- 1 -
CONTENT PAGE
Intended Use 2
Items supplied 2
Technical Data 2
Safety instructions 2
Description of the appliance 3
Operation 3
Cleaning and care 4
Disposal 5
Importer 5
Warranty and Service 5
Read these operating instructions carefully before using the appliance for the first time and preserve this
maual for later reference. Pass this manual on to whoever might acquire the appliance at a future date.
IB_KH4414_E26059_LB6 16.04.2009 12:23 Uhr Seite 1

- 2 -
THERMAL HEAT
BINDING MACHINE
KH 4414
Intended Use
This thermal binder is intended exclusively for use in
the thermal binding of brochures in domestic house-
holds.
It is NOT intended for use with any other materials.
It is also NOT intended for commercial or industrial
applications.
The warranty does not provide compensation for
damage caused by improper use of the appliance!
Items supplied
Thermal Binder KH 4414
4x Thermal binder covers, 2mm, for 20 sheets of
80g/m2
3x Thermal binder covers, 3mm, for 30 sheets of
80g/m2
3x Thermal binder covers, 6mm, for 60 sheets of
80g/m2
Operating instructions
Order card
Technical Data
Mains voltage: 220 - 240 V~50 Hz
Nominal power: 250 W
Rated current : 1,2 A
Warm-up time: approx. 3 minutes
Protection class: II /
Binding capacity:
max. 300 sheets with a 30mm thermal binder
cover
max. sheet size - DIN A4
Safety instructions
Injury hazard
• This appliance is not intended for use by individuals
(including children) with restricted physical, physio-
logical or intellectual abilities or deficiences in
experience and/or knowledge unless they are
supervised by a person responsible for their safety
or receive from this person instruction in how the
appliance is to be used.
• Children should be supervised to ensure that they
do not play with the appliance.
• Unplug the power cable after every use and before
cleaning, so as to prevent the appliance from
switching itself on inadvertently.
• Check the appliance and all parts for visible
damages. The safety concept can work only if
the appliance is in a faultless condition.
• Ensure that the appliance stands at a safe and
secure positioning.
• Do not operate the appliance if it has sustained
a fall or is damaged. Arrange for the appliance
to be checked and, if necessary, repaired by
qualified technicians.
Some parts of the appliance become very
hot during operation. To avoid burns, do
not touch these parts.
• Do not use an extension cable. Place the appliance
where the power wall socket is easily accessible,
so that in the event of an emergency the plug can
be quickly withdrawn.
Never insert your hands into the binding
shaft. There is a risk of being burnt!
IB_KH4414_E26059_LB6 16.04.2009 12:23 Uhr Seite 2

- 3 -
Risk of electric shocks.
• Connect the appliance to a mains power socket
supplying a voltage of 220 - 240 V ~/50 Hz.
• Do not operate the appliance if the power cable
or power plug is damaged.
• Arrange for defective power plugs and/or cables
to be replaced at once by qualified technicians
or our Customer Service Department.
• Never immerse the appliance in water.
Just wipe it with a damp cloth.
• Do not expose the appliance to rain and never
use it in a humid or wet environment.
• Ensure that the power cable never becomes wet
during operation.
• Unplug the appliance immediately after use.
The appliance is free of electricity only when you
remove the power plug from the power socket.
• Do not open the casing or attempt to repair the
appliance yourself. Should you do so, appliance
safety can no longer be assured and the warranty
will become void.
Risk of fire!
• Do not use the appliance in the vicinity of hot
surfaces.
• Do not place the appliance in locations exposed
to direct sunlight.
If you do, this could lead to overheating and
cause irreparable damage.
• Do not leave the appliance unattended when in
use.
• Do not use an external timing switch or a separate
remote control system to operate the appliance.
Caution - property damage!
• Never attempt to bind flammable, heat-sensitive
and/or meltable materials and do not bind
drawings made on temperature-sensitive paper
or material that could undergo changes in colour
or quality when subjected to heat.
• Fundamentally, never bind valuable or unique
documents. Although this thermal binder satisfies
all relevant safety norms and standards, functional
errors can never be completely discounted - as
with all electrical appliances. Functional errors
with the appliance could cause damage to the
documents being bound.
Description of the appliance
1Binder shaft
2Document holder
3Power cable
4 ON / OFF switch
5START button
6Control lamp
7Control lamp
8Retainer bracket
Operation
Note:
On this first use the development of a light odour
may occur, caused by production residues (a slight
smoke development is also possible). This is normal
and dissipates after a short time. Provide for sufficient
ventilation. Open a window, for example.
1. Ensure the appliance has a stable positioning.
2. Fold the retainer bracket 8upwards, until it
engages, and draw the document holder 2out.
IB_KH4414_E26059_LB6 16.04.2009 12:23 Uhr Seite 3

- 4 -
3. Insert the plug into a mains power socket.
4. Switch the appliance on by pressing the ON / OFF
switch 4. The red control lamp 7glows.
• As soon as the green control lamp 6
glows the appliance has reached its operating
temperature. Additionally, an acoustic signal
sounds.
5. Select a suitable thermal binder cover for your
document:
6. Tap the sides of the sheaf of papers a few times
to ensure that ALL of the sheets are lying exactly
above each other.
7. Lay the sheets into a suitable thermal binder cover
and then tap them down a couple of times,
against and using the cover spine.
8. Slide the thermal binder brochure through the re-
teainer bracket 8into the binding shaft 1such
that the spine of the brochure makes firm contact
with the hotplate on the floor of the thermal
shaft 1.
9. Press the START 5button. The control lamp 7
glows, the control lamp 6blinks.
Number of
sheets 80g/m2
Brochure thik-
kness in mm
20 2 mm
30 3 mm
60 6 mm
10. As soon as an acoustic signal sounds and the
control lamp 6glows constantly you
can remove the thermally bound brochure from
the binding shaft 1. Place it in the document
holder 2so that the adhesive can harden.
The binding is sufficiently hardened after approx.
60 seconds.
11. After use, place the ON/OFF switch 4at O and
remove the plug from the mains power socket.
Note:
If you are binding particularly thick documents, with
a spine width of 20 mm (200 sheeds), then repe-
at the binding process approx. 5 times.
Cleaning and care
Risk of potentially fatal electrical
shock:
• Always remove the plug from the mains power
socket before you clean the appliance!
• Never open the housing of the appliance.
There are no user-serviceable elements inside.
• Never submerse the appliance into water or
other liquids!
➩Allow the appliance to cool down completely.
➩Clean the surface of the housing with a slightly
damp wash cloth.
➩Ensure that moisture cannot permeate into the
appliance.
IB_KH4414_E26059_LB6 16.04.2009 12:23 Uhr Seite 4

- 5 -
Disposal
Do not dispose of the appliance in your
normal domestic waste. This product is
subject to the provisions of European
Directive 2002/96/EC.
Dispose of the appliance through an approved dispo-
sal centre or at your community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Dispose of all packaging materials in an
environmentally friendly manner.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
Warranty and Service
This appliance comes with a 3 year warranty. Purchase
date. This appliance has been manufactured with
care and meticulously examined before delivery.
Please retain your receipt as proof of purchase. In
the case of a warranty claim, please make contact
by telephone with our service department. Only in
this way can a post-free despatch for your goods
be assured.
The warranty covers only claims for material and
manufacturing defects, not for wearing parts or for
damage to fragile components, e.g. buttons or batteries.
This product is for private use only and is not intended
for commercial applications.
In the event of misuse and improper handling, use
of force and interference not carried out by our
authorized service branch, the warranty will become
void. Your statutory rights are not restricted in any
way by this warranty.
DES Ltd
Units 14-15
Bilston Industrial Estate
Oxford Street
Bilston
WV14 7EG
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
Kompernass Service Ireland
Tel: [phone] (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: [e-mail]
