INSTRUCTION MANUAL
AIR PURIFIER
Model No: KF-P20W
Keep these instructions for future reference

Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to
Thank you for purchasing the innovative KF-P 2 0 W air purif er for the proper operation of the
device. These instructions describe the safety precautions to be observed during operation. They are
designed to prevent injuries or damage to this device.
operate the equipment.
SAFETY PRECAUTIONS:
1.
2.
3.
4.
5.
6.
7.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
Our air purifier is used 120~240V, 50/60Hz.
Cleaning the unit, while it is plugged in may result in electric shock, electric spark and serious
injury. Unplug the unit before cleaning or maintenance.
This air purifier contains a UV-C emitter.
Unintended use of the air purifier or damage to the housing may result in the escape of dangerous
UV-C radiation UV-C radiation may, even in little doses, cause harm to the eves and skin.
Air purifier are obviously damaged must not be operated.
According to the working environment, the device needs to be cleaned within 2-4 weeks. Before
cleaning, unplug the device, open the back cover, remove the filter, wipe the interior of the device
with a wet towel.
If the UV light is damaged, it must be replaced by the manufactures, its service agent, or similarly
qualified persons in order to avoid a hazard.
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARING: To reduce the risk of fire, electric shock or injury, read and understand this user guide before
operation this air purifier.

1. The air purifier is not to be used by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction. Children being supervised not to play with the air purifier. (For Others)
2. This air purifier can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the air purifier in a safe way and understand the
hazards involved. Children shall not play with the air purifier. Cleaning and user maintenance shall
not be made by children without supervision. (For Europe)
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
4. Do not operate unite if cord or plug is damaged. Doing so can result in electric shock. Discard the
damaged unite or take if to an authorized service facility for examination and /or repair.
5. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or similar coverings.
DO NOT ROUTE CORD UNDER FURNITURE OR AIR PURIFIER. Arrange cord away from
traffic area and where it will not be tripped over.
6. Only use the air purifier as described in this manual.
7. Do not handle the unit with wet hands. Thoroughly dry your hands before handling any part of the
air purifier.
8. Hair, loose clothing and body parts can get caught in the air purifier resulting in injury. Keep hair,
loose clothing and body parts away from openings and moving parts.
9. Do not unplug by pulling on the cord. Doing so may result in electrical spark or fire, unplug the unit
by grasping.And pulling the plug.
10. Do not use an extension cord.
11. Do not place the air purifier near sources of heat, such as: stove tops, ovens, radiators or computers.
12. Unplug the air purifier from the power supply before servicing.
13. This equipment should be inspected frequently and the dirt that has collected should be removed
regularly to prevent excessive accumulation that may result in flash over or fire.
14. Do not use the air purifier outdoors or on wet surfaces.
15. Do not use the air purifier in an enclosed space where flammable, combustible or explosive gases
are present.
16. Do not use in an area where toxic vapors, flammable dust or oxygen tanks are present. Checked the
location and make sure these elements are not present.
17. Do not place open flames, including candles, directly in front of the air purifier.
18. It is important to keep all objects away from the air intake grille.
19. Place the air purifier on a flat, solid, stable surface. Never place the unit on soft surfaces such as a
bed or sofa.
20. Position the air purifier so that the dirty air is not drawn across your head or body while sitting or
sleeping.
21. Place the air purifier so the plug on the power cord easily reaches a standard electrical outlet for a
polarized plug.
22. Children should be supervised when product is in used. Do not allow children to play on or near the
air purifier. Keep children’s hair, loose clothing, and body parts away from/ out of the intake grille,
bents, holes, or openings.
23. This product is suitable for use with solid-state speed controls.

PRODUCT DIAGRAM:
FEATURES AND OPERATION:
Instructions for usage
Power: When plug in, display will be on for 1 second and a beep sound will be heard. The
“Power” button will be shown and "WIFI" icon (for WIFI version only) will flash (it will always
be on after connecting to theApp in mobile phone), then the air purifier keep in standby state.

Touch “Power” button, air purifier starts up and the air quality indicator around the screen
alternates between green, yellow, orange and red. Display shows symbol which means the air
purifier is working in Auto Mode with medium speed. PM2.5 value “000” is flashing at the beginning
and 10 seconds later it begins to show air quality in real-time data. Air quality indicator shows air
quality in the corresponding color and air purifier will adjust the speed according to the air quality
automatically per 1 minute.
Auto Mode Chart
Color Air Quality PM2.5 Data Fan Speed
Red Bad ＞151 3 (High)
Orange Moderate 101~150 2
Yellow Good 51~100 1
Green Very Good ＜50 Lower 1
Speed: Touch "Speed" button air purifier will exit the Auto Mode. Cycles through fan speeds:
speed 1, speed 2, speed 3 and then Auto Mode.
The fan speed cannot be changed during Sleep mode.
Timer: Touch "Timer" button, “--” icon flashes in display. Touch the button continually to set
the timer from 1~12 hours, after choosing desired timer, display is flashing timer 3 times and switch to
show PM2.5 data, it means setting is done, display show icon. It calculates by counting down
every hour. When the time is up, the air purifier shuts down.
Touch the button till icon “--” or long press the button for 2 seconds to cancel timer setting.
In the timing function, touch the timing button again can check the remaining time.
ION/UV: Touch "ION/UV" button to turn on the Anion function with according icon show.
Touch the button again to turn on UV function with according icon show. Touch the third time to
turn off Anion function. Touch fourth time to turn off the UV function.
Sleep: Touch "Sleep" button, the air purifier will enter Sleep Mode. Sleep Mode uses the lowest
possible fan speed (even lower than “lower 1”speed) to create a quite environment.
Display only shows the icon with 1\3 brightness. Touch any button to illumine the display in 1\3
brightness, then you can operate other functions. If 15 seconds without any operation, display show the
icon with 1\3 brightness only again. Touch again to turn back toAuto Mode.

Display turn off function: Long press “Sleep”button for 2 seconds to turn off the display. Touch
any button to illumine the display in 1\3 brightness, and then press it to operate other functions. 15
seconds without any operation, display turns off again. Long press this button to exit display turn off
function.
When turn off display in the sleep mode, the "sleep" button is in bright pink. Otherwise, the "s"Sleep"
button is in bright red.
FILTER CHANGE
When air purifier working hours reach to 3000H, the filter change indicator icon in the display
flashing in red to remind user change filter till filter changed. After filter is changed, touch this
button , display will be on for 1 second and then in standby mode. At the moment, touch
"Power" button to switch on the air purifier.
PROTECTION
The air purifier has protection function. When the filter cover is removed or not installed well, the air
purifier will automatic cut off.
WIFI OPERATION INSTRUCTION:
1. Download “Tuya Smart” from App store. After installment, register by E-mail or mobile number, and
then follow below steps.
2. Long press “Power” button for about 3 seconds (or long press for about 6 seconds to enter AP
mode), display shows WIFI icon and keep twinkling. It means the air purifier has entered the
network state successfully. (If you long press this button for about 10 seconds, the air purifier will exit
the connection with the mobile APP).
3. Enter App, add corresponding device and then follow the operation as App indicated.
4. When the App is connected to the air purifier successfully, the WIFI icon on the screen will be
on, and then theApp can control the air purifier.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20cm
between the radiator & your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
AROMA BOX
1. Draw out aroma box from the top part.
2. Use water-soluble aroma oil and drop on to the sponge.
3. Put the aroma box back into device, the aroma function will remain on when the device is running.
4. To stop the aroma function or when storing the device, clean the sponge in the aroma box.

5. Only drop aroma oil into aroma cotton.
MAINTENANCE:
After using period of time, dust on the sensor will affect its sensitivity. We suggest clean it every two
months. But time can be shortened or extended according to indoor environment.
HOW TO CLEAN THE DUST SENSOR:
Unplug then open the dust sensor cover, and dip the cotton swab in clean water. Clean the lens with
cotton swab. Then wipe the lens with dry cotton swab to make it dry.
TOUBLESHOOTING:
If your air purifier is not working correctly, please check the following causes:
Trouble Possible reasons Shooting Way
No power Fault in power
source
Switch on when the power
source get regular
Not working
Plug not connected
Fault in electric
circuit
Insert the plug again
Try again in other place
Unusual noise
There is foreign
body in the air
purifier
Take to service center.
Dirty filter Replace the filter

3. Consumption power: 2
TECHNICAL SPECIFICATIONS:
1. Input voltage: AC -240V
2. Frequency: 50/60Hz
4. Applicable area: 20m²
5. Noise level: ≤50dB
6. CADR: 82CFM (139m³/H)
7. Operating condition: Temperature: 10℃~45℃
8. Humidity: ≤95%RH
WARRANTYAND SERVICE:
WE GUARANTEE THE UNIT TO BE FREE FROM DEFECTS IN MATERIAL OR
WORKMANSHIP FORAPERIOD OF ONE (1) YEAR FROM THE DATE OF PURCHASE.
Should this unit be operated under conditions other than those recommended or at voltages other than
the voltage indicated on the unit, or any attempts made to service or modify the unit, this will render
WARRANTYVOID. The product you buy may sometimes differ slightly from illustration.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.
120
2W
