Content
Introduction 2
Information for these operating instructions . . . . . . . . . . . . . . . . . . 2
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Limited liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions 4
Initial use 5
Package contents and transport inspection . . . . . . . . . . . . . . . . . . 5
Device description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation 7
Charging the Power Pack with the mains power unit . . . . . . . . . . . 7
Charging the Power Pack with the car adapter . . . . . . . . . . . . . . . 8
Charging 5V devices with the Power Pack. . . . . . . . . . . . . . . . . . . 9
Troubleshooting 10
Malfunction causes and remedies . . . . . . . . . . . . . . . . . . . . . . . .10
Cleaning/Storage/Disposal 12
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Appendix 13
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Information regarding the EG conformity declaration . . . . . . . . . 14
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Compatibility table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

GB
2KH 997
Introduction
Information for these operating instructions
These operating instructions are a component of the Power Pack KH 997
and they supply you with important information for proper use, safety,
connections as well as operation of the Power Pack.
The operating instructions must be constantly kept available close to
the Power Pack. They are to be read and used by anyone assigned
to service and repair malfunctions in the Power Pack.
Keep these operating instructions and hand them over with the
Power Pack to any future owners.
Copyright
This documentation is copyright protected.
Any duplication and/or reproduction wholly or partially including
reproduction of the illustrations, also in a modified form, is only
permitted with written authorization from the manufacturer.
Limited liability
The manufacturer assumes no responsibility for damage caused
by failure to observe the instructions, improper use, inappropriate
repairs, making unauthorized changes or for using unapproved
replacement parts.

3
KH 997
GB
Warnings
In the current operating instructions the following warnings are used:
WARNING
A warning of this danger level signifies a possible
dangerous situation.
If the dangerous situation is not avoided it can lead to injuries.
The directives in this warning are there to avoid personal►
injuries.
IMPORTANT
A warning of this danger level signifies possible
property damage.
If the situation is not avoided it can lead to property damage.
The directives in this warning are there to avoid property►
damage.
NOTE
A note signifies additional information that assists in the►
handling of the device.

GB
4KH 997
Proper use
This Power Pack is intended exclusively for power supply to devices
with an operating voltage of 5V (Mobile telephones, MP3 Play-
ers, etc.). Another or any other usage is regarded as unintended use
and can lead to damages and injuries. Claims of any kind for dam-
age resulting from unintended use will not be excepted.
Safety instructions
For safe handling of the device observe the following safety instructions:
Before use check the device for visible external damage. Do not■
put into operation a device that is damaged or has been dropped.
Damaged cables or connections should be replaced by authorized■
qualified persons or by the customer service department.
This device is not intended for use by individuals (including children)■
with restricted physical, physiological or intellectual abilities or
deficiences in experience and/or knowledge unless they are
supervised by a person responsible for their safety or receive
from this person instructions on how the device is to be used.
Only permit children to use the device under supervision.■
Protect the device from moisture and liquid penetration.■
The device is intended for indoor■ use only.
Do not place the device in the vicinity of flammable or explosive■
devices.

5
KH 997
GB
Do not place the device in locations that are subject to direct■
sunlight as this could lead to overheating and cause irreparable
damage.
Use only the supplied mains power unit and/or the supplied■
car adapter. By using other mains power units the Power Pack
and/or connected devices could be damaged.
Disconnect the Power Pack from the mains power unit/car adapter■
and from connected devices before cleaning and when not in use
to avoid the risk of an electric shock.
Initial use
WARNING
Packaging material should not be used as a play thing.
There is a risk of suffocation!
Package contents and transport inspection
Power Pack▯
USB power plug unit with 3 exchangeable power plugs for▯
USA, GB and Europe
Car adapter▯
Retractable USB cable▯
11 Plug connection attachments for 5V▯ devices
Storage case▯
These operating instructions▯
NOTE
Check the contents to make sure everything is there and for►
visible damage.
In the event of incomplete delivery or damage as a result of►
defective packaging or through transportation contact the
Service-Hotline (see chapter "Warranty").

GB
6KH 997
Device description
1Battery charge indicator (shows the rechargeable battery status)
2Rechargeable battery test button (activates the battery charge
indicator)
3USB OUTPUT socket (connection for 5V DC devices)
4INPUT DC 5V socket (connection for the mains power unit/
car adapter)
5RESET button (Return the Power Pack to the factory default settings)
6Plug connection attachment for Nokia, large
7Plug connection attachment for Nokia, small
8Plug connection attachment for Playstation Portable
9Plug connection attachment for Motorola
0Plug connection attachment USB-USB
qPlug connection attachment for Nintendo DS
wPlug connection attachment for Samsung
ePlug connection attachment for Sony Ericsson
rPlug connection attachment Mini USB
tPlug connection attachment Mini USB 8 Pin
zPlug connection attachment Micro USB
uRetractable USB cable
iCar adapter
oMains power plug USA
pMains power plug GB
aMains power plug Europe
sMains power plug unit

7
KH 997
GB
Operation
Preparation
Select the correct mains power plug (o, p, a)for your country
and insert this into the mains power plug unit s. Make sure that the
mains power plug completely locks into place. To release the mains
power plug press on the area marked PRESS and pull the mains
power plug up and away.
Charging the Power Pack with the mains power unit
1. Activate the rechargeable battery test button 2.One to three
of the charging indicator 1LEDs light up and thus shows the
current rechargeable battery status. If all four LEDs light up then
the Power Pack is fully charged.
2. Connect the retractable USB cable uto the mains power plug unit s.
3. Connect the Mini USB plug connection attachment rto the other
end of the retractable USB cable u.
4. Plug the Mini USB plug connection attachment rinto the socket
INPUT DC 5V 4of the Power Pack.
5. Connect the mains power plug unit sto a mains power wall
socket. The mains power wall socket should be easily accessible
so that, in the event of a malfunction, the power plug unit can be
quickly pulled from it. The charging indicator 1LEDs blink one
after the other and thus indicate that the rechargeable battery is
charging. If all of the charging indicator’s 1LEDs are constantly
alight then the rechargeable battery is fully charged.
6. Disconnect the Power Pack from the mains power plug unit sand
pull the unit out of the mains power wall socket.
NOTE
You can also charge the Power Pack via the USB output of a► PC/Notebook. For this connect the retractable USB cable u
to the USB output of the PC and plug the Mini USB plug con-
nection attachment r into the INPUT DC 5V 4socket of the
Power Pack. The charging process could take longer due to the
reduced current output.

GB
8KH 997
Charging the Power Pack with the car adapter
IMPORTANT
Never leave the Power Pack in the car!
With strong sunlight and a correspondingly heated car interior►
the Power Pack could become overheated and be irreparably
damaged.
1. Activate the rechargeable battery test button 2. One to three of
the charging indicator 1LEDs light up and thus shows the current
rechargeable battery status. If all four LEDs light up then the
Power Pack is fully charged.
2. Connect the retractable USB cable u to the car adapter i.
3. Connect the Mini USB plug connection attachment r to the other
end of the retractable USB cable u.
4. Plug the Mini USB plug connection attachment rinto the INPUT
DC 5V 4socket of the Power Pack.
5. Connect the car adapter ito a 12V on-board power supply socket
and/or to a 12V cigarette lighter socket. The charging indicator 1
LEDs blink one after the other and thus indicate that the recharge-
able battery is charging. If all of the charging indicator’s 1LEDs are
constantly alight then the rechargeable battery is fully charged.
6. Disconnect the Power Pack from the car adapter iand pull the
adapter out of the 12V on-board power supply socket and/or the
12V cigarette lighter socket.

9
KH 997
GB
Charging 5V devices with the Power Pack
Preparation
1. Check for the maximum input voltage of the device that you want
to charge. For this consult the operating instructions of the device.
2. Make sure that the maximum current consumption does not
exceed 800 mA.
3. Check to see which plug connection attachment is required for the
device (see compatability table S. 16 + 17).
Charging of 5V devices
IMPORTANT
Devices with a USB connection that require an input voltage►
corresponding to the USB specifications of 4.75 V – 5.25 V
(iPod®or iPhone®) must use the supplied plug-in connector
attachment USB-USB (UA01) 0. The current draw of these
devices must be at least 100 mA.
1. Insert the plug of the retractable USB cable uinto the socket
USB OUTPUT 3.
2. Connect the appropriate plug connection attachment to the other
end of the retractable USB cable u.
3. Insert the plug connection attachment into the device’s power
supply socket.
4. Press the rechargeable battery test button 2. The device now
receives its power supply from the Power Pack. If the device has a
charging indicator this will show that the device is being charged.

GB
10 KH 997
NOTE
Should the charging proccess not function as described try to
reset the Power Pack to its factory default settings by pressing
the RESET button 5.
Carefully press the RESET button► 5 with the help of a paper
clip. The RESET button 5 is recessed to avoid an inadvertent
resetting of the Power Pack.
Troubleshooting
Malfunction causes and remedies
The following table will help with localizing and remedying minor
malfunctions:
Defect Possible cause Solution
The connected
device will not
charge.
The voltage of the
device does not match
that of the Power Pack.
Consult the operating
instructions for the
device.
Defective connection
between the device and
the Power Pack.
Make sure that the USB
cable u is correctly
connected to the device
and the Power Pack.
The wrong plug connec-
tion attachment is being
used.
Check the plug connec-
tion attachment and, if
necessary, exchange it
for another.
Power Pack voltage is
too low.
Recharge the recharge-
able battery pack.

11
KH 997
GB
Defect Possible cause Solution
The recharge-
able battery
pack runs down
too quickly.
The Power Pack was
not fully charged before
use.
Fully recharge the
Power Pack.
The supplied mains
power unit s/car
adapter i was not
used for the charging of
the Power Pack.
For charging of the
Power Pack use only
the supplied mains
power unit s/car
adapter i.
The recharge-
able battery
pack can not
be charged.
Defective connection
between the recharge-
able battery pack and
mains power unit s.
Make sure that the USB
cable u is correctly
connected at the mains
power unit s/car
adapter i and at
the INPUT DC 5V 4
socket.
The mains socket is not
functioning properly. Check to see if the mains socket is providing elec-
tric power by connecting
a different device to it.
NOTE
Should the malfunction not be resolved by the above men-►
tioned solution proposals or if another type of malfunction
occurs please contact our service department (see warranty
and service).

GB
12 KH 997
Cleaning/Storage/Disposal
Cleaning
WARNING
Disconnect the Power Pack, before cleaning and
when not in use, from the mains power unit/car
adapter, and from connected devices, to avoid
the risk of an electric shock.
For cleaning the outside of the Power Pack use a soft, lint-free cloth.►
Do not use aggressive detergents or scouring agents.►
Storage
Store the Power Pack in a dry environment.
Disposal
Under no circumstances should you throw
the device into the normal household waste.
This product is subject to the European
directive 2002/96/EC.
Dispose of the device through an approved disposal
centre or at your community waste facility. Observe
the currently applicable regulations. In case of doubt,
please contact your waste disposal centre.
Dispose of the packaging materials in an environmen-
tally responsible manner.

13
KH 997
GB
Appendix
Technical data
Power Pack
Rechargeable battery Lithium-Polymer 2200 mAh
Input voltage 5 V , max. 1000 mA
Output voltage 5.6 V , max. 800 mA
Charging time approx. 4.5 - 5.5 h
Operating temperature 0- +40 °C
Humidity (no condensation) 5-90 %
Dimensions 8.7 x 6 x 1.7 cm
Weight 85 g
Mains plug
Manufacturer Minwa Electronics Co., Ltd.
Model MW3NU10GT
Input voltage 100-240V~60/50 Hz, 0.13 A
Output voltage 5.2 V , 1 A
Protection class II /
Dimensions 7.2 x 4.6 x 3.3 cm
Weight 50 g
Vehicle adapter
Manufacturer Minwa Electronics Co., Ltd.
Model MW3381
Input voltage 12 - 13.8 V , 540 mA
Output voltage 5 V , 1 A
Dimensions 10.5 x 4.5 x 2 cm
Weight 38 g

GB
14 KH 997
Information regarding the EG conformity
declaration
This device complies regarding conformity to the basic
requirements and other relevant regulations of the EMV
directive 2004/108/EC, the low voltage directive
2006/95/EC as well as the Eco-design directive
2009/125/EC (Provision 1275/2008 supplement II, Nr. 1).
The complete original declaration of conformity can be
obtained from the importer.
Warranty
You receive a 3-year warranty for this device as of the purchase
date. This device has been manufactured with care and meticulously
examined before delivery. Please retain your receipt as proof of
purchase. In the case of a warranty claim, please get in touch, by
telephone, with our service department. Only in this way can a post-
free dispatch for your goods be assured.
NOTE
The warranty adjustment applies only to material or manu-►
facturing defects and not for transport damage, parts subject
to wear and tear or for damage to breakable parts, for
example, switches or rechargeable batteries.
This device is intended solely for private domestic use, not for com-
mercial applications. In the event of misuse and improper handling,
use of force and interference not carried out by our authorized
service branch, the warranty will become void. Your statutory rights
are not restricted in any way by this warranty. The warranty period
will not be extended through the defects liability. This also applies to
replacement and repaired parts.

15
KH 997
GB
Possible damage and defects already present at the time of purchase
must be reported immediately after unpacking or, in any event, no later
than two days after the purchase date. After expiration of the warranty
period incidental repairs are subject to costs.
Service
DES UK LTD
Tel.: [phone] (£ 0.10 / minute)
e-mail: [email protected]
Kompernass Service Ireland
Tel: [phone] (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: [email protected]
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com

GB
16 KH 997
Compatibility table
Illustra-
tion Product type Make/Model
Nokia™
"large"
Mobile
telephone
Nokia™:
1100, 1101, 1110, 1600, 2300, 2600,
2650, 2652, 3100, 3120, 3220, 3230,
3300, 3660, 5100, 5240, 5140i, 6020,
6021, 6030, 6060, 6100, 6170, 6230,
6230i, 6260, 6310i, 6600, 6610i, 6670,
6680, 6681, 6810, 6820, 6822, 7260,
7270, 7280, 7360, 7380, 7610, 7710,
8800, 9210i, 9300, 9300i, 9500, E60, E70
Nokia™
"small"
Mobile
telephone
Nokia™:
3250, 6070, 6101, 6103, 6111, 6125,
6136, 6233, 6270, 6280, 7360, 7370,
E61, N70, N71, N72, N80, N81, N90,
N91, N92, N93, 5800i x plus
Playstation®
Portable
Game consol PSP™
Motorola™ Mobile
telephone
Motorola™:
E398, ROKR E1, V500 / V600 series,
E550, V300, V80, T720i, V975, V980,
C975, C980, A1000, E1000
USB - USB MP3 Player
Mobile
telephone
Apple®:
iPod®, iPhone®
Nintendo
DS™
Game consol Nintendo®:
NDS™ Lite

17
KH 997
GB
Illustra-
tion Product type Make/Model
Samsung™ Mobile
telephone
Samsung™:
SGH-D520, SGH-D800, SGH-D80,
SGH-D820, SGH-D900, SGH-ES540,
SGH-E550, SGH-E780, SGH-E870, SGH-
P300, SGHT509, SGH-T809, SGH-V804,
SGH-Z150, SGHZ510, SGH-Z540
Sony
Ericsson™
Mobile
telephone
Sony Ericsson™:
D750i, J100i, J230i, K310i, K610i,
K610iM, K750i, K800i, M600i, P990i,
V630i, W300i, W600i, W710i, W800i,
W810i, W880i, W900i, W950i, Z310i,
Z520i, Z530i, Z550i, Z610i
Mini USB Mobile
telephone
PDA
Alcatel™:
OT-E801, OT-S853
Motorola™:
A732, A780, A910, E1070, E770v,
KRZR, K1, SLVR L2, SLVR L6, SLVR L7,
MPx200, RIZR Z3, ROKR E2, PEBL U6,
V191, V195, V235, V360, V1075,
RAZR V3, RAZR VR 3i, RAZR V3x
RIM®:
BlackBerry®
Mini USB
8 Pin
Bluetooth®
Headset
Jabra™:
BT125, BT135, BT320, BT325, BT5010,
BT5020, BT8010
Sennheiser™:
VMX100-T, VMX100-B
Micro USB Smart Phone HTC™:
Nexus One, HTC™HD2, HTC™Desire,
HTC™Legend, HTC™HD mini
