Konig CMP-MOBPLAY10 User manual

MEDIA PLAYER ENCLOSURE
CMP-MOBPLAY10
CMP-MOBPLAY30
1. Package contents
For CMP-MOBPLAY10:
1 Media player enclosure
Carrying bag
Remote control
Power adapter
Stand
Driver CD
Manual
2 A/V cables
USB cable
For CMP-MOBPLAY30:
1 Media player enclosure
Remote control
Power adapter + cable
Driver CD
Manual
2 A/V cables
USB cable
2. System requirements
Windows 98, ME, 2000, XP + SP2, Vista
Pentium II 233 MHz or higher
128 MB RAM (256 MB recommended)
CD-ROM drive
Free USB port (USB 2.0 recommended)
For media playback: FAT32 formatted HDD
3. Hardware installation
For CMP-MOBPLAY10:
Step 1: Open the enclosure.
-1-
Step 2: Lift up board carefully and slide backwards to remove.
Step 3: Gently lift up the board.
Step 4: Attach the board to the hard drive with the screws.
Step 5: Slide the hard drive with attached board back into the enclosure.
-2-
ENGLISH
INSTRUCTIONS
EN

Step 6: Align the board with the connections in the back plate and close the enclosure.
For CMP-MOBPLAY30:
Step 1: Open the enclosure by unscrewing the back panel and pulling out the board.
Step 2: After removing the board, connect the data and power cables to the hard drive and
slide it carefully onto the board.
Step 3: . Connect the hard drive to the board using the screws.
-3-
Step 4: Gently slide the board with the hard drive connected to it back into the aluminum
enclosure. Close up the enclosure with two screws on each side of the back plate.
4. Connections
For CMP-MOBPLAY10:
The enclosure has the following connections and buttons:
- Backup button (used for back-up software on PC)
- Switch (to choose between TV/Off/USB mode)
- USB 2.0 connection
- Video output connection
- Audio output connection
- 5V Power connection.
If you want to use your media player as a USB 2.0 storage drive, then put the switch to USB
mode. If you want to switch off the player, set the switch to Off mode. Finally, if you want to
use the media player to display multimedia on TV, then set the switch to TV mode.
For CMP-MOBPLAY30:
The enclosure has the following connections and buttons:
- Copy button (used for back-up software on PC)
- USB 2.0 connection
- Video output connection
- Audio output connection
- Power connection.
-4-
EN
EN

5. Remote control functions
The remote control has the following functions for CMP-MOBPLAY10:
Button
Function
PLAY
Takes you to play or execute the current selection.
UP
Direction button to move cursor on the screen.
DOWN
Direction button to move cursor on the screen.
LEFT
Direction button to move cursor on the screen.
RIGHT
Direction button to move cursor on the screen.
PHOTO Mode.
MUSIC
MUSIC Mode.
VIDEO
VIDEO Mode.
FILE
FILE Mode.
MAIN MENU
Go to the main menu.
SETUP
Setup and customize the settings of the media player
INFO
See the information of the file.
REV
Previous section in Music or Video.
PAUSE
Interrupts file playback.
FWD
Next section in Music or Video.
PLAY
Continue playback.
NEXTPAGE
Jump to next page.
PREVIEW
Previous file.
STOP
Stop the current action.
NEXT
Next file.
VOL+
Increase the volume.
VOL -
Decrease the volume.
MUTE
Turn off the sound.
AUDIO
Choose the sound channel.
REPEAT
Repeat setup when photo music
and video are playing.
SLIDESHOW
Playback music under slideshow
with photos.
ROTATE
Rotate the photo.
ZOOM
Zoom out the photo.
TRANSITION
Allows you to choose the transition
mode.
-5-
For CMP-MOBPLAY30:
Button
Function
OK
Takes you to play or execute the current selection.
UP
Direction button to move cursor on the screen.
DOWN
Direction button to move cursor on the screen.
LEFT
Direction button to move cursor on the screen.
RIGHT
Direction button to move cursor on the screen.
PHOTO Mode.
MUSIC
MUSIC Mode.
VIDEO
VIDEO Mode.
FILE
FILE Mode.
MAIN MENU
Go to the main menu.
SETUP
Setup and customize the settings of the media player
INFO
See the information of the file.
REV
Previous section in Music or Video.
PAUSE
Interrupts file playback.
FWD
Next section in Music or Video.
LASTPAGE
Jump to last page.
PLAY
Continue playback.
NEXTPAGE
Jump to next page.
PREVIEW
Previous file.
STOP
Stop the current action.
NEXT
Next file.
VOL+
Increase the volume.
VOL -
Decrease the volume.
MUTE
Turn off the sound.
AUDIO
Choose the sound channel.
REPEAT
Repeat setup when photo music
and video are playing.
SLIDESHOW
Playback music under slideshow
with photos.
ROTATE
Rotate the  hoto.
ZOOM
Zoom out the  hoto.
TRANSITION
Allows you to choose the transition
mode.
TV/VGA
Change display between VGA and
TV
-6-
EN
EN

6. Set up and use the player
When you start the media player and connect it to the TV, then you can adjust the TV settings
in the set up main page. Press the SETUP button to enter the main menu for set up. Then go
to PREFERENCES. You can choose the TV TYPE and select either MULTI-SYSTEM (PAL
and NTSC), NTSC or PAL. For Europe, please select PAL system.
6.1 Photos
Press the arrow key to select PHOTO mode in the main menu or press the PHOTO button on
the remote control to start playing photos. Press the PLAY button on the remote control to
start displaying the full size picture. To zoom in, press the ZOOM button on the remote
control to zoom in. Press the ZOOM button again to disable this function. By pressing the
arrow buttons, you can move the photo when it’s zoomed in.
Rotating the photos can be done by pressing the ROTATE button on the remote control. The
photo will be turned in clockwise direction.
Press the SETUP button to enter the main menu and choose SLIDESHOW SETUP to select
your play mode. You can choose between MANUAL (press the arrow up or down to select
the next or previous photo) or choose AUTO to let the photos change automatically.
In the PHOTO SLIDESHOW SETUP, you can also choose e.g. the Interval time between
each photo and the type of transition. AUTO START enables the player to start displaying as
soon as the player has been switched on. If set to OFF, you should manually start displaying
your files.
6.2 Music
Press the arrow key to select MUSIC mode from the main start-up menu or press the MUSIC
button on the remote control. Press the up or down arrow button to select the file you want to
play. You can press the EQ button to change the equalizer settings (Classic, Jazz, Rock, Pop,
Ballade, Dance).
Select MUSIC SETUP from the main set-up menu and go to REPEAT mode to change which
song(s) are being played. You can select ONE (same song will be repeated), OFF (music will
stop playing after last track has been played) or ALL (all songs will be repeated continuously).
6.3 Video
You can press the arrow key to select VIDEO from the main menu or press the VIDEO button
on the remote control. Press the PAUSE button to pause or resume playback Press STOP to
stop playback of video. To go to the previous video file, press the PREVIOUS or REV button
on the remote control. Press NEXT or FWD to go to the next video.
6.4 File library
Alternatively, you can also go to the FILE option and manually browse through all the files
stored on the hard drive of the player to select any file you want to play. Press INFO on the
remote control and you can delete, rename a file or create a new folder. Press CANCEL to go
back to the file library.
-7-
6.5 Other setup functions
In the PREFERENCE page, you can also set OSD LANG (On Screen Display language) and
change the language used. Go to OSD MESSAGE to switch on or off the On Screen
messages. Go to SETUP VALUES if you for any reason want to reset the player to its default
settings.
6.6 Hard drive setup
Please note that the player can only recognize the HDD if it is formatted in FAT32. If the
HDD is formatted with NTFS, no files can be displayed on the TV.
-8-
EN
EN

Safety precautions:
To reduce risk of electric shock, this product should ONLY be opened by an authorized
technician if service is required. Disconnect the product from mains and other equipment if a
problem should occur.
Warranty:
No guarantee or liability can be accepted for any changes and modifications of the product or
damage caused due to incorrect use of this product.
General:
Designs and specifications are subject to change without notice.
