INSTALLATION INSTRUCTIONS
LIGHTING MIRROR W ANTI-FOG FILM
K-15478T/K-15479T/K-45101T
()
158 200436
BEFORE YOU BEGINBEFORE YOU BEGIN
Prior to drilling into walls, check there
are no hidden electrical wires, cables or
water supply pipes with the aid of ar,
electronic detector. If you use power
tools do not forget:
1. Wear eye protection.
2. Unplug equipment after use.
1.
2.
!
!
Congratulation on your purchase of this high
quality Bathroom Accessory. Before
proceeding with the installation, please
carefully read this installation instruction in
order to ensure proper care and assembly of
this accessory.
Please keep this installation instruction for
future reference.
!
!
1110777-T01-A1110777-T01-A
Reference Value
K-15478T
850 53
1175612-T01-A

-2-
INSTALLATION
1. 6mm
7
2.
3.
4.
Note: Please make sure power is shut off
before installation.
1. Put the mounting plate at the desired place
for installation. Drill 7 installation holes with
a 6mm drill.
2. Insert the wall anchors into the drilled holes
on the wall.
3. Pull the wire through the thread hole on the
mounting plate.
4. Fix the mounting plate on the wall with
screws and then tighten the wall anchors.
Installation Hole Mounting Plate
Screw
Power Wire
Thread Hole
Finished Wall
Wall Anchor
NOTE:
1. For the sake of your safety, please turn off
the electricity before installation, dismantling
or cleaning.
2. The installation is suggested to be executed
by certified electrician, and the ground wires
Should be properly connected.
1.
2.
PREPARE THE SITEPREPARE THE SITE
Kohler reserves the right to change marked dimensions without prior notice.
K-15479T/K-45101T
53
480
K-15479T: 600
K-45101T: 900
1175612-T01-A

-3-
7. Drill through the pre-prepared hole on the
lampshade.
8. Pull the waterproof wire clip through the pre-
prepared hole on the lampshade. Tighten
the nut with the waterproof wire clip.
7.
8.
Nut
Pre-prepared Hole
Lampshade Waterproof Wire Clip
9.
10.
9. Pull the power line through the waterproof
wire clip on the lampshade and bind it on
the fixture.
10. Bind the waterproof plug wire to the fixture.
Waterproof Plug Wire
Input Terminal
Output Terminal
Ground Wire
Fixture
Hot Wires
Neutral Wires
Ground Wires
Lampshade
Waterproof Wire Clip
Waterproof Plug Wire Terminal
Power Wire
5.
6.
5. Connect the plug with the socket.
6. Fix the fluorescent lamp to the spring slice.
Socket
Fluorescent Lamp Spring Slice
Plug
1175612-T01-A

-4-
12. 112. Pull the screw through the bracket and the
mounting hole. Tighten the wall anchors.
Bracket Installation Hole
Screw 1
1
13.13. Drill 6mm holes according to lamp location
and mirror size, then insert anchor.
11.
11. Fix the lampshade on the mounting plate
with screws.
The seal ring must be embedded into the
lampshade.
Note:
Lampshade
Screw Mounting Plate
L2 L2
L1 L1
SKU L1 L2
15478T 200 300
15479T 140 50
45101T 230 50
1175612-T01-A

14. 214. Fix the supporting block onto wall with
screws. Tighten the wall anchors.
Supporting Block
Screw 2
2
Wall Anchor
15.
16. ;
17.
15. Connect the waterproof gasket with the
socket and then tighten the socket with the
plug.
16. Hang the hook to the bracket.
17. Turn on power to check whether the lamp
and the defogger are functioning.
Hook
Waterproof Gasket
Waterproof Socket
Waterproof Plug
Bracket
-5-
