kowatec miniBot User manual

miniBotminiBot

Tools

Parts
Body
Feet
3 x AAA Battery
and holder Cable for LED
EV8
LED
Motor
Legs
Head
Shoulders

Assembling
Right Shoulder
Left Shoulder

Back Back
Front
LEGS
1. Left Leg
2. Right Leg

Snap the top end of the
leg on the inside slot of
the back cover Back view
Body Back Cover

Snap the legs completely
into the back body cover
Take the cable of the motor
and insert into the hole on
the back cover

Snap the right shoulder
to the body
Repeat for left shoulder

Place the front
over to the body.
Place the head
Secure the body
with screws

Glue the battery holder on the
back of the body. Make sure it
does not touch the head.
Make sure the motor
cables come out from here

Put double-side tape on the EV8 and place it on the short edge of the battery holder.
Make sure the golden
fingers are completely
above the battery holder.

Peel off the
cables

Combine the red cable of the motor and the red peel-off cable together. Cut a piece of black
tape and tape the cables together. Then connect the joined cable to the pin on the EV8.

Repeat the step with the black cable of the motor and the black peel-off cable. Then
connect the joined cable to the pin on the EV8.

Use double-sided tape to tape the LED
cable to the long edge of the battery holder
and opposite side of the EV8.
Use double-sided tape to tape the LED
cable to long edge of the battert holder and
oppisite side of the EV8.

Connect the power cable to the pin on the EV8.
Pay attention to the color order of the cable.

Use double-sided tape to tape the feet. Make sure the feet are in-line.

Tie up all the cables.

Place the LEDs in the white
connector. Insert the short pin of
each LED together in the middle
hole. Then bend the LED upward.

If you have a EV8-Writer, connect the
Writer to the EV8. Connect the USB
cable to the computer and download
the program. Then insert the batteries.
