KraftMaid DELUXE ROLL-OUT TRAY User manual

REV A - 12/7/2018 DELUXE ROLL-OUT TRAY
TRADITIONAL MOUNTING INSTRUCTIONS
PARTS LIST
A Front Mounting Block w/ (1) attached screw 2
B Plastic Fasteners (1L, 1R) 2
C Metal Mounting Bracket 2
D #8 x 5/8" Truss Head Screw 4
E #7 x 1 1/4" Fillister Head Screw 2
F 6mm x 13mm Euro Flathead Screw 2
Deluxe Roll-Out Tray 1
Front Clips (attached to above tray) 1 PAIR
Runner (1L,1R) 2
PART# DESCRIPTION QTY
INS0176 P/N: 9862037 Page 1 of 2
Step 1:
(See Diagram #1a)
First, install metal mounting bracket into
each plastic fastener plate (L&R) by
inserting top edge of metal bracket under
tabs of plastic fastener plate and
snapping into place.
(See Diagram #1b)
Insert completed assembly into vertical
row holes on back panel at desired
height and secure with (2) #8 x 5/8"
Truss Head Screw.
Repeat for other side.
This assembly supports the back end of
the runner system.
ABC
Front Mounting
Block Plastic Fastener
Plate (Left & Right) Metal Mounting
Bracket
D
E
F
Euro Flathead Screw
Fillister Head Screw
Truss Head Screw
Diagram #1a
(Left & Right)
Metal Mounting Bracket
(Part # C)
Plastic Fastener
(Part # B)
Rear Fastener Assembly
(Left & Right) Diagram #1b
(Left & Right)
Cabinet Back Panel
Cabinet Side Panel
Vertical Side Panel
Hole
#8 Truss Head Screw
(Part # D)
Diagram #2a
(Back Side Shown) Diagram #2b (Left Side Shown)
Diagram #3a
(Left Side Shown) Diagram #3b (Left Side Shown) Assembled Components (Left Side Shown)
Diagram #4a
Front Mounting Block
w/ attachment screw (Part # A)
5mm Peg
Front Mounting Block
w/ attachment screw (Part # A)
Fillister Head Screw
(Part # E
Cabinet Frame Stile
Pre-mounted 6mm x 13mm
Pan Head Euro Screw
Step 2:
(See diagram #2a)
Locate the 5mm peg on the backside of
the front mounting block and insert into
the side panel vertical row hole directly
behind the cabinet frame stile at the
same level as the rear mounting bracket.
(See diagram #2b)
Secure front mounting block to cabinet
side panel using pre-mounted #6 x
14mm pan head Euro screw. Insert (1)
#7x1 1/4" Fillister head screw into top
front hole of front mounting block and
tighten into the backside of cabinet
frame stile.
Repeat for other side.
This assembly will support the front end
of the runner system.
Step 3:
(See diagram #3a)
Select corresponding (L&R) runners
(Letters are printed on backside of
runners) Slide slotted end under tabs of
metal mounting bracket. Push back
runner until top front screw hole aligns
with front hole on the mounting block.
(See diagram #3b)
Secure runner to front mounting block
with (1) #6 x 13mm Euro flathead
screws.
Repeat for other side.
Step 4:
(See diagram #4a)
Attach roll-out drawer onto cabinet
runners. Some pressure is required for
the initial insertion of the tray, the cabinet
runners will self adjust to their smooth
action position. Please note some added
pressure might be applied to either the
outer or inner side of the cabinet runner
during the initial roll-out drawer insertion.
It is extremely important that the cabinet
is installed squarely in order to achieve
the smooth action feature of the roll-out
tray system.
**See page 2 for installing a Center Stile
DXROT block
Rear Fastener Assembly
Metal Mounting Bracket
(Part #C)
Tabs
Slotted End Runner
6mm Euro Flathead
Screw (Part #C)
Front Mounting Block
(Part #A) Runner
Left Rear
Fastener Assembly
Left Runner Right Rear
Fastener Assembly
Right Runner
Front Mounting Block
Deluxe Roll-Out Tray

REV A - 12/7/2018 DELUXE ROLL-OUT TRAY
CENTER STILE MOUNTING INSTRUCTIONS
PARTS LIST
A Center Stile Block w/ (1) attached screw 1
B #7 x 1 1/4" Fillister Head Screw 2
C 6mm x 13mm Euro Flathead Screw 2
Deluxe Roll-Out Tray 1
Front Clips (attached to above tray) 1 PAIR
Runner (1L,1R) 2
PART# DESCRIPTION QTY
INS0176 P/N: 9862037 Page 2 of 2
Step 1:
First, install the Rear Fastener Assembly
as shown on page 1, Step 1.
(See Diagram #1a & #1b)
Locate the 5mm peg on the front side of
the Center Stile Mounting Block and
insert into the very bottom hole of the
center stile.
A
Center Stile
Block
B
C
Euro Flathead Screw
Fillister Head Screw
Diagram #2a
(Center Stile Block)
Fillister Head Screw
(Part # B)
Diagram #1a
(Center Stile Mounting Block)
Diagram #2b
(Installed Blocks)
Diagram #3a
(Left Side of Center Stile Shown) Diagram #3b (Left Side of Center Stile Shown) Assembled Components (Left Side of Center Stile Shown)
Diagram #4a
Front Mounting Block
w/ attachment screw (Part # A)
5mm Peg
Step 4:
(See diagram #4a)
Attach roll-out drawer onto cabinet
runners. Some pressure is required for
the initial insertion of the tray, the cabinet
runners will self adjust to their smooth
action position. Please note some added
pressure might be applied to either the
outer or inner side of the cabinet runner
during the initial roll-out drawer insertion.
It is extremely important that the cabinet
is installed squarely in order to achieve
the smooth action feature of the roll-out
tray system.
Rear Fastener Assembly
Tabs
6mm Euro Flathead
Screw (Part #C)
Center Stile Block
(Part #A)
Runner
Left Rear
Fastener Assembly
Left Runner
Right Rear
Fastener Assembly
Right Runner
Center Stile Block
Deluxe Roll-Out Tray
6mm x 13mm Pan Head Euro Screw
6mm x 13mm Pan Head Euro Screw
(Use for upper Deluxe Roll-Out Trays)
6mm x 13mm Pan Head Euro Screw
(Do not use for bottom installation)
Frame Center Stile
5mm Drill Hole
Cabinet Floor
Diagram #1b
(Frame Center Stile Drilling)
Step 2:
(See Diagram #2a)
All Center Stile Blocks will need to be
secured to the Center Stile with (2)
Fillister Head Screws.
(See Diagram #2b)
Do not use the 6mm x 13mm Euro Screw
when installing Center Stile Block to the
bottom of the Center Stile. For cabinets
receiving more than (1) Center Stile
Block you will use the 6mm x 13mm Pan
Head Euro Screw when securing the
Center Stile Block to the other holes in
the Center Stile.
Center Stile Block
(Part # A)
Slotted Runner
Step 3:
(See Diagram #3a)
Select corresponding (L&R) runners
(Letters are printed on backside of
runners). Slide slotted end under tabs of
metal mounting bracket. Push back
runner until top front screw hole aligns
with front hole on the Center Stile Block.
(See Diagram #3b)
Secure runner to Center Stile Block with
(1) 6mm x 13mm Flathead Euro Screw.
Repeat for other side.
