Konica Minolta bizhub c3110 User manual

bizhub C3110
Service Launch Guide
07/2014

Konica Minolta bizhub C3110
Table of Contents
bizhub C3110 Specifications ............................................................................................................... 1
Duty Cycle.......................................................................................................................................... 1
Space Requirements........................................................................................................................... 2
Environmental Requirements ............................................................................................................... 2
Electrical Requirements....................................................................................................................... 2
Component Considerations.................................................................................................................. 3
Mixed Original Support........................................................................................................................ 6
Standard Tray Support ........................................................................................................................ 6
Print Drivers ....................................................................................................................................... 6
Print Controller (Standard) ................................................................................................................... 6
Print Specifications ............................................................................................................................. 7
Scanning Function (Standard) .............................................................................................................. 7
PageScope Software........................................................................................................................... 7
Paper Considerations.......................................................................................................................... 8
Paper Weight Conversion Chart ........................................................................................................... 8
Paper Type Specifications ................................................................................................................... 8
How to Build a bizhub C3110 (from start to finish) ................................................................................ 9
Accessory Options for bizhub C3110 Digital Color Printer/Copier/Scanner............................................ 10
Consumable Yields ........................................................................................................................... 10
Documentation................................................................................................................................. 11
Firmware and Drivers........................................................................................................................ 12
New Enhancements to Warranty Solution Bulletin 7689
bizhub C3110 Technical Training Announcement Bulletin 9237
bizhub C3110 Startup Parts Bulletin 9332
SSD Mobile Access: It’s Not Just for Smartphones Bulletin 9140
HTML version Service Manuals now accessible directly from MyKonicaMinolta.com Bulletin 8661
One Stop Product Support - Improvements and Enhancements Bulletin 9214
Successful Searching on MyKonicaMinolta.com Bulletin 9215
National Solutions Group Bulletin 9256
Solutions Support: New Dedicated Phone Number Bulletin 9257
Critical Accident Reporting (CAR) Procedure Bulletin 9267
Material Safety Data Sheets
bizhub C3110 Eco Declaration

Konica Minolta bizhub C3110
Specification & Installation Guide
1
bizhub C3110 Specifications
Type Full Color Printer/Copier/Scanner
Document Holder Stationary (mirror scanning)
Types: Sheets, books (page spreads),
3-dimensional objects
Size: Maximum 8.5" x 14"
Photoconductor Organic Photoconductor
Luminous Source LED
Copying System Laser electrostatic copy method
Developing System Dual-component
Fusing System Belt fusing system
Resolution Scanning: Up to 600 x 600 dpi
Copying/Printing: 600 x 600 dpi,
1200 x 1200 dpi
Paper Plain Paper (60-90 gsm)
Thick Paper* (90-210 gsm)
postcards*, letterhead*, colored paper,
glossy stock*, envelopes**, label sheets*,
recycled paper
*Via Multipurpose and Standard Tray only.
**Via Multipurpose Tray only.
Paper Sizes Multipurpose Tray:
4"(W) x 6"(L) to 8.5"(W) x 14"(L)
Standard Tray:
4"(W) x 6"(L) to 8.5"(W) x 11"(L)
Lower Feeder:
8.5"(W) x 11"(L) to 8.5"(W) x 14"(L)
Paper Tray Capacity Multipurpose Tray: 100 sheets
Standard Tray: 250 sheets
Lower Feeder: 500 sheets
Exit Tray Capacity Plain Paper: 150 sheets
Special Paper: 10 sheets
Warm-up Time 36 seconds or less
at room temperature (73˚ F)
Image Loss Width Position Copy Print
Leading edge: 0.157" 0.165"
Trailing edge: 0.157" 0.165"
Rear edge: 0.157" 0.165"
Front edge: 0.157" 0.165"
First Copy Full Color: 17 seconds or less
Black: 13 seconds or less
First Print Full Color: 12.9 seconds
Black: 12.9 seconds
Print/Copy Speed: Full Color:
Plain paper/letter: 32 ppm single-sided
Thick paper/letter: 16 ppm single-sided
B/W:
Plain paper/letter: 32 ppm single-sided
Thick paper/letter: 16 ppm single-sided
Magnification Ratios Platen: Reduce/Enlarge: 25%–400%
(1% increments)
RADF: Reduce/Enlarge: 25%–200%
(1% increments)
Multiple Copies 1 to 99
Density Control Copy Density: Manual Density Adjustment
(7 steps)
Power Requirements 120V/60 Hz
Power Consumption 990 W or less (max.)
Dimensions 17.6" (W) x 21.4" (D) x 19.7" (H)
Memory 1 GB RAM (2 GB Max.)
Hard Disk Space Optional 320 GB HDD
Weight Approx. Approx. 75.6 lbs.
(base unit with consumables)
Duty Cycle
Up to 120,000 monthly. The maximum monthly duty cycle
describes the maximum number of pages a device can output
on a monthly basis. This specification is a guideline intended to
offer a comparison of durability as it relates to the entire Konica
Minolta MFP and printer product line so that the appropriate
device can be placed in order to meet customer needs.
06/09/2014

2
Konica Minolta bizhub C3110
Specification & Installation Guide
Environmental Requirements
Temperature 50°F to 86°F (operating)
Humidity 15% to 85% (operating)
Engine Noise Printing:
Standby:
54 db
39 db
Ozone
Emission
Monochrome:
Color:
1.5 mg/h or less
3.0 mg/h or less
Electrical Requirements
Line options Dedicated NEMA Diagram for 5-15P
Voltage 120V/60 Hz
Amperage 9.0 A or less
NEMA Part No. 5-15P
Cord Length 6 ft.
Space Requirements
Front View Side View
4.6"
(117)
9.0"
(229)
Right Door
Opened
18.1"(459)
26.9"(684.5)
9.0"
(229)
0.1"
(2.5)
28.5"(723)
15.9"(405)
16.6"(421.5)
17.6"(446.5)
26.6"(675.5)
24.1"(612) 19.7"(500)
34.8"(885)
35.5"(902)
21.4"(544)
20.5"(520)
33.3"(846)
28.7"(729)
Units: Inch(mm)
Units: Inch(mm)

3
Component Considerations
Konica Minolta bizhub C3110
Specification & Installation Guide
HD-P06 Hard Disk Drive*
Type Internal Hard Drive
Capacity 320 GB
Functions Adds additional memory, security, and convenience functions.
Required for printing from USB.
FK-512 Fax Kit
Communication Super G3
Compatible Lines PSTN, PBX
Modem Speed 2.4 – 33.6 kbps
Compression MH/MR/MMR/JBIG
Transmit Paper Size Max. 11” x 14”
Receive Paper Size Max. 11” x 14”
Transmission Speed Less than 3 sec. (V.34, 33.6 Kbps, JBIG)
Scan Speed Up to 31 opm
Transmission Size Flatbed: 8.5” (W) x 14” (L)
ADF: 8.5” (W) x 39” (L)
Receiving Size Max: 8.5” (W) x 14” (L)
Fax destinations 2,100 (2,000 single + 100 group)
i-Fa x Yes
PC-Fax Yes
Functions Program, Select from Address Book, Group Dial Program, Auto
Redial, Original Type (Text, Text/Photo, Photo), Density, Memory TX,
Busy / Error Redial, Broadcast TX, Timer TX, Confidential TX, Relay
TX Request, Polling RX, TX Original Size Setting, Mixed Original TX,
Ecm Off, V34 Off TX, Password TX, Memory RX, Memory Vicarious
Execution RX, Password RX, Call Rejection, Confidential Print,
Auto Reduction Print, Full Size Print, Tel/Fax Auto Switch, Audio
Response, Answering Machine Connection, Number Display, Dial-
in, Vicarious Execution Forward, Remote RX, Nighttime Receiving
User Box Destination Setting, Activity Report, TX Result Report,
Broadcast Result TX Report, Broadcast Result RX Report, Various
Lists, Long Paper Original TX/RX, PC-Fax TX/RX, Mistake TX
Prevention
MK-P04 Fax Mount Kit
Type Fax mount kit
Function Required for installation of FK-512
AU-202H
AU-204H
KP-101
AU-202H
AU-204H
KP-101
* Can only be purchased from Konica Minolta.

4
Component Considerations
Konica Minolta bizhub C3110
Specification & Installation Guide
PF-P14 Lower Feeder Unit
Type 1 x 500 sheet drawer
Support Paper Weight 16–24 lb bond
Support Paper Size 8.5" x 11" to 8.5" x 14"
Paper Capacity 500 Sheets
Power Requirements Supplied from main body
SCD-25 Copy Desk
Type Storage drawer only
Function Storage of accessories, paper, supplies, etc. Brings machine
toworking height.
1 GB Expanded Memory Unit*
Type DIMM
Capacity 1 GB
Functions Increases the printable file size.
SX-4600WAN Wireless Network Adapter
Type Miscellaneous Option
Functions Provides wireless connectivity.
AU-201H Proximity Card Authentication Unit**
Dimensions (WxHxD) 3.625"x2.5"x0.625"
Weight 0.25 lb.
Power Supply Supplied from USB Port
System Conditions Ambient Temperature: 32°to 104° F
(operating mode) Humidity: 20% to 85%
System Conditions Ambient Temperature: -4°to 122° F
(non-operating mode) Humidity: 20% to 85%
Radio Law Division Self-Guided Read-Write Communication Facility
Applicable Card ISO 14443 Type A, FeliCa-based non-contact IC Card
Acquired Standard VCCI Class B
AU-202H
AU-204H
AU-201H
AU-202H
AU-204H
AU-201H
* Can only be purchased from Konica Minolta.
** Requires optional Hard Disk Drive HD-P06.

5
Component Considerations
Konica Minolta bizhub C3110
Specification & Installation Guide
AU-202H HID iClass Card Reader**
Dimensions (WxHxD) 4.0" x 1.9" x 0.9"
Weight 0.25 lb.
Power Supply Supplied from USB Port
System Conditions Ambient Temperature: 31˚ to 150˚ F
(operating mode) Humidity: 5% to 95%
Transmit Frequency 13.56 MHz
Environmental IP55
Certifications UL294/cUL (US), FCC Certification (US), IC (Canada), RoHS
Card Type Compatibility All HID 2k, 16k or 32k iClass Cards
HID iClass Card 26-bit, HID Corporate 1000®
Format Compatibility
LK-106 i-Option License Kit**
Type License key
Function Supports Barcode Font Printing
LK-107 i-Option License Kit**
Type License key
Function Supports Unicode Font Printing
LK-108 i-Option License Kit**
Type License key
Function Supports OCR Font Printing
LK-111 i-Option License Kit
Type License Key
Function Provides ThinPrint®client support
CS-1 Convenience Stapler
Type Standalone electronic stapler
Stapling Capacity Up to 50 sheets
Paper Weight Up to 90 gsm
Durability Cycle Up to 200,000 stapling operations
Staple Position Side or corner of document
Type of Clinch Flat clinch
Dimensions (WxHxD) 5.31' x 5.7" x 7.48"
Weight Approx. 3.74 lb.
Power Supply AC adaptor (supplied). Separate power output required.
Refill Staples SK-602 (No. 505: 5,000 staples)
AU-202H
AU-204H
AU-201H
AU-202H
AU-204H
AU-201H
** Requires optional Hard Disk Drive HD-P06.

6
Konica Minolta bizhub C3110
Specification & Installation Guide
Mixed Original Support •Possible × Not Possible
Maximum Document Width1
Document Size2
11" x 17"
landscape
8.5" x 11"
portrait
8.5" x 14"
landscape
8.5" x 11"
landscape
5.5" x 8.5"
portrait
5.5" x 8.5"
landscape
8.5" x 14" (L)×ו•× ×
8.5" x 11" (L)×ו•× ×
1Indicates the width of the widest document size of the mixed originals.
2Indicates the document sizes that can be mixed together based on the maximum document width.
Standard Paper Tray Support
Main Unit – bizhub C3110 (Standard Tray and Multipurpose)
Component Capacity Size Weight
Multipurpose 100 sheets 4"x 6" to 8.5" x 14" Up to 110 lb. index
Standard Tray 250 sheets 4" x 6" to 8.5" x 11" Up to 110 lb. index
Print Controller (Standard)
Type Emperon Print System
CPU MV78230 (1.066 GHz)
Memory 1 GB (2 GB max.)
Print Speed Color: 32 ppm Letter Portrait
B&W: 32 ppm Letter Portrait
Print Resolution 600 x 600 dpi
1200 x 1200 dpi
PDL PostScript 3, PCL 6, XPS
Ethernet
Protocol
TCP/IP, IPP over SSL, IPv6, DPWS (WSD),
IPsec (IPv6), NTP, SSL/TLS, Dynamic DNS,
LLTD, IEEE 802.1x, DHCPv6, HTTP, HTTPS,
IPP 1.1, SNMP, FTP, DHCP, Boot P, SLP, SMB
Supported OS Windows XP x32/x64 (SP2), Windows Vista
x32/x64, Windows 7 x32/x64, Windows 8
x32/x64, Windows Server 2003 x32/x64,
Windows Server 2008 x32/x64;
Macintosh OS X (10.2.8 or later),
SuSE Linux Enterprise Desktop 10,
Red Hat Enterprise Linux 5 Desktop
Font PCL Resident Fonts: 80 outline
PS3 Emulation Resident Fonts: 137
Interface Gigabit Ethernet (10/100/1000BaseTX);
USB 2.0; USB 1.1
Print Drivers
Page Description
Language
Printer
Driver
Supported
Operating Systems
PCL 6
Emulation
Konica
Minolta
Windows 7 x64/Windows 7,
Windows 8, Windows Vista x64/
Windows Vista/Server 2003 x64/
Server2003/XP x64/
XP(SP2+)/2000(SP4+)
PostScript 3
Emulation
Konica
Minolta
Windows 7 x64/ Windows 7,
Windows 8, Windows Vista x64/
Windows Vista/Server 2003 x64/
Server2003/XP x64/
XP(SP2+)/2000(SP4+)
PPD Konica
Minolta
Macintosh OS X 10.2.8 or later
XPS v1.0 * Konica
Minolta
Windows Vista x64/Vista,
Windows 7 x64/Windows 7,
Windows 8

Konica Minolta bizhub C3110
Specification & Installation Guide
7
Scanning Function (Standard)
Type Full-Color Scanner
Scanning Size Up to 8.5" x 14"
Scanning Resolution 600 x 600 dpi, 300 x 300 dpi,
200 x 200 dpi, 150 x 150 dpi
Scanning Speed 300 dpi: Up to 31 ppm1
Main Function Scan-to-Email, Scan-to-SMB,
Scan-to-FTP, Scan-to-USB,
Scan-to-HDD, Scan-to-WebDAV,
TWAIN, WIA
Interface Gigabit Ethernet (10/100/1000 Base-TX),
US B 1.1
Protocol TCP/IP (FTP, SMB, SMTP, WebDAV)
Support OS Windows XP, Vista, Windows 7, Windows8,
Server 2003, Server 2008, Server 2012,
Mac OS X (10.3 or later)
Output Format PDF, JPEG2, TIFF, XPS, Compact PDF,
PDF/A
Driver Network TWAIN, WIA (1.0/2.0) Driver
(Windows only)
Address Setting LDAP
1Scan speed varies by resolution and amount of data being scanned.
2Single page at a time.
PageScope Software
Network, Device Management and User Tools
PageScope Direct Print*
PageScope Data Administrator
Download Manager*
Print Status Notifier
Driver Packaging utility
PageScope Mobile
PageScope Net Care Device Manager
PageScope Web Connection
PageScope Enterprise Suite Plug-in
PageScope Account Manager*
PageScope Authentication Manager*
PageScope My Print Manager*
Print Specifications
Item Specifications
Model Built-in print system
Power Supply Common with the main body
CPU MV78230 (1.066 GHz)
RAM 1 GB (2 GB max.)
Hard Disk 320 GB (Optional)
Interface Standard Ethernet 10/100/1000 Base TX,
Standard USB 2.0, USB 1.1
Ethernet Protocol TCP/IP, IPP over SSL, IPv6, DPWS (WSD),
IPsec(IPv6), NTP, SSL/TLS, Dynamic DNS,
LLTD, IEEE 802.1x, DHCPv6, HTTP, HTTPS,
IPP 1.1, SNMP, FTP, DHCP, Boot P, SLP, SMB
Print Speed Color: 32 pages/minute
B&W: 32 pages/minute
First Print Time Color: 12.9 seconds or less
B&W: 12.9 seconds or less
Operating
Environment
Conditions
50˚ to 86˚ F, 15-85% RH
Resolution 600 x 600 dpi
1200 x 1200 dpi
Supported
Paper Sizes
4" x 6" to 8.5" x 14"
Printer Fonts PCL Resident Fonts: 80 outline
PS3 Emulation Resident Fonts: 137
Compatible
Computers
IBM PC or compatible and Macintosh
Supported OS Windows XP x32/x64 (SP2), Windows Vista
x32/x64, Windows 7 x32/x64, Windows 8
x32/x64, Windows Server 2003 x32/x64,
Windows Server 2008 x32/x64;
Macintosh OS X 10.2.8 or later,
SuSE Linux Enterprise Desktop 10,
RedHat Enterprise Linux 5 Desktop

8
Konica Minolta bizhub C3110
Specification & Installation Guide
Paper Weight Conversion Chart
Caliper
gsm Bond Offset Cover Tag Index Point Bristol inches mm
60.20 16 40 22 37 33 3.2 27.4 0.0032 0.081
67.72 18 45 24 41 37 3.6 30.9 0.0036 0.092
75.20 20 50 28 46 42 3.8 34.3 0.0038 0.097
90.30 24 60 33 56 50 4.8 41.2 0.0048 0.120
105.35 28 70 39 64 58 5.8 48.1 0.0058 0.147
109.11 29 73 40 62 60 6.0 49.8 0.0060 0.152
116.63 31 81 45 73 66 6.1 53.2 0.0061 0.155
131.68 35 90 48 80 74 6.2 60.1 0.0062 0.157
135.45 36 90 50 82 75 6.8 61.8 0.0068 0.173
146.73 39 100 54 90 81 7.2 67.0 0.0072 0.183
150.50 40 100 56 93 83 7.3 68.7 0.0073 0.185
161.78 43 110 60 100 90 7.4 73.8 0.0074 0.188
165.55 44 110 61 02 92 7.6 75.5 0.0076 0.193
176.83 47 120 65 108 97 8.0 80.7 0.0078 0.198
199.41 53 135 74 122 110 9.0 91.0 0.0085 0.216
Paper Considerations
Paper Size Conversion Chart
Paper Letter Legal Statement Custom
Measurement 8.5" x 11" 8.5" x 14" 5.5" x 8.5" 3.6"(W) x 5.8"(H) to 8.5"(W) x 14"(H)
Normal (Plain Paper)
Normal paper is for general use and is called “PPC paper.”
The normal paper is usually not a recycled paper. Specify
[Normal] to the tray to which the normal paper or the recycled
paper is loaded.
Thick Paper 1
Thick Paper 1 is paper weighing between 24.25 to 40 lb. bond
It can be fed via the bypass tray1or main tray2.
Thick Paper 2
Thick Paper 2 is paper weighing between 40 to 55.5 lb. bond
It can be fed via the bypass tray1or main tray2.
Envelopes
Envelopes can be fed through the bypass tray1.
1. Up to 10 sheets.
2. Up to 20 sheets.
Paper Type Specifications

Konica Minolta bizhub C3110
Specification & Installation Guide
9
Hard Disk
(Optional)
USB Flash Drive
Memory
Wireless LAN
(SX-4600WAN)
(Optional)
FK-512 Analog Fax
(Optional)
Barcode Font
LK-106 (Opt.)
Unicode Font
LK-107 (Opt.)
OCR Font
LK-108 (Opt.)
ThinPrint Client
LK-111 (Opt.)
How to Build a bizhub C3110 System (from start to finish)
Multipurpose Tray
(100 sheets)
Step 1: Base Unit
C3110 Digital Color Printer/Copier/Scanner
(Includes PS & PCL Controller, Automatic Duplex Unit,
Reversing Automatic Document Feeder, 1 GB Standard
Memory, Standard USB2.0 (supports local printing), Toner
andCMYK Imaging Units, One‑year Warranty)
Step 2: Paper Handling Options
Lower Feeder Unit (500 sheets)
Automatic Duplex Unit (Standard)
Step 3: Image Controller
Emperon Print System (PCL/PS) (Standard)
Step 4: Storage and Memory Options
320 GB HDD
1 GB Additional Memory
Step 5: Analog Fax Options
FK-512 Fax Kit (Requires MK‑P04)
MK-P04 Mount Kit for FK-512
Step 6: Finishing Option
CS-1 Convenience Stapler
Step 7: Additional Options
AU-201H Proximity Card
AuthenticationUnit
AU-202H iClass Card
AuthenticationUnit
LK-106 i-Option License Kit
Barcode Printing
LK-107 i-Option License Kit
Unicode Font Printing
LK-108 i-Option License Kit
OCR Font Printing
LK-111 i-Option License Kit
ThinPrint®Client Support
SX-4600 WAN
Wireless Network Adapter
Output Tray
(150 sheets)
Standard Reversing Automatic
Document Feeder
Control Panel
Lower Feeder Unit
(500 sheets)
(Optional)
Standard Paper Tray
(250 sheets)
SCD-25 Copy Desk
AU-202H
iClass Card
Authentication Unit
(Optional)
AU-201H
Proximity Card
Authentication Unit
(Optional)
CS-1
Convenience
Stapler
(Optional)
Automatic
Duplex Unit

10
Konica Minolta bizhub C3110
Specification & Installation Guide
Accessory Options for bizhub C3110 Digital Color Printer/Copier/Scanner
DESCRIPTION ITEM NO. NOTES
BASE UNIT
C3110 Digital Color Printer/
Copier/Scanner
A6 DT011 Includes PS & PCL Controller, Automatic Duplex Unit, Reversing Automatic Document
Feeder, 1 GB Standard Memory, Standard USB 2.0 (supports local printing), Toner
andCMYK Imaging Units, anda one-year warranty.
PAPER HANDLING OPTIONS
Lower Feeder Unit (500 sheets) A73HWY1 Lower Feeder Unit adds 500 sheets of paper capacity (8.5" x 11" or 8.5" x 14").
SCD-25 Copy Desk 7640015306 Adds storage and mobility. Brings printer to operational height.
STORAGE AND MEMORY OPTIONS
320 GB internal hard disk A734WY1 Adds proof then print, secured job, print and hold, usb flash drive direct print
and stored job functions. Required for i-Option and card reader support.
1 GB expansion memory — Adds 1 GB memory for faster processing.
FINISHING OPTION
CS-1 7640013463 Standalone electronic stapler.
ADDITIONAL OPTIONS
LK-10 6** A0PD019 i-Option License Kit provides Barcode Font printing support.
LK-107** A0PD01F i-Option License Kit provides Unicode Font printing support.
LK-10 8** A0PD01G i-Option License Kit provides OCR Font printing support.
LK-111 A0PD01K i-Option License Kit provides ThinPrint®client support.
AU-201H** 7640005064 Allows access to AiO via HID proximity cards. Optional HDD required.
AU-202H** 7640008394 Allows access to AiO via HID iClass cards. Optional HDD required.
SX-4600WAN SX4600WAN Provides wireless connectivity.
ANALOG FAX OPTIONS
FK-512 A6 E DW11 Supports single-line fax capabilities. MK-P04 Mount Kit required.
MK-P04 A735WY1 Mount kit required for FK-512.
CONSUMABLE YIELDS*
CONSUMABLE ITEM NO. YIELD
Imaging Unit – K A73303F 30,000
Imaging Unit – C A7330KF 30,000
Imaging Unit – M A7330EF 30,000
Imaging Unit – Y A73308F 30,000
Toner – K A0X5135 6,000
Toner – C A0X5435 6,000
Toner – M A0X5335 6,000
Toner – Y A0X5235 6,000
Transfer Belt Unit A1480Y1 100,000
2nd Transfer Roller A1480Y2 100,000
Waste Toner Bottle A1AU0Y1 30,000
Fusing Unit A148010 100,000
* Approximate yield at 5% coverage.
** Requires optional hard disk drive.

Konica Minolta bizhub C3110
Documentation Information
All documentation can be downloaded from MyKonicaMinolta.com by clicking on Product Reference
Materials under the Products Portlet.
User Manuals
bizhub C3110 Scan Functions User Guide
bizhub C3110 Quick Start User Guide
bizhub C3110 Print Functions User Guide
bizhub C3110 PC-Fax Functions User Guide
bizhub C3110 Maintenance Troubleshooting User Guide
bizhub C3110 Introduction User Guide
bizhub C3110 Fax Functions User Guide
bizhub C3110 Description of Utility Keys
bizhub C3110 Copy Functions User Guide
bizhub C3110 Applied Functions User Guide
bizhub C3110 Advanced Functions User Guide
Installation Instructions
bizhub C3110 Set Up Guide
Service Manuals
bizhub C3110 PDF Service Manual
bizhub C3110 HTML Service Manual
Parts Manuals
bizhub C3110 Parts Manual
PF-P14 Parts Manual
HD-P06 Parts Manual
FK-512 Parts Manual
MK-P04 Parts Manual
11

Program Release Information
CSES ID-No. DLBT1404696EN00
Model: bizhub C3110
Title: Initial Mass-production Program (Controller Firmware) 2014/4/15
1/1
1. Release version and download file name
The newly released program version and download file name are as follows.
[Release Version]
Model Program Name Current Ver. New Ver. Download file name SHA-256
bizhub
C3110 Controller firmware - A6DT30G0116-
999
bizhubC3110_Cont_A6
DT30G0116-999.zip
8bd521b569f21b82e59aa
87a94c87bc9aebaca8998
6dea4f7335e084ebcecf1b
[Download file name]
bizhubC3110_Cont_A6DT30G0116-999.zip
PRI_DLBT1404696EN_0.doc
2. Changes
This is the initial version.
3. Restrictions
<Planned to be supported in MR of around the middle of Nov,2014.>
- When the machine wakes up from Deep Sleep mode with a USB flash memory connected to it, sometimes ”USB CONN
ERR” is displayed and printing cannot be done.(This does not occur if a USB flash memory is connected during Deep
Sleep mode. It occurs when the machine enters Deep Sleep mode with a USB flash memory connected and wakes up
later.)
- If you specify 2W or below as power consumption for Deep Sleep mode (development goal), sometimes the machine
does not wake up.
(Remove the function that sets the power consumption to 2W or below.)
- When there is no HDD installed, if canceling a copy job during Memory Full caused by paper empty or something, the job
status will be shown as “Printing” in PSWC although the true status is “Being cancelled”.
- During a fax transmission, if you start a copy job and press Stop or Reset key while scanning the copy document, you
will see “Please wait…” on the operation panel. If the fax job has been completed before the message “Are you sure to
cancel the job?” appears, the “Please wait…” message will be kept displayed.
<The following item remains unsupported this time.>
- When the part life of the second transfer roller, transfer belt, or the fixer reaches 256K pages, their life information will be
cleared. (Therefore it appears to be as if there is still remaining life.)
(Based on the product specification, 100K is the normal life value. This phenomenon occurs because 256K exceeds the
normal life value.)
4. Programs to be applied at the same time
There is no specific program to be applied with this firmware.
However, using with the latest version programs is recommended.
5. How to install
Please refer to "J. Rewriting of firmware ", Service Manual.
*Company names and product names in this document are the registered trademarks for respective companies.
Copyright(C) 2014 KONICA MINOLTA, INC.
12

Program Release Information
CSES ID-No. DLBT1408853EN00
Title: KONICA MINOLTA Universal Print Driver Ver.2 Maintenance Release 5 (PCL/Version 2.50.0.0)
2014/05/30
1/10
1. Release version and download file name
The newly released program version and download file name are as follows.
When a Universal Printer Driver which is older than this version (v2.50.0.0) is installed in your PC, if this version
(v2.50.0.0) is updated by Add install, the Printing preferences and the Printer properties will not be displayed
correctly. If this version (v2.50.0.0) is installed by the installer (Setup.exe), the following message will be
displayed and this version (v2.50.0.0) cannot be installed.
"The printer driver is not a target for update."
Please be sure to install this version (v2.50.0.0) after deleting the older version.
[Release version]
Program Name Current Ver. New Ver. Language Install Type
KONICA MINOLTA
Universal PCL v2.40.0.0 v2.50.0.0
JA/EN/FR/IT/DE/ES/
KO/ZH-CN/ZH-TW Exe type
Model Child Driver Version Note
Baseline *1
KONICA MINOLTA 163/211 1.0.1.UPD_05
KONICA MINOLTAA3 common *3
KONICA MINOLTA mc8650 1.0.1.UPD_03
KONICA MINOLTAA4 common *2
KONICA MINOLTA C30P/C31P
KONICA MINOLTA C20
KONICA MINOLTA C20P
KONICA MINOLTA 40P
KONICA MINOLTA mc5550/mc5570
KONICA MINOLTA mc5650/mc5670
KONICA MINOLTA mc4650
KONICA MINOLTA mc4695MF
KONICA MINOLTA pp4650/pp5650
KONICA MINOLTA mc5450
1.0.0.UPD_02
KONICA MINOLTA 500/420/360 3.0.2.UPD_03
KONICA MINOLTA 501/421/361 2.0.1.UPD_03
KONICA MINOLTA 750/600 3.1.0.UPD_03
KONICA MINOLTA 751/601 (1.0.3.UPD_03) 1.0.3.UPD_03 MFP FW ver.19 series or older
KONICA MINOLTA 751/601 (2.0.0.UPD_03) 2.0.0.UPD_03 MFP FW ver.20 series or later
KONICA MINOLTA C650/C550/C451 6.3.0.UPD_04
KONICA MINOLTA C450/C450P/C351 1.0.0.UPD_04
KONICA MINOLTA C352/C352P/C300 1.0.1.UPD_03
KONICA MINOLTA C250/C250P 1.1.1.UPD_04
KONICA MINOLTA C252/C252P 1.1.1.UPD_03
KONICA MINOLTA C353/C253/C203 6.3.0.UPD_04
KONICA MINOLTA 350/250/200 1.1.2.UPD_03
KONICA MINOLTA 362/282/222 1.1.0.UPD_03
KONICA MINOLTA
C652(DS)/C552(DS)/C452 3.0.16.UPD_03
KONICA MINOLTA C360/C280/C220 3.0.16.UPD_05
KONICA MINOLTA 423/363/283/223 1.1.2.UPD_03
KONICA MINOLTA 652/602/552/502 1.1.0.UPD_05
KONICA MINOLTA C35
KONICA MINOLTA C35P/mc4750
KONICA MINOLTA C25
1.1.2.UPD_03
KONICA MINOLTA 20 1.0.0.UPD_04
KONICA MINOLTA 20P 1.0.0.UPD_04
KONICA MINOLTA 42/36 (EU/JP) 1.0.0.UPD_01
KONICA MINOLTA 42/36 2.0.0.UPD_02
KONICA MINOLTA C754(e)/C654(e) 4.1.0.UPD_01
13

Program Release Information
CSES ID-No. DLBT1408853EN00
Title: KONICA MINOLTA Universal Print Driver Ver.2 Maintenance Release 5 (PCL/Version 2.50.0.0)
2014/05/30
2/10
KONICA MINOLTA 195/215/235 1.0.0.UPD_06
KONICA MINOLTA
C554(e)/C454(e)/C364(e)/C284(e)/C224(e) 4.1.0.UPD_01
KONICA MINOLTA 754(e)/654(e) 4.1.0.UPD_01
KONICA MINOLTA 4700P/4000P/3300P 1.0.9.UPD_07
KONICA MINOLTA
554e/454e/364e/284e/224e 4.1.0.UPD_01
KONICA MINOLTA C3850/C3350 1.3.1.UPD_03
KONICA MINOLTA 4020/3320 1.2.0.UPD_05
KONICA MINOLTA 4750/4050 1.1.1.UPD_02
KONICA MINOLTA 25e 1.0.0.UPD_04
KONICA MINOLTA C3100P 1.1.2.UPD_03
KONICA MINOLTA C3110 1.0.0.UPD_03
*1 Baseline: Common driver (mc1650/2550/7440/7450/7450II/C10P, etc)
You can select 163/211 from Model Name.
*2 KONICA MINOLTAA4 common: KM Common driver (pagepro Series, magicolor (A4))
You can select C30P/C31P/C20/C20P/40P/mc5550/mc5570/mc5650/mc5670/mc4650/mc4695MF/pp4650/pp5650/
mc5450 from Model Name.
*3 KONICA MINOLTAA3 common: KM Common driver (bizhub Series (A3), mc8650, etc)
You can select mc8650 from Model Name.
*4 When trying to connect to a device from Device Selector window and individual child driver is not contained, KM
common driver may be used. In case the child driver for each model, KM common driver can not be used, the common
driver (Baseline) will be selected.
[Download file name]
KM_UniversalDriver_pcl_v2.50.0.0_x86.zip
KM_UniversalDriver_pcl_v2.50.0.0_x64.zip
PRI_DLBT1408853EN_0.doc
14

Program Release Information
CSES ID-No. DLBT1408853EN00
Title: KONICA MINOLTA Universal Print Driver Ver.2 Maintenance Release 5 (PCL/Version 2.50.0.0)
2014/05/30
3/10
[Supported OS] OS WHQL
Windows Server 2003, Standard Edition
Windows Server 2003, Enterprise Edition
Windows Server 2003 R2, Standard Edition
Windows Server 2003 R2, Enterprise Edition
Windows Server 2003, Standard x64 Edition
Windows Server 2003, Enterprise x64 Edition
Windows Server 2003 R2, Standard x64 Edition
Windows Server 2003 R2, Enterprise x64 Edition
Yes
Windows Vista Home Basic*
Windows Vista Home Premium*
Windows Vista Ultimate*
Windows Vista Business*
Windows Vista Enterprise*
Yes
Windows Server 2008 Standard*
Windows Server 2008 Enterprise* Yes
Windows Server 2008 R2 Standard
Windows Server 2008 R2 Enterprise Yes
Windows 7 Home Basic*
Windows 7 Home Premium*
Windows 7 Professional*
Windows 7 Enterprise*
Windows 7 Ultimate*
Yes
Windows 8 *
Windows 8 Pro*
Windows 8.1 *
Windows 8.1 Pro*
Windows Server 2012 Standard
Windows Server 2012 Datacenter
Windows Server 2012 Essentials
Windows Server 2012 R2 Standard
Windows Server 2012 R2 Datacenter
Windows Server 2012 R2 Essentials
Yes
* Both 32bit (x86), 64bit (x64)
Support the following operation environments.
- Windows Server 2003 / 2008 Cluster Server Service (32/64 bit)
- Windows Server 2008 R2 / 2012 / 2012 R2 Cluster Server Service
- Citrix Presentation Server 4.5
- Citrix XenApp 5.0/6.0
- Terminal Services
- Remote Desktop
- Terminal Services Easy Print
- Remote Desktop Easy Print
15

Program Release Information
CSES ID-No. DLBT1408853EN00
Title: KONICA MINOLTA Universal Print Driver Ver.2 Maintenance Release 5 (PCL/Version 2.50.0.0)
2014/05/30
4/10
2. What changed
2-1. The following issue is modified in this version.
1. Following Child drivers are added.
- KONICA MINOLTA C3100P
- KONICA MINOLTA C3110
2. Support the following models.
- KONICA MINOLTA C3100P
- KONICA MINOLTA C3110
- KONICA MINOLTA C754e/C654e,C554e/C454e/C364e/C284e/C224e,754e/654e,554e/454e/364e/284e/224e
Function Version 5
- KONICA MINOLTA 4750/4050 Ver.A6F730G0236-999
- KONICA MINOLTA C3850/C3350 Ver.A3GN30G0206-999
3. Multi-Language is supported.
4. When installing the driver by Add install, Device Selector is not shown.
3. Restrictions
1. The message "Operation could not be completed." may be displayed when you open the Device Selector window
from Printing Preferences...(document property) and then, close with Cancel button.
2. With the Windows Server 2003:
1) To open the help topic, "?" button on the Upper right on the driver dialog does not work.
2) To open the help topic, the right button click menu of the mouse does not work.
Note: Windows Vista does not have above two features. It is the restriction from OS.
Note: To open help topic, please click help button on the driver dialog.
Apply to the following models:
KONICA MINOLTA C450/C450P/C351
KONICA MINOLTA C352/C352P/C300
KONICA MINOLTA C250/C250P
KONICA MINOLTA C252/C252P
KONICA MINOLTA 350/250/200
KONICA MINOLTA 500/420/360
KONICA MINOLTA 750/600
3. There are following restrictions under IPv6 connection.
<The case that is used linklocal address>
The driver cannot acquire the device information but, Printing is possible.
Use IPv4 to acquire the device information.
<Connecting to MFP with an IPv6 global address does not work.>
Please connect with IPv4 address or please use IPv6 link local address when it is not necessary to be retrieved the
device information.
Apply to the following models:
KONICA MINOLTA C650/C550/C451
KONICA MINOLTA C353/C253/C203
KONICA MINOLTA C450/C450P/C351
KONICA MINOLTA C352/C352P/C300
KONICA MINOLTA C250/C250P
KONICA MINOLTA C252/C252P
KONICA MINOLTA 350/250/200
KONICA MINOLTA 500/420/360
KONICA MINOLTA 750/600
KONICA MINOLTA 751/601
4. When printing the job from Microsoft PowerPoint2007, "Remove White Background" does not work in the Universal
Print Driver.
16

Program Release Information
CSES ID-No. DLBT1408853EN00
Title: KONICA MINOLTA Universal Print Driver Ver.2 Maintenance Release 5 (PCL/Version 2.50.0.0)
2014/05/30
5/10
5. If you print the job from Microsoft Excel when selecting the destination printer on the Device Selector and using it,
paper size and printing direction that were saved in Excel file may not be reflected.
Countermeasure
Please select Excel file >Print >Properties and perform setting again.
6. If you open "Properties" when using the Universal Print Driver under the following conditions, do not switch the
application until the Device Selector is opened.
When the following sympton1 occurs, please close the Device Selector.
Condition:
32bit Application is installed on Windows 64bit OS.
Procedure/ Symptom
1) Open Print> Properties of 32bit application (ex. applicationA). After that, if you switch to another application (ex.
applicationB), switched application (applicationB) does not respond.
2) If you close "Print Dialog" of 32bit application (applicationA) under the condition1, 32bit application
(applicationA) does not respond.
7. Incorrect driver may be selected when trying to print on the same MFP with changing the driver like example below.
Occurring case
- The firmware for the MFP updated.
- When you selected the driver manually, and the driver manually selected was the different one from the driver
listed on the network search.
Occurring PDL
PCL Driver
Countermeasure
User who operates the MFP performs Logoff, and login to the MFP again.
8. When printing the file has a large image from KONICA MINOLTA 20/20P PCL Child Driver, the Black line appears on
the image.
Countermeasure
Use KONICA MINOLTA 20/20P PS Driver or KONICA MINOLTA 20/20P PCL Driver of product.
9. In Dynamic Mode, even if change the port from the Device Selector screen, the port may not be changed when
opening Printer properties. (Specification for OS)
10. On Microsoft Publisher 2007, there is a restriction as below.
After installing Universal Print Driver, if you never use it and print the job from Dynamic Mode, Printing Preferences
is not reflected in the printing result.
Countermeasure
1) Close Microsofot Publisher 2007.
2) Open Printing Preferences of Universal Print Driver from "Printer and Faxes".
3) Select the Device from the Device Selector screen and click "OK" button in displayed Printing Preferences
screen.
17

Program Release Information
CSES ID-No. DLBT1408853EN00
Title: KONICA MINOLTA Universal Print Driver Ver.2 Maintenance Release 5 (PCL/Version 2.50.0.0)
2014/05/30
6/10
11. In Citrix Presentation Server 4.5/Citrix XenApp 5.0, there are restrictions as below.
- Dynamic Mode is not supported. Please use Traditional Mode.
- When installing Universal Print Driver to Client PC from Traditional Mode, if Admin Privilege User opens "Printing
Preferences" or "Properties" of AutoCreate Driver, the Device Selector screen is started. (Specification for
Presentation Server 4.5/ Citrix XenApp 5.0)
It is possible to print the job if select output port and child driver from started Device Selector screen.
If any user except Admin Privilege user performs this, this symptom does not occur.
- If perform the following operation, cannot close the Properties screen of Citrix Universal Print Driver. (Specification
for Universal Print Driver of Citrix)
1) Create the printer icon from Traditional Mode on the Client PC.
2) Connect to the Citrix.
3) When open the Properties of AutoCreate Printer icon from "Printer and Faxes", the Properties of Citrix
Universal Print Driver is displayed.
4) If click "Local Printer Settings" button, the Properties of KONICA MINOLTA Universal Print Driver is displayed.
Click "OK".
5) Even if click OK or Cancel from the Properties of Citrix Universal Print Driver, the Properties screen is not
closed.
If open the Properties from the application, this symptom does not occur.
Countermeasure
- Please open the Properties setting from the printer icon that created from Traditional Mode of Client PC and
perform setting before connecting to the Citrix.
12.When using Dynamic Mode, there is a restriction as below.
When changing the Device from the Device Selector screen, Printing Preferences setting may not go back to the
default.
Countermeasure
Please select "Default Setting" from the Favorite Setting and set Printing Preferences to the Default.
Occurring PDL
PCL Driver
13.Any user except the user installed Universal Print Driver or Admin Privilege User cannot open the Device Selector
screen.
When open the Device Selector screen, please use "Run as administrator".
Occurring OS
- WindowsVista
- Windows Server 2008
14. In CorelDRAW Graphics Suite, if select "Collate", it does not work.
Countermeasure
1) Select "File"> "Print".
2) Click "References" button and select "Printer Preferences" of Driver.
3) Select "Collate" of "Printer Preferences".
18
