KOHTECT AVV-711 User manual

2016
KOHTECT AVV-711
LASER SHAFT ALIGNMENT SYSTEM
USER’S MANUAL

AVV-711 User’s Manual
2

AVV-711 User’s Manual
3
CONTENT
General .................................................................................................................. 5
Safety Precautions ................................................................................................ 5
Laser Safety Precautions ........................................................................................ 5
EC Declaration of conformity .................................................................................. 6
Technical Description................................................................................................ 7
Designation .......................................................................................................... 7
Misalignment Parameters ....................................................................................... 7
Specification and Features...................................................................................... 9
System Package.................................................................................................. 10
System overview................................................................................................. 10
Mounting Transducers.......................................................................................... 11
Laser Beam Adjustment ....................................................................................... 12
Getting Started...................................................................................................... 13
Common control keys consideration ...................................................................... 13
Auto save........................................................................................................... 13
Device setup....................................................................................................... 13
setup Menu Items ............................................................................................... 14
Horizontal Machine Alignment.................................................................................. 16
Short Explanation................................................................................................ 16
Transducer’s Positions Conventions ....................................................................... 16
Parameters......................................................................................................... 17
Taking Measurements. Clock Mode. 3/4 Points ........................................................ 19
Taking Measurements. Multipoint Mode.................................................................. 21
Taking Readings. Auto Shooting mode ................................................................... 22

AVV-711 User’s Manual
4
Readings quality assessment ................................................................................ 22
Measurements edit Mode ..................................................................................... 23
Result Screen ..................................................................................................... 24
Movable machine Adjustment ............................................................................... 24
Report file saving ................................................................................................ 26
Soft Foot............................................................................................................... 27
Vertical Machine Alignment ..................................................................................... 29
Short Explanation................................................................................................ 29
Transducer’s Positions Conventions ....................................................................... 29
Parameters......................................................................................................... 30
Taking Measurements. Clock Mode ........................................................................ 31
Result Screen ..................................................................................................... 33
Charging batteries............................................................................................... 35
Firmware Upgrade............................................................................................... 36
Firmware Upgrade Using Windows Mobile Device Center .......................................... 38
Standard Tolerances of Shaft Misalignment ............................................................... 40
Delivery Set .......................................................................................................... 41

AVV-711 User’s Manual
5
GENERAL
SAFETY PRECAUTIONS
Be sure the machines to be measured, cannot be started unintentionally as this can cause
injuries. For this purpose, before the mounting of equipment, either block the power switch
in the “Off” position or remove the safety fuses. These precautionary rules must be
followed until the measuring system is dismantled from the measured machine.
LASER SAFETY PRECAUTIONS
The KOHTECT AVV-711 alignment system is the class II laser device at typical wavelength
of 670nm, delivered output power of less than 1 mW and maximum radiant energy per
pulse of 0.1 mJ. The Class II laser comply with requirement outlined by USA’s FDA as well
as international ANSI, BS 4803 and IEC 825 standard. Be sure to follow the following
safety precautions to avoid personal injuries and damage to the system
Do not look directly into the laser beam at any time!
Do not direct laser beam on to the people’s eyes!
ATTENTION!
Do not expose AVV-711 parts to heavy impacts, high humidity and extreme temperature.
Do not try open / dismantle measuring units and the display unit –this can damage the
system, and your after-sales service warranty will come void.
INJURY RESPONSIBILITY DISCLAIMER
Neither the NPP KOHTECT enterprise nor our authorized dealers are liable for the damages
caused to machinery or equipment by use of the AVV-711 system. We carefully check text
of this manual to eliminate errors, nonetheless there may be mistakes or inaccuracy
involved. We will be grateful for your reporting to us about any error, and we will be able
to correct them in the subsequent editions of the manual.

AVV-711 User’s Manual
6
EC DECLARATION OF CONFORMITY
We, NPP KOHTECT, 167, Pogranichnaya str., of.201, Nikolaev, Ukraine herewith
declare that the following product:
Shaft Alignment Tool AVV-711
has been designed and manufactured in accordance with: EMC DIRECTIVE
2004/108/EC as outlined in the harmonized norm for EN 61326-1:2013 Electrical
equipment for measurement, control and laboratory use –
Part 1: General Requirements,
EN 55011: 2009 +A1:2010, EN 61000-4-2: 2009, EN 61000-4-3: 2006 +A1:2008
+A2:2010, EN 61000-4-4: 2004 +A1:2010, EN 61000-4-5: 2006, EN 61000-4-6:
2009, EN 61000-4-11: 2004
EUROPEAN ROHS DIRECTIVE 2011/65/EU
The laser is classified in accordance with the EN 60825-1:2007. The laser complies
with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice
No. 50, dated June 24, 2007.
The enclosed device complies with Part 15 of the FCC Rules.
47CFR: 2011 Part 15 Sub Part B Unintentional Radiators. Contains FCC ID: QOQWT11IA,
contains IC: 5123A-BGTWT11IA. Manufacturer’s Name, Trade Name or Brand Name:
Bluegiga. Model Name: WT11i.
Kiev, Ukraine, Nov 17, 2015
Oleg Ivanov, Head of Product Development

AVV-711 User’s Manual
7
TECHNICAL DESCRIPTION
DESIGNATION
AVV-711 alignment system (further as System) is designed for measurement of shaft axis
misalignment of coupled machines, and calculation of movable machine adjustment
required to eliminate misalignment that exceeds permissible tolerances;
The machine alignment means adjustment of the relative position of two coupled machines
(e.g. motor and pump) so that the center line of the axis will be concentric when the
machines are running under normal working conditions.
MISALIGNMENT PARAMETERS
Misalignment of any rotating machine is expressed in parallel (Offset) and angular (Gap) of
the shafts. Most frequently in practice, both of them are present simultaneously. Different
kinds of misalignment of axes are shown in Fig. 2.
S transducer
installed on the
shaft of Stationary
machine
M transducer
installed on the
shaft of the
machine to be
moved

AVV-711 User’s Manual
8
S–stationary machine
M–moveable machine
Shaft Angular (Gap)
value
Shaft Parallel (Offset)
value
Vertical adjustment values
S
M
The parallel (Offset) and angular (Gap) misalignment of axes is determined in two
mutually perpendicular planes. For the purpose of elimination of the parallel and angular
misalignment of axes, in each of the planes a correction of position of the movable
machine (M) will be done.
For the horizontal mounted machine –the movable machine (M) position is adjusted in the
horizontal and vertical planes.
For the vertical mounted machine, operator determines arrangement of the correction
planes, basing on considerations of the convenience and technological effectiveness of
moving of the movable (M) machine.
Stationary machine (S) - in the process of eliminating of the axes misalignment the
position of this machine stay static, i.e. it does not move.
Movable machine (M) –the machine, which position is adjusted for eliminating of the
parallel and angular misalignment of axes.
The measurement system calculates the values of the angular and parallel misalignment of
axes in the plane of the coupling (in two mutually perpendicular planes), and the
adjustment values for the machine feet on the movable (M) machine, that is necessary for
elimination of this misalignment of axes. Fig. 3 shows misalignment of axes and the values
for its correction just for vertical plane.
Parallel misalignment of axes –Offset (displacement)
Angular misalignment of axes –Gap
Parallel and angular misalignment of axes –(Offset + Gap)
Fig 2

AVV-711 User’s Manual
9
SPECIFICATION AND FEATURES
-Separation distance between measuring transducer units, up to 10 m
-Display control operating temperature range, -10..+55 degree C
-Measurement accuracy, 1%+0.01
-Laser type: Visible red 635-670 nm, <1 mW
-Detector type: Positional-sensitive photodiodes, 10 x 10 mm
-Display resolution, 0.01 or 0.001 mm, (1 or 0.1 mil )
-Measuring resolution, 0.001mm
-Electronic inclinometer resolution, 0.1 degree
-Power supply: Rechargeable Li-Ion battery
-Gross weight, incl. carry case, 6.5 kg
-Built-in application programs and options:
ohorizontal shaft alignment at any shaft position, from 60°, up to 360º, up to 36
readings can be measured; auto sweep mode can be used;
overtical (flange machine) shaft alignment;
oeditable misalignment tolerances;
osetup options;
osoft foot;
othermal growth;
oshimming simulator to calculate for expected residual misalignment;

AVV-711 User’s Manual
10
3
4
5
6
1
2
SYSTEM PACKAGE
The System includes (Fig. 1):
1- AVV-711 display unit
2- two measuring transducer units –S, M
3- universal chain brackets for mounting of
measuring units S, M
4- measuring tape
5- 120…240 Volts AC charger
6- USB PC communication cable
7- Operating instructions manual and ConSpect
freeware on the internal drive of display unit
8- Carry case
SYSTEM OVERVIEW
8
Locking
knobs
Connectors
Detector
window
Laser
aperture
Laser
adjustment
knobs
Datum lines for measuring
of dimension input

AVV-711 User’s Manual
11
MOUNTING TRANSDUCERS
Firmly tighten rods 1 into the shaft brackets 2.
Put thumb nut 3 into the bracket 2, then hook the chain 5 on the stud 4.
Firmly tighten the thumb nut 3. Shaft brackets with rods must be mounted at the
same angular position.
Mount transducers on the rods. Always try to mount transducers at minimal
possible radial height. Make sure that transducers are not touching brackets or
machine parts.
4
1
3
2
5
1
LED
indicator
Transducers
connectors
USB and
Charger
connectors

AVV-711 User’s Manual
12
LASER BEAM ADJUSTMENT
Mount transducers at the same height relative to the axis of the shafts
Close transducers windows and use green circle as the target
Adjust laser beams to the centers of targets by means of adjustment knobs
Open transducers windows
Laser
adjustment
knobs

AVV-711 User’s Manual
13
GETTING STARTED
COMMON CONTROL KEYS CONSIDERATION
To turn ON/OFF display unit and transducers –press and hold the power button for
~2 sec.
In case the system hangs and device did not respond to any keys - press and hold the
power button for ~10 sec, the system will be reset.
To close any currently active window, without saving, except main menu of the device,
press button (it serves as escape key).
The button in most cases causes applying (saving) changes (invoke selection) and
exit (from edit box; or from current window, except such windows as collect data, aligning,
soft foot and so on where it is not applicable).
To invoke menu item –move cursor to this item and press key, or just press the
shortcut key regardless of the cursor position. In most cases the shortcut key is depicted
left to the menu item.
AUTO SAVE
All procedures are designed with auto save. For temporarily shut down your current work
press until program exits to main menu of the device. Data saved now and device
can be turned off.
DEVICE SETUP
To invoke Setup menu –move cursor to
Setup and press button.

AVV-711 User’s Manual
14
Serial
number
+Function
enabled,
valid till
01.01.2099
Number of
transducers to
be connected
SETUP MENU ITEMS
–to setup date and time
–to set device auto off delay in seconds. When set
to 0 –auto off is disabled.
–to install license file which enables
measurement functions. Press 9, browse
to the license file, press Enter to open
and install licenses.
–to switch between wireless/cable transducers
connection. For wireless connection –press 1 or 2 to
enter number of transducers to be connected

AVV-711 User’s Manual
15
–to choose user interface language
Use keys to choose language, then press
–to switch AVV-711 into USB mass
storage device mode. By default device
can be connected to the PC via Microsoft Windows
Mobile Device Center. USB mass storage device
mode can be used as alternative.
–to adjust the display backlight brightness
-to choose default alignment
mode 1-D or 2-D biaxial mode. In
biaxial mode both horizontal and
vertical machine aligning could be
made at a static transducers position
(e.g. 3 h).

AVV-711 User’s Manual
16
HORIZONTAL MACHINE ALIGNMENT
SHORT EXPLANATION
oMount transducers on shafts
oRun Horizontal program
oEnter dimensions
oSet parameters. E.g. Measurement mode –clock type (9-12-3 o’clock positions)
oTurn shafts with transducers at first position 9 o’clock (90°). Press Start to take
readings
oTurn shafts with transducers at second position 12 o’clock (180°). Press Start to
take readings
oTurn shafts with transducers at last position 3 o’clock (270°). Press Start to take
readings
oAfter that the device will calculate misalignment and displays required corrections
for Movable machine
TRANSDUCER’S POSITIONS CONVENTIONS
While taking measurements, it is necessary to
follow conventions for transducers positions on
the shafts with the S and M measuring
transducers with regard to the relative position of
the S and M machines as depicted on the figure.
Angular positions in degrees adopted in the
device are as follows:
6 o’clock - 0°
9 o’clock - 90°
12 o’clock - 180°
3 o’clock - 270°
9
3
12
S
M
6

AVV-711 User’s Manual
17
PARAMETERS
In Main Menu run Horizontal program.
Choose New Task to start from scratch or
Continue… - to resume interrupted work.
Machine dimensions / measurement setup screen
Press key to start editing the dimensions’ values
Press key for parameters/key legend:
Press - to toggle Spacer shaft Yes/No

AVV-711 User’s Manual
18
Press - to toggle dimensions input
M-F1, M-F2 / S-F1, S-F2
Press - to toggle data input –LD transducer’s data / MD –manual data
Press - to toggle angle input –IA use inclinometer / MA manual angle. Manual angle
input used for vertical machines, when electronic inclinometer cannot be used.
Press - to toggle displayed precision –2 or 3 digit.
Press - to toggle measurement mode:
Turn 3 point (e.g. clock mode 9-12-3 o’clock),
Turn 4 point –readings to be taken at four
predefined shaft positions separated by 90° (3hr).
After that the device itself will proceed to the
result screen.
Multipoint mode –measurements may be taken
at any minimum 3 up to 36 positions. After taking enough readings one should press
to proceed to the result screen.
Press to toggle metric/imperial units mm/in
Press to toggle 1-D / 2-D Biaxial alignment mode
Press to setup Averaging. Averaging is turned off if set to 0.
9
3
12
S
M

AVV-711 User’s Manual
19
3–clock mode
4 –4 pnt clock mode
*–multipoint
First reading
Press to enter tolerance setup menu.
Press to use predefined RPM/tolerance table
Press to enter user defined tolerance values
Press to save changes, to discard changes.
TAKING MEASUREMENTS. CLOCK MODE. 3/4 POINTS
Press to edit dimensions.
Set parameters and enter dimensions then press key to
proceed.
Turn shafts to first position –9 o’clock
(90°)
Press to take first reading.
Yellow clock face means that point is already collected and shafts
should be turned to the next position.
S
M
Predefined positions
transducers should
be turned to take
readings

AVV-711 User’s Manual
20
Turn shafts to second position –12 o’clock (180°)
Press to take second reading.
Turn shafts to third position –3 o’clock (270°)
Press to take third reading. When
three reading are taken, device will proceed
to the result screen. For 4 points mode, one
more position should be measured. This
mode to be used when advanced alignment
precision is required.
12
S
M
S
M
Third
position
