KoolMore KM-CW92DZ-SS User manual

OWNER’S MANUAL
Read This Manual
Inside you will find many helpful hints on how to use and maintain your
wine cooler properly. Just a little preventative care on your part can
save you a great deal of time and money over the life of your wine
cooler. You’ll find many answers to common problems in the chart of
troubleshooting tips. If you review the chart of Troubleshooting Tips
first, you may not need to call for service.
DUAL-ZONE WINE COOLER
MODELS: KM-CW92DZ-SS, KM-CW155DZ-SS
Before using your wine cooler,please read this
manual carefully and keep it for future reference.
For any service-related Issues,
please contact us:
Phone Number: 718-576-6342
Email address: [email protected]

1
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS……………………………………………………..……..2
NAMES OF THE PARTS…………………………………………………………………………..……3
INSTALLATION INSTRUCTIONS
BEFORE USING YOUR WINE COOLER………………………..……………………………………………. ………4
INSTALLING YOUR WINE COOLER….……..………….………………………………………………………………4
ELECTRICAL CONNECTION ……………….……………………………………………….…………………………….4
USING YOUR WINE COOLER
TEMPERATURE CONTROL …..…………….……………………………………….……………………………………5
BEFORE SWITCHING ON ……………….………………………………………….….……………………………..……7
DURING FIRST USE ……………….………………..………………………………..….………………………………..….7
SWITCHING ON THE APPLIANCE AND SETTING THE TEMPERATURE………..……….…………....8
SAFE LOCK…………………………………………………………………………………………………………………….….8
LOADING THE WINE COOLER………………………………………………………………………………….…..……9
STORING YOUR WINES………………………………………………………………………………………….…….……9
REVERSING THE DOOR………………………………………………………………..…………………………..….…….11
CARE AND MAINTENANCE
CLEANING YOUR APPLIANCE………………………………..……….…………………………………………………12
VACATION TIME………………………………………………………………………….……………………………………12
MOVING YOUR APPLIANCE…………………..……………………………………….…………………………………13
ENERGY SAVING TIPS……………….……….…………………..………………………………………………………….13
TROUBLESHOOTING GUIDE……………………………………..…………………………………………………….13
TECHNICAL SPECIFICATIONS
ELECTRICAL CIRCUIT DIAGRAM.………………………………………………………………………………………..15
Please read these instructions carefully before the first use of this

2
product and save this manual for your future reference.
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY!
IMPORTANT SAFETY INSTRUCTIONS
WARNINGTo reduce the risk of fire, electrical shock, or injury when using your appliance,
follow these basic precautions:
•Before using check that the voltage of wall outlet corresponds to the one shown on the rating
plate.
•Use this appliance only as described in this manual. Other uses not recommended may cause
fire, electric shock or personal injury.
•This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance. Never
allow children to operate, play with, or crawl inside the appliance.
•Keep the mains cord out of the reach of children. Do not let the mains cord hang over the edge
of the table or worktop on which the appliance stands.
•DANGER or WARNING: Risk of child entrapment. Child entrapment and suffocation are not
problems of the past. Junked or abandoned appliances are still dangerous . . . even if they will
“just sit in the garage a few days”.
•Before you throw away your old Wine Cooler: Ta ke off the door. Leave the shelves in place
so that children may not easily climb inside.
•Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or
explosion.
•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or
any other appliance. The fumes can create a fire hazard or explosion.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons to avoid a hazard. It is recommended to check regularly the supply
cord for any sign of possible deterioration, and the appliance should not be used if the cable is
damaged.
•Do not use the appliance if the plug, the mains cord or the appliance itself is damaged. If the
mains cord is damaged, you must have it replaced by the manufacturer, or an authorized
service centre or similarly qualified persons in order to avoid a hazard.
•Do not repair or replace any part of the refrigerator or attempt any servicing unless specifically
recommended in the user-maintenance instructions or in published user-repair instructions.
Replace the fuse with the same type.

3
•This appliance has been incorporated with a grounded plug. Please ensure the wall outlet in
your house is well earthed.
•Unplug the appliance from the plug socket when not in use, when moving from one location to
another and before cleaning. To disconnect the appliance, grip the plug and pull it from the
wall outlet. Never pull by the cord.
•The appliance is not intended to be operated by means of an external timer or a separate remote –
control system.
NAMES OF THE PARTS
KM-CW92DZ-SS KM-CW155DZ-SS

4
INSTALLATION INSTRUCTIONS
Before Using Your Wine Cooler
•Remove the exterior and interior packing.
•Before connecting the wine cooler to the power source, let it stand upright for
approximately 4 hours. This will reduce the possibility of a malfunction in the cooling system from
improper handling during transportation.
•Clean the interior surface with lukewarm water using a soft cloth. (Cleaning instruction on page
11)
Installing Your Wine Cooler
•This wine cooler is designed to be free standing only, and should not be recessed or built-in.
•Allow 5 inches of space between the back and sides of the wine cooler, which allows the
proper air ventilation.
•Adjust the feet to keep the wine cooler level.
•Locate the wine cooler away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Ambient temperature below 5°C or above 32°C will hinder the performance of this
appliance.
•Depending on the location of the appliance, the direction of the door opens can be changed.
•This unit is not designed for use in a garage or any other outside installation.
•Avoid locating the wine cooler in moist areas.
•Plug the wine cooler into dedicated, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized service center.
•This unit is not designed to be installed in an RV or used with an inverter.
•After plugging the wine cooler into a wall outlet, turn the unit on and allow the unit to cool
down for 3 ~ 4 hours under before placing wine bottles or beverages in the appliance.
Electrical Connection

5
WARNING
•Improper use of the grounded plug can result in the risk of electrical shock. If the power cord
is damaged, have it replaced by an authorized service center.
•This wine cooler should be properly grounded for your safety. The power cord of this wine
cooler is equipped with a three-prong plug which mates with standard three prong wall
outlets to minimize the possibility of electrical shock.
•Do not, under any circumstances, cut or remove the third ground prong from the power cord
supplied. This wine cooler requires a standard 220~240 Volt A.C. /50Hz electrical outlet with
three-prong ground.
•This wine cooler is not designed to be used with an inverter.
•The cord should be secured behind the wine cooler and not left exposed or dangling to
prevent accidental injury.
•Never unplug the wine cooler by pulling the power cord. Always grip the plug firmly and
pull straight out from the receptacle.
•Do not use an extension cord with this appliance. If the power cord is too short, have a qualified
electrician or service technician install an outlet near the appliance. Use of an extension
cord can negatively affect the performance of the unit.
•If any problems with the wine cooler persist, please contact the Customer Service Dept.
USING YOUR WINE COOLER
Temperature Control
Control Panel
The control panel is located in the middle of the appliance.
LIGHT BUTTON
To turn the inner light on/off.
cc

6
REGLAGE DE TEMPERATURE BUTTON
To choose and set the internal temperature of each compartment.
POWER BUTTON
To control the appliance turn on or off. To turn OFF the appliance, touch the + buttons
and hold 5 seconds.
UP BUTTON
Used to increase (warm) the set temperature by 1°C.
DOWN BUTTON
Used to lower (cool) the set temperature by 1°C.
SELECTOR DISPLAY
Choose to display temperatures in Celsius or Fahrenheit. To choose one of these displays press the
button for 5 seconds.
SELECT THE TEMPERATURE
Your wine cellar has two separate compartments. The temperature of the upper and lower
compartments can be chosen between +5 and +22°C (40 ° and 72 ° F). It is recommended to set
the temperature in the lower of 12 ° C to 22 ° C (55 - 72 ° F) range which is ideal for storing red
wines and to adjust the high zone between 5 and 12 ° C (40-55 ° F) range suitable for champagnes
and white wines.
IMPORTANT:
THE TEMPERATURE SELECTED FOR THE LOWER COMPARTMENT MUST ALWAYS BE HIGHER THAN
THE TOP COMPARTMENT. FOR OPTIMUM PERFORMANCE, THE DIFFERENCE BETWEEN THE TWO
ZONES SHOULD BE MINIMUM OF 4 ° C
Description of the product features
1) Control panel
oThe control panel is located in the middle of the appliance, it is very easy to set the temperature
of the appliance and see what temperature the appliance is set to.
2) Interior light
oThe wine cooler has an interior light. The light can be switched on and off by using the light
control button.
3) The wine cooler shelves

7
oThe shelves are fully adjustable to suit various wine bottle shapes and sizes.
oTo prevent damaging the door gasket, make sure the door is fully open when pulling shelves
out of the rail compartment.
For easy access to the bottles stored, pull the shelves out approximately 1/3. The shelves are
designed with an emergency stop to prevent them being removed too far when loaded.
Before switching on
oMake sure that it has been installed by a suitably qualified person, as per the information
contained in the installation instructions.
oAfter delivery, wait for eight hours before connecting the appliance to your mains supply. This
will allow any refrigerant gasses that may have been disturbed during the transportation process
to settle.
oThe outside of the appliance and the removable accessories contained within it, should be
cleaned with a solution of liquid detergent and water.
oThe interior of the appliance should be cleaned with a solution of sodium bicarbonate dissolved
in lukewarm water.
The interior and accessories should be thoroughly dried, after the cleaning process has been
completed.
oThere can be an odor when you first switch on the appliance. It will lessen as the appliance
starts to cool.
During first use
IMPORTANT: When you use the wine cooler for the first time or restart the appliance after it
has been turned off for a long time, there could be a few degrees variance between the
temperature you select and the one indicated on the LED display. This is normal and it is due
to the length of activation time. Once the wine cooler has been running for a few hours
everything will be back to normal.
oWhen you first switch on the appliance, the compressor will run continuously until the wine
cooler reaches a cool enough temperature.
oDuring this period of time, you should try not to open the door frequently or place bottles
inside of the appliance.
oIf the unit is switched off or unplugged, you must allow at least 5 minutes before restarting the
appliance or reconnecting it to your mains supply.

8
Switching on the appliance and setting the temperature
To switch the appliance on, press the + buttons and hold 5 seconds To turn the appliance
off again, press and hold the power button for 5 seconds.
oPress the "SET" to set the internal temperature of each zone. Temperatures in degrees will
appear on every screen corresponding to distinct areas for the top compartment and the
lower compartment.
When you press the "SET” for the first time, the LED displays indicate the factory preset
temperature, or to the compartment above 10 ° C/50 ° F and the lower compartment 16 ° C/60 ° F.
oPress the "SET" button once. The left display will flash above the compartment. Press the
buttons "UP" or "DOWN" to choose the temperature you want.
oIf you press again the button "SET" , the right display will flash the bottom of the
compartment. Press the "UP" or "DOWN" to choose the temperature you want.
oThe temperature increase of 1 ° C or 1 ° F if you click once on "UP" or decrease by 1 ° C / 1 ° F if
you press once on the button "DOWN"
To see theset temperature ofeach zone at any time, touch thebuttons "UP" or"DOWN",
settemperatures temporarily flash on thedisplay for about 5 seconds. Use the "SET" tosee
the selected temperature zone or the other.
IMPORTANT: When the temperature is changed, the compressor works harder to reach
the required temperature. During this time, the side panels of the wine cooler can reach
up to 45°C however they will cool down when the set temperature is reached.
Changing between Fahrenheit and Celsius
oYou can select whether the temperature displays show Celsius or Fahrenheit.
To alter what the temperature displays are showing, press the press the button for 5 seconds.
Safety lock
The wine cooler has an automatic safety lock to prevent unintentional operation of the wine cooler
by other persons such as children.
oIf no buttons have been pressed for 2 minutes, the control panel will lock automatically. All
buttons on right side of control panel will be deactivated. But the buttons on left side of
control panel is still active.
+ and hold for 5 seconds, all buttons on theoTo release the safety lock, press the
control panel will be activated.

9
Loading the wine cooler
IMPORTANT: Your appliance is ideally suited to store 0.75 litre Bordeaux style wine bottles.
Whilst it can store larger bottles, you must make sure that they do not prevent the door from
shutting properly.
oAlways check that you can close the door without it fouling on a wine bottle, before shutting it.
oWhen loading several bottles of wine at once, it will take longer for the appliance to cool the
individual bottles.
oAs many bottles may differ in size and dimensions, the actual number of bottles you are able to
store may vary.
oThe maximum storage number is based on standard 0.75 liter Bordeaux style wine bottles.
Storing your wines
The chart below indicates the ideal storage temperatures for different types of wine:
Type of wine Temperature (Celsius) Temperature (Fahrenheit)
Red wine (*) 15.5 – 18°C 59.9 – 65°F
White wine (**) 10 - 15°C 50 – 59°F
Sparkling
wines/champagne 7.2 – 9.5°C 45 – 49.1°F
Rose wine 9.5 – 10.5°C 49.1 – 50.9°F
Vintage wine 13°C 55°F

10
oTemperature stability is the most important factor when it comes to storing wine.
oExposure to light, vibrations or fluctuations in temperature and humidity can all cause wine to
spoil. When properly stored, wines not only maintain their quality but many will actually improve in
aroma, flavor and complexity as they mature.
oWines kept at a higher temperature will age faster. Wine that is exposed to temperatures that
are greater than 18°C (65°F) will suffer from poorer flavor and aroma.
oIf wine is kept at too low a temperature, this can result in the development of harmful
deposits. A humidity of 60%~70% is ideal for keeping corks from shrinking.
oAfter a bottle of wine has been opened, the wine comes into contact with air. So it is best to
store the remainder of the bottle upright, to minimize the surface area of the wine that is coming
into contact with the air.
oOnce opened, wine will remain in a drinkable condition for two days for delicate whites or
three days for rich reds, as long as the bottle as been resealed. You should make sure that the seal
is firm by checking the stopper.
oSpecial stoppers that keep wine sparking and Champagne bubbling for one or two days after
opening, can be bought at most good wine shops.
oWhen stored correctly, white wines can keep well for up to two years. Full bodied reds will age
well for ten years and dessert wines will age well for up to twenty years.
oWhen you buy a bottle of wine, you should transfer it to a suitable storage location
immediately (if you are not going to store it in your wine cooler).
oCheaper bottles of wine will not age as well as more expensive ones.
oTo make the most of the bouquet and taste of your wine, never fill more than half a glass at a
time. It will also help if the shape of your wine glass is appropriate for your wine. The size and
shape of your wine glass’s bowl will determine the intensity and complexity of the bouquet. The
stem should be long enough to allow you to avoid hand contact with the bowl of the glass and
should be tulip-shaped or tapered at the top.

11
Reversing the door Swing
This unit has the capability of either opening the door from the left or right side. The unit is
delivered to you with the door opening from the left side. Should you desire to reserve the
opening direction, please follow these instructions:
Note: Before reversing the door, the power must be shut off. All parts removed must be saved to
to the reinstallation of the door. This unit has been built with the door hinges on the right. If you
wish to change the opening direction, follow the instructions below:
1. As shown in figure ①, remove the screws of the lower door hinge and the fixing plate of the
door hinge shaft
2. As shown in figure ②, remove the door
3. As shown in figure ③, replace door hinge.
4. As shown in figure ④, install the upper door, and then install the door hinge shaft fixing plate
and lower door hinge.
①②

12
③ ④
CARE AND MAINTENANCE
Cleaning Your Appliance
★Upon installation of your new appliance, it is recommended that it be cleaned thoroughly.
★Turn off the wine cooler first and then unplug the unit from the wall outlet.
★Remove all contents.
★Wash the inside with a damp warm cloth soaked in lukewarm water and baking soda solution.
The solution should be about 2 tablespoons of baking soda to a quart of water.
★Be sure to keep the door gasket (seal) clean to keep the unit running efficiently.
★The outside of the wine cooler should be cleaned with mild detergent and warm water.
★Dry the interior and exterior with a soft cloth.
★Dust or anything else blocking the vent may hinder the cooling efficiency of the appliance.
Vacuum the vent if necessary.
Vacation Time
★Turn off the wine cooler first and then unplug the unit from the wall outlet.
★Remove all the contents.
★Clean the appliance.
★Leave the lid open slightly to avoid possible formation of condensation, mold, or odors.
★Short vacations: Leave the wine cooler operating during vacations of less than three weeks.
★Long vacations: If the wine cooler will not be used for several months, remove all content and
unplug the power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth,
leave the door open slightly: blocking it open if necessary.

13
Moving Your Appliance
★Turn off the wine cooler first and then unplug the unit from the wall outlet.
★Remove all the contents.
★Securely tape down all loose items inside your appliance.
★Tape the doors shut.
Energy Saving Tips
★The wine cooler should be located in the coolest area of the room, away
from heat producing appliances or heating ducts, and out of the direct sunlight.
★Ensure that door is properly closed when the wine cooler is turned on.
TROUBLESHOOTING GUIDE
You can solve many common wine cooler problems easily, saving you the cost of a possible service
call. Try the suggestions below to see if you can solve the problem before calling for service.
PROBLEM
POSSIBLE CAUSE
Wine cooler does not operate. •Not plugged in.
•
The circuit breaker tripped or a blown fuse.
Temperature inside the wine cooler
is too warm.
•Temperature control is set too warm. Turn the control to a cooler
setting and allow several hours for the temperature to stabilize.
•Door is kept open too long or is opened too frequently. Warm air
enters the wine cooler every time the door is opened. Open the
door less often.
•The door is not closed completely.
•The door gasket does not seal properly.
•The wine cooler has recently been disconnected for a period of
time.
•4 hours are required for the wine cooler to cool down completely.
Temperature inside the wine cooler is too
cold.
•Temperature control is set too cold. Turn the control to a warmer
setting and allow several hours for the temperature to stabilize.
Vibrations.
•Check to assure that the wine cooler is on a level surface.
•The wine cooler is touching the wall. Re-level the wine cooler and
move it from the wall.
•If continued vibration occurs, turn off the wine cooler and unplug
the power plug. Contact Customer Service Dept. for further
assistance.

14
Moisture forms on inside wine cooler walls.
•Door is slightly open.
•Door is kept open too long, or is opened too frequently. Open the
door less often.
•The door is not sealed properly.
Moisture forms on outside of appliance. •Door is slightly open, causing cold air from inside the wine cooler
to meet warm moist air from outside.
The door will not close properly. •The wine cooler is not on a level surface. The gasket is dirty.
TECHNICAL SPECIFICATIONS
Type
KM-CW155DZ-SS
Volume (liter)
428 L
Material
Case
stainless steel
Door
Glass
Unit Dimension(W×D×H)(mm) 595*676*1747 MM
Packaging Dimension ( W×D×H)(mm)
660*770*1830 MM
Net Weight (Kg)
109 KG
Gross Weight (Kg)
114.3 KG
Fitting ambient temperature range of working
N,SN
Temperature Range
5°C —22°C
Rated Voltage
115V
Rated Frequency
50Hz
Rated current 2.0A
Type
KM-CW92DZ-SS
Volume (liter)
275 L
Material
Case
stainless steel
Door
Glass
Unit Dimension(W×D×H)(mm) 595*566*1397 MM
Packaging Dimension ( W×D×H)(mm)
660*670*1465 MM
Net Weight (Kg)
73 KG
Gross Weight (Kg)
85.8 KG
Fitting ambient temperature range of working
N,SN
Temperature Range
5°C —22°C
Rated Voltage
115V
Rated Frequency
50Hz
Rated current 2.0A

15
ELECTRICAL CIRCUIT DIAGRAM
We decline liability for any damage or accident derived from any use of this
product which is not in conformity with the instructions contained in this booklet.
•
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health fr
om uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take t
his product for
environmental safe recycling.
