Komatsu WB140PS-2N Install guide

April 2003 Copyright 2003 Komatsu
Published in USA
Komatsu America Corp.
00-1
CEBM011100
Shop
Manual
WB140PS-2N
WB150PS-2N
BACKHOE LOADER
This material is proprietary to Komatsu Utility Division and is not to be reproduced, used, or disclosed except in accordance
with written authorization from Komatsu Utility Division.
It is our policy to improve our products whenever it is possible and practical to do so. We reserve the right to make changes or
add improvements at any time without incurring any obligation to install such changes on products sold previously.
Due to this continuous program of research and development, periodic revisions may be made to this publication. It is recom-
mended that customers contact their distributor for information on the latest revision.
SERIAL NUMBERS WB140PS-2N A40001 and UP
WB150PS-2N A70001
WB140PS-2N, WB150PS-2N

FOREWORD CONTENTS
00-2 WB140PS-2N, WB150PS-2N
12 CONTENTS 00
10 STRUCTURE AND FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
20 TESTING AND ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-1
30 REMOVAL AND INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-1
90 OTHER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90-1
