Worn cylinder bore.
●Worn or broken piston rings.
●Worn valve stems/valve guides.
Oil Leaks from Oil Seals, Gaskets
●Breather reed broken.
●Clogged, broken, or inoperative crankcase breather.
●Loose or improperly torqued fasteners.
●Piston blow by, or leaky valves.
●Restricted exhaust.
EXTERNAL ENGINE INSPECTION
NOTE: It is good practice to drain oil at a location away
from workbench. Be sure to allow ample time for
complete drainage.
Before cleaning or disassembling engine, make a
thorough inspection of its external appearance and
condition. This inspection can give clues to what
might be found inside engines (and cause) when it is
disassembled.
●Check for buildup of dirt and debris on crankcase,
cooling fins, grass screen, and other external surfaces.
Dirt or debris on these areas can cause overheating.
●Check for obvious fuel and oil leaks, and damaged
components. Excessive oil leakage can indicate a
clogged or inoperative breather, worn or damaged
seals or gaskets, or loose fasteners.
●Check air cleaner cover and base for damage or
indications of improper fit and seal.
●Check air cleaner element. Look for holes, tears,
cracked or damaged sealing surfaces, or other
damage that could allow unfiltered air into engine. A
dirty or clogged element could indicate insufficient or
improper maintenance.
●Check carburetor throat for dirt. Dirt in throat is further
indication that air cleaner was not functioning properly.
●Check if oil level is within operating range on dipstick.
If it is above, sniff for gasoline odor.
●Check condition of oil. Drain oil into a container; it
should flow freely. Check for metal chips and other
foreign particles.
Sludge is a natural by-product of combustion; a small
accumulation is normal. Excessive sludge formation
could indicate over rich fuel settings, weak ignition,
overextended oil change interval or wrong weight or
type of oil was used.
CLEANING ENGINE
WARNING
Cleaning Solvents can cause severe injury or
death.
Use only in well ventilated areas away from
ignition sources.
Carburetor cleaners and solvents are extremely
flammable. Follow cleaner manufacturer’s warnings
and instructions on its proper and safe use. Never use
gasoline as a cleaning agent.
After inspecting external condition of engine, clean
engine thoroughly before disassembly. Clean individual
components as engine is disassembled. Only clean
parts can be accurately inspected and gauged for wear
or damage. There are many commercially available
cleaners that will quickly remove grease, oil, and grime
from engine parts. When such a cleaner is used, follow
manufacturer’s instructions and safety precautions
carefully.
Make sure all traces of cleaner are removed before
engine is reassembled and placed into operation. Even
small amounts of these cleaners can quickly break down
lubricating properties of engine oil.

Troubleshooting
18 20 690 01 Rev. FKohlerEngines.com
Condition Conclusion
Crankcase breather clogged or inoperative. NOTE: If breather is integral part of valve cover and
cannot be serviced separately, replace valve
cover and recheck pressure.
Disassemble breather, clean parts thoroughly, check
sealing surfaces for flatness, reassemble, and recheck
pressure.
Seals and/or gaskets leaking. Loose or improperly torque
fasteners.
Replace all worn or damaged seals and gaskets. Make
sure all fasteners are tightened securely. Use appropriate
torque valves and sequences when necessary.
Piston blow by or leaky valves (confirm by inspecting
components).
Recondition piston, rings, cylinder bore, valves and
valves guides.
Restricted exhaust. Check exhaust screen/spark arrestor (if equipped). Clean
or replace as needed. Repair or replace any other
damaged/restricted muffler or exhaust system parts.
CRANKCASE VACUUM TEST
WARNING
Carbon Monoxide can cause severe nausea,
fainting or death.
Avoid inhaling exhaust fumes.
Engine exhaust gases contain poisonous carbon
monoxide. Carbon monoxide is odorless, colorless,
and can cause death if inhaled.
To test crankcase vacuum with manometer:
1. Insert rubber stopper into oil fill hole. Be sure pinch
clamp is installed on hose and use tapered adapters
to connect hose between stopper and one
manometer tube. Leave other tube open to
atmosphere. Check that water level in manometer is
at 0 line. Make sure pinch clamp is closed.
2. Start engine and run no-load high speed.
3. Open clamp and note water level in tube.
Level in engine side should be a minimum of 10.2
cm (4 in.) above level in open side.
If level in engine side is less than specified (low/no
vacuum), or level in engine side is lower than level in
open side (pressure), check for conditions in table
below.
4. Close pinch clamp before stopping engine.
To test crankcase vacuum with vacuum/pressure gauge:
1. Remove dipstick or oil fill plug/cap.
2. Install adapter into oil fill//dipstick tube opening,
upside down over end of a small diameter dipstick
tube, or directly into engine if a tube is not used.
Insert barbed gauge fitting into hole in stopper.
3. Run engine and observe gauge reading.
Analog tester–needle movement to left of 0 is a
vacuum, and movement to right indicates a pressure.
Digital tester–depress test button on top of tester.
Crankcase vacuum should be a minimum of 10.2 cm
(4 in.) of water. If reading is below specification, or if
pressure is present, check table below for possible
causes and conclusions.
WARNING
Rotating Parts can cause severe injury.
Stay away while engine is in operation.
Keep hands, feet, hair, and clothing away from all
moving parts to prevent injury. Never operate engine
with covers, shrouds, or guards removed.
A partial vacuum should be present in crankcase when engine is operating. Pressure in crankcase (normally caused
by a clogged or improperly assembled breather) can cause oil to be forced out at oil seals, gaskets, or other available
spots.
Crankcase vacuum is best measured with either a water manometer or a vacuum gauge. Complete instructions are
provided in kits.

1920 690 01 Rev. F KohlerEngines.com
Troubleshooting
COMPRESSION TEST
For Command Twins:
A compression test is best performed on a warm engine. Clean any dirt or debris away from base of spark plug(s)
before removing them. Be sure choke is off, and throttle is wide open during test. Compression should be at least 160
psi and should not vary more than 15% between cylinders.
All other models:
These engines are equipped with an automatic compression release (ACR) mechanism. It is difficult to obtain an
accurate compression reading because of ACR mechanism. As an alternative, use cylinder leakdown test described
below.
CYLINDER LEAKDOWN TEST
A cylinder leakdown test can be a valuable alternative to a compression test. By pressurizing combustion chamber
from an external air source you can determine if valves or rings are leaking, and how badly.
Cylinder leakdown tester is a relatively simple, inexpensive leakdown tester for small engines. This tester includes a
quick-connect for attaching adapter hose and a holding tool.
1. Run engine for 3-5 minutes to warm it up.
2. Remove spark plug(s) and air filter from engine.
3. Rotate crankshaft until piston (of cylinder being tested) is at top dead center (TDC) of compression stroke. Hold
engine in this position while testing. Holding tool supplied with tester can be used if PTO end of crankshaft is
accessible. Lock holding tool onto crankshaft. Install a 3/8 in. breaker bar into hole/slot of holding tool, so it is
perpendicular to both holding tool and crankshaft PTO.
If flywheel end is more accessible, use a breaker bar and socket on flywheel nut/screw to hold it in position. An
assistant may be needed to hold breaker bar during testing. If engine is mounted in a piece of equipment, it may
be possible to hold it by clamping or wedging a driven component. Just be certain that engine cannot rotate off of
TDC in either direction.
4. Install adapter into spark plug hole, but do not attach it to tester at this time.
5. Turn regulator knob completely counterclockwise.
6. Connect an air source of at least 50 psi to tester.
7. Turn regulator knob clockwise (increase direction) until gauge needle is in yellow set area at low end of scale.
8. Connect tester quick-connect to adapter hose. While firmly holding engine at TDC, gradually open tester valve.
Note gauge reading and listen for escaping air at combustion air intake, exhaust outlet, and crankcase breather.
Condition Conclusion
Air escaping from crankcase breather. Ring or cylinder worn.
Air escaping from exhaust system. Defective exhaust valve/improper seating.
Air escaping from intake. Defective intake valve/improper seating.
Gauge reading in low (green) zone. Piston rings and cylinder in good condition.
Gauge reading in moderate (yellow) zone. Engine is still usable, but there is some wear present.
Customer should start planning for overhaul or
replacement.
Gauge reading in high (red) zone. Rings and/or cylinder have considerable wear. Engine
should be reconditioned or replaced.

20
Air Cleaner/Intake
KohlerEngines.com 20 690 01 Rev. F
BREATHER TUBE
Ensure both ends of breather tube are properly
connected.
AIR COOLING
WARNING
Hot Parts can cause severe burns.
Do not touch engine while operating or just
after stopping.
Never operate engine with heat shields or guards
removed.
Proper cooling is essential. To prevent over heating,
clean screens, cooling fins, and other external surfaces
of engine. Avoid spraying water at wiring harness or any
electrical components. Refer to Maintenance Schedule.
AIR CLEANER
These systems are CARB/EPA certified and components
should not be altered or modified in any way.
Air Cleaner Components
B
C
A
D
E
AAir Cleaner Base BPaper Element
CPrecleaner DAir Cleaner Cover
EAir Cleaner Knob
NOTE: Operating engine with loose or damaged air
cleaner components could cause premature
wear and failure. Replace all bent or damaged
components.
NOTE: Paper element cannot be blown out with
compressed air.
Loosen knobs and remove air cleaner cover.
Precleaner (if equipped)
1. Remove precleaner.
2. Replace or wash precleaner in warm water with
detergent. Rinse and allow to air dry.
3. Saturate precleaner with new engine oil; squeeze
out excess oil.
4. Reinstall precleaner into cover, aligning hole in
precleaner with upper cover knob.
Paper Element
1. Remove element from base; replace element.
2. Install element with pleated side out and seat rubber
seal onto edges of base.
Reinstall air cleaner cover and secure with knobs.
