koppel KCSS Series User manual

Operation Manual
Fan Coil Unit

CONTENTS
SAFETY PRECAUTIONS
NAME OF EACH PART
IDENTIFICATION –CONTROLLER
UNIT OPERATION
CARE & MAINTENANCE
Cleaning your air filters
Not operating for a long period of time
TIPS ON USING THE AIR CONDITIONER
TROUBLE-SHOOTING
……..…………...………………………………….. 3
………………...………....…………………………….. 4
………..…….….….………..…………….. 5
…………..…...…………………….….……………….….. 5
……..…………..………………...…………....….. 6
……..………..………..…………………....….. .6
……..….…...…..……………….7
……...…........………..……....….. .7
…..…...……...….…………..…………………....….. .8
2
WARRANTY CERTIFICATE ….…...…...….…………..…………………....….. .9
Before putting the system back to operation …….….….……………….7
Fan Coil Unit

•Please read this manual carefully before operating the air conditioner.
•Pay special attention to signs of “WARNING” and “CAUTION”. The “Warning” section
contains matters, which, if not observed strictly, may cause death or serious injury.
The “Caution” section contains matters, which may result in serious consequences if not
observed properly.
•Please follow all instructions strictly to help ensure your safety.
WARNING
•Read this manual carefully before using your Fan Coil Unit.
•All wiring must conform to local and national electrical codes.
•To avoid possible electrical shock, you must ground your air conditioner.
•This air conditioner requires a separate power supply on a separately fused circuit.
•Do not insert your finger, a stick or any other object into the air inlet and air outlet.
•Do not expose the skin directly to the indoor airflow for an extended period of time.
CAUTION
•Keep this manual for future reference as it contains important installation and safety
instructions.
•Do not install the unit near tanks or containers of flammable gas. The unit may catch fire if
flammable gas leaks.
Call for service immediately when:
•When abnormal operating noise is heard.
•A fuse blows or a circuit breaker trips frequently.
•The controls do not work properly.
3
Fan Coil Unit

INDOOR UNIT
4
NAME OF EACH PART
AIR DISCHARGE
PORT
BLOWER WHEEL
12,000 Btu/hr - 36,000 Btu/hr
Fan Coil Unit

Fan Coil Unit 5

UNIT OPERATION
Fan Coil Unit6

Fan Coil Unit 7
UNIT OPERATION

Cleaning Your Air Filters
A dirty air filter will cause a reduction of airflow, which in turn causes the unit to overload and also consumes
more electricity. Therefore regular cleaning is necessary for efficient and trouble-free operation.
It is necessary to clean the Air Filter at least once every two weeks.
WARNING: Ensure that the power supply is switched off before
commencing maintenance work.
NOTE
8
Lift the filter screen upward as shown.
Pull the filter gently.
METHOD A
METHOD B
Slidethe filter sideways in the direction
shown.
TO REMOVE AIR FILTER
Fan Coil Unit

Not Operating For A Long Period Of Time
When the Fan Coil Unit is not going to be used for a long period of time, switch off the power from
the circuit breaker.
9
Before Putting The System Back To Operation
Check if the filter screen is clean. Turn on the main power to the system.
Remove the dust from the air filter by using
vacuum pump cleaner or if it is very dirty,
wash it with soap and wipe dry before
reinstalling it.
Clean the filter every other week for
higher efficiency.
Use curtains or blinds to prevent heat
gain from the sun light to the room,
doing so will help reduce electric
consumption.
Close all windows and doors when operating
the unit so that there is no leakage of
conditioned air outside the room.
It is good to introduce fresh air into the
room for awhile by opening the window
but not too long as energy will be drained
out.
Fan Coil Unit

Check the following before you contact the service man, you may find the solution to your problems
and save yourself time and money. And if the problem still persists, contact your service person.
PROBLEM
No operation.
CAUSES
•Check to see if the power supply switch is OFF.
•Check to see if you have a power failure.
Air Conditioner runs but
does not cool. •Check whether the sunlight is directly shining into the room.
If yes, use curtains or blinds to prevent heat gain to the room.
•Check whether the door and window are opened.
•Ensure that no heating appliances have been placed under
the return air area.
•Check the air filter for dirt.
•Call for service if the room is not cold after running for more
than a reasonable cooling time.
Controller is not working Call for service.
There’s a strange noise
coming from the unit. Call for service.
Water leaking from the indoor
unit and water drain line. Turn the unit off and call for service.
10
THE FOLLOWING ARE NORMAL CONDITIONS FOR THE UNIT.
Condensate water or water
droplets on the air outlet.
•In Cool Mode, condensate water can sometimes be
seen forming on the air outlet due to the differences
in temperature between the room air and the outlet air.
Fan Coil Unit

(OWNER’S COPY)
WARRANTY REGISTRATION FORM
IMPORTANT! In order not to void this warranty, please visit our website and register at our online
warranty registration www.koppel.ph/customer-support/online-warranty-registration/
within ten (10) days from date of purchase and/or start up. For any clarifications, please call
our Koppel hotline no. [phone].
"
UNIT MODEL : ______________________________
SERIAL NUMBER :____________________________
PRODUCT WARRANTY CERTIFICATE
UNIT MODEL : ___________________________________________________
SERIAL NUMBER :________________________________________________
OWNER’S NAME : ____________________________ TEL. NO.: ___________
ADDRESS : _____________________________________________________
DEALER’S NAME : _______________________________________________
DATE PURCHASED : _____________________________________________
INSTALLER’S NAME : ____________________________________________
KOPPEL, INC. warrants to the purchaser of this product that it will furnish labor and/or
replacement part or at its option, repair any part thereof which proves upon inspection by
KOPPEL, INC. or its authorized service company, to have been defective within one (1)
year from the date of original purchase, if it was used thereafter solely within the
Republic of the Philippines, in accordance with the terms of this warranty through the
KOPPEL, INC. Service Department or any of its authorized service company.
This warranty is non-transferable and does not apply to damage(s) arising from accident,
improper use or abuse, force majeure such as typhoons, floods, lightning, earthquakes
among others, from use with voltages beyond THE ALLOWABLE VOLTAGE RANGE OF
207 TO 253 VOLTS, or from failure to follow operating instructions provided. If the serial
number of the unit is removed, obliterated or defaced, or if the unit is faultily installed,
tampered with or altered by anyone other than a duly authorized service personnel,
service dealer or accredited installer of KOPPEL, INC., this warranty is considered null
and void.
KOPPEL, INC. is not responsible and will not be held liable in contract or in tort
(including strict liability and negligence) for any special, indirect or consequential
damages, including but not limited to damage to structure or contents, or injury to
persons by reason of the installation,use or failure of any
KOPPEL, INC. products.

Koppel, Inc.
106 Industry Drive,
Carmelray Industrial Park 1,
Brgy. Canlubang, Calamba City,
Laguna,Philippines 4028
Manufacturer reserves the right to discontinue, or change at any time,
specifications or designs without notice and without incurring any obligation.
